Eviant 4.3 Portable Digital TV User manual

M4
-
-

1
Introduction
Congratulations on purchasing your Eviant Portable Digital TV.
On June 12, 2009 the conversion to digital
television broadcasting will be complete all
throughout the United States and Puerto
Rico. Your portable digital television is
designed to pick up both the older analog
signals as well as the new digital signals.
Use your portable digital TV at work or take it on vacation and relax
with your favorite TV programs anywhere. Please read these
instructions carefully to get the most from your new Eviant digital TV.
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
WARNING: To reduce the risk of fire
or electric shock. DO NOT expose
this product to rain or moisture.

2
Important Safety Instructions
7) Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two blades
and a third grounding prong. The wide blade or the third prong
is provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the
obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused
for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the

3
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
15) Apparatus shall not be exposed to dripping or splashing and
no objects filled with liquids, such as vases, shall be placed on
the apparatus.
16) CAUTION: Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
17) Warning: the battery pack or batteries installed shall not be
exposed to excessive heat such as sunshine, fire or the like.
18) Install in accordance with the manufacturer’s instructions. Do
not use any cover over the TV, or enclose the AC/DC adapter,
with any objects like a cloth or box which blocks the vents.
This will cause the TV to overheat and present a fire hazard.
Always leave sufficient space around the product for
ventilation.
19) Apparatus does not have wall/ceiling mount function.
20) Warning: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
The MAINS plug or an appliance coupler is used as the disconnect
device, the disconnect device shall remain readily operable.
WARNING
The apparatus shall not be exposed to dripping or splashing and that
no objects filled with liquids, such as vases, shall be placed on the
apparatus.

4
Important Safety Instructions
CAUTION: These servicing instructions are for use by qualified
service personnel only. To reduce the risk of electric shock, do not
perform any servicing other than that contained in the operating
instructions unless you are qualified to do so.
Refer to service manual for servicing instructions. To reduce the risk
of fire or electric shock, do not expose this apparatus to rain or
moisture.
The images in this manual are only for reference and they may
be different from the actual ones.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
un-insulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric
to persons.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.

5
FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received,
including interference that may cause undesired
operation.
This equipment has been tested and found to comply with limits for
Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on. The user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna on the
affected receiver.
• Increase the separation between this device and the
receiver. Connect this device into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
This Class B digital apparatus complies with Canadian ICES-003.

6
Accessories
The Following Items Are Included With Your TV.
1. TV Unit
2. AC Adaptor
3. DC Adaptor
4. Telescoping Antenna
5. Soft carrying pouch
6. Documentation
NOTE: The Telescoping Antenna comes attached to the unit.
Table of Contents
Introduction
Important Safety Information .................................................. 1
FCC Compliance .................................................................... 5
Accessories ............................................................................ 5
Getting Started
Front View .............................................................................. 7
Side View................................................................................ 8
Top & Rear View..................................................................... 9
Antenna .................................................................................. 9
Using AC Adaptor .................................................................. 10
Using DC Adaptor.................................................................. 10
About Rechargeable Battery...................................................11
Connecting to Earphones .......................................................11

7
Display Options & Channel Setup
Scan Channel ........................................................................ 12
Display Setup ........................................................................ 13
Audio Setup ........................................................................... 13
System Menu......................................................................... 14
Service & Support
Troubleshooting..................................................................... 16
Specifications......................................................................... 17
Getting Started
Front View
1. LCD Screen

8
Side View
1. Power & Hold button
Power: Press and hold it to
turn off the unit; press it
once to turn on the unit.
Hold: press it to lock the
buttons.
2. DC 5V Power Jack
3. Headphone Jack
1. CH Up/Down (CH+/-,
also use as Up&
Down direction button)
2. Volume Up/Down
(VOL+/-, also use as
Left& Right direction
button)
3. OK
4. LCD (LCD setup)

9
Top & Rear View
1. Telescoping Antenna
(Removable)
2. Menu
1. Speaker
2. Stand
Getting Started
Antenna
The TV unit is supplied with a telescoping antenna that will provide
good reception in most situations. Be sure to keep the TV stationary
when trying to receive a signal. Any movement of the TV can result in
loss of the digital signal.
Note: You can also connect your own antenna cable connected to
any suitable TV antenna or cable system to improve reception.
Simply remove the telescoping antenna by positioning the antenna
vertical to the TV and gently pull up. Insert the external antenna plug
and position the antenna for best reception.

10
Using AC Adaptor
The TV unit is supplied with a 100~240v AC Power Adaptor for
charging the internal battery and for powering the unit. Plug the
adaptor into the wall socket and plug the small DC plug into the DC
jack adjacent to the power switch.
Using DC Adaptor
The TV unit is supplied with a Car Adaptor for charging the battery in
a vehicle.
To Use: Connect the car adaptor into the 5V cigarette lighter socket
in a vehicle.
Attention
 Do not operate the unit or view video software while driving a
vehicle.
 Place the unit in a proper position for viewing.
 Unplug the unit from the Car Adaptor when starting the
vehicle.

