EverFocus EQ700 User manual

EVERFOCUS
Ultra Series Super Low Light
720+ TVL OSD EWDR
Dual Voltage Box Style Camera
Operation Instructions
Model No. EQ700
Please read this manual first for correct installation and operation. This manual should be
retained for future reference. The information in this manual was current when published. The
manufacturer reserves the right to revise and improve its products. All specifications are
therefore subject to change without notice.
PRECAUTIONS
1. Do not install the camera near electric or magnetic fields.
Install the camera away from TV/radio transmitters, magnets, electric motors, transformers
and audio speakers since the electromagnetic fields generated from these devices may
distort the video image or otherwise interfere with camera operation.
2. Never disassemble the camera beyond the recommendations in this manual nor
introduce materials other than those recommended herein. Improper disassembly or
introduction of corrosive materials may result in equipment failure or other damage.
3. Try to avoid facing the camera toward the sun.
In some circumstances, direct sunlight may cause permanent damage to the sensor and/or
internal circuits, as well as creating unbalanced illumination beyond the capability of the
camera to compensate.
4. Keep the power cord away from water and other liquids and never touch the power
cord with wet hands. Touching a wet power cord with your hands or touching the power
cord with wet hands may result in electric shock.

1
5. Never install the camera in areas exposed to oil, gas or solvents.
Oil, gas or solvents may result in equipment failure, electric shock or, in extreme cases, fire.
6. Cleaning
For cameras with interchangeable lenses, do not touch the surface of the sensor directly
with the hands. Use lens tissue or a cotton tipped applicator and ethanol to clean the sensor
and the camera lens. Use a damp soft cloth to remove any dirt from the camera body. Please
do not use complex solvents, corrosive or abrasive agents for cleaning of any part of the
camera.
7. Do not operate the camera beyond the specified temperature, humidity or power
source ratings. This camera is suitable for indoor operation only. Use the camera at
temperatures within -10ºC ~ +50 ºC (14 ℉ ~122 ℉ ) and humidity between 20% and 80%.
This device is not rated as submersible. The input power source is 12VDC / 24VAC.
8. Mounting
Use care in selecting a solid mounting surface which will support the weight of the camera
plus any wind, snow, ice or other loading, and securely attach the camera to the mounting
surface using screws and anchors which will properly support the camera. If necessary (e.g.
when mounting to drop ceilings) use a safety wire to provide additional support for the
camera.
Table of Contents
Product Overview……………………………………………….....……………..1
Main Features……………………………..……………..…….…………………2
Content List……………………………………………………………………… 2
Specifications………………………………………………………….…………. 3
Dimensions…………………………………………………………………….…. 4
Installation……………………………………………………….………………...4
OSD Menu…………………………………………………………………………5
Product Overview
Get incredible low light sensitivity and the resolution listed in the specs from the actual camera
you install. The EverFocus Ultra Series EQ700 uses the Sony Exview HAD II 960H CCD to
produce in excess of 720 horizontal TV lines of resolution from each and every Ultra Series
720+ camera we deliver (megapixel lenses are recommended to take full advantage of the
amazing resolution available from this advanced imaging technology). Combine this with an
almost unbelievable useable native Ultra low light sensitivity of 0.0001 lux without using digital

