USER’S MANUAL
FOR
EVGA NFORCE4
MOTHERBOARD
MODELS: 131-K8-NF44-XX
131-K8-NF44 MANUAL - REV 1.0 - REV DATE 11 JAN 2006

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 2
Notice:
Specifications and information contained in this documentation are
furnished for informational use only, and are subject to change at any
time without notice, and should not be construed as a commitment by the
manufacturer.
This manual covers the following motherboards from EVGA CORP.
131-K8-NF44-XX
CPU SUPPORT
The 131-K8-NF44-XX motherboard will support the following AMD 939 pin
CPUs:
• Athlon FX 64 (FX55, FX57, FX60)
• Athlon 64 X2 (Dual Core)
• Athlon 64
• Sempron (when available in 939 pin)

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 3
TABLE OF CONTENTS
CHAPTER 1 - Introduction to nForce Motherboards 4
1-1 Motherboard Features 4
1-1.1 Special Features of the Motherboard 5
1-2 Specifications 6
1-3 Layout Diagram and Jumper Settings 7
1-3.1 Jumpers, Connectors, Headers, and Sockets 8
CHAPTER 2 - Hardware Installation 10
2-1 Hardware Installation Steps 10
2-2 Checking The Motherboard Jumper Settings 10
Clearing the CMOS RAM 10
Keyboard Power On Function 11
USB Power On Function 11
2-3 Installing The CPU 11
Glossary of Terms 11
2-3-2 About AMD Athlon64 939-pin CPUs 12
2-4 Installing Memory 13
Memory Installation Diagrams 14
2-5 Expansion Cards 15
2-5-1 Procedure For Expansion Card Installation 15
2-5-2 Assigning IRQs For Expansion Cards 15
2-5-3 Interrupt Request Table 16
2-5-4 PCI-Express Slots 16
Diagram of PCI-Express Slot Locations and Functions 16
Table of Standard IRQ Assignments 17
2-5-5 SLI Bridge Installation For NVIDIA SLI Cards (SLI Version Only) 18
2-6 Connectors and Headers 20
2-6-1 Connector Locations 20
2-7 Starting Up Your Computer 29
Beep Code Table 29
CHAPTER 3 - BIOS 30
3-0 Introducting BIOS 30
3-1 Entering BIOS Setup 30
CHAPTER 4 - DRIVER INSTALLATION 31
4-0 Driver Installation 31
4-1 RAID Installation 32
APPENDIX 1 - POST CODES 33
Quick Debug POST Codes 33
Boot Block POST Codes 34
APPENDIX 2 - TRADEMARKS AND NOTICES 35
Copyrights, Trademarks, and Notices 35
FCC Compliance Statement 35
APPENDIX 3 - WARRANTY INFORMATION 36
37APPENDIX 4 - CONTACTING SUPPORT AND OTHER USEFUL INFORMATION

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 4
Chapter 1
Introduction of nForce4Motherboards
1-1 Motherboard Features
Motherboards based on NVIDIA nForce4 single chip technology support the
innovative 64-bit AMD Athlon64 FX and dual core multi-tasking Athlon64 X2
processors with HyperTransport Technology. The motherboard delivers leading-
edge performance with both of the benefits from 64-bit multi-tasking dual core
AMD processors and NVIDIA Scalable Link Interface (SLI) Technology.
Utilizing the 64-bit multi-tasking socket 939 solution and the dual channel
PC3200 DDR memory size expandable to 4.0GB, this motherboard series meets
the demands of computing in the future.
These motherboards carry the advanced NVIDIA nForce4 single chip with
1000 MHz HyperTransport system bus of data transferring and provided with
133MHz / 166MHz / 200MHz memory clock frequency for DDR266/DDR333/
DDR400 DDR Module with dual channel capability. The NVIDIA nForce4 single
chipset offers ULTRA ATA 133 and Serial ATA RAID 0, 1, 0+1 functions to
accelerate hard disk drives and guarantee data security without failure in
advanced computing applications.
The motherboard provides Gigabit LAN by using the NVIDIA Giga-LAN
controller which supports 10M/100M/1Gbps data transfer rate and full duplex or
half duplex transportation. The embedded 8-channel AC’97 CODEC is fully
compatible with Sound Blaster ProTM standards and offers you home cinema
quality and complete software compatibility.
Two 8X PCI-Express graphics slots deliver up to 2Gbyte/sec data transfer rate
at each relative direction which is fully compatible with the latest NVIDIA SLI
Technology. And, one PCI-Express x16 slot offers full function at speeds of up
to 4Gbyte/sec.
The embedded USB controller has the capability of supporting up to 8 USB 2.0
ports, delivering 480Mb/s bandwidth each.
And the embedded Firewire controller allows connection and use of IEE1394
compliant devices.

