evosanitary 15WG15-15 User manual

1
MANUAL DE UTILIZARE / USER’S MANUAL
KIT RIDICARE PRESIUNE PANOURI SOLARE/
BOOSTER PUMP KIT FOR SOLAR PANEL
15WG15-15
www.honest.ro

2
RO_________________________________________________
Va multumim pentru achizitionarea acestui produs EVOSANITARY,
fabricat conform celor mai inalte standarde de siguranta si de
functionare.
Avertizare! Pentru siguranta dumneavoastra cititi cu atentie acest manual
si instructiunile generale de siguranta inaintea utilizarii echipamentului.
Nerespectarea acestor reguli poate avea ca rezultat producerea
electrocutarilor, a incendiilor si/sau a ranirilor personale.
Simboluri
Simbolurile utilizate in manual sau pe produs au urmatoarele semnificatii:
Masuri de siguranta generale pentru echipamentele electrice
Masuri de siguranta a echipamentului in exploatare
ATENTIE! Verificati intotdeauna ca tensiunea de alimentare sa corespunda cu
cea inscrisa pe placuta echipamentului.
Nu rasuciti cablul electric de alimentare al echipamentului
Nu transportati echipamentul tinandu-l de cablul electric si nu trageti de cablul electric pentru
a-l scoate din priza.
Tineti cablul electric de alimentare al echipamentuluila distanta fata de sursele de caldura, de
petele de ulei, de grasimi, de obiectele ascutite si sursele care emana caldura.
Verificati stecherul si cablul electric in mod regulat si in caz de deteriorare a acestora apelati
la un electrician autorizat.
Nu suprasolicitati pompa! Ea poate fi folosita in conditii de siguranta daca sunt respectati
parametrii de exploatare care o caracterizeaza. Nu utilizati unelte electrice cu un alt scop fata
de cel pentru care sunt destinate.

Service
Repararea trebuie realizata numai de catre personal autorizat prin inlocuirea cu accesorii si
piese de schimb originale pentru a se evita producerea accidentelor datorate reparatiilor
necorespunzatoare.
Masuri de siguranta specifice kitului de ridicare a presiunii
Nu este permisa functionarea pompei fara apa mai mult de 5 secunde.
Evitati folosirea pompei in conditii de temperaturi ale mediului ambiant mai ridicate de 40°C si
mai scazute de 0°C, sau functionarea cu apa la o temperatura mai mare de 110°C.

3
PERICOL DE INGHET! In situatia in care pompa ramane inactiva la temperaturi sub
0ºC,asigurati-va ca nu exista apa reziduala care poate ingheta si prin urmare poate distruge
componentele pompei.
Atunci cand pompa este utilizata pentru transportul apei dintr-un panou solar, o data cu apa
sunt absorbite si impuritati, de aceea este recomandata montarea unui filtru.
Atunci cand pompa este repornita dupa o lunga perioada de pauza, exista posibilitatea ca
motorul sa nu functioneze in conditiile unei porniri imediate datorate pastrarii si solidificarii
nisipului si a particulelor straine din apa in capul pompei.In acest caz decuplati pompa de la
sursa de alimentare cu energie electrica, dupa care rotiti de cateva ori axul din spate al
motorului ceea ce va ajuta sa reporniti si sa folositi pompa in exploatare ca de obicei.
Instalarea pompei trebuie efectuata de catre personal calificat.
Domeniu de utilizare.Meniude ilizare.
Pompa se instaleaza pe conducta de apa calda intre panoul solar si consumator cu scopul
de a ridica presiunea in instalatie. Este echipat cu un intrerupator automat controlat de
curgerea apei care, la deschiderea robinetului porneste pompa iar la inchiderea robinetului
opreste pompa.
NU ESTE PROIECTATA PENTRU UZ INDUSTRIAL.
ATENTIE ! Pompa este proiectata si construita pentru extragerea apei fara
continut de substante explozive , particule solide sau fibre,cu o densitate de
1kg/dmc si o viscozitate cinematica de 1mm² / s sau a lichidelor non-agresive
chimic.
Pregatire
Pregatirea pentru punerea in functiune
a pentru punerea in funct
ATENTIE! IN CAZUL IN CARE APAR ZGOMOTE ANORMALE IN FUNCTIONARE
OPRITI IMEDIAT ECHIPAMENTUL SI ADRESATI-VA UNUI SERVICE AUTORIZAT
PENTRU CONSTATARI SI REPARATII.
ATENTIE ! Deconectati alimentarea cu energie electrica inaintea inceperii oricarei
operatiuni de reglare sau intretinere
Verificare pompei inainte de instalare:
Instalati robinetul de inchidere cat mai aproape de pompa pentru o interventie facila in
cazul lucrarilor de verificare si reparare.
Se recomanda instalarea unei supape de sens inainte de aspiratia pompei.
Conexiune hidraulica
Se face utilizand tubulatura rigida sau flexibila din metal sau plastic.
La instalarea pompei trebuie sa se tina cont de directia de curgere indicata pe pompa si
pe intrerupatorul automat.
Intrerupatorul automat se va monta dupa pompa.
Circuitul de iesire din pompa nu trebuie sa prezinte pierderi hidraulice, in caz contrar
poate exista riscul pornirilor si opririlor repetate.
Este recomandata utilizarea unei tubulaturi cu un diametru interior cel putin egal cu cel al
pompei, pentru evitarea scaderii performantelor pompei si aparitiei colmatarii.
La montarea instalatiei solare nepresurizate, rezervorul panoului solar trebuie sa fie
amplasat deasuprea nivelului robinetului de consum al apei astfel incat, la deschiderea
acestuia, sa se asigure un debit minim care sa actioneze intrerupatorul si astfel sa fie
pornita pompa.
In situatiile in care debitul este prea mic pentru a realiza actionarea intrerupatorului
automat, dupa deschiderea robinetului se va trece intrerupatorul pe pozitia “manual”iar

