evertz 7700 Series User manual

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
TABLE OF CONTENTS
1. OVERVIEW............................................................................................................................. 1
2. INSTALLATION...................................................................................................................... 3
2.1. VIDEO CONNECTIONS ............................................................................................................... 3
2.2. GENLOCK REFERENCE ............................................................................................................. 4
2.3. 6 HZ PULLDOWN REFERENCE ................................................................................................. 4
3. SPECIFICATIONS .................................................................................................................. 5
3.1. SERIAL VIDEO INPUT................................................................................................................. 5
3.2. RECLOCKED SERIAL VIDEO DA OUTPUTS............................................................................. 5
3.3. DOWNCONVERTED SERIAL VIDEO OUTPUTS........................................................................ 6
3.4. DOWNCONVERTED COMPOSITE ANALOG VIDEO OUTPUTS............................................... 6
3.5. GENLOCK INPUT ........................................................................................................................ 6
3.6. 6 HZ INPUT .................................................................................................................................. 6
3.7. INPUT TO OUTPUT PROCESSING DELAY (HD INPUT VIDEO)...............................................6
3.8. ELECTRICAL ............................................................................................................................... 7
3.9. PHYSICAL.................................................................................................................................... 7
4. STATUS INDICATORS........................................................................................................... 7
4.1. AUDIO STATUS LEDS................................................................................................................. 8
5. ON SCREEN MENUS............................................................................................................. 8
5.1. NAGIVATING THE ON SCREEN MENU SYSTEM...................................................................... 8
5.2. ON SCREEN DISPLAY – MAIN MENU ....................................................................................... 9
5.3. CONFIGURING THE VIDEO CONTROLS ................................................................................. 10
5.3.1. Setting the Video Input Type ......................................................................................... 10
5.3.2. Setting the Video Input and Output Standard ................................................................ 11
5.3.3. Selecting the Genlock Source ....................................................................................... 11
5.3.4. Resetting the Input Line Buffer ...................................................................................... 12
5.3.5. 3:2 Pulldown Processing ............................................................................................... 12
Revision 1.3

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
5.3.5.1. Selecting the 3:2 Pulldown Reference with 24 Fps and 23.98 Fps Input Video13
5.3.5.2. Accommodating Non-Standard 3:2 Sequences ...............................................13
5.3.6. Setting up the Video Output Timing............................................................................... 15
5.3.6.1. Calculating the Delay through the Downconverter. .......................................... 15
5.3.6.2. Setting the Vertical Phase of the Output Video – 525 Line Video .................... 16
5.3.6.3. Setting the Horizontal Phase of the Output Video – 525 Line Video ................ 17
5.3.6.4. Setting the Vertical Phase of the Output Video – 625 Line Video .................... 17
5.3.6.5. Setting the Horizontal Phase of the Output Video – 625 Line Video ................ 17
5.3.6.6. Setting the Minimum Delay...............................................................................18
5.4. CONFIGURING THE OUTPUT PICTURE.................................................................................. 18
5.4.1. Setting the Aspect Ratio of the Output Picture ..............................................................18
5.4.2. Setting the Action to Take when Input Video Is Missing................................................19
5.4.3. Set the Colour of the Panels..........................................................................................20
5.5. CONFIGURING THE SCALER...................................................................................................20
5.5.1. Setting the Scaler Horizontal filter Sharpness ............................................................... 20
5.5.2. Setting the Scaler Vertical filter Sharpness ................................................................... 20
5.6. CONFIGURING THE VERTICAL INTERVAL PROCESSING.................................................... 21
5.6.1. Putting Closed Captions on the Program Video Outputs...............................................21
5.6.2. Setting the Caption Decoder Line for 525 Line Video Outputs ......................................21
5.6.3. Setting the VITC Line for 625 Line Video Outputs......................................................... 22
5.6.4. Putting VITC On The Program Video Outputs...............................................................22
5.6.5. Setting The Contents Of The VITC User Bits ................................................................ 22
5.6.6. Setting the VITC Line for 525 Line Video Outputs......................................................... 22
5.6.7. Setting the VITC Line for 625 Line Video Outputs......................................................... 22
5.7. CONFIGURING THE VIDEO PROCESSING FUNCTIONS .......................................................23
5.7.1. Setting the Gain Levels..................................................................................................24
5.7.2. Setting the DC Offset.....................................................................................................24
5.7.3. Setting the Hue ..............................................................................................................24
5.7.4. Setting the Gamma Level .............................................................................................. 24
5.7.5. Setting the Detail Gain...................................................................................................24
5.7.6. Setting the Luma Floor ..................................................................................................24
5.7.7. Setting the Detail Noise Floor ........................................................................................ 25
5.7.8. Setting the Enhancement Limit...................................................................................... 25
5.7.9. Setting the Horizontal Band ........................................................................................... 25
5.7.10. Setting the V Enhancement ........................................................................................... 25
5.8. CONFIGURING THE AUDIO PROCESSING.............................................................................25
5.8.1. Selecting The Audio Groups That Will Be De-Embedded ............................................. 26
5.8.2. Selecting The Audio Groups That Will Be Embedded ...................................................26
5.8.3. Configuring the Output Audio Channel Sources............................................................ 27
Revision 1.3

