EVGA P67 FTW User manual

User Guide
EVGA P67 FTW
Motherboard

EVGA P67 FTW Motherboard
2

EVGA P67 FTW Motherboard
3
Table of Contents
User Guide ....................................................................................................................1
EVGA P67 FTW Motherboard.......................................................................................1
Before You Begin… ......................................................................................................6
Parts NOT in the Kit ................................................................................................. 7
Intentions of the Kit .................................................................................................. 7
EVGA P67 FTW Motherboard.......................................................................................8
Motherboard Specifications...................................................................................... 8
Unpacking and Parts Descriptions ..............................................................................10
Unpacking .............................................................................................................. 10
Equipment .............................................................................................................. 10
EVGA P67 FTW Motherboard................................................................................ 12
Hardware Installation ..................................................................................................15
Safety Instructions.................................................................................................. 15
Preparing the Motherboard .................................................................................... 16
Installing the CPU .............................................................................................. 16
Installing the CPU Fan ....................................................................................... 17
Installing System Memory (DIMMs) ................................................................... 18
Installing the Motherboard...................................................................................... 19
Installing the I/O Shield ...................................................................................... 19
Securing the Motherboard into the chassis........................................................ 20
Connecting Cables................................................................................................. 20
24-pin ATX Power (PW1)............................................................................... 21
8-pin ATX 12V Power (PW12) ....................................................................... 22

EVGA P67 FTW Motherboard
4
Bios Select Jumper ............................................................................................ 22
Connecting SATA Cables .................................................................................. 23
Connecting Internal Headers ............................................................................. 24
Front Panel Header ........................................................................................ 24
IEEE1394a (Firewire)..................................................................................... 25
USB Headers ................................................................................................. 26
Audio Header ................................................................................................. 27
Fan Connections ................................................................................................ 28
Expansion Slots ................................................................................................. 29
PCI-E x1 Slots ................................................................................................ 30
PCI-E x16/x8 Slots ......................................................................................... 30
Onboard Buttons .................................................................................................... 31
Clear CMOS Button ....................................................................................... 31
RESET and POWER Button .......................................................................... 31
Post Port Debug LED and LED Status Indicators.................................................. 32
Post Port Debug LED..................................................................................... 32
LED Status Indicators .................................................................................... 32
Installing Drivers and Software ..................................................................................33
Windows XP/Vista/7 Driver Installation.................................................................. 33
Appendix A. POST Codes...........................................................................................34
EVGA Glossary of Terms............................................................................................39
Compliance Information ..............................................................................................42

EVGA P67 FTW Motherboard
5
List of Figures
Figure 1. EVGA P67 FTW Motherboard Layout.................................................... 15
Figure 2. Chassis Back Panel Connectors............................................................ 14
Figure 3. PW1 Motherboard Connector ................................................................ 21

EVGA P67 FTW Motherboard
6
Before You Begin…
Thank you for purchasing the EVGA P67 FTW Motherboard. This board is based off
of the ne Intel P67 chipset ith native support for SATA III/6G for the performance
you demand, delivered hen you need it.
As al ays this board comes ith the added bonus of EVGA’s industry leading 24/7
technical support in case you ever have any issues or questions.

EVGA P67 FTW Motherboard
7
Parts NOT in the Kit
This kit contains all the hard are necessary to install and connect your ne
EVGA P67 FTW Motherboard. Ho ever, it does not contain the follo ing
items that must be purchased separately to make the motherboard functional.
 Intel Socket 1155 Processor
 DDR3 System Memory
 Socket 775 or 1155/1156 CPU cooler for the processor
 PCI Express raphics Card
 Power Supply
EVGA assumes you have purchased all the necessary parts needed to allo for
proper system functionality. For a full list of supported CPU’s on this
motherboard, please visit http:// .evga.com/support/motherboard/.
Intentions of the Kit
This kit provides you ith the motherboard and all connecting cables necessary
to install the motherboard into a PC case. If you are building a PC, you ill use
most of the cables provided in the kit. If ho ever, you are replacing a
motherboard, you ill not need many of the cables.
When replacing a motherboard in a PC case, you ill need to reinstall an
operating system even though the current Hard Disk Drive may already have
one installed.