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 5
1-1.1 Special Features of the Motherboard
CPU Thermal Throttling Technology
To prevent increasing heat from damaging the CPU or causing accidental
shutdown while under high workloads, the CPU Thermal Throttling Technology
will force the CPU to enter an idle mode from 87.5% to 12.5% according to
preset CPU operating temperatures in the BIOS (from 40○to 90○). When the
system senses the CPU operating temperature reaching the preset value, the
CPU operating bandwidth will be decreased to the preset idle percentage
allowing the processor to cool down. When in throttling mode, a beeper sound
can be optionally selected to indicate it has reduced the CPU performance. (for
detailed settings, please read the BIOS PDF located on the CD)

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 6
Spec Description
Design ATX form factor 4 layers PCB size: 24.5x24.5 cm
Chipset NVIDIA nForce4 SLI Technology
CPU Socket 939
Supports 64bit AMD Athlon64 939-Pin package processors
Support up to 4000+ processor & Dual –Core, Including:
Athlon FX 64/64 X2/64/and 939 Sempron
Memory Sockets 184-pin DDR Module socket x 4
Support 4pcs DDR266/DDR33/DDR400 DDR Modules Expandable to 4.0GB
Support Dual channel function
Expansion Slots PCI-Express x16 slot x 1
PCI-Express x8 slot x 2
32 bit PCI slots x 1
Integrated IDE and
Serial ATA II RAID
One PCI IDE controller supporting PCI Bus Mastering, ATA PIO/DMA and the
ULTRA DMA 33/66/100/133 functions that deliver the data transfer rate up to
133 MB/s; Four Serial ATA II ports provide 300 MB/sec data transfer rate for
Four Serial ATA Devices and offer RAID 0, 1, 0+1 functions
LAN Integrated Gigabit LAN provides 10Mb/100Mb/1Gb /s data transfer rates
8CH-Audio 8-channel AC’97 Digital Audio controller integrated
Audio driver and utility included
SPDIF-Out Optical support (Cable optional)
BIOS Award 4MB Flash ROM
Multi I/O PS/2 keyboard and PS/2 mouse connectors
Floppy disk drive connector x1
Parallel port x1
Serial port x1
USB2.0 port x 4 and headers x 4 (connecting cable optional)
Audio connector (Line-in, Line-out, MIC/ 8CH Audio)
IEEE 1394 Firewire Support
Game Port Connector
1-2 Specifications

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 7
1-3 Layout Diagram & Jumper Settings
SURRBACK
LINE IN
CEN/LFE
LINE OUT
SURROUND
MIC-IN
GIGA LAN + USB 2
FIREWIRE + USB 1
PRINTER
DIGITAL AUDIO
OUT COM 1
PS/2 MOUSE
PS/2 KEYBOARD
FRONT PANEL AUDIO CD AUDIO IN IR HEADER
PCI EXPRESS SLOTS
SYSFAN 2
JP9
USB 1
JBAT
USB 2
SYSFAN 1
PLED SPEAKER
FRONT PANEL CONNECTOR
SERIAL ATA
CONNECTORS
ICE CONNECTOR
FLOPPY CONNECTOR
ATX POWER
CONNECTOR
DIMM SOCKETS
CPU SOCKETCPU FAN
ATX 12V CONNECTOR
GAME PORT
FAN 5
SUPPLEMENTAL
SLI POWER
SLI MODE
JUMPERS
PCI SLOT
FIREWIRE HEADER

