EWM Phoenix 355 Progress puls LP MM TKM User manual

Operatinginstructions
EN
Weldingmachine
Phoenix 355 Progress puls LP MM TKM
090-005502-EW501
25.11.2015
Register now
and benefit!
Jetzt Registrieren
und Profitieren!
www.ewm-group.com
*For details visit
www.ewm-group.com
*

General instructions
CAUTION
Read the operating instructions!
The operating instructions provide an introduction to thesafe use of the products.
•Read the operating instructions for all system components!
•Observe accidentprevention regulations!
•Observe all local regulations!
•Confirm with a signature where appropriate.
In the event of queries on installation, commissioning, operation or special conditions at the
installation site, or on usage, please contact your sales partner or our customer service
department on [phone].
A list of authorised sales partners can be found at www.ewm-group.com.
Liability relating to the operation of this equipment is restricted solely to the function of the
equipment. No other form of liability, regardless of type, shall be accepted. This exclusion of
liability shall be deemed accepted by the user on commissioning the equipment.
The manufacturer is unable to monitor whether or not these instructions or the conditions and
methods areobserved during installation, operation, usage and maintenance of the equipment.
An incorrectly performed installation can result in material damage and injure persons as a
result. For this reason, we do not accept any responsibility or liability for losses, damages or
costs arisingfrom incorrectinstallation, improper operation or incorrectusage and maintenance
or any actions connected to this in any way.
© EWMAG · Dr. Günter-Henle-Str. 8 · D-56271 Mündersbach, Germany
The copyright to this document remains the property of the manufacturer.
Reprinting, including extracts, only permitted with written approval.
The content of this document has been prepared and reviewed with all reasonable care. The information
provided is subject to change, errors excepted.

Contents
Notes on the use of these operating instructions
090-005502-EW501
25.11.2015
3
1 Contents
1Contents.......................................................................................................................................3
2Safety instructions.......................................................................................................................6
2.1 Notes on the use of these operating instructions.....................................................................6
2.2 Explanation of icons..............................................................................................................7
2.3 General................................................................................................................................8
2.4 Transport and installation....................................................................................................12
2.4.1 Ambient conditions...............................................................................................13
2.4.1.1 In operation ...........................................................................................13
2.4.1.2 Transport and storage ............................................................................13
3Intended use ..............................................................................................................................14
3.1 Applications .......................................................................................................................14
3.1.1 MIG/MAG standard welding ..................................................................................14
3.1.1.1 forceArc.................................................................................................14
3.1.1.2 rootArc ..................................................................................................14
3.1.2 MIG/MAG pulse welding .......................................................................................14
3.1.2.1 forceArc puls..........................................................................................14
3.1.2.2 rootArc puls ...........................................................................................14
3.1.3 TIG (Liftarc) welding .............................................................................................14
3.1.4 MMA welding .......................................................................................................14
3.1.4.1 Air arc gouging.......................................................................................14
3.2 Documents which also apply ...............................................................................................15
3.2.1 Warranty..............................................................................................................15
3.2.2 Declaration of Conformity......................................................................................15
3.2.3 Welding in environments with increased electrical hazards......................................15
3.2.4 Service documents (spare parts and circuit diagrams) ............................................15
3.2.5 Calibration/Validation............................................................................................15
4Machine description –quick overview .......................................................................................16
4.1 Front view..........................................................................................................................16
4.2 Rear view...........................................................................................................................18
4.2.1 Operating elements in the machine........................................................................20
4.3 Machine control –Operating elements.................................................................................22
5Design and function...................................................................................................................24
5.1 General..............................................................................................................................24
5.2 Installation .........................................................................................................................25
5.2.1 Protective flap, welding machine control ................................................................26
5.3 Machine cooling .................................................................................................................26
5.4 Workpiece lead, general .....................................................................................................26
5.5 Notes on the installation of welding current leads..................................................................27
5.6 Mains connection ...............................................................................................................29
5.6.1 Mains configuration ..............................................................................................29
5.7 Welding torch cooling system..............................................................................................30
5.7.1 Cooling module connection...................................................................................30
5.8 Shielding gas supply (shielding gas cylinder for welding machine) .........................................31
5.8.1 Gas test...............................................................................................................32
5.8.2 Rinse hose package function ................................................................................32
5.8.2.1 Setting the shielding gas quantity ............................................................32
5.9 Welding torch holder...........................................................................................................33
5.10 Welding data display...........................................................................................................34
5.11 MIG/MAG welding ..............................................................................................................35
5.11.1 Welding torch and workpiece line connection .........................................................35
5.11.2 Wire feed.............................................................................................................37
5.11.2.1 Open the protective flap of the wire feeder...............................................37
5.11.2.2 Inserting the wire spool...........................................................................37
5.11.2.3 Changing the wire feed rollers.................................................................38
5.11.2.4 Inching the wire electrode.......................................................................40
5.11.2.5 Spool brake setting ................................................................................42