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
5.9. SETTING UP THE ANALOG OUTPUT PARAMETERS ............................................................ 28
5.9.1. Setting the Composite Display Mode – Colour or Monochrome.................................... 28
5.9.2. Setting the Analog Video Output Level.......................................................................... 28
5.9.3. Setting the Hue .............................................................................................................. 28
5.9.4. Setting the Saturation .................................................................................................... 29
5.9.5. Setting the Contrast ....................................................................................................... 29
5.9.6. Setting the Brightness.................................................................................................... 29
5.9.7. Setting the NTSC Setup Pedestal on the Analog Video Output .................................... 29
5.9.8. Setting the NTSC Setup Pedestal on Line 21 of the Analog Video Output ................... 29
5.10. UTILITIES ................................................................................................................................... 30
5.10.1. Selecting the On Screen Display ................................................................................... 30
5.10.2. Recalling Configurations to the User Presets or the Factory Preset ............................. 30
5.10.3. Saving Configurations to the User Presets.................................................................... 31
5.10.4. Initiating a Software Upgrade ........................................................................................ 31
5.10.5. Accessing Information About this Module and its Firmware .......................................... 31
6. LOCATION OF LEDS AND JUMPERS ................................................................................ 32
6.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS.......................................................................................... 32
6.2. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES ............................................... 33
6.3. CONTROLLING THE OUTPUT VIDEO STANDARD ON LOSS OF VIDEO ............................. 33
6.4. DISABLING THE ON SCREEN DISPLAY ON THE PROGRAM VIDEO OUTPUTS................. 33
6.5. SELECTING THE FUNCTION OF THE COMP/SDI OUTPUTS 1 TO 3.....................................34
6.6. SELECTING THE 6 HZ INPUT (REV A AND LATER BOARDS ONLY) ................................... 34
6.7. SELECTING THE GENLOCK INPUT SOURCE ........................................................................ 34
6.7.1. Rev 1 Boards ................................................................................................................. 34
6.7.2. Rev A and Later Boards ................................................................................................ 35
7. VISTALINK™ REMOTE MONITORING/CONTROL ............................................................ 36
7.1. WHAT IS VISTALINK™? ............................................................................................................... 36
7.2. VISTALINKTM MONITORED PARAMETERS .............................................................................. 37
7.3. VISTALINKTM CONTROLLED PARAMETERS ........................................................................... 37
7.4. VISTALINKTM TRAPS .................................................................................................................. 39
8. MENU QUICK REFERENCE ................................................................................................ 40
Revision 1.3

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
Figures
Figure 1: 7713HDC Block Diagram ........................................................................................................................ 2
Figure 2: 7713HDC Rear Panel Overlay ................................................................................................................ 3
Figure 3: 3:2 Pulldown Sequence Insertion – 24 Fps and 23.98 Fps Input Video............................................... 14
Figure 4: 6 Hz Pulldown Sequence A Frame Alignment – 1080p/23.98sF Input Video ...................................... 14
Figure 5: RP188 Pulldown Sequence A Frame Alignment – 24 Fps and 23.98 Fps Input Video........................ 14
Figure 6: Aspect Ratio Conversions..................................................................................................................... 19
Figure 7: LED and Jumper Locations Rev 1 Boards............................................................................................ 32
Figure 8: LED and Jumper Locations Rev A and Later Boards ........................................................................... 32
Figure 9 Genlock Selection Schematic showing BNC Genlock condition (Rev 1 Boards) .................................. 35
Figure 10 Genlock Selection Schematic showing BNC Genlock condition (Rev A and Later Boards) .............. 36
Tables
Table 1: Video Input Formats ................................................................................................................................. 5
Table 2: Audio Group Status LEDs ........................................................................................................................ 8
Table 3: Video Delay ............................................................................................................................................ 16
Table 4: Genlock Source Jumper Configuration (Rev 1 Boards)......................................................................... 34
Table 5: Genlock Source Jumper Configuration (Rev A and Later Boards) ........................................................ 35
Table 6: VistaLINK™ Monitored Parameters ....................................................................................................... 37
Table 7: VistaLINK™ Controlled Parameters....................................................................................................... 38
Revision 1.3

