EverFocus ED310e User manual

ED310e
Indoor Dome Camera
700TVL 3-Axis High Resolution Compact
User’s Manual
Copyright © EverFocus Electronics Corp,
Release Date: June, 2012

i
Cautions
1. Do not install the camera near electric or magnetic fields.
2. Never disassemble the camera beyond the recommendations in this manual nor introduce
materials other than those recommended herein.
3. Try to avoid facing the camera toward the sun.
4. Keep the power cord away from water and other liquids and never touch the power cord
with wet hands.
5. Never install the camera in areas exposed to oil, gas or solvents.
6. Do not operate the camera beyond the specified temperature or humidity. Use the camera
at temperatures within -10°C~50°C (14°F~122°F) and humidity between 20%~ 80%; this
device is not rated as submersible.
7. Determine the polarity of the power adapter pigtail before connecting the camera to the
power source. The input power source is 12V DC.
Contents
1. INTRODUCTION.........................................................................................................................1
1.1 FEATURES ......................................................................................................................1
1.2 PACKAGE CONTENTS ..................................................................................................... 2
1.3 DIMENSIONS .................................................................................................................2
2. SPECIFICATIONS......................................................................................................................... 3
3. INSTALLATION & OPERATION .................................................................................................... 4
4. OSD MENU ................................................................................................................................6
4.1 Main Menu Display .......................................................................................................6
4.2 OSD Main Menu Description ........................................................................................7

ED310e Indoor Dome
1
1. INTRODUCTION
The ED310e delivers amazing 700 TVL video by using 1/3” Sony Exview HAD CCD II 960H sensor.
Advanced surveillance features like Motion Detection and Privacy Mask benefit from Sony Effio-E
platform. Stylish design and low profile luxury color accompany with the extraordinary video
performance of ED310e. Built-in Vari-Focal DC Iris 2.8~10.5mm lens provide flexibility from wide
angle to mid range distance. Incredible view result in very low light environment. ATR(D-WDR)
technology smoothly work with BLC, AGC functions to get clear and better image in challenging
back light environment. This is the camera to bring value to your surveillance business and so
called EverFocus Value Dome.
Model Name Descriptions
ED310e / NB NTSC, Black.
ED310e / NW NTSC, White.
ED310e / PB PAL, Black.
ED310e / PW PAL, White.
Note: The models differ among countries. Please visit EverFocus regional Websites for detailed
ordering information.
1.1 FEATURES
•3-Axis, Day/Night camera with Sony 1/3” Exview HAD CCD II 960H Sensor, 700 TVL resolution
•Sony Effio-E platform to provide advanced camera functions
•Easy to use OSD Setup Menu
•Vari-Focal DC Iris Lens 2.8~10.5mm
•High sensitivity, low smear, high anti-blooming and high S/N ratio for high performance
video
•D-WDR function by Sony ATR technology
•DNR function to improve video quality and recording details
•Built-in Auto Electronic Shutter (AES), Auto Gain Control (AGC) and Auto White Balance
(AWB)
•Built-in Motion Detection, Privacy Mask advanced surveillance functions

ED310e Indoor Dome
2
1.2 PACKAGE CONTENTS
•ED310e camera x 1 •Mounting template x 1
•User Manual x 1 •Accessory kit x 1 (containing mounting
•Power adapter pigtail x 1 screws and plastic ahchors)
1.3 DIMENSIONS

