EVERSPRING EVR_AN1582 User manual

1 (c) 2012 Z-Wave Europe GmbH, Goldbachstr. 13, 09337 Hohenstein-Ernstthal, Germany, www.zwaveeurope.com
EVR_AN1582
Z-Wave Power Meter plus Switch -
Schuko
Firmware Version : 1.1
Quick Start
Plug this module into a wall outlet near the load to be controlled. Plug the load into the module and switch the load to the ON
position. To turn ON the module and the load plugged into it, press and release the ON/OFF button of the module.
Inclusion and Exclusion are confirmed by a tripple click of the button of the device.
Please refer to the chapters below for detailed information about all aspects of the products usage.
What is Z-Wave?
This device is equipped with wireless communication complying to the Z-Wave standard. Z-Wave is the international standard
for wireless communication in smart homes and buildings. It is using the frequency of 868.42 MHz to realize a very stable
and secure communication. Each message is reconfirmed (two-way communication) and every mains powered node can act as
a repeater for other nodes (meshed network) in case the receiver is not in direct wireless range of the transmitter.
Z-Wave differentiates between Controllers and Slaves. Slaves are either sensors (S) transmitting metered or measured data or
actuators (A) capable to execute an action. Controllers are either static mains powered controllers (C) also referred to as
gateways or mobile battery operated remote controls (R). This results in a number of possible communication patterns within a Z-
Wave network that are partly or completely supported by a specific device.
Controllers control actuators1.
Actuators report change of status back to controller2.
Sensors report change of status of measured values to controller3.
Sensors directly control actuators4.
Actuators control other actuators5.
Remote controls send signals to static controllers to trigger scenes or other actions6.
Remote controls control other actuators.7.
There are two different role a controller can have. There is always one single primary controller that is managing the network and
including/excluding devices. The controller may have other functions - like control buttons - as well. All other controllers don't
manage the network itself but can control other devices. They are called secondary controllers. The image also shows that its not

2 (c) 2012 Z-Wave Europe GmbH, Goldbachstr. 13, 09337 Hohenstein-Ernstthal, Germany, www.zwaveeurope.com
possible to operate a sensor just from a remote control. Sensors only communicate with static controllers.
Product description
The AN1582 is a pluggable switch that controls electrical loads connected to mains power using standard Schuko wall outlets. It
can switch all electrical loads up to 3500 W and additionally measure the electrical power taken by this load (in Wh) and meters
the electrical energy consumed (in kWh). The device is IP 20 rated and therefore, it only can be used in dry environments. The
device is operated either wirelessly using Z-Wave or with a button on the device. A red LED indicates the switching status.
Before Device is installed
Please read carefully the enclosed user manual before installation of the radio-actuator, in order to ensure an error-free
functioning.
ATTENTION: only authorized technicians under consideration of the country-specific installation guidelines/norms may do works
with 230 Volt mains power. Prior to the assembly of the product, the voltage network has to be switched off and ensured against
re-switching.
The product is permitted only for proper use as specified in the user manual. Any kind of guarantee claim has to be forfeited if
changes, modifications or painting are undertaken. The product must be checked for damages immediately after unpacking. In the
case of damages, the product must not be operated in any case. If a danger-free operation of the equipment cannot be assured,
the voltage supply has to be interrupted immediately and the equipment has to be protected from unintended operation.
Installation Guidelines
The device can be plugged into every standard Schuko outlet (plug type E). Do not locate the Module facing direct sunlight, humid
or dusty place. The suitable ambient temperature for the module is 0°C ~ 40°C.
Behavior within the Z-Wave network
I On factory default the device does not belong to any Z-Wave network. The device needs to join an existing wireless network to
communicate with the devices of this network. This process is called Inclusion. Devices can also leave a network. This process is
called Exclusion. Both processes are initiated by the primary controller of the Z-Wave network. This controller will be turned into
exclusion respective inclusion mode. Please refer to your primary controllers manual on how to turn your controller into inclusion
or exclusion mode. Only if the primary controller is in inclusion or exclusion mode, this device can join or leave the network.
Leaving the network - i.e. being excluded - sets the device back to factory default.
If the device already belongs to a network, follow the exclusion process before including it in your network. Otherwise inclusion of
this device will fail. If the controller being included was a primary controller, it has to be reset first.
Inclusion and Exclusion are confirmed by a tripple click of the button of the device.
Operating the device
The device is able to switch and measure any electric load up to 3500 W. Any load above 3500 W is considered as overloading.