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
REVISION HISTORY
REVISION DESCRIPTION DATE
1.0 First version Dec 04
1.1 Updated for Rev A boards Feb 05
1.2 Typos fixed, updated Genlock jumper info, and VistaLINK™ Traps Mar 05
1.3 Revised Block Diagram July 05
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for
the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of
Evertz products are for informational use only and are not warranties of future performance, either express or implied. The only warranty offered by
Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is
granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.
Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,
Revision 1.3

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or
specifications.
Revision 1.3

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
1. OVERVIEW
The 7713HDC is a reclocking high definition serial digital video distribution amplifier and a high quality
downconverter for 1.5 Gb/s HDTV signals. It can also function as a monitoring distribution amplifier for
standard definition 270 Mb/s signals. The 7713HDC provides 4 reclocked DA outputs and 3
downconverted SDI or composite analog NTSC/PAL outputs (selectable). The 7713HDC accepts all the
popular international SMPTE 292M video formats. When the 7713HDC down converts 1080p/23.98sF
input video to 525i/59.94 with a 3:2 pulldown, the 3:2 pulldown cadence can be free running, locked to
embedded RP188 time code or an external 6Hz input.
The 7713HDC has color space conversion from ITU rec. 709 to ITU rec. 601, and will provide various
down converted formats such as 16:9 letterbox, 14:9 letterbox, 13:9 letterbox, 4:3 center crop, and 4:3
anamorphic squeeze. Full 10 bit processing is provided throughout the signal path to achieve excellent
downconversion quality with detail enhancement and gamma correction. The 7713HDC has the ability to
adjust video parameters such as brightness, hue and saturation. The 7713HDC also de-embeds two
groups of audio and re-embeds the audio on the SDI output in time with the video. It can also reassign
audio channels within the groups. All parameters may be controlled by use of the on screen display menu
or through VistaLINK™ PRO.
The 7713HDC provides card edge LEDs to indicate signal present and audio groups present. The
7713HDC occupies one card slot in the 3 RU frame, which will hold up to 15 modules or the 1RU frame,
which will hold up to three modules.
Features:
Serial digital 1.5 Gb/s HD input per SMPTE 292M•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Supports most international standards including 1080i/60, 1080i/59.94, 1080i/50, 1080p/24,
1080p/23.98, 1080p/24sF, 1080p/23.98sF, 720p/60, 720p/59.94, 720p/50, 480p/60, and 480p/59.94
Will also accept 270 Mb/s SD input SDI per SMPTE 259M in a pass through mode – auto senses HD
or SD inputs
4 Reclocked DA outputs (HD if HD inputs applied, SD if SD inputs applied)
3 Selectable SDI or Composite Outputs (downconverted from HD if HD input applied), (from reclocked
SD if SD input applied)
High quality HD -> SD down conversion
Detail enhancement provided on SDI or composite outputs
Supports 16:9 letterbox, 14:9 letterbox, 13:9 letterbox, 4:3 center crop, and 4:3 anamorphic squeeze
aspect ratio conversions.
1080p/23.98sF conversion to 525i/59.94 with 3:2 pulldown sequence – time code or 6 Hz Reference
HD to SD colour space conversion (ITU rec. 709 to ITU rec. 601)
Reference input from card or 7700FR-G Frame reference allows for phasing of output video
On screen display used to configure the operating modes
De-embeds Audio from HD video and embeds into standard definition SDI video (2 groups)
Moves ANC data (e.g. captioning, time code) from HD video to standard definition SDI video
Card Edge LEDs for signal presence, genlock presence, equalization warning, audio groups present,
module status
VistaLINK™ - enabled offering remote monitoring, control and configuration capabilities via SNMP.
VistaLINK™ is available when modules are used with the 3RU 7700FR-C frame and a 7700FC
VistaLINK™ Frame Controller module in slot 1 of the frame using the model 9000NCP Network
Control Panel or Evertz VistaLINK™ PRO or other third party SNMP manager software.
Revision 1.3 7713HDC-1