Contents
Notes on the use of these operating instructions
4
090-005502-EW501
25.11.2015
5.11.3 Definition of MIG/MAG welding tasks .....................................................................43
5.11.4 Welding task selection ..........................................................................................43
5.11.4.1 Basic welding parameters .......................................................................43
5.11.4.2 Operating mode......................................................................................44
5.11.4.3 Choke effect / dynamics..........................................................................44
5.11.5 MIG/MAG operating point......................................................................................45
5.11.5.1 Selecting the display unit.........................................................................45
5.11.5.2 Operating point setting using material thickness .......................................45
5.11.5.3 Arc length correction setting....................................................................46
5.11.5.4 Accessory components for operating point setting ....................................46
5.11.6 forceArc / forceArc puls.........................................................................................47
5.11.7 rootArc/rootArc puls..............................................................................................48
5.11.8 MIG/MAG functional sequences / operating modes .................................................49
5.11.8.1 Explanation of signs and functions...........................................................49
5.11.9 MIG/MAG program sequence ("Program steps" mode)............................................55
5.11.9.1 Example, tack welding (non-latched)........................................................56
5.11.9.2 Example, aluminium tack welding (non-latched special) ............................56
5.11.9.3 Example, aluminium welding (latched special)..........................................56
5.11.10 Main program A mode...........................................................................................57
5.11.10.1Selecting parameters (program A) ...........................................................59
5.11.11 MIG/MAG automatic cut-out ..................................................................................59
5.11.12 Standard MIG/MAG torch......................................................................................60
5.11.13 MIG/MAG special-torches .....................................................................................60
5.11.13.1Program- and Up- / down operation .........................................................60
5.11.13.2Switching between Push/Pull and intermediate drive.................................60
5.12 TIG welding........................................................................................................................61
5.12.1 Welding torch and workpiece line connection..........................................................61
5.12.2 Welding task selection ..........................................................................................62
5.12.2.1 Welding current setting ...........................................................................62
5.12.3 TIG arc ignition.....................................................................................................62
5.12.3.1 Liftarc ignition.........................................................................................62
5.12.4 Function sequences/operating modes....................................................................63
5.12.4.1 Explanation of signs and functions...........................................................63
5.12.4.2 TIG automatic cut-out .............................................................................66
5.13 MMA welding......................................................................................................................67
5.13.1 Connecting the electrode holder and workpiece lead...............................................67
5.13.2 Welding task selection ..........................................................................................68
5.13.2.1 Welding current setting ...........................................................................68
5.13.2.2 Arcforce.................................................................................................68
5.13.2.3 Hotstart..................................................................................................68
5.13.2.4 Antistick.................................................................................................68
5.14 Remote control ...................................................................................................................69
5.15 Interfaces for automation.....................................................................................................69
5.15.1 Automation interface.............................................................................................70
5.15.2 Remote control connection socket, 19-pole ............................................................71
5.15.3 RINTX12 robot interface.......................................................................................72
5.15.4 BUSINTX11 Industrial bus interface......................................................................72
5.16 PC Interfaces......................................................................................................................72
5.17 Protecting welding parameters from unauthorised access......................................................73
5.18 Special parameters (advanced settings) ...............................................................................73
5.18.1 Selecting, changing and saving parameters............................................................74
5.18.1.1 Reset to factory settings..........................................................................76
5.18.1.2 Special parameters in detail ....................................................................77
5.19 Machine configuration menu................................................................................................86
5.19.1 Selecting, changing and saving parameters............................................................86
5.19.2 Aligning the cable resistance .................................................................................87
5.19.3 Power-saving mode (Standby)...............................................................................88
6Maintenance, care and disposal .................................................................................................89
6.1 General..............................................................................................................................89
6.2 Maintenance work, intervals.................................................................................................89