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 8
Jumper Name Description
JBAT CMOS ROM Clear 3-pin Block
JP1 Keyboard/USB0,1 Power On
Enabled/Disabled
3-pin Block
JP9 USB Power On Enabled/Disabled 3-pin Block
JP2, JP3, JP4, JP5, JP6,
JP7, JP8
SLI Selection Mode Jumpers 3-pin Block
Connector Name Description
ATXPWR ATX Power Connector 24-pin Block
ATX12V ATX 12V Power Connector 4-pin Block
KB PS/2 Mouse & PS/2 Keyboard Connector 6-pin Female
CN1 Fire Wire and USB Port Connectors 1x Fire Wire/2x USB
PARALLEL Parallel Port Connector 25-pin Female
CN3 8-CH Audio Connector 6 jack Connector
COM1 Serial Port COM1 Connector 9-pin Connector
FDD Floppy Driver Connector 34-pin Block
IDE1 Primary IDE Connector 40-pin Block
SATA1~4 Serial ATA IDE Connector 7-pin Connector
SPDIF_RX1~1 SPDIF Outputs TOSLINK and RCA
J1 Supplemental SLI Power Connector 4-pin Molex Type
UL1 GIGALAN and USB Port Connectors RJ-45 Connector/2x USB
Header Name Description
AUDIO SPEAKER, MIC header 9-pin Block
USB1~2 USB Port Headers 9-pin Block
SPEAK1 PC Speaker connector 4-pin Block
PWR LED Power LED 3-pin Block
JW_FP
(Power LED/Reset/
IDE LED/Power
Button)
Front Panel Header
(including Power LED/ IDE activity
LED/Reset switch / Power On Button
lead)
9-pin Block
CHAFAN, SYSFAN1~2,
CPUFAN, FAN5
FAN Headers 3-pin Block
CDIN CD Audio-In Header 4-pin Block
IR Ir Header 5-pin Block
GAME1 Game Port Header 15-pin Block
IEEE1 Firewire Header 9-pin Block
1-3.1 JUMPERS, CONNECTORS, HEADERS, AND SOCKETS

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 9
Socket/Slot Name Description
ZIF Socket 939 CPU Socket 939-pin mPGAB Athlon64 CPU Socket
DIMM1~4 DDR Module Socket 184-pin DDR Module Socket
PCI1 PCI Slot 32-bit PCI Local Bus Expansion slots
PE1, PE3 PCI-Express x8 Slot PCI-Express x8 Expansion Slot
PE2 PCI-Express x16 Slot PCI-Express x16 Expansion Slot
1-3.1 JUMPERS, CONNECTORS, HEADERS, AND SOCKETS CONT.

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 10
Chapter 2
Hardware Installation
2-1 Hardware Installation Steps
Before using your computer, please complete the following steps:
1. Check motherboard jumper settings
2. Install CPU and Fan
3. Install System Memory (DIMM)
4. Install Expansion cards
5. Connect IDE and Floppy cables, Front /Back Panel cables
6. Connect ATX Power cable
7. Power-On and Load Standard Default BIOS Settings
8. Reboot
9. Install Operating System
10. Install Motherboard Drivers and Utilities
2-2 Checking the Motherboard’s Jumper Settings
CMOS RAM Clear (3-pin) : JBAT
A battery must be used to retain the motherboard configuration in CMOS RAM
short 1-2 pins of JBAT to store the CMOS data.
To clear the CMOS, follow the procedure below:
1. Turn off the system and unplug the AC power
2. Remove the ATX power cable from the ATX power connector
3. Locate JBAT and short pins 2-3 for a few seconds
4. Return JBAT to its normal setting by shorting pins 1-2
5. Connect the ATX power cable back to the ATX power connector
CMOS RAM Clear Setting
2-3 closed Clear CMOS
JBAT
13
JBAT
13
1-2 closed Normal

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 11
Keyboard Function Enabled/Disabled: JP1
USB Power On function Enabled/Disabled: JP9
2-3 Install CPU
2-3-1 Glossary
Chipset (or core logic) - one or more integrated circuits which control the
interfaces between the system processor, RAM, I/O devises, and adapter
cards.
Processor slot/socket - the slot or socket used to mount the system processor
on the motherboard.
Slot (PCI-E, PCI, RAM) - the slots used to mount adapter cards and system
RAM.
PCI - Peripheral Component Interconnect - a high speed interface for video
cards, sound cards, network interface cards, and modems; runs at 33MHz.
PCI-Express- Peripheral Component Interconnect Express- a high speed
interface for video cards, sound cards, network interface cards, and modems.
Serial Port - a low speed interface typically used for mouse and external
modems.
Parallel Port - a low speed interface typically used for printers.
PS/2 - a low speed interface used for mouse and keyboards.
Keyboard/Mouse & USB Power On Setting
2-3 closed
KB/USB Power ON Enabled
JP1
1
3
JP1
1
3
1-2 closed
KB/USB Power ON Disable (Default)
USB2/USB3 Power On Setting
2-3 closed USB Power On Enabled
JP3
13
JP3
13
1-2 closed USB Power On Disable
(Default)