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
7713HDC-2 Revision 1.3
HD or SDI
Serial Video
Input
3 Downconverted
Outputs
(each are selectable)
as SDI (SMPTE 259M)
or composite analog
(NTSC/PAL)
Auto
Equalizer
S/P
&
Reclocker
4 HD/SD
Re-clocked
Outputs
* bypassed when SD SDI applied to input
EQ
Warning
* 3/2 pulldown
Downconverter
Aspect ratio
conversion
SDI
P/S
* Audio/ANC
De-embedder
* Audio/
ANC &
Caption
Inserter
NTSC/
PAL
Encoder
Audio Groups
HD SD
* Frame
Buffer
On Screen
Display
Module
Status
Card Edge
Control &
Indicators
Genlock
Present
VistaLINKTM
Interface
* Video
Proc
6 Hz
Pulse
Genlock
Reference
Video
Present
Figure 1: 7713HDC Block Diagram

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
2. INSTALLATION
The 7713HDC comes with a companion rear plate that occupies one slot in the frame. For information on
inserting the module into the frame see the 7700FR chapter section 3.
Figure 2: 7713HDC Rear Panel Overlay
2.1. VIDEO CONNECTIONS
INPUT Input BNC connector for 10-bit serial digital video signals compatible with the SMPTE 292M or
SMPTE 259M-C standards. (SMPTE 259M not supported at the time of writing.)
DA OUTPUT 1 to 4 These four BNC connectors are used to output reclocked serial component video, in
the same standard as the video input. DA OUTPUT 4 can also be used as a 6 Hz or genlock
input by reconfiguring jumpers on the main circuit board. See section 6.6 and 6.7 for
information on configuring this BNC.
Revision 1.3 7713HDC-3

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
COMP/SDI OUT 1 to 3 These three BNC connectors can be individually configured either as
downconverted SDI video outputs, compatible with the SMPTE 259M-C standard, or as
composite analog (NTSC/PAL) video outputs. See section 6.5 for information on selecting the
output type. COMP/SDI OUT 1 can also be used as a genlock input by reconfiguring jumpers
on the main circuit board. See section 6.7 for information on selecting the Genlock source.
2.2. GENLOCK REFERENCE
For proper synchronization of the output video, the downconverter must be locked to a genlock signal of
the output video format. In addition, the input video must be clock-locked to the genlock signal.
GLCK IN There are four possible sources to connect the genlock reference. DA OUTPUT 4 or
COMP/SDI OUT 1 can be used as a genlock input by reconfiguring jumpers on the main
circuit board. (See section 6.7). When the card is installed in a model 7700FR-G frame, the
Genlock source can come from one of the two frame Genlock signals carried on the frame
mid-plane. The genlock signal may be NTSC or PAL colour black (the same as the output
video format), and is auto-detected by the module. Jumper J21 on the 7713HDC module
selects whether the selected reference input is terminated to 75 ohms (default) or high
impedance. On Rev A and later boards, the Frame Genlock Source menu item is used to
select whether one of the two Frame Genlock signals or the GLCK IN signal will be used.
On Rev 1 boards, there is also a jumper that must be set (See section 6.7). The output
video can be timed with respect to the genlock video using the H Phase Offset and V
Phase Offset menu items. (See section 5.3.6) When no Genlock is provided, the output
video is timed with respect to the input video.
2.3. 6 HZ PULLDOWN REFERENCE
For control of the 3/2 cadence on the output video, the downconverter can be locked to a 6 Hz reference
pulse.
6 HZ IN DA OUTPUT 4 / 6 HZ IN can also be configured as a 6 Hz input by reconfiguring jumper
J11 on the main circuit board. (See section 6.6 for information on configuring the BNC as a
6 Hz Input) The 6 Hz pulse should be a 1/30th second wide TTL level active high pulse
occurring 6 times per second and must be coincident with the start of an input frame. The 6
Hz pulse will normally identify the A frame candidates.
7713HDC-4 Revision 1.3