EVGA P67 FTW Motherboard
8
EVGA P67 FTW
Motherboard
Motherboard Specifications
 Size
EATX form factor of 12 inches x 10.3 inches
 Microprocessor support
Intel Socket 1155 Processor
 Operating systems:
Supports Windo s XP/Vista/7 32 and 64 bit
 Contains Intel P67 chipset
 System Memory support
Supports Dual channel DDR3-1333+. Officially supports up to 16GBs of
DDR3 memory.
 USB 2.0 Ports
Supports hot plug
Ten USB 2.0 ports (Six rear panel ports, four via onboard USB header)
Supports ake-up from S1 and S3 mode
Supports USB 2.0 protocol up to a 480 Mbps transmission rate
 USB 3.0 Ports
Four USB 3.0 ports (T o rear panel ports, t o via onboard USB header)
Back ards compatible USB 2.0 and USB 1.1 support
Supports transfer speeds up to 5Gbps

EVGA P67 FTW Motherboard
9
 Six (6) onboard SATA ports up to 3.0 Gb/s (300 M/s)
data transfer rate
T o (2) SATA ports up to 6.0 Gb/s (600 M/s) data transfer rate
Six SATA ports from P67Chipset support for RAID 0, RAID 1, RAID 0+1,
RAID5 and RAID 10
T o ESATA supports 3.0 Gb/s (on I/O panel)
 Onboard LAN
Integrated Dual LAN ports
Supports 10/100/1000 Mbit/sec Ethernet
 Onboard IEEE 1394a (Fire ire)
Supports hot plug
T o IEEE 1394a ports (one rear panel port, one onboard header) ith a
rate transmission of 400 Mbps
 Onboard Audio
Realtek High-Definition audio
Supports 8-channel audio
Supports Jack-Sensing function
 PCI-E Support
Six (6) PCI-E 2.0 Slots
Lo po er consumption and po er management features
 Green Function
Supports ACPI (Advanced Configuration and Po er Interface)
Supports S0 (normal), S1 (po er on suspend), S3 (suspend to RAM), S4
(Suspend to disk - depends on OS), and S5 (soft - off)
 Expansion Slots
T o PCI-E x1 slots
Five PCI-E x8/x16 slots

EVGA P67 FTW Motherboard
10
Unpacking and
Parts Descriptions
Unpacking
The EVGA P67 FTW Motherboard comes ith all the necessary cables for
adding a motherboard to a system case. If replacing a motherboard, you may
not need many of these cables.
Equipment
The follo ing accessories are included ith the EVGA P67 FTW Motherboard:
The EVGA P67 FTW Motherboard
This PCI-E motherboard contains the Intel P67 chipset and is
LI-ready for 2 or 3-way LI configurations.
1 - Visual Guide
Helps to quickly and visually guide you through the hardware
installation of the motherboard.
1 - I/O Shield
Installs in the system case to block radio frequency
transmissions, protect internal components from dust, foreign
objects, and aids in proper airflow within the chassis.

EVGA P67 FTW Motherboard
11
1 – I/O Shield Fan
Exhausts Air from the IO hield out of the rear of the case.
Attaches to IO hield.
2 - -Port SATA Power Cables
Allows a Molex power connector to adapt to a ATA power
connector.
1 - -Port USB .0 / 1394a Firewire Bracket
Provides two additional U B ports and 1 additional 1394a
Firewire port to the back panels of the chassis.
1 – -Port USB 3.0 Bracket
Allows Addition of 2 U B 3.0 ports by Connecting to the
motherboard header.
2 – SATA II/3G Data Cables
Used to support the ATA protocol and each one connects a
single drive to the motherboard.
2 – SATA III/6G Data Cables
Used to support the ATAIII/6G high speed protocol and each
one connects a single drive to the motherboard.
1 - 3-way SLI Bridge
Bridges three (3) graphics cards together which allows for
3-way LI.
1 - -way SLI Bridge
Bridges two (2) graphics cards together which allows for
2-way LI.