ED310eIndoorDome

3
2. SPECIFICATIONS
PickupDevice1/3 " SONYExviewHADCCDII(960H)
VideoFormatNTSCorPAL(dependsonmodelselected)
PictureElements1020x508(NTSC),1020x596(PAL)
HorizontalResolution700TVL
Sensitivity0.03Lux/F=1.2
S/NRatioOver48dB(AGCoff)
ElectronicShutter1/50(1/60)~1/100,000sec.
VideoOutputBNC1.0Vp‐p,75ohm
GammaCorrection0.45
LensTypeVari‐focalDCIrisLens2.8‐10.5mm
BackLightCompensationOn/Off
AutoGainControlYes
WhiteBalanceAuto/Indoor/Outdoor/Manual/PushAuto
Sync.ModeInternalSync.
Day&Night Yes
OSDmenuYes(English/Japanese/German/French/Russian/Portuguese
/Spanish/SimplifiedChinese)
DNROn/Off
D‐WDROn/Off(SonyATR)
MirrorOn/Off
MotionDetectionOn/Offfor24*16DetectionBlocks
PrivacyMaskOn/Offfor8Areas(SizeAdjustable)
PowerSource12VDC
PowerConsumption12VDC:120mA/1.5Wmax.
OperatingTemperature‐10°C~50°C/14°F~122°F
Humidity20%~80%non‐condensing
Dimensions(O.DxH)111.4x83mm/4.38x3.27in
Weight440g/0.9lb
CertificationsCE/FCC




ED310e Indoor Dome
4
3. INSTALLATION & OPERATION
1. Remove the dome cover from the main body by loosening the screw that securing the
dome cover.
2. Camera Image Adjustment:
•Adjust camera to any direction by using Pan, Tilt, and Rotate mechanism.
• Pan Base covers total 120° angle (60° to each side).
•Tilt Base covers total 120° angle (60° to each side).
• Angle range of Rotate Base is 360°.
3. Vari-Focal Dome Operation Guide
Once the picture appears on the monitor, open the cover and adjust the lens wrench to
“NEAR←→FAR”, get your desired view zoom and adjust the focus wrench of the lens to
obtain the best picture. After adjustment, tighten both wrenches.

ED310e Indoor Dome
5
4. Adjusting the Function Control Board
1 IR Board WEFER 3 POWER/VIDEO (CAMERA) 5 DAY IN
2 OSD KEY 4 POWER/VIDEO (DC/ BNC)
5. Connect the video output to the monitor or other video device through a 75 Ohms type
coaxial cable and the DC-Jack or AC/ DC-Terminator to the power source.
Note: Power adapter is sold separately.

ED310e Indoor Dome
6
4. OSD MENU
4.1 Main Menu Display
OSD Setup Menu page 1
LENS
SHUTTER/ AGC
WHITE BAL
BACKLIGHT
ATR
NR
PICT ADJUST
NEXT
↲
EXIT
↲
SAVE ALL
AUTO
↲
AUTO
↲
ATW
OFF
OFF
↲
↲
OSD Setup Menu page 2
DAY/ NIGHT
PRIVACY
MOTION DET
CAMERA ID
LANGUAGE
CAMERA RESET
BACK
↲
EXIT
↲
SAVE ALL
AUTO*
OFF
OFF
OFF
ENGLISH
Main Menu Setup
•In order to display the setup menu on the screen, set the menu command or press the
button panel.
•Use UP/ DOWN control buttons to select each item.
•Use LEFT/ RIGHT control buttons to change the data.
•Use MENU control button to ENTER/ EXIT the menu display.
•↲=ENTER.

ED310e Indoor Dome
7
4.2 OSD Main Menu Description
4.2.1 LENS: MANUAL /AUTO selectable.
LENS: MAUNAL
No adjustment
LENS: AUTO
AUTO
TYPE：DC
MODE：AUTO/ OPEN /CLOSE
SPEED：000~255
AUTO: Camera automatically controls the lens.
OPEN: Lens fully opens.
CLOSE: Lens fully closed.
SPEED: Speed of the lens.
4.2.2 SHUTTER/AGC: AUTO / MANUAL selectable.
SHUTTER/AGC: AUTO
AUTO
HIGH LUMINANCE
MODE：SHUT+AUTO IRIS / AUTO IRIS / SHUT
BRIGHTNESS：000~255
LOW LUMINANCE
MODE：AGC / OFF
BRIGHTNESS：x0.25、x0.50、x0.75、x1.00
HIGH LUMINANCE
When LENS is setup to AUTO mode
SHUT+AUTO IRIS: Exposure is controlled by auto electronic shutter combined with
auto iris.
AUTO IRIS: Exposure controlled by auto iris.
When LENS is setup to Manual mode
SHUT: Exposure controlled by electronic shutter.
LOW LUMINANCE
Setup low lux environment, minimum AGC level.