Contents
Notes on the use of these operating instructions
090-005502-EW501
25.11.2015
5
6.2.1 Daily maintenance tasks.......................................................................................89
6.2.1.1 Visual inspection....................................................................................89
6.2.1.2 Functional test .......................................................................................89
6.2.2 Monthly maintenance tasks...................................................................................90
6.2.2.1 Visual inspection....................................................................................90
6.2.2.2 Functional test .......................................................................................90
6.2.3 Annual test (inspection and testing during operation) ..............................................90
6.3 Disposing of equipment.......................................................................................................90
6.3.1 Manufacturer's declaration to the end user.............................................................90
6.4 Meeting the requirements of RoHS......................................................................................90
7Rectifying faults.........................................................................................................................91
7.1 Checklist for rectifying faults................................................................................................91
7.2 Error messages..................................................................................................................92
7.3 Resetting JOBs (welding tasks) to the factory settings...........................................................94
7.3.1 Resetting a single JOB .........................................................................................94
7.3.2 Resetting all JOBs................................................................................................95
7.4 General operating problems................................................................................................95
7.4.1 Interface for automated welding.............................................................................95
7.5 Vent coolant circuit.............................................................................................................96
8Technical data............................................................................................................................97
8.1 Phoenix 355 Progress puls MM TKM ...................................................................................97
9Accessories ...............................................................................................................................98
9.1 General accessories...........................................................................................................98
9.2 Remote control/connecting and extension cable ...................................................................98
9.2.1 7-pole connection.................................................................................................98
9.2.2 19-pole connection...............................................................................................98
9.3 Options..............................................................................................................................99
9.4 Computer communication ...................................................................................................99
10 Replaceable parts .................................................................................................................... 100
10.1 Wire feed rollers ...............................................................................................................100
10.1.1 Wire feed rollers for steel wire.............................................................................100
10.1.2 Wire feed rollers for aluminium wire.....................................................................101
10.1.3 Wire feed rollers for cored wire............................................................................101
10.1.4 Wire guide.........................................................................................................101
11 Appendix A ..............................................................................................................................102
11.1 JOB-List...........................................................................................................................102
12 Appendix B ..............................................................................................................................103
12.1 Overview of EWM branches..............................................................................................103

Safety instructions
Notes on the use of these operating instructions
6
090-005502-EW501
25.11.2015
2 Safety instructions
2.1 Notes on the use of these operating instructions
DANGER
Working or operating procedures which must be closely observed to prevent imminent
serious and even fatal injuries.
•Safety notes include the "DANGER" keyword inthe heading with a general warning symbol.
•The hazard is also highlighted using a symbol on the edge of the page.
WARNING
Working or operating procedures which must be closely observed to prevent serious
and even fatal injuries.
•Safety notes include the "WARNING" keyword in the heading with a general warning
symbol.
•The hazard is also highlighted using a symbol in the page margin.
CAUTION
Working or operating procedures which must be closely observed to prevent possible
minor personal injury.
•The safety information includes the "CAUTION" keyword in its heading with a general
warning symbol.
•The risk is explained using a symbol on the edge of the page.
CAUTION
Working and operating procedures which must be followed precisely to avoid damaging
or destroying the product.
•The safety information includes the "CAUTION" keyword in its heading without a general
warning symbol.
•The hazard is explained using a symbol at the edge of the page.
Special technical points which users must observe.
Instructions and lists detailing step-by-step actions for given situations canbe recognised via bullet
points, e.g.:
•Insert the welding current lead socket into the relevant socket and lock.