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
3. SPECIFICATIONS
3.1. SERIAL VIDEO INPUT
Standard: 270 Mb/s SMPTE 259M - pass through mode
1.485 Gb/sec SMPTE 292M – auto-detects standard
SMPTE 260M, SMPTE 274M, SMPTE 296M, SMPTE 349M – see Table 1 for a
list of supported HD video standards
Common Name Pixels /
Active Lines
Frame Rate Progressive
/Interlace
SMPTE
Standard
Output Format
1080i/60 1920 x 1080 30 I 274M 525i/60
1080i/59.94 1920 x 1080 29.97 (30/1.001) I 274M 525i/59.94 (NTSC)
1080i/50 1920 x 1080 25 I 274M 625i/50 (PAL)
1080p/29.97sF 1920 x 1080 29.97 (30/1.001) P (sF) 274M 525i/59.94 (NTSC)
1080p/25sF 1920 x 1080 25 P (sF) 274M 625i/50 (PAL)
1080p/24 1920 x 1080 24 P 274M 525i/60
1080p/23.98 1920 x 1080 23.98 (24/1.001) P 274M 525i/59.94 (NTSC)
1080p/24sF 1920 x 1080 24 P (sF) 274M 525i/60
1080p/23.98sF 1920 x 1080 23.98 (24/1.001) P (sF) 274M 525i/59.94 (NTSC)
1035i/60 1920 x 1035 30 I 260M 525i/60
1035i/59.94 1920 x 1035 29.97 (30/1.001) I 260M 525i/59.94 (NTSC)
720p/60 1280 x 720 60 P 296M 525i/60
720p/59.94 1280 x 720 59.94 (60/1.001) P 296M 525i/59.94 (NTSC)
720p/50 1280 x 720 50 P 296M 625i/50
480p/60 720 x 483 60 P 293M, 349M 525i/60
480p/59.94 720 x 483 59.94 (60/1.001) P 293M, 349M 525i/59.94 (NTSC)
Table 1: Video Input Formats
Connector: BNC per IEC 60169-8 Amendment 2.
Input Equalization: Automatic to 100m @ 1.5Gb/s with Belden 1694 or equivalent cable.
Return Loss: >15 dB up to 1.5GHz
3.2. RECLOCKED SERIAL VIDEO DA OUTPUTS
Standard: Same as input
Number of Outputs: 4 Per Card reclocked
Connector: BNC per IEC 60169-8 Amendment 2
Signal Level: 800mV nominal
DC Offset: 0V ±0.5V
Rise and Fall Time: 200ps nominal for HD
750ps nominal for SD
Overshoot: <10% of amplitude
Return Loss: > 15 dB at 1.5 Gb/s
Jitter: < 0.2 UI
Revision 1.3 7713HDC-5

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
3.3. DOWNCONVERTED SERIAL VIDEO OUTPUTS
Standard: SMPTE 259M-C (270 Mb/s)
Number of Outputs: up to 3 Per Card (jumper selectable)
Connector: BNC per IEC 60169-8 Amendment 2.
Signal Level: 800mV nominal
DC Offset: 0V ±0.5V
Rise and Fall Time: 750ps nominal
Overshoot: <10% of amplitude
Return Loss: > 15 dB at 270 Mb/s
Jitter: < 0.2 UI
3.4. DOWNCONVERTED COMPOSITE ANALOG VIDEO OUTPUTS
Standards: Analog composite NTSC (SMPTE 170M) or
Analog composite PAL (ITU-R BT.470)
Number of Outputs: up to 3 Per Card (jumper selectable)
Connectors: BNC per IEC 60169-8 Amendment 2.
Signal Level: 1 V p-p nominal
DC Offset: 0V ±0.1V
Return Loss: >35dB up to 5 MHz
Frequency Response: 0.1dB to 4 MHz, 0.15dB to 5.5 MHz
Differential Phase: <0.5°(<0.3°typical)
Differential Gain: <0.8% (<0.5 % typical)
SNR: >78dB to 5 MHz (shallow ramp)
Impedance: 75 ohm
3.5. GENLOCK INPUT
Type: NTSC or PAL Colour Black 1 V p-p
Connector: BNC per IEC 60169-8 Amendment 2
or Frame Genlock on 7700FR-G frames. (selectable)
Termination: High impedance or internal 75 ohm termination (jumper selectable)
3.6. 6 HZ INPUT
Type: TTL level active high pulse 1/30 sec wide
Connector: BNC per IEC 60169-8 Amendment 2 (jumper selectable)
Termination: 500 ohm
3.7. INPUT TO OUTPUT PROCESSING DELAY (HD INPUT VIDEO)
Video Delay: Approximately 1 to 2 frames depending on input video format, processing mode
and phase setting – see table Table 3.
Audio Delay: Audio is delayed and re-embedded in time with the output picture
7713HDC-6 Revision 1.3