ED310e Indoor Dome
8
SHUTTER/AGC: MANUAL
MANUAL
MODE：SHUT+AGC
SHUTTER：
NTSC：
1/60, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000
PAL：1/50, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000
AGC：6.00、12.00、18.00、24.00、30.00、36.00、42.00、
44.80
SHUTTER: Fixed electronic shutter speed.
AGC: Fixed AGC gain control.
4.2.3 WHITE BAL
ATW / PUSH / USER1 / USER2 / ANTI CR / MANUAL / PUSH LOCK selectable.
WHITE BAL.: ATW
ATW
SPEED：000~255
DELAY CNT：000~255
ATW FRAME：x0.50、x1.00、x1.50、x2.00
ENVIRONMENT：INDOOR、OUTDOOR
SPEED：ATW Speed
DELAY CNT：ATW Delay Time
ATW FRAME：ATW Frame Range Setup
ENVIRONMENT：ATW Environment Range Setup
WHITE BAL.: PUSH
The function will keep on detecting the Color Temperature, and then keeps saving
up the parameter to the camera.
WHITE BAL.: USER1
USER1 B-GAIN：000~255
R-GAIN：000~255
WHITE BAL.: USER2
USER2 B-GAIN：000~255
R-GAIN：000~255
WHITE BAL.: MANUAL
MANUAL LEVEL：19~54
WHITE BAL.: ANTI CR
The function can reduce the color rolling issue, and it is the same with CRS (Color
Rolling Support) function.

ED310e Indoor Dome
9
WHITE BAL.: PUSH LOCK
The function will detect the Color Temperature to save into the camera.
4.2.4 BACKLIGHT: BLC / HLC / OFF selectable.
BACKLIGHT.: BLC
Enable the function of Back Light Compensation, using BLC Smart detection
method.
BACKLIGHT.: HLC
Enable the function of High Light Compensation.
4.2.5 ATR: ON / OFF selectable.
ATR.: ON
LUMINANCE LOW、MID、HIGH
CONTRAST LOW、MIDLOW、MID、MIDHIGH、HIGH
LUMINANCE：Set the extent of the luminance compression
CONTRAST：Set the extent of the contrast enhancement.
NOTE: When ATR funciton has been enabled, please avoid enabling the BACKLIGHT
function at the same time.
4.2.6 NR: ↲
NR MODE Y/C、Y、C、OFF
Y LEVEL 000~015
C LEVEL 000~015
NR MODE：Set the DNR mode of Y/C, Y and C.
Y LEVEL：Set the Y filter strength.
C LEVEL：Set the C filter strength.
NOTE: The Y/C mode is the automanic DNR mode.
4.2.7 PICT ADJUST: ↲
MIRROR ON / OFF
BRIGHTNESS 000~255
CONTRAST 000~255
SHARPNESS 000~255
HUE 000~255
GAIN 000~255
All camera parameters can be adjusted here.

ED310e Indoor Dome
10
4.2.8 NEXT: ↲
Enter MAIN MENU, page 2.
4.2.9 EXIT: ↲
Exit OSD to select the option list.
4.2.10 SAVE ALL:
When you change the OSD menu settings, before leaving the OSD item option SAVE
ALL. Press ENTER key to change the memory settings for the OSD.
4.2.11 DAY/NIGHT：AUTO / DAY / NIGHT / EXT1 / EXT2 selectable.
DAY/NIGHT: AUTO
AUTO
BURST：ON/OFF
DELAY CNT：000~255
DAYNIGHT：000~255
NIGHT DAY：000~255
BURST：Select whether or not to output the burst signal when Night status has been
identified.
DELAY CNT：Set the Night/ Day identification transfer time (Default: 4Sec.).
DAYNIGHT：Set the threshold for identifying the Night status from the Day status.
NIGHT DAY：Set the threshold for identifying the Day status from the Night status.
DAY/NIGHT: DAY
Day mode forcibly
DAY/NIGHT: NIGHT
Night mode forcibly
Night
BURST：ON/OFF
IR OPTIMIZER：ON/OFF
MODE：CENTER/AUTO
LEVEL：00~31
BURST：Select whether or not to output the burst signal.
IR OPTIMIZER ：The IR Optimizer function makes it possible to minimize this
overexposure by optimizing the exposure control during Night
operations.
MODE：Set the IR OPTIMIZER operating mode.
LEVEL：Adjust the reference level of the IR Optimizer (Default: Level 5).