Safety instructions
Explanation of icons
090-005502-EW501
25.11.2015
7
2.2 Explanation of icons
Symbol
Description
Special technical points which users must observe.
Correct
Wrong
Press
Do not press
Press and keep pressed
Turn
Switch
Switch off machine
Switch on machine
ENTER
enter the menu
NAVIGATION
Navigating in the menu
EXIT
Exit the menu
4 s
Time display (example: wait 4s/press)
Interruption in themenu display (other setting options possible)
Tool not required/do not use
Tool required/use

Safety instructions
General
8
090-005502-EW501
25.11.2015
2.3 General
DANGER
Electromagnetic fields!
The power source may cause electrical or electromagnetic fields to be produced which
could affect the correct functioning of electronic equipment such as IT or CNC devices,
telecommunication lines, power cables, signal lines and pacemakers.
•Observe the maintenance instructions - See 6 Maintenance, care and disposal chapter!
•Unwind welding leads completely!
•Shield devices or equipment sensitive to radiation accordingly!
•The correctfunctioning of pacemakers may be affected (obtain advice froma doctor if
necessary).
Do not carry out any unauthorised repairs or modifications!
To avoid injury and equipment damage, the unit must only be repaired or modified by
specialist, skilled persons!
The warranty becomes null and void in the event of unauthorised interference.
•Appoint only skilled persons for repair work (trained service personnel)!
Electric shock!
Welding machines use high voltages which can result in potentially fatal electric shocks
and burns on contact. Even low voltages can cause you to get a shock and lead to
accidents.
•Do not touch any live parts in or on the machine!
•Connection cables and leads must be free of faults!
•Switching off alone is not sufficient!
•Place welding torch and stick electrode holder on an insulated surface!
•The unit should only be opened by specialist staff after the mains plug has been
unplugged!
•Only wear dry protective clothing!
•Waitfor 4 minutes until the capacitors have discharged!
WARNING
Risk of injury due to radiation or heat!
Arc radiation results in injury to skin and eyes.
Contact with hot workpieces and sparks results in burns.
•Use welding shield or welding helmet with the appropriate safety level (depending on the
application)!
•Weardry protective clothing (e.g. welding shield, gloves, etc.) accordingto the relevant
regulations in the country in question!
•Protect persons not involved in the work against arc beams and the risk of glare using
safety curtains!
Explosion risk!
Apparently harmless substances in closed containers may generate excessive pressure
when heated.
•Move containers with inflammable or explosive liquids away from the working area!
•Never heat explosive liquids, dusts or gases by welding or cutting!

Safety instructions
General
090-005502-EW501
25.11.2015
9
WARNING
Smoke and gases!
Smoke and gases can lead to breathing difficulties and poisoning. In addition, solvent
vapour (chlorinated hydrocarbon) may be converted into poisonous phosgene due to
the ultraviolet radiation of the arc!
•Ensure that there is sufficientfresh air!
•Keep solvent vapour away from the arc beam field!
•Wearsuitable breathing apparatus if appropriate!
Fire hazard!
Flames may arise as a result of the high temperatures, stray sparks, glowing-hot parts
and hot slag produced during the welding process.
Stray welding currents can also result in flames forming!
•Check for firehazards inthe working area!
•Do not carryany easily flammable objects such as matches or lighters.
•Keep appropriate fire extinguishing equipment to hand inthe working area!
•Thoroughly remove any residue of flammable substances from the workpiece before
starting welding.
•Only continue work on welded workpieces once they have cooled down.
Do not allow to come into contact with flammable material!
•Connect welding leads correctly!
Risk of accidents due to non-compliance with the safety instructions!
Non-compliance with the safety instructions can be fatal!
•Carefully read the safety instructions in this manual!
•Observe the accident prevention regulations and any regional regulations!
•Inform persons inthe working area that they must comply with the regulations!
Danger when coupling multiple power sources!
Coupling multiple power sources in parallel or in series has to be carried out by
qualified personnel and in accordance with the manufacturer's guidelines. Before
bringing the power sources into service for arc welding operations, a test has to verify
that they cannot exceed the maximum allowed open circuit voltage.
•Connection of the machine may be carriedout by qualified personnel only!
•Whendecommissioning individual power sources, all mains and welding current leads have
to be safely disconnected from the welding system as a whole. (Danger due to inverse
voltages!)
•Do not couple welding machines with pole reversing switch (PWSseries) or machines for
AC welding, as a minor error inoperation can cause the welding voltages to be combined.
CAUTION
Noise exposure!
Noise exceeding 70 dBA can cause permanent hearing damage!
•Wearsuitable ear protection!
•Persons located within the working area must wear suitable ear protection!