4
dupa pornirea pompei se va reveni pe pozitia “automat”.
Conexiune electrica
Asigurati impamantare si masuri de protectie impotriva socurilor electrice. Pompa trebuie
amplasata astfel incat sa se evite patrunderea apei in interiorul ei.
Pornirea pompei:
Se alimenteaza electric pompa.
Se deschide robinetul de alimentare.
ATENTIE! In cazul supraincalzirii motorului pompa se opreste automat.Dupa racire
va porni din nou in mod automat, fara a fi necesara nici o interventie.
Curatare si intretinere
ATENTIE! Inainte de orice interventie asupra echipamentului, deconectati
alimentarea cu energie electrica de la retea.
Curatare
NU utilizati solventi (ca de exemplu : petrol si derivati, alcool) intrucat acestia pot deteriora
partile din plastic.
Intretinere
Echipamentul nostru a fost proiectat astfel incat sa poata fi utilizat pentru o perioada indelungata cu
un minimum de intretinere. Nu necesita nici un fel de ungere suplimentarara, datorita lubrifiantilor
long-life utilizati de producator pentru componentele in miscare.
Date tehnice
Putere
120W
Tensiune / Frecventa
220V/50Hz
Debit maxim
25 L/ min
Temperatura maxima apa
110°C
Inaltime maxima de pompare
15m
Racorduri intrare/iesire
3/4” / 3/4"
Turatie maxima
2860 rot/min
Condensator
5μF
Nivel zgomot
86 dB

5
Depozitare
Depozitati pompa intr-un spatiu inaccesibil copiilor intr-o pozitie stabila si sigura intr-un loc fara
praf sau supus vibratiilor, evitand temperaturile prea ridicate sau scazute.
Protejati pompa fata de actiunea directa a razelor solare si pastrati-o intr-un loc intunecos,
daca este posibil.
Garantie
Garantia acopera toate materialele componente si viciile de fabricatie cu exceptia,fara insa a fi
limitate la:
Componente uzate ca urmare a unei exploatari normale (perii colectoare, rulmenti, cabluri,
etc) sau accesorii ,
Defecte cauzate de o exploatare, intretinere si depozitare necorespunzatoare, modificari
neautorizate asupra echipamentului, costul transportului.
Pagube materiale si leziuni corporale rezultate in urma exploatarii necorespunzatoare a
echipamentului.
Deteriorari cauzate de lichide,patrundere excesiva de praf, distrugere intentionata , utilizare
inadecvata (pentru scopuri in care acest echipament nu este proiectat), etc..
DIAGRAMA DE FUNCTIONARE
EXEMPLU SCHEMA DE MONTAJ