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
3.8. ELECTRICAL
Voltage: +12VDC
Power: 10 Watts.
EMI/RFI: Complies with FCC regulations for class A devices.
Complies with EU EMC directive.
3.9. PHYSICAL
Number of slots: 1
4. STATUS INDICATORS
The 7713HDC has 11 LED Status indicators on the main circuit board front card edge to show operational
status of the card at a glance. Figure 7 shows the location of the LEDs and card edge controls.
Two large LEDs on the front of the board indicate the general health of the module
LOCAL FAULT: This Red LED indicates poor module health and will be On during the absence of a
valid input signal or if a local input power fault exists (i.e.: a blown fuse). The LOCAL
FAULT indication can also be reported to the frame through the FRAME STATUS
jumper.
MODULE OK: This Green LED indicates good module health. It will be On when a valid input
signal is present, and board power is good.
There are five small LEDs near the upper edge of the board that indicate the status of the equalizer and
reclocker.
VIDEO PRESENT: This Green LED will be On when there is a valid signal present at the module input.
HD INPUT: This Green LED will be On when there is a valid high definition signal present at the
module input.
SD INPUT: This Green LED will be On when there is a valid standard definition (525 or 625 line)
SDI signal present at the module input.
SIGNAL WARNING: This Red LED will be On when the cable equalizer detects that the cable length is
greater than a preset threshold (factory set for 100 meters of Belden 1694A or
equivalent cable).
GENLOCK PRESENT: This Green LED will be On when a Bi-Level Reference input is detected.
Revision 1.3 7713HDC-7

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
4.1. AUDIO STATUS LEDs
Four LEDs located on the lower edge of the module (near the card extractor) indicate which audio groups
are present in the input video. Audio group LED 1 is located closest to the center of the module.
Audio Group
LED
Colour Audio Group Status
1 Off No group 1 present on input video.
Green Group 1 present on input video.
2 Off No group 2 present on input video.
Green Group 2 present on input video.
3 Off No group 3 present on input video.
Green Group 3 present on input video.
4 Off No group 4 present on input video.
Green Group 4 present on input video.
Table 2: Audio Group Status LEDs
5. ON SCREEN MENUS
5.1. NAGIVATING THE ON SCREEN MENU SYSTEM
A toggle switch and pushbutton allow card edge navigation of a set of on-screen menus used to configure
the card. To enter the on-screen menu system, press the pushbutton once. This will bring you to the
main setup menu where you can use the toggle switch to move up and down the list of available sub
menus. An arrow (Î) moves up and down the left hand side of the menu items to indicate which item you
are currently choosing. Once the arrow is on the desired item, press the pushbutton to select the next
menu level.
On all menus, there are two extra selectable items: Back and Exit. Selecting Back will take you to the
previous menu (the one that was used to get into the current menu) while Exit will return the display to its
normal operating mode. On the main menu, BACK and EXIT will both take you to the normal operating
mode.
Once in a sub menu, there may be another menu layer, or there may be a list of parameters to adjust. If
there is another set of menu choices, use the toggle switch to select the desired menu item and press the
pushbutton.
To adjust any parameter, use the toggle switch to move up or down to the desired parameter and press
the pushbutton. The arrow will move to the right hand side of the line (Í) indicating that you can now
adjust the parameter. Using the toggle switch, adjust the parameter to its desired value. If the parameter
is a numerical value, the number will increase if you lift the toggle switch and decrease if you push down
on the toggle switch.
When you have stopped at the desired value, depress the pushbutton. This will update the parameter to
the selected value and move the arrow back to the left side of the parameter list (Î). Continue selecting
and adjusting other parameters or use the BACK or EXIT commands.
7713HDC-8 Revision 1.3

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
5.2. ON SCREEN DISPLAY – MAIN MENU
The OSD menu is arranged in a layered structure that groups similar configuration items together. The
following section gives a brief description of the first level of menus that appear when you enter the OSD
screens. Selecting one of these items will take you to the next menu level. Sections 5.3 to 5.9 provide
detailed descriptions of each of the sub menus. The tables in sections 5.3 to 5.9 are arranged in an
indented structure to indicate the path taken to reach the control. Menu items or parameters that are
underlined indicate the factory default values.
Video Sets the input and output video standards and timing for the video output.
Output Picture Configuration of the output picture aspect ratio, action on loss of input, panel
colours, and other items related to the output picture.
Scaler Configuration of the scaler filter sharpness
VANC Data Processing Controls how vertical interval data is processed
Video Proc Controls the video processing parameters
Audio Sets the Audio groups
Analog Output Configuration of the analog video output parameters
Utilities Card preset management and various debug and maintenance features.
Revision 1.3 7713HDC-9