Safety instructions
General
10
090-005502-EW501
25.11.2015
CAUTION
Obligations of the operator!
The respective national directives and laws must be observed for operation of the
machine!
•National implementation of the framework directive (89/391/EWG), as well as the
associated individual directives.
•In particular, directive (89/655/EWG), on the minimum regulations for safety and health
protection when staff members use equipment during work.
•The regulations regarding work safety and accidentprevention for the respective country.
•Setting up and operating the machine accordingto IEC60974-9.
•Check at regular intervals that users are working in a safety-consciousway.
•Regular checksof the machine according to IEC 60974-4.
Damage due to the use of non-genuine parts!
The manufacturer's warranty becomes void if non-genuine parts are used!
•Only use system components and options (power sources, welding torches, electrode
holders, remote controls, spare parts and replacement parts, etc.) fromour range of
products!
•Only insert and lock accessory components into the relevant connection socket when the
machine isswitched off.
Damage to themachine due to stray welding currents!
Stray welding currents can destroy protective earth conductors, damage equipment and
electronic devices and cause overheating of components leading to fire.
•Make sure all welding leads are securely connected and check regularly.
•Always ensure a proper and secure electrical connection to the workpiece!
•Set up, attach or suspend all conductive power source components like casing, transport
vehicle and crane frames so they are insulated!
•Do not place any other electronic devices such as drillers or angle grinders, etc., on the
power source, transport vehicle or craneframes unless they are insulated!
•Always put welding torches and electrode holders on an insulated surface when they are
not in use!
Mains connection
Requirements for connection to the public mains network
High-performance machines caninfluence the mains quality by taking currentfrom the mains
network. For some types of machines, connection restrictions or requirements relating to the
maximum possible line impedance or the necessary minimum supply capacity at the interface
with the public network (Point of Common Coupling, PCC) can therefore apply. In this respect,
attention is also drawn to the machines' technical data. Inthis case, it is the responsibility of
the operator, where necessary in consultation with the mains network operator, to ensure that
the machine can be connected.

Safety instructions
General
090-005502-EW501
25.11.2015
11
CAUTION
EMC Machine Classification
In accordance with IEC 60974-10, welding machines are grouped in two electromagnetic
compatibility classes - See 8 Technical data chapter:
Class A machines are not intended for use in residential areas where the power supply comes
fromthe low-voltage public mains network. When ensuring the electromagnetic compatibility of
class A machines, difficulties canarise inthese areas due to interference not only in the supply
lines but also in the form of radiated interference.
Class B machines fulfil the EMC requirements in industrial as well as residential areas,
including residential areas connected to the low-voltage public mains network.
Setting up and operating
Whenoperating arc welding systems, in some cases, electro-magnetic interference canoccur
although all of the welding machines comply with the emission limits specifiedin the standard.
The user is responsible for any interference caused by welding.
In order to evaluate any possible problems with electromagnetic compatibility in the
surrounding area, the user must consider the following: (see also EN 60974-10 Appendix A)
•Mains, control, signal and telecommunication lines
•Radios and televisions
•Computers and other control systems
•Safety equipment
•The health of neighbouring persons, especially if they have a pacemaker or wear a hearing
aid
•Calibration and measuring equipment
•The immunity to interference of other equipment in the surrounding area
•The time of day at which the welding work must be carriedout
Recommendations for reducing interference emission
•Mains connection, e.g. additional mains filter or shielding with a metal tube
•Maintenance of the arc welding equipment
•Welding leads should be as short as possible and run closely together along the ground
•Potential equalization
•Earthing of the workpiece. In cases where it is not possible to earth the workpiece directly,
it should be connected by means of suitable capacitors.
•Shielding from other equipment in the surrounding area or the entire welding system

Safety instructions
Transport and installation
12
090-005502-EW501
25.11.2015
2.4 Transport and installation
WARNING
Incorrect handling of shielding gas cylinders!
Incorrect handling of shielding gas cylinders can result in serious and even fatal injury.
•Observe the instructions from the gas manufacturer and inany relevant regulations
concerningthe use of compressed air!
•Place shielding gas cylinders inthe holders provided for them and secure with fixing
devices.
•Avoid heating the shielding gas cylinder!
Risk of accident due to improper transport of machines that may not be lifted!
Do not lift or suspend themachine! The machine can fall down and cause injuries! The
handles and brackets are suitable for transport by hand only!
•The machine may not be lifted by crane or suspended!
CAUTION
Risk of tipping!
There is a risk of the machine tipping over and injuring persons or being damaged itself
during movement and set up. Tilt resistance is guaranteed up to an angle of 10°
(according to IEC 60974-1).
•Set up and transport the machine on level, solid ground.
•Secure add-on parts using suitable equipment.
Damage due to supply lines not being disconnected!
During transport, supply lines which have not been disconnected (mains supply leads,
control leads, etc.) may cause hazards such as connected equipment tipping over and
injuring persons!
•Disconnect supply lines!
CAUTION
Equipment damage when not operated in an upright position!
The units are designed for operation in an upright position!
Operation in non-permissible positions can cause equipment damage.
•Only transport and operate in an upright position!

