evplug 20011 User manual
Page | 1 User manual for evplug Type 2 connector PN. EV20012 www.evplugchargers.com
TYPE 2 FEMALE CONNECTOR
ASSEMBLING PN.20011
Type 2 Mennekes IEC 62196-2
Features:
Charging plug meet: IEC 62196-2
Operating temperature: -30ºC to +50ºC
Excellent protection performance
Protection Grade IP65-Working condition.
Mechanical Properties
Mechanical life: no-load plug in / pull out >
10000times
Impact of external force: can afford 1m drop
and 2T vehicle run over pressure
Electric Performance
Rated Current and Voltage: as table
attached below
﹒Insulation Resistance: >1000MΩ (DC500V)
﹒Terminal Temperature Rise: < 50K
﹒Contact impedance: 0.5 mΩ Max
Warnings:
﹒Carefully read these instructions and
your vehicle owner’s handbook before
charging your EV.
Page | 2 User manual for evplug Type 2 connector PN. EV20012 www.evplugchargers.com
﹒Use only on the mains with fault
current circuit breaker.
﹒DO not use this product if the cable is
damaged.
﹒The product must be grounded.
﹒DO not use this unit with an extension
cord or adapter.
﹒DO not insert any fingers into the
charging plug.
﹒The unit contains no user serviceable
parts. DO not try to repair or service the
charging cable yourself.
﹒If the unit does not work properly in
accordance with the operating
instructions, do not use this unit. Contact
a repair or replacement.
﹒Use the product under normal away
from high temperature erosive materials
or ignition source.
﹒DO not contact metal conductor to
prevent electric shock accident.
﹒Product shell is made of thermoplastic,
please do not pound it
Charging:
1. Check the power distribution cable for
damage before powering up.
2. Plug the mains plug into the EV charger.
3. Make sure that the EV charger outlet
complies with national standards
4. Plug the vehicle plug into the socket of
your vehicle.
5. Make sure that the vehicle connector is
fully inserted until it clicks into place.
6. When your EV is fully charged
7. Disconnect the EV charger side gun.
8. Disconnect the EV side.
9. Cover the connector and cover the gun
10. Insert the charging cable into the
carrying case.
GUARANTEE:
Damage caused for the following reasons
is not covered by the warranty:
1. Improper handling, installation, use and
maintenance by the user.
2. The product falls into the water.
This warranty is for the original purchaser
only and is NOT transferable.
PLEASE NOTE: This document includes
the most recent information at the time of
going to press. EVplug reserves the right
to make changes to this product without
notice. Changes or modifications to this
product by a service center other than the
authorized one may void the product
warranty.
Assembly:
1. Performs cable crimping
2. Pass the cables through the connector
security piece
3. Insert the connectors on the front of the
gun looking at the numbers that appear on
the front of the gun, according to the
following list:
•Center, ground cable color yellow into
connector PE
Page | 3 User manual for evplug Type 2 connector PN. EV20012 www.evplugchargers.com
•Line 1 on L1, and if it is three-phase, Line 2
in L2 and Line 3 in L3
•The neutral connector (Blue wire) in the N
•The long pin in the PP
•The short Pin in PN
4. Push the piece at point 1 until you hear a
click. Once fitted, it cannot be removed
again.
5. Put the three small black screws into the
black frame to prevent it from coming loose.
6. Now insert the complete set into the white
frame and push until you hear a click. Once
attached, it cannot be released again.
7. Now insert the black rubber and the back
piece on the other side of the cable
8. Attach the metal vise with the screw that
comes in the large silver bag.
9. To finish mounting, insert the three large
black screws on the back cover and the
small silver screw on the bottom of the gun,
where the features appear.
New mounting plug:
Page | 4 User manual for evplug Type 2 connector PN. EV20012 www.evplugchargers.com
In case you are installing a new charging cable,
you shall include the resistor as the following
draw. In case you are mounting the 3 phases
plug, just add the L2 and L3 as well as is installed
the L1 on the following diagram:
MANUALES EN OTROS IDIOMAS
For manuals in any other language,
please, read the following code or go
to
https://evplugchargers.com/downloa
ds/
Para manuales en otro idioma, por
favor lea el siguiente código o vaya a
https://evplugchargers.com/downloa
ds/
Pour les manuels dans une autre
langue, veuillez lire le code ci-dessous
ou allez sur
https://evplugchargers.com/downloa
ds/
Für Handbücher in einer anderen
Sprache lesen Sie bitte den Code
unten oder gehen Sie zu
https://evplugchargers.com/downloa
ds/
Per i manuali in un'altra lingua,
leggere il codice qui sotto o andare su
https://evplugchargers.com/downloa
ds/
Aby uzyskać instrukcje w innym
języku, przeczytaj poniższy kod lub
przejdź do
https://evplugchargers.com/downloa
ds/
Başka bir dildeki kılavuzlar için lütfen
aşağıdaki kodu okuyun veya
https://evplugchargers.com/downloa
ds/ adresine gidin.