2
slow shutter this camera truly provides color without compromise: over 720TVL resolution,
plus your choice of full motion color or true day/night images in ultra low light with guaranteed
ZERO ghosting and Digital Wide Dynamic Range to handle the most challenging of bright or
unbalanced scene lighting conditions. The EQ700 offers complete flexibility for selection of lens
field of view, electronic or DC iris, wide choices for housing styles and mounting configurations,
dual voltage operation and a full suite of OSD Menu and DSP functions controllable at the
camera (DNR to save DVR HDD space, privacy masking, mirroring, and much more) This is the
camera that you have been waiting for to create analog CCTV systems that produce astounding
image clarity in the widest range of applications and in almost any light level.
FEATURES
•Ultra resolution of over 720 horizontal TV lines for astounding image quality
•Exview HAD II sensor delivers amazing ultra high sensitivity of .0001 lux - 500X better
native light sensitivity without DSS low light boost - Zero Ghosting guaranteed
•Color without compromise: your choice of full motion color or true day/night images in low
light without ghosting
•True Day/Night with ICR module
•Adaptive Tone Curve Reproduction (ATR)/Digital Wide Dynamic Range expansion to deliver
properly exposed images despite unbalanced lighting in the scene
•Provides 2D-Noise Reduction to improve picture clarity while enabling DVRs to improve disk
storage utilization
•Accepts C/CS mount manual or DC iris lenses
•Easy to use OSD setup menu
•Motion detection for 4 configurable zones
•Privacy mask function for 4 configurable zones
•Dual voltage (12VDC/24VAC) with Anti-Crawl for stability even without line lock
Box Contents
Camera
This User Guide
C-mount lens adapter ring
AI lens plug (for connecting lenses not already equipped with a plug)

3
SPECIFICATIONS
Imaging Device 1/3" Sony Exview HAD II 960H High Sensitivity Interline D
Video Format NTS –or- PAL (separate models)
Picture Elements NTS : 1020(H)x508(V) PAL:1020(H)x596(V)
Effective Picture Elements NTS : 976(H) x 494(V) PAL:976(H) x 582(V)
Horizontal Resolution More than 720 TVL from production cameras
Sensitivity olor ~.001 lux, B/W ~ 0.0001Lux/F=1.0 (Zero ghosting guaranteed)
S/N Ratio Over 50dB (AG off)
Video Output BN 1.0V p-p 75Ω,
Gamma orrection 0.45
Lens Type / S Mount (lens sold separately; megapixel lenses recommended for
maximum image clarity)
Back Light ompensation OFF/BL /HSBL Selectable
Auto Gain ontrol Low light auto, Bright light auto, Manual selectable
Electronic Shutter 1/60 ~1/100,000 sec.
White Balance ATW/One Push/User1/User2/Anti- rawl/Manul/Push Lock
Sync. Mode Internal (plus Anti- hroma rawl White Balance option above)
Day & Night True D/N with motorized IR cut filter; hoose olor, B/W, Auto
OSD Menu Multiple functions
OSD Languages English, Spanish, Portuguese, German,
Russian, Japanese, hinese, French
2D-DNR On/Off (level adjustable)
Adaptive Tone urve Reproduction/
Digital WDR (ATR) On/Off (3 levels each adjustable for luminance and contrast)
Mirror Off/On
Motion Detection Off/On for 4 selectable zones (On screen indication on alarm)
Privacy Mask Off/On for 4 selectable zones
Power Source 12VD /24VA
Power onsumption 12VD :180mA (2.16W) max. / 24VA :2.9W max.
Operating Temperature 14°F~122°F ; -10° ~50°
Storage Temperature -4°F~140°F ; -20° ~60°
Humidity Less than 80% non condensing
Dimensions 2.28” x 2.28” x 4.765” / 58mm x 58mm x 121mm (includes BN at rear)
Weight ~.88 lb/~400g
ertifications E / F

4
DIMENSIONS
INSTALLATION
Warning
• To prevent electrical shock, turn off the electrical power before making electrical
connections.
1. Choose an appropriate mounting location which allows
the desired field of view without obstructions. Select
and attach a suitable lens. If a C-mount type lens you
MUST attach the C- to CS-mount adapter ring between
the lens and the camera. If a DC iris lens, attach the lens
control wire to the jack on the side of the camera.
2. Insure that the mounting surface will support the
weight of the camera, mount, and any (optional)
housing used to protect the camera. Add a safety wire
if needed.
3. Attach mount (see instructions provided with mount)
and if a housing is used install camera
into housing.
4. Attach camera (or housing) to mount.
5. Attach power and video coax BNC to
camera.
6. Press MENU button and adjust OSD
menu settings to suit application.

5