EVGA P67 FTW Motherboard
12
1 – EVGauge (Optional)
Analog Gauge that represents your CPU frequency in real time.
1 – ECP Panel (Optional)
Allows monitoring of post codes and remote control of PCIe
slot disable, voltages and CMO reset all on one bay mounted
panel.
1 - Installation CD
Contains drivers and software needed to setup the
motherboard.
1 – User Manual
Contains Information needed to properly install and configure
your EVGA Motherboard.
EVGA P67 FTW
Motherboard
The EVGA P67 FTW Motherboard ith the Intel P67 chipset is an SLI-ready
motherboard. Figure 1 sho s the motherboard and Figure 2 sho s the back
panel connectors.

EVGA P67 FTW Motherboard
13
1. CPU ocket 1155 11. IEEE 1394a Connector 21. CPU Fan Connector
2. Intel P67 Chipset 12. U B Headers 22. 8-pin ATX_12V Power Connector
3. DDR3 DIMM lots 1 – 4 13. Clear CMO Button 23. BIO Chip election witch
4. Fan Connectors 14. Power Button 24. U B 3.0 Header
5. 24-Pin ATX Power Connector 15. Reset Button 25. EVGauge Connector
6. Motherboard Battery 16. PC peaker 26. upplementary PCI-E power connector
7. ATA III connectors 17. PCI-E 2.0 lot 27. X-Cool Jumper
8. ATA II Connectors 18. PCI-E x1 lot 28. Compact Flash port
9. Debug LED Display - CPU Temperature
Monitor
19. Front Panel Audio Connector/ PDIF
Connector
10. Front Panel Connector 20. Back Panel Connectors (Figure 2)
Figure 1. EVGA P67 FTW Motherboard Layout
1
10
5
24
1
7
18
18
20
1
7
1
4
1
3
17
4
21
17
2
1
1
1
2
16
9
4
4
3
6
19
1
5
23
17
22
7
8
4
4
4
25
26
27
28

EVGA P67 FTW Motherboard
14
1. Clear CMO Button
2. IEEE 1394a (Firewire) Port
3. U B 2.0 ports (six)
4. E ATA ports
5. U B 3.0 ports (two)
6. Dual LAN Ports with LEDs to indicate status:
7. Audio Port 2-Channel 6-Channel 8-Channel________
Blue Line-In Line-In Line-In
Green Line-Out Front peaker Out Front peaker Out
Pink Mic In Mic In Mic In
Orange Center/Subwoofer Center/ ubwoofer
Black Rear peaker Out Rear peaker Out
Grey Side Speaker Out
Figure 2. Chassis Back Panel Connectors
3
3
1
4
5
2
6
Activity LED Status Description
Off No data transmission
Blinking (Green) Data transmission
Speed/Link LED Status Description
Yellow 1000 Mbps data rate
Green 100 Mbps data rate
Off 10 Mbps data rate
7
6
3

EVGA P67 FTW Motherboard
15
Hardware Installation
This section ill guide you through the installation of the motherboard. The
topics covered in this section are:
 Preparing the motherboard
 Installing the CPU
 Installing the CPU fan
 Installing the memory
 Installing the motherboard
 Connecting cables
Safety Instructions
To reduce the risk of fire, electric shock, and injury, always follow basic
safety precautions.
Remember to remove power from your computer by disconnecting the
AC main source before removing or installing any equipment from/to the
computer chassis.

EVGA P67 FTW Motherboard
16
Preparing the Motherboard
Installing the CPU
Be very careful hen handling the CPU. Hold
the processor only by the edges and do not
touch the bottom of the processor.
Use the follo ing procedure to install the CPU
onto the motherboard:
Unhook the socket lever by pushing down and
away from the socket.
Pull the socket lever back and the load plate ill
automatically lift. There is a protective
socket cover ithin the CPU socket to
protect the socket hen there is no CPU
installed.
Remove the protective socket cover from the
CPU Socket.
Note: After removing the CPU socket cover, it is recommended that you keep it
in case you need to remove the CPU so for any reason you can replace
the cover to avoid damaging the CPU socket pins.