ED310e Indoor Dome
11
DAY/NIGHT: EXT1
DN_IN 0[h]: Night mode
1[h]: Day mode
DAY/NIGHT: EXT2
DN_IN 0[h]: Day mode
1[h]: Night mode
4.2.12 PRIVACY: ON / OFF selectable.
PRIVACY: ON
AREA SEL Max. 8
TOP 000~244 (NTSC) / 000~288(PAL)
BOTTOM 000~244 (NTSC) / 000~288(PAL)
LEFT 600TVL：000~378 (NTSC)、000~370 (PAL)
700TVL：000~474 (NTSC)、000~468 (PAL)
RIGHT 600TVL：000~378 (NTSC)、000~370 (PAL)
700TVL：000~474 (NTSC)、000~468 (PAL)
COLOR 1~8
TRANSP 0.00 / 0.50 / 0.75 / 1.00
MOSAIC ON / OFF
AREA SEL: Select the mask frame for adjustment.
NOTE: When the MONITOR AREA has been set to ON by the MOTION DET setting,
only 4 PRIVACY AREA SEL are selectable (1 / 4, 2 / 4, 3 / 4, 4 / 4).
TOP: Set the selected top side of the mask frame.
BOTTOM: Set the selected bottom side of the mask frame.
LEFT: Set the selected left side of the mask frame.
RIGHT: Set the selected right side of the mask frame.
COLOR: Set the selected colors of the mask frames (1~8).
TRANSP: Set the transparency ratio of the mask frames (0/ 0.5/ 0.75/ 1).
MOSAIC: Set the mask frame mosaic function to ON or OFF.

ED310e Indoor Dome
12
4.2.13 MOTION: ON / OFF selectable.
MOTION DET: ON
DETECT SENSE 000~127
BLOCK DISP ON / OFF / ENABLE
MONITOR AREA ON / OFF
AREA SEL 1~4
TOP 000~244 (NTSC) / 000~288(PAL)
BOTTOM 000~244 (NTSC) / 000~288(PAL)
LEFT 600TVL：000~378 (NTSC)、000~370 (PAL)
700TVL：000~474 (NTSC)、000~468 (PAL)
RIGHT 600TVL：000~378 (NTSC)、000~370 (PAL)
700TVL：000~474 (NTSC)、000~468 (PAL)
DETECT SENSE: Set the motion detection sensitivity.
BLOCK DISP: Control the ON/ OFF status of the motion detection block display.
MONITOR AREA: Set whether to use the monitoring frames.
AREA SEL: Select the monitoring frame for setup.
TOP: Set the selected top side of the monitoring frame.
BOTTOM: Set the selected bottom side of the monitoring frame.
LEFT: Set the selected left side of the monitoring frame.
RIGHT: Set the selected right side of the monitoring frame.