3 (c) 2012 Z-Wave Europe GmbH, Goldbachstr. 13, 09337 Hohenstein-Ernstthal, Germany, www.zwaveeurope.com
When overloading is detected the device will turn off the load, lock the local button and indicate the status by flashing the LED for
30 sec. Unplugging and replugging the module will reset the module to normal state. The electrical load can be switching using
wireless commands and operating the local button. The LED inside the local button will indicate the switching status.
To access the metered and measure electric values a gateway with appropriate visualization is required.
Associations
A Z-Wave devices control other Z-Wave devices. The relationship between one device controlling another device is called
association. In order to control a different device, the controlling device needs to maintain a list of devices that will receive
controlling commands. These lists are called association groups and they are always related to certain events (e.g. button
pressed, sensor triggers, ...). In case the event happens all devices stored in the respective association group will receive a
common wireless command.
Association Groups:
1 Send Alarm, Switch Report and Meter Report (max. nodes in group: 1)
2 Pressing button to switch other devices (max. nodes in group: 4)
Configuration Parameters
Z-Wave products are supposed to work out of the box after inclusion, however certain configuration can adapt the function better
to user needs or unlock further enhanced features.
IMPORTANT: Controllers may only allow configuring signed values. In order to set values in the range 128 … 255 the value sent in
the application shall be the desired value minus 256. For example: to set a parameter to 200 it may be needed to set a value of
200 minus 256 = minus 56. In case of a two byte value the same logic applies: Values greater than 32768 may needed to be given
as negative values too.
True Period (Parameter Number 1, Parameter Size 1) This is the time the switching status needs to remain
unchanged after a change to cause the device to send out a status message
Value Description
0 Disable
1 — 120 10 * 100 ms = 1 sec (Default 10)
Send Out Basic Command (Parameter Number 2, Parameter Size 1) Enable or Disable the status message
function when the local button press changes the switching state
Value Description
0 Disable (Default)
1 Enable
Meter Report Period (Parameter Number 3, Parameter Size 2) The device will report its meter value within the
interval set. Set to 0 will disable the autoreporting function.
Value Description
0 Disabled

4 (c) 2012 Z-Wave Europe GmbH, Goldbachstr. 13, 09337 Hohenstein-Ernstthal, Germany, www.zwaveeurope.com
1 — 3240 Interval = Wert * 10 sec (Default 3)
Command Classes
Supported Command Classes
Basic (version 1)
●
Association (version 2)
●
Version (version 1)
●
All Switch (version 1)
●
Manufacturer Specific (version 1)
●
Configuration (version 1)
●
Meter (version 2)
●
Binary Switch (version 1)
●
Technical Data
Power Supply 230V ~50-60 Hz
Attachable Loads 16A (3500 W), overcurrent is detected above 3000W
IP Rating 20
Explorer Frame Support No
SDK 5.02 pl2
Device Type Slave with routing capabilities
Generic Device Class Binary Switch
Specific Device Class Binary Power Switch
Routing Yes
FLiRS No
Firmware Version 1.1
Explanation of Z-Wave specific terms
Controller — is a Z-Wave device with capabilities to manage the network. Controllers are typically Gateways, Remote Controls
●
or battery operated wall controllers.
Slave — is a Z-Wave device without capabilities to manage the network. Slaves can be sensors, actuators and even remote
●
controls.
Primary Controller — is the central organizer of the network. It must be a controller. There can be only one primary controller
●
in a Z-Wave network.
Inclusion — is the process of bringing new Z-Wave devices into a network.
●
Exclusion — is the process of removing Z-Wave devices from the network.
●
Association — is a control relationship between a controlling device and a controlled device.
●
Wakeup Notification — is a special wireless message issued by a Z-Wave device to announces that is able to communicate.
●
Node Information Frame — is a special wireless message issued by a Z-Wave device to announce its capabilities and
●
functions.

5 (c) 2012 Z-Wave Europe GmbH, Goldbachstr. 13, 09337 Hohenstein-Ernstthal, Germany, www.zwaveeurope.com
Disposal Guidelines
The product does not contain hazardous chemicals.
Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local
government for information regarding the collection systems available. If electrical appliances are disposed of in landfills or
dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being.