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 12
USB - Universal Serial Bus - a medium speed interface typically used for
mouse, keyboards, scanners, and some digital cameras.
Sound (interface) - the interface between the sound card or integrated sound
connectors and speakers, MIC, game controllers, and MIDI sound devices.
LAN (interface) - Local Area Network - the interface to your local area network.
BIOS (Basic Input/Output System) - the program logic used to boot up a
computer and establish the relationship between the various components.
Driver - software, which defines the characteristics of a device for use
by another device or other software.
Processor - the "central processing unit" (CPU); the principal integrated circuit
used for doing the "computing" in "personal computer".
Front Side Bus Frequency - the working frequency of the motherboard, which
is generated by the clock generator for CPU, DRAM and PCI BUS.
CPU L2 Cache - the flash memory inside the CPU, normal it depend on CPU
type.
2-3-2 About AMD Athlon64 939-pin CPUs
This motherboard provides a 939-pin surface mount, Zero Insertion Force (ZIF)
socket, referred to as the mPGA939 socket supporting AMD Athlon64
processors in the 939 Pin package utilizing Flip-Chip Pin Grid Array
technology.
The CPU that you use with the motherboard should have a cooling FAN
attached to prevent overheating. If this is not the case, then purchase the
correct cooling FAN before you turn on your system.
CPU ZIF mPGAB Socket
Golden Arrow
Socket 939
WARNING! Be sure that there is sufficient air circulation across
the processor’s heatsink and CPU cooling FAN is
working correctly, otherwise it may cause the
processor and motherboard to overheat and
damage your system, you may install an auxiliary
cooling FAN, if necessary.

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 13
To install a CPU, locate the ZIF socket and open it by first pulling the lever
sideways away from the socket then upward to a 90-degree angle. Insert the
CPU with the correct orientation as shown on the previous page. The notched
corner should point toward the end of the lever. Because the CPU has a corner
pin for two of the four corners, the CPU will only fit in the orientation as shown.
When you put the CPU into the ZIF socket. No force is required to insert the
CPU. Press the lever to Locate position slightly without any extra force.
2-4 Install Memory
This motherboard provides four 184-pin DDR DUAL INLINE MEMORY
MODULES (DIMM) slots for DDR memory expansion available from minimum
memory size of 64MB to maximum memory size of 4.0GB DDR SDRAM.
Valid Memory Configurations
Generally, installing DDR SDRAM modules to your motherboard is very easy,
you can refer to the following page to see what a 184-Pin DDR266/DDR333/
DDR400 DDR SDRAM module looks like.
Bank 184-Pin DIMM PCS Total Memory
Bank 0, 1 (DIMM1) DDRDDR266/DDR333/DDR400
DDR SDRAM Module X1 128MB~1.0GB
Bank 2, 3 (DIMM2) DDRDDR266/DDR333/DDR400
DDR SDRAM Module X1 128MB~1.0GB
Bank 4, 5 (DIMM3) DDRDDR266/DDR333/DDR400
DDR SDRAM Module X1 128MB~1.0GB
Bank 6,7 (DIMM4) DDRDDR266/DDR333/DDR400
DDR SDRAM Module X1 128MB~1.0GB
Total System Memory (Max. 4.0GB) 4 128MB~4.0GB
For Dual Channel Memory
Dual channel only operates when 2 DIMM Modules are plugged into either
DIMM1 & DIMM3 or DIMM2 & DIMM4, or four DIMM Modules are
plugged into DIMM1~DIMM4.
DIMM1 & DIMM3, or DIMM2 & DIMM4 must be the same type, same size, and
same frequency for dual channel to function.
Note: Computer will not boot if RAM is in 3 and 4 only.

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 14
DIMM3(BANK2+BANK3)
DIMM4(BANK0+BANK1)
DIMM1(BANK6+BANK7)
DIMM2(BANK4+BANK5)
DIMM1 & DIMM3: Dual Channel 1
DIMM2 & DIMM4: Dual Channel 2
NOTE! When you install the DIMM modules fully into the DIMM
socket the eject tab should be locked into the DIMM
module very firmly and fit into its indention on both sides.
WARNING! When the DDR SDRAM CLOCK is set at 200MHz, use only
DDR400 compliant DDR Modules. When this motherboard
operates at 200Mhz, most systems will not even boot if
non-compliant modules are used because of the strict
timing issues involved, if your DDR Modules are not
DDR400-compliant, set the SDRAM clock to 133MHz to
ensure system stability.