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
5.3. CONFIGURING THE VIDEO CONTROLS
The Video menus are used to configure parameters associated with the input and output video standards
and output video timing. Other than the Video Type menu, these menu items are not applicable when a
standard definition input video is connected. The chart below shows the items available in the Video
menu. Sections 5.3.1 to 5.3.6 give detailed information about the menu item.
Video Type Selects if the video input will be High Definition or Standard definition.
Std Selects the video input and output standards.
Genlock Source Selects the genlock source
Reset Input Buffer
Resets the input buffer so that the current video source is the midpoint. The
input can now vary ±1/4 line from the current source without any
disturbance in the output.
Pulldown Reference Selects the reference source when 3:2 pulldown is being added on the
output.
A Frame Offset Sets the offset of the A Frame from the Pulldown Reference when 3:2
pulldown is being added on the output
525 V Phase Offset Sets the vertical phase of the output signal to the NTSC Genlock reference
input.
525 H Phase Offset Sets the horizontal phase of the output signal to the NTSC Genlock
reference input.
625 V Phase Offset Sets the vertical phase of the output signal to the PAL Genlock reference
input.
625 H Phase Offset Sets the horizontal phase of the output signal to the PAL Genlock reference
input.
Set Minimum Delay Sets the output timing to achieve minimum delay.
5.3.1. Setting the Video Input Type
Video
Video Type
Auto
SD
HD
With this control, you can set whether the 7713HDC will function
as a reclocking high definition serial digital video distribution
amplifier and a high quality downconverter for 1.5 Gb/s HDTV
signals or function as a monitoring distribution amplifier for
standard definition 270 Mb/s signals.
When set to Auto, the module will autodetect the input video
type. You can also force it to either high definition mode (HD) or
standard definition mode (SD).
"
When the input video is Standard Definition, the 7713HDC operates as a monitoring
distribution amplifier. In this mode it does not process the audio or vertical interval
data but merely passes it through. Accordingly, the menu items that control these
functions
(
as described in sections 5.3.2 to 5.7
)
have no effect when the 7713HDC
7713HDC-10 Revision 1.3

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
is operating with standard definition video.
5.3.2. Setting the Video Input and Output Standard
Video
Std
Auto
1080i/60 to 525i/60
1080i/59.94 to 525i/59.94
720p/60 to 525i/60
720p/59.94 to 525i/59.94
1080i/50 to 625i/50
1080p/24 to 525i/60
1080p/23.98 to 525i/59.94
1080p/24sF to 525i/60
1080p/23.98sF to 525i/59.94
1080p/30sF to 525i/60
1080p/29.97sF to 525i/59.94
1080p/25sF to 625i/50
1035i/60 to 525i/60
1035i/59.94 to 525i/59.94
480p/60 to 525i/60
480p/59.94 to 525i/59.94
720p/50 to 625i/50
With this control, you can set the input and output video
standards. This menu item is not applicable when a standard
definition input video is connected.
Note: When set to Auto, the module cannot distinguish between
1080i/59.94, 1080p/29.97sF and 480p/59.94, so it will be treated
as 1080i/59.94. Similarly 1080p/25sF will be treated as
1080i/50.
5.3.3. Selecting the Genlock Source
Video
Genlock Source
Frame Ref. 1
Frame Ref. 2
External Input
If the card is installed in a 7700FR-G frame, two reference inputs are
available on the frame that supplies the genlock signal to every card in the
frame. Either of these two inputs may be selected as reference sources. On
Rev 1 boards you must also set a jumper to enable the Frame genlock
reference. On Rev A and later boards this is done automatically by selecting
the Frame Ref 1 or Frame Ref 2 menu choices.
See section 6.6 and 6.7 for information on selecting the card reference
source and termination. The reference may either be an externally supplied
color black reference signal or you may use the input video as a reference.
On Rev 1 boards this control allows you to select which frame reference will
be used when the jumpers are configured for a Frame genlock reference.
When the jumpers are configured for a BNC reference, this control has no
effect. On Rev A and later boards the Frame Genlock Jumper is replaced
with a switch under menu control. When you select External Input then the
Genlock BNC reference will be used.
!
The Genlock Source adjustments are REAL TIME ADJUSTMENTS and will affect
the output video timing immediately. This setting should not be adjusted when
the output video is in the broadcast chain.
Revision 1.3 7713HDC-11