EVGA P67 FTW Motherboard
17
Align the notches in the processor ith the
notches on the socket.
Lo er the processor straight do n into the socket
ith out tilting or sliding it into the socket.
Note: Make sure the CPU is fully seated and level in
the socket.
Close the load plate over the CPU and press
do n hile you close and engage the
socket lever.
The CPU installation is complete.
Installing the CPU Fan
There are many different fan types that can be used ith this motherboard.
Follo the instruction that came ith your fan assembly. Be sure that the fan
orientation is correct for your chassis type and your fan assembly.
Please note that there are 2 sets of mounting holes, there are holes to be used
for Socket 1156 and 1155 heatsinks and are labeled. The other holes are to be
used for Socket 775 heatsinks.
In most cases, the Socket 1156/1155 mounting holes ill be used.
Align notches with notches on the CPU

EVGA P67 FTW Motherboard
18
Installing System Memory (DIMMs)
Your ne motherboard has four 240-pin slots for DDR3 memory. These slots
support 1GB, 2GB and 4GB DDR3 DIMMs. There must be at least one
memory slot populated to ensure normal operation. Use the follo ing the
recommendations for installing memory. (See Figure 1 on page 13 for the
location of the memory slots.)
 One DIMM: If using 1 DIMM (Single Channel), install into: DIMM slot 1.
 Two or Four DIMMs: If using 2 DIMMs (Dual Channel), install into:
DIMM slots 1 and 3. If using 4 DIMMs (Dual Channel), install into:
DIMM slots 1, 2, 3, and 4.
Use the follo ing procedure to install DIMMs. Note that there is only one gap
near the center of the DIMM slot. This slot matches the slot on the DIMM to
ensure the component is installed properly.
1. Unlock a DIMM slot by pressing the module clips out ard.
Align the memory module to the DIMM slot, and insert the module vertically
into the DIMM slot. The plastic clips at both sides of the DIMM slot
automatically lock the DIMM into the connector.
DIMM Slot 1
DIMM Slot
DIMM Slot 3
DIMM Slot 4

EVGA P67 FTW Motherboard
19
Installing the Motherboard
The sequence of installing the motherboard into a system case depends on the
chassis you are using and if you are replacing an existing motherboard or
orking ith an empty system case. Determine if it ould be easier to make all
the connections prior to this step or to secure the motherboard and then make
all the connections. It is normally easier to secure the motherboard first.
Use the follo ing procedure to install the I/O shield and secure the
motherboard into the chassis.
Note: Be sure that the CPU fan assembly has enough clearance for the system
case covers to lock into place and for the expansion cards. Also make sure
the CPU Fan assembly is aligned with the vents on the covers. This will
depend on the system case being used.
Installing the I/O Shield
The motherboard kit comes ith an I/O shield that is used to block radio
frequency transmissions, protects internal components from dust and foreign
objects, and promotes correct airflo ithin the chassis.
Before installing the motherboard, install the I/O shield from the inside of the
chassis. Press the I/O shield into place and make sure it fits securely. If the
I/O shield does not fit into the chassis, you ould need to obtain the proper
size from the chassis supplier.
Also Note that for ease of installation you may ant to install I/O shield Fan
before installing into case.

EVGA P67 FTW Motherboard
20
Securing the Motherboard into a System Case
Most system cases have a base ith mounting studs or spacers to allo the
motherboard to be secured to the chassis and help to prevent short circuits. If
there are studs that do not align ith a mounting hole on the motherboard, it is
recommended that you remove that stud to prevent the possibility of a short
circuit. In most cases, it is recommended to secure the motherboard using a
minimum of nine (9) spacers and scre s.
1. Carefully place the motherboard onto the stand offs located inside the chassis.
2. Align the mounting holes ith the stand offs.
3. Align the connectors to the I/O shield.
4. Ensure that the fan assembly is aligned ith the chassis vents according to the fan
assembly instruction.
5. Secure the motherboard ith a recommended minimum of nine (9) scre s.
Connecting Cables
This section takes you through all the necessary connections on the
motherboard. This ill include:
 Po er Connections
24-pin ATX po er ( PW1 )
8-pin ATX 12V po er ( PW1 -1 & PW1 - )
 Internal Headers
Front Panel Header
IEEE 1394a Header
USB Headers
Audio Header
 SATA II
 SATA III
 Chassis Fans
 USB 2.0
