EQ150
560 TVL Black/White Box Type Camera
Features
• 1/3” Sony Interline Transfer Super HAD CCD
560 TVL of horizontal resolution
Low light sensitivity of 0.06 Lux/F=1.2
Digital Signal Processing (DSP) circuitry design to
deliver excellent picture quality and performance
Wide range automatic electronic shutter:
1/50 (1/60) ~ 1/100,000
Auto line lock with external phase adjustment
C/CS mount adjustable with easy back focus adjustment
Dual voltage
•
•
•
•
Ordering Information
• EQ150/E: 560 TVL, B/W Box Type Camera
Pickup Device
Video Format
Picture Format
Horizontal Resolution
Sensitivity
Video Output
S/N Ratio
Sync. Mode
Electronic Shutter
Gamma Correction
Backlight Comp.
Auto Gain Control
Power Source
Power Consumption
Dimensions (L x W x H)
Weight
Operating Temp.
1/3” Sony Interline Transfer Super HAD CCD
NTSC/PAL
768 x 494 (NTSC) / 752 x 582 (PAL)
560 TVL
0.06 Lux / F=1.2
BNC 1.0 Vp-p, 75ohm
Over 48dB (AGC Off)
Line Lock/Internal Sync.
1/50 (1/60) ~ 1/100,000
0.45
On/Off Switch
On/Off Switch
12VDC/24VAC
24VAC: 7W max. / 12VDC: 4.5W max.
140.2 x 51 x 57 mm / 5.5” x 2” x 2.3”
500 g / 1.1 lbs
0°C ~ 50°C / 32°F ~ 122°F
Dimensions
EZ180
Black/White Cameras
Features
Ordering Information
• EZ180/E-1: 560 TVL, B/W Weatherproof Bullet Style Camera,
Heater, IP66, 3.5~8mm lens
• EZ180/E-2: 560 TVL, B/W Weatherproof Bullet Style Camera,
Heater, IP66, 9~22mm lens
Dimensions
560 TVL Black/White Outdoor
Weatherproof Bullet Style Camera
51 52
1/50 (1/60) ~
1/100,000 sec
Black/White Cameras Box Type Cameras Black/White Cameras Bullet Style Cameras
Specifications
•
•
•
51 mm / 2”
57 mm / 2.25”
140.2 mm / 5.52”
20° ~ 80° humidity
Humidity
1/50 (1/60) ~
1/100,000 sec
• 1/3” Sony Interline Transfer Super HAD CCD
560 TVL of horizontal resolution
Low light sensitivity of 0.1 Lux/F=1.6
Built-in vari-focal lens for versatile application
Designed with sturdy aluminum housing specifically
for outdoor surveillance
Built-in heater allows camera to be operated in
extremely low temperatures
Weatherproof IP66 rated to endure any weather
conditions
Removable sun shield
Dual voltage
•
•
•
•
•
•
•
•
156 mm / 6.14”
132 mm / 5.2”
172 mm / 6.8”
Pickup Device
Video Format
Picture Format
Horizontal Resolution
Video Output
Sensitivity
S/N Ratio
Electronic Shutter
Backlight Comp.
Auto Gain Control
Auto White Balance
Gamma Correction
Power Source
Lens
Dimensions (L x W x H)
Operating Temperature
Power Consumption
Weight
Weatherproof
Heater Activation Temp.
1/3” Sony Interline Transfer Super HAD CCD
NTSC or PAL
768 x 494 (NTSC) / 752 x 582 (PAL)
560 TVL
BNC 1.0 Vp-p, 75 ohm
0.1 Lux/F=1.2
Over 48dB (AGC Off)
1/50 (1/60) ~ 1/100,000 sec.
On/Off switch
On/Off switch
Yes
0.45
12VDC / 24VAC
Vari-focal f=3.5mm~8mm/F=1.2 or
Vari-focal f=9mm~22mm/F=1.6
With Sun Shield: 172 x 70 x 82 mm /
6.8” x 3.3” x 2.8”
Without Sun Shield: 132 x 57 mm /
5.2” x 2.2” (L x D)
-40°C~50°C/-40°F~122°F (20~80% humidity)
With Heater:
24VAC: 12.5W max. / 12VDC: 7.5W max.
Without Heater:
24VAC: 6W max. / 12VDC: 4W max.
500 g / 1.1 lbs
IP66 rated
-10°C / 14°F
Specifications