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
5.3.4. Resetting the Input Line Buffer
Video
Reset Input Buffer
Reset
Cancel
There is a line buffer on the input of the 7713HDC that allows the input to be
switched between feeds that are genlocked, but offset ±1/4 of a line from a
reference point.
When the input buffer is reset, the current video source is set to be the
reference. An upstream router may now switch between feeds that are
offset from this video source by ±1/4 of a line without any visual disruption in
the output video.
!
Resetting the Input Buffer will affect the output video timing. These settings
should not be adjusted when the output video is in the broadcast chain.
5.3.5. 3:2 Pulldown Processing
When using a 1080i/60 or 1080i/59.94 input video feed containing 3:2 pulldown, the 7713HDC
downconverts each field of the incoming image to one field of output image, so there will be no pulldown
related de-interlacing artifacts on film originated material with 3:2 pulldown, or video originated material
acquired at a nominal 24 frames per second.
When using a 720p/60, 720p/59.94, 720p/50, 480p/60 or 480p/59.94 input video feed the 7713HDC
downconverts each frame of the incoming image to one field of output image, so there will be no pulldown
related artifacts on film originated material with 3:2 pulldown, or video originated material acquired at a
nominal 24 frames per second.
When using a 1080p/24sF or 1080p/23.98sF input video feed the 7713HDC combines each segment of
the incoming image back to a progressive frame before down conversion. When using a 1080p/24 or
1080p/23.98 input video feed the 7713HDC downconverts each frame of the incoming image. After down
conversion, extra fields are inserted to create a 3:2 pulldown at the output. The Pulldown Reference and A
Frame Offset menus are used to determine the cadence of the 3:2 output.
7713HDC-12 Revision 1.3

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
5.3.5.1. Selecting the 3:2 Pulldown Reference with 24 Fps and 23.98 Fps Input Video
"
This menu setting is only used when the input video is 1080p/24, 1080p/23.98,
1080p/24sF or 1080p/23.98sF. In other input video formats it is not applicable.
Video
Pulldown Reference
Auto
RP 188
6 Hz Input
Free Run
On 24 Fps and 23.98 Fps video input formats the Pulldown Reference menu
is used to identify the input frame that will become an A frame at the output.
This frame is called the A frame candidate (see Figure 3). The output of the
A frame candidate frame will be delayed by 2 frames, will consist of two
video fields and will normally be in time with the input. Additionally, an
offset can be added to the A Frame reference using the A Frame Offset
control to accommodate situations where the A frames are not in time with
the A Frame reference. (See section 5.3.5.2)
When you select Auto the 7713HDC will auto detect the pulldown reference
according to the following priority:
•
•
•
6 Hz pulse if present
RP188 ancillary time code if present
Free Run pulldown if RP188 is not present
Select RP 188 when the embedded ancillary time code present on the input
video is used to determine the pulldown. The input frames with time code
frame numbers divisible evenly by 4 will normally identify the input A frame
candidates.
Select 6 Hz Input when a 6 Hz pulse connected to DA OUTPUT 4 / 6 HZ
BNC is used to determine the pulldown. (See section 6.6 for information on
configuring the BNC as a 6 Hz Input) The 6 Hz pulse should be a 1/30th
second wide TTL level active high pulse occurring 6 times per second and
must be coincident with the start of an input frame. The 6 Hz pulse will
normally identify the A frame candidates.
Select Free Run when you want a continuous 3:2 pulldown on the output
but do not care if it matches specific frames of the input video.
5.3.5.2. Accommodating Non-Standard 3:2 Sequences
"
This menu setting is only used when the input video is 1080p/24, 1080p/23.98,
1080p/24sF or 1080p/23.98sF. In other input video formats it is not applicable.
Video
A Frame Offset
0
1
2
3
This control allows the user to select other frames as the A Frames.
Figure 4 shows how this control defines the A frame candidate when the 6
Hz pulse is present. Figure 5 shows how this control defines the A frame
when RP188 Ancillary data is used to control the 3:2 pulldown.
Revision 1.3 7713HDC-13

7700 MultiFrame Manual
7713HDC Downconverter & Distribution Amplifier
7713HDC-14 Revision 1.3
1080p/24sF
A Frame Candidate
6 Hz Input
A Frame Offset
0
1
2
3
0
odd
0
even
0 1
1
odd
1
even
2
1
odd
2
even
3
2
odd
3
even
3
odd
3
even
0
odd
0
even
1
odd
1
even
2
odd
2
even
3
odd
3
even
1080p/23.98sF
525i/59.94
Frame
Buffer
A Frame
A Frame Candidate
4
A Frame Candidate
4
odd
4
even
B Frame C Frame D Frame
Figure 3: 3:2 Pulldown Sequence Insertion – 24 Fps and 23.98 Fps Input Video
Figure 4: 6 Hz Pulldown Sequence A Frame Alignment – 1080p/23.98sF Input Video
:00 :01 :02 :03
1080p/24sF
A Frame Candidate
A Frame Offset
0
1
2
3
Figure 5: RP188 Pulldown Sequence A Frame Alignment – 24 Fps and 23.98 Fps Input
Video