ED310e Indoor Dome
13
4.2.14 CAMERA ID: ON / OFF selectable.
A B C D E F G H I J K L M N O P Q R S T U V
W X Y Z 0 1 2 3 4 5 6 7 8 9 - ! ” # $ % & ’
( ) _ ‵, ￥：；< = > ? @ \^ * .
x
+ /
Each User Font
← → ↑ ↓
The camera ID cursor moves in the direction
of the arrow when the Enter operation input
is performed from the status in which←, →,
↑ or ↓ has been selected using the
character selection cursor.
CLR
The character selected by the camera ID
cursor is cleared when the Enter operation
input is performed from the status in which
CLR has been selected using the character
selection cursor.
POS
The display switches to the camera ID displ
ay
position setting screen when the Enter
operation input is performed from the status
in which POS has been selected using the
character selection cursor. On the camera ID
display position setting screen, the camera ID
display position is changed in real
time in
response to the left, right, up or down
operation input. When the Enter operation
input is performed, the display position is
entered, and the display returns to the
camera ID setting screen.
4.2.15 LANGUAGE
8 Selectable languages: English / Japanese / German / French / Russian / Portuguese /
Spanish / Simplified Chinese.
4.2.16 CAMERA RESET
Reset Factory default setup.
4.2.17 BACK
Return to MAIN MENU, page1.

EverFocus Electronics Corp.
EverFocus Taiwan:
12F, No.79, Sec. 1, Shin-Tai Wu Road,
Hsi-Chih, Taipei, Taiwan
TEL: [phone]
FAX: [phone]
www.everfocus.com.tw
[e-mail]
EverFocus Europe - Germany:
Albert-Einstein-Strasse 1, D-46446
Emmerich, Germany
TEL: [phone]
FAX: [phone]
www.everfocus.de
[e-mail]
EverFocus China - Beijing:
Room 609, Technology Trade Building,
Shangdi Information Industry Base,
Haidian District, Beijing 100085, China
TEL: [phone]~39
FAX: [phone]
www.everfocus.com.cn
[e-mail]
EverFocus China - Shenzhen:
4F, No. 2, D4 Building, Wan Yelong
Industrial Park, Tangtou Road, Shiyan,
Baoan, Shenzhen, Guangdong 518101, China
TEL: [phone]
FAX: [phone]
www.everfocus.com.cn
[e-mail]
EverFocus USA - California:
1801 Highland Avenue, Unit A, Duarte, CA 91010,
USA
TEL: [phone]
FAX: [phone]
www.everfocus.com
[e-mail]
EverFocus USA - New York:
415 Oser Avenue, Unit S, Hauppauge, NY 11788, USA
TEL: [phone]
FAX: [phone]
www.everfocus.com
[e-mail]
EverFocus Japan:
5F, Kinshicho City Building, 2-13-4
Koto-Bashi,Sumida-Ku, Tokyo, 130-0022, Japan
TEL: [phone]
FAX: [phone]
www.everfocus.co.jp
[e-mail]
EverFocus Europe - UK:
Unit 12, Spitfire Business Park,
Hawker Road, Croydon Surrey, CR0 4WD, UK
TEL: [phone]
FAX: [phone]
www.everfocusuk.co.uk
[e-mail]
EverFocus India:
Suite 803, Housefin Bhavan, C-21, Bandra Kurla
Complex, Bandra (East), Mumbai 400051, India
TEL: [phone]
FAX: [phone]
www.everfocus.in
[e-mail]
Your EverFocus product is designed
and manufactured with high quality
materials and components which can
be recycled and reused.
This symbol means that electrical and
electronic equipment, at their
end-of-life, should be disposed of
separately from your household waste.
Please, dispose of this equipment at
your local community waste
collection/recycling centre.
In the European Union there are
separate collection systems for used
electrical and electronic product.
Please, help us to conserve the
environment we live in!
Ihr EverFocus Produkt wurde entwickelt
und hergestellt mit qualitativ
hochwertigen Materialien und
Komponenten, die recycelt und wieder
verwendet werden können.
Dieses Symbol bedeutet, dass
elektrische und elektronische Geräte am
Ende ihrer Nutzungsdauer vom
Hausmüll getrennt entsorgt werden
sollen.
Bitte entsorgen Sie dieses Gerät bei
Ihrer örtlichen kommunalen
Sammelstelle oder im Recycling Centre.
Helfen Sie uns bitte, die Umwelt zu
erhalten, in der wir leben!