Safety instructions
Transport and installation
090-005502-EW501
25.11.2015
13
2.4.1 Ambient conditions
CAUTION
Installation site!
The machine must not be operatedin the open air and must only be set up and
operated on a suitable, stable and level base!
•The operator must ensure that the ground is non-slip and level, and provide sufficient
lighting for the place of work.
•Safe operation of the machine must be guaranteed at all times.
CAUTION
Equipment damage due to dirt accumulation!
Unusually high quantities of dust, acid, corrosive gases or substances may damage the
equipment.
•Avoid high volumes of smoke, vapour, oil vapour and grinding dust!
•Avoid ambient air containing salt (sea air)!
Non-permissible ambient conditions!
Insufficient ventilation results in a reduction in performance and equipment damage.
•Observe the ambient conditions!
•Keep the cooling air inlet and outlet clear!
•Observe the minimum distance of 0.5 m fromobstacles!
2.4.1.1 In operation
Temperature range of the ambient air:
•-25 °C to +40 °C
Relative air humidity:
•Up to 50% at 40 °C
•Up to 90% at 20 °C
2.4.1.2 Transport and storage
Storage in an enclosed space, temperature range of the ambient air:
•-30 °C to +70 °C
Relative air humidity
•Up to 90% at 20 °C

Intendeduse
Applications
14
090-005502-EW501
25.11.2015
3 Intended use
WARNING
Hazards due to improper usage!
Hazardsmay arise for persons, animals and material objects if the equipment is not
used correctly. No liability is accepted for any damages arising from improper usage!
•The equipment must only be used in line with proper usage and by trained or expert staff!
•Do not modify or convert the equipment improperly!
3.1 Applications
3.1.1 MIG/MAG standard welding
Metal arc welding using a wire electrode, where the arc and the weld pool are shielded fromthe
atmosphere with inert (MIG) or active (MAG) gasses or gas mixtures.
3.1.1.1 forceArc
Low-heat, directionally stable and powerful high-performance arc with deep fusion penetration for the
upper power range Unalloyed, low-alloy and high-alloy steels as well as high-tensile fine-grained steels.
3.1.1.2 rootArc
Short arc with perfect weld modelling capabilities for effortless gap bridging, especially for positional
welding
3.1.2 MIG/MAG pulse welding
Welding process for optimum welding results when joining unalloyed, low-allow and high-alloy steels and
aluminium thanks to controlled droplet transfer and targeted, adapted heat input.
3.1.2.1 forceArc puls
Effective extension of the forceArc arc.Secure sidewall fusion, easy to model and control by the user.
Ideal for welding filler and final passes in all power ranges and positions.
3.1.2.2 rootArc puls
The perfect enhancement for focused heat input for the higher performance range
3.1.3 TIG (Liftarc) welding
TIG welding procedure with arc striking by contact with the workpiece and subsequent removal of the
electrode.
3.1.4 MMA welding
Manual arc welding or, for short, MMA welding. It is characterised by the fact that the arc burns between
a melting electrode and the molten pool. There is no external protection; any protection against the
atmosphere comes from the electrode.
3.1.4.1 Air arc gouging
During gouging, an arc burns between a carbon electrode and the workpiece, heating the workpiece until
it is molten. At the same time, the molten metal is blown out with compressed air. Special electrode
holders with a compressed-air connection and carbon electrodes arerequired for gouging.