6
EN_________________________________________________
Thank you for buying this EVOSANITARY product, manufactured
according to the highest safety and performance standards
WARNING! For your own safety, read this manual and the general safety
Instructions carefully before using the appliance. Your power tool
should only be given to other users together with these instructions.
Symbols
In this manual and/or on the machine the following symbols are used:
General power tools safety warnings
Electrical safety
Always check that the power supply corresponds to the voltage on the rating
plate.
Do not abuse the cord. Never use the cord for carrying, lifting or operating the pump
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
Check plug and power cord regularly and in case of damage call to a qualified personnel.
Do not overload the pump! It can be used safely if operating according to parameters. Do not
use power tools for a different purpose than the one for which they are intended.
Service
Your power tool should be serviced by a qualified specialist using only standard spare parts. This
will ensure that it meets the required safety standards.
Specific safety instructions for booster pump kitsubmersible pump
Never let pump run dry for more than 5 seconds.
Installation should be performed by qualified personnel.
Avoid using the pump in conditions of temperatures higher than 40 ° C and lower than 0 ° C
When the pump is fixed to transport water from a pool, with the water are absorbed also
impurities, so it is recommended to install a filter.
When the pump is restarted after a long break, is possible that the engine will not operate
immediate after start due to preservation and hardening sand and foreign particles from the
water in the pump head.In this case disconnect the power supply, then turn several times the
electrical motor spindle which will help to reboot and use the pump in operation as usual.
Danger of frost! When the pump remains inactive at temperatures below 0ºC, make sure
there is no residual water that can freeze and therefore destroy the pump component

7
When the pump is used to transport water from a solar panel, once with water also impurities
are absorbed, therefore is recommended to install a filter.
Application
The pump is installed on the hot water pipe between the collector and the consumer and is
intended to raise the pressure in the system. It is equipped with an automatic switch controlled by
water flow. At the valve opening the pump starts and stops at the valve closing.
IT IS NOT DESIGNED FOR PROFFESIONAL USE.
This pump is built up for pumping water, free from explosive substances,solid
particles and fibers, with a density of 1kg/dmc and a kinematic viscosity of
1mm² / s and chemically non-aggressive liquids.
Assembly
WARNING! In case of any abnormal noise, immediately turn off the tool and
contact an authorized service facility for repairs
Disconnect the power plug before carrying out any adjustments or maintenance.
Checking of the pump before installation
Install closing valve near to the pump for an easy intervention in the case of testing and
repairs.
It is recommended installation of backflow preventer valves before the pump inlet.
Hydraulic connectiom
Use rigid or flexible metal or plastic pipes
When installing the pump must pay attention the flow direction indicated on the pump.
Automatic switch will be installed after the pump.
Output circuit of the pump must not have hydraulic leaks, otherwise there may be risk of
repeated starting and stopping.
It is recommended to use a pipe with an inside diameter at least equal to the pump to avoid
clogging and pump performance decreasing.
When installing non-pressurized solar installation, solar panel tank must be located above
the tap in order to ensure a minimum flow to switch on the pump.
When the flow is too low to operate the main switch automatically, after opening the valve
move the switch to the "manual" and after the pump starting return to the "automatic".
Electrical connection
Provide grounding and protective measures against electric shock. The pump must be located
to avoid water penetration inside.
Starting the pump:
Plug the pump of the electrical network
Open the valve.
WARNING! When overheating pump stops automatically.After cooling will restart
automatically, without requiring any intervention.

8
Cleaning and maintenance
Before performing anywork on the equipment, pull the power plug.
Cleaning
Never use solvents such as petrol, alcohol, ammonia water, etc. These solvents may
damage the plastic parts.
Maintenance
Our machines have been designed to operate over a long period of time with a minimum of
maintenance.In normal operation the pump does not require any type of maintenance,thanks to the oil
bath lubricated seal and to the grease-for-life bearings.
Technical data
Power
120W
Voltage / Frequency
230V/50Hz
Maximum flow
25 L/ min
Liquid temperature range
110°C
Maximun height
15m
Connections Inlet/outlet
3/4" / 3/4 "
No load speed
2860 rpm
Capacitor
5μF
Noise level
86 dB
Storage
Store it out of the reach of children, in a stable and secure position,dust-free and avoid too
high and too low temperatures.
Protect it from exposure to direct sunlight. Keep it in the dark, if possible.
Warranty
This warranty covers all material or production flaws excluding:
Defective parts subject to normal wear & tear such as bearings, brushes, cables, and plugs,
or accessories;
damage or defects resulting from maltreatment, accidents or alterations; nor the cost
transportation.
We also disclaim all liability for any bodily injury resulting from inappropriate use of the
tool.
Definitely excluded from the warranty is damage resulting from fluid permeation, excessive
dust penetration, intentional damage (on purpose or by gross carelessness), inappropriate
usage (use for purposes for which the device is not suitable), incompetent usage (e.g. not
following the instructions given in the manual), inexpert assembly, lightning strike, erroneus
net voltage. This list is not exhaustive.