11
About Rechargeable Battery
Your portable TV device comes with a built-in rechargeable
Lithium-Ion battery. Charge the battery fully before initial use.
Charging time is normally about 3.5 hours. A fully charged battery
delivers about 3.5 hours of use.
When the battery is weak, an indication symbol will appear on the
LCD screen and the unit will power off automatically after a few
minutes.
Connecting to Earphones
You may connect stereo
earphones (not included) to
the headphone jack for
private listening.
When earphones are
connected, the speakers will
automatically turn off.
Caution:
Loud volume can damage your hearing.
Decrease the volume before connecting earphones, then raise the
volume back to a comfortable level.

12
Display Options & Channel Setup
Use the on-screen menus to adjust the scan channel, audio, display
and other functions.
Navigate the menus with the navigation buttons on the side view of
TV.
Press MENU to enter the setup modes. Press MENU again to go
back or exit the menu.
Scan Channel
Press the ◄►(VOL) buttons to select and select OK to enter.
The system would go to
auto search. Automatically
finds all digital channels
available through the built-in
antenna and stores all the
active channels found.
It will take for seconds to complete scanning as the on-screen
prompt appears. Press MENU to stop scanning and exit.
Note: Extend the antenna on the unit to its full length for
scanning.

13
Display Options & Channel Setup
Display Setup
Press the ◄►button to select and select OK to enter.
Press the ◄►button to select the desired sub-menu.
Select which screen aspect to use between Normal and Wide
Screen.
Display Options & Channel Setup
Audio Setup
Press the ◄►button to select and select OK to enter.
Press the ◄►button to select the desired sub-menu.
Note: The unit supports bilingual broadcast.

14
Display Options & Channel Setup
System Menu
Press the ◄►button to select and select OK to enter.
Press the ◄►button to select the desired sub-menu.
Time Zone Setup
Press the ▲▼(CH+/-) button to select desired time zone.
Parental Lock
The option allows you to set up specific channels and ratings
through blocking schemes.
Parental Guidelines
Blocking TV programs that
you or your family may not
wish to watch, based on the
rating scheme set.
Use◄►button repeatedly
to select a rating then press
OK.

15
General
Rating Description
TV-Y All Children.
TV-Y7 Directed toward children age 7 and older.
TV-G General Audience.
TV-PG Parental Guidance Suggested.
TV-14 Parents Strongly Cautioned.
TV-MA Mature Audience Only.
Note: The age limit meets FCC Standard.
Factory Reset
Press the ◄►button to select Factory Reset.
Press OK to enter the menu.
To reset all settings including channel settings to factory defaults,
press ◄►buttons to select “YES”
Caution: This will erase all settings and channel scans.
System Info.
Use this option to view the information about the system.

16
Troubleshooting
Before contacting customer service, review the steps below to solve
simple problems.
If you still suspect something wrong with this unit, immediately turn
the power off, disconnect the power connector from the unit, and
contact Eviant Customer Service.
Never try to repair the unit yourself.
Problem Possible Cause & Solution
The Power does
not turned on
Plug the power cord into the wall outlet
securely; The battery is discharged.
Recharge the battery.
No Sound Volume is turned down; Check audio setup.
No Display Check power switch and power adaptor
connection; Charge battery with power
adaptor
No Signal No broadcast signals in the area or signals
too weak; Check the signal strength and
adjust the antenna location and direction.
Other possibilities
Static or other external interference may cause the unit to function
abnormally. In order to reset normal status, turn off the unit and
unplug the power supply and try again. If the problem is still present,
turn off the unit, disconnect the power supply and consult a qualified
technician.

17
Specifications
TFT screen size .................................4.3 inches
Resolution ..........................................480 x 234
AC Power Adaptor..............................Input: 100-240v AC
50/60Hz 1A
....................................................Output: 5v DC 2A
Power Consumption...........................< 10 W
Dimensions (H, W, D).........................120mm x 78mm x 19.5mm
Weight ................................................ ~ 140g
Design and specifications are subject to change without notice.
All products distributed by Eviant Inc. unless otherwise indicated
Eviant ©2009QuattoManagementLimited.Eviant
1661 Fairplex Drive is a trademark and service mark of Quatto
La Verne, CA 91750 Management Limited. All other brand,
USA trademarks and service marks are property
Made in China of their owners.
www.eviant.com
We are seriously concerned about environmental protection, and we
hope that you share our concern as well. For more information
regarding our recycling program, please visit us at
http://www.eviant.com/green or call us at 1-866-935-4396.