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 15
2-5 Expansion Cards
WARNING! Turn off your system power when adding or removing
expansion cards or other system components. Failure
to do so may cause severe damage to both your
motherboard and expansion cards.
2-5-1 Procedure For Expansion Card Installation
Read the documentation for your expansion card and make any necessary
hardware or software setting for your expansion card such as jumpers.
Remove your computer’s cover and the bracket plate on the slot you intend to
use.
• Align the card’s connectors and press firmly.
• Secure the card on the slot with the screen you remove above.
• Replace the computer system’s cover.
• Set up the BIOS if necessary.
• Install the necessary software driver for your expansion card.
2-5-2 Assigning IRQs For Expansion Card
Some expansion cards need an IRQ to operate. Generally, an IRQ must be
exclusively assigned. In a standard design, there are 16 IRQs available but
most of them are already in use. The following table will show you the default
assignment of IRQs.
If should be noted that in most modern Plug and Play Operating Systems, that
IRQ assignment is handled by the computer itself automatically. This automatic
assignment is generally very effective and you should only have to resort to
manual assignment in the most extreme cases.

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 16
2-5-3 Interrupt Request Table For This Motherboard
Interrupt requests are shared as shown in the table below:
INT A INT B INT C INT D INT E INT F INT G INT H
Slot 1 X
Slot 2 X
Slot 3 X
Onboard USB 1 X
Onboard USB 2 X
AC97/MC97 X
IMPORTANT! If using PCI cards on shared slots, make sure that
the drivers support “Shared IRQ” or that the cards
don’t need IRQ assignments. Conflicts will arise
between the two PCI groups that will make the
system unstable or cards inoperable.
2-5-4 PCI-Express Slots
This motherboard provides three PCI-Express slots intended for Graphics (Two
symmetrical PCI-Express x8 graphics slots deliver up to 2Gbyte/sec data
transfer rate at each relative direction which is fully compatible with the latest
NVIDIA SLI Technology [SLI version only]. And one x16 PCI-Express Slot
intended for single video card solutions. Fully compliant to the PCI-Express
Base Specification revision 1.0a , supporting PCI-Express VGA cards, and
other PCI-Express devices.
FROM TOP TO BOTTOM
8x PCI-E (In 16X slot, for SLI)
16x PCI-E
8x PCI-E (In 16X slot, for SLI)

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 17
Standard Interrupt Assignments
IRQ Priority Standard function
0 N/A SystemTimer
1 N/A Keyboard Controller
2 N/A Programmable Interrupt
3 * 8 Communications Port (COM2)
4 * 9 Communications Port (COM1)
5 * 6 Sound Card (sometimes LPT2)
6 * 11 Floppy Disk Controller
7 * 7 Printer Port (LPT1)
8 N/A System CMOS/Real Time Clock
9 * 10 ACPI Mode when enabled
10 * 3 IRQ Holder for PCI Steering
11 * 2 IRQ Holder for PCI Steering
12 * 4 PS/2 Compatible Mouse Port
13 N/A Numeric Data Processor
14 * 5 Primary IDE Channel
15 * 1 Secondary IDE Channel
* These IRQs are usually available for PCI devices.

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 18
2-5-5 SLI Bridge for NVIDIA SLI Supported VGA Cards
In order to activate the NVIDIA SLI technology (SLI version only), you have to
install the included SLI Bridge for your NVIDIA SLI Supported VGA Cards
before you can activate the advanced multi-GPU functions.
STEP 1 - Install your NVIDIA SLI Supported VGA Cards in the PCI-E x8 slots
located on the left and right, leaving the center PCI-E slot vacant.
STEP 2 - Prepare to install the SLI Bridge with your NVIDIA SLI Supported
VGA Cards

EVGA Corporation 2900 Saturn St. Suite B, Brea, CA 92821
Phone: 888 / 881-EVGA - 714 / 528-4500 - Fax: 714 / 528-4501
Page 19
STEP 3 - Be careful with the pins as to not damage the adapter or graphics
cards during installation.
STEP 4 - Plug the SLI Bridge adapter onto both of the NVIDIA SLI Supported
VGA Cards
