EVERSPRING ZH143-0 User manual

0
ZH143-0 Portable Multimedia
Tablet User Manual

1
Content
1. Product Overview………….…………………………………………………………………………………………………………….…………..2
1.1 Front View…………………………………………………………………………………………………………………………………………..2
1.2 Back View ............................................................................................................................................... ...3
1.3 Botton Side........................................................................................................................................ ….....3
1.4 Top Side................................................................................................................................................... ..3
2. Product Features …..………………………………….………………………………………………………………………………….…….…….4
3. Product Speci fications.……….……………….……………………………………………………………………………………….…….…….5
4. Appendics ..……………………………………………………………………………………………………………………………………………6-7

2
1. Product Overview
1-1 Front View
Microphone
Front Camera
Status Indicator-Red、Blue、Green
Message Indicator-Orange
IR Sensor
Touch Screen Panel
1
2
3
4
5
6
1
2
3
5
6
4

3
1-2 Back View
Audio Speaker
1-3 Bottom Side
Dock Port
1-4 Top Side
Power Button
1
1
1
1
1
1
1

4
2. Product Features
Disconnecting to a network
Connecting to a network
S
lide
your finger up to
your
Home screen

5
3. Product Specification
Mode Name ZH143-0 (Portable Multimedia Tablet)
Operating System AndroidTM5.0
Display 8
”
(1280x800)
Panel OGS+Direct Bonding
CPU Intel® Atom Z3735D 1.33GHz Quad core
Memory DDR3L 2GB
Storage eMMC 16GB
Wireless Data Network WLAN 802.11 a/b/g/n (Dual Band)
Bluetooth Bluetooth v4.0
Front Camera 1.2M (FF)
Audio Audio speaker 1Wx2
Interface 1x Pogo connector
Button Power Key
Sensor Proximity Sensor
Battery (3.8V, 3070mAH)
Dimensions 224.35*138.20*10.8 (mm)
Weight 388g
Power -05V/3A
Operating environment -0°C to 35°C

6
Appendices
Model ZH143-0
Federal Communications Commission Statement
This devi ce complies wi th FCC Rules Pa rt 15.Operation is subject to the following two conditions:
• This device ma y not cause harmful interference.
• This device must accept a ny interference received，including interference that may cause undesired
opera tion.
This equipment has been tes ted and found to compl y with the limits for a class B digital devi ce, purs uant to
Part 15 of the Federal Communications Commission (FCC) rules. These limi ts are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment genera tes ,
uses , a nd can radiate radi o frequency energy and, if not installed and used in accordance wi th the ins tructions,
may cause harmful interference to radio communications. However, there is no gua rantee tha t interference
will not occur in a parti cula r installation. If this equipment causes harmful interference to radi o or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by doing one or more of the following measures :
• Reorient or relocate the recei ving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the recei ver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user‘s authority to operate the equipment.
The antenna(s) used for this tra nsmitter mus t not be co-located or operating in conjunction with any other
antenna or transmitter.
RF Exposure Warning
The equipment complies with RF exposure limi ts set forth for an uncontrolled envi ronment. The antenna(s )
used for this tra nsmitter mus t not be co-loca ted or operating in conjunction with any other antenna or
transmitter.
You a re cautioned that changes or modifi ca tions not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.
Proper disposal
DO NOT throw the Portable Multimedia Tablet in municipal waste. This product has been designed to
enable proper reuse of parts and recycling. The s ymbol of crossed out wheeled bin indicates that the
product (electri cal , electronic equipment and mercury-containing button cell battery) should not be
placed in municipal was te. Check local regula tions for disposal of electronic products .

7
DO NOT throw the battery in muni cipal waste. The symbol of the crossed out wheeled bin indicate
tha t the battery should not be placed in municipal waste.
Recycle
Caution: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED
BATTERIES ACCORDING TO THE INSTRUCTIONS.