Intendeduse
Documents which also apply
090-005502-EW501
25.11.2015
15
3.2 Documents which also apply
3.2.1 Warranty
For more information refer to the "Warranty registration" brochure supplied and our information
regarding warranty, maintenance and testing at www.ewm-group.com!
3.2.2 Declaration of Conformity
The designated machine conforms to EC Directives and standards in terms of its design
and construction:
•EC Low Voltage Directive (2006/95/EC),
•EC EMC Directive (2004/108/EC),
This declaration shall become null and void in the event of unauthorised modifications, improperly
conducted repairs, non-observance of the deadlines for the repetition test and / or non-permitted
conversion work not specifically authorised by the manufacturer.
The original copyof the declaration of conformity is enclosed with the unit.
3.2.3 Welding in environments with increased electrical hazards
In compliance with IEC / DIN EN 60974, VDE 0544 themachines can be used in
environments with an increased electrical hazard.
3.2.4 Service documents (spare parts and circuit diagrams)
DANGER
Do not carry out any unauthorised repairs or modifications!
To avoid injury and equipment damage, the unit must only be repaired or modified by
specialist, skilled persons!
The warranty becomes null and void in the event of unauthorised interference.
•Appoint only skilled persons for repair work (trained service personnel)!
Original copies of the circuitdiagrams are enclosed with the unit.
Spare parts canbe obtained fromthe relevant authorised dealer.
3.2.5 Calibration/Validation
Wehereby confirmthat this machine has been tested using calibrated measuring equipment, as
stipulated in IEC/EN 60974, ISO/EN 17662, EN 50504, and complies with the admissible tolerances.
Recommended calibration interval: 12 months

Machine description –quickoverview
Front view
16
090-005502-EW501
25.11.2015
4 Machine description – quick overview
4.1 Front view
Figure 4-1

Machine description –quickoverview
Front view
090-005502-EW501
25.11.2015
17
Item
Symbol
Description 0
1
Transport bar
2
Carrying handle
3
Protective cap
Cover for the wire feed mechanism and other operating elements.
Depending on the machine series, additional stickers with information on the
replacement parts and JOB lists will be located on the inside.
4
Wire spool inspection window
Check wire supply
5
Slide latch, lock for the protective cap
6
Machine control- See 4.3 Machine control –Operating elements chapter
7
Cooling air inlet
8
Welding torch connection (Euro torch connector)
Welding current, shielding gas and torch trigger integrated
9
Machine feet
10
Park socket, polarity selection plug
Retainer for the polarity selection plug in MMA mode or for transport.
11
19-pole connection socket (analogue)
For connecting analogue accessory components (remote control, welding torch control
lead, etc.)
12
Connection socket, "+" welding current
•MIG/MAG coredwire welding: Workpiececonnection
•TIG welding: Workpiececonnection
•MMA welding: Workpiececonnection
13
"-" welding current connection socket
•MIG/MAG welding: Workpiececonnection
•TIG welding: Welding currentconnection for welding torch
•MMA welding: electrode holder connection
14
Welding current cable, polarity selection
Welding current to Euro torch connector/torch, for polarity selection
•MIG/MAG: Connection socket for “+” welding current
•Self-shielding flux cored wire/TIG: Connection socket, “-” welding current
•MMA: Park socket
▼ optional, factory-fitted ▼
15
Key switch for protection against unauthorised use
Position “1” > changes possible,
Position “0” > changes not possible.
- See 5.17 Protecting welding parameters from unauthorised access chapter
▲ optional, factory-fitted ▲
16
Protective cap
- See 5.2.1 Protective flap, welding machine control chapter

Machine description –quickoverview
Rear view
18
090-005502-EW501
25.11.2015
4.2 Rear view
Figure 4-2

Machine description –quickoverview
Rear view
090-005502-EW501
25.11.2015
19
Item
Symbol
Description 0
1
Main switch, machine on/off
2
Connecting nipple G¼, shielding gas connection
3
4-pole connection socket
Cooling unit voltage supply
4
8-pole connection socket
Cooling unit control lead
5
7-pole connection socket (digital)
For connecting digital accessory components (documentation interface, robot interface
or remote control, etc.).
6
Mains connection cable
- See 5.6 Mains connection chapter
▼ Retrofitting option ▼
7
19-pole mechanised welding interface (analogue)
- See 5.15.1 Automation interface chapter
▲ Retrofitting option ▲
8
Cooling air outlet
9
External wire feed inlet
Pre-cutcasing inlet for external wire feed.

Machine description –quickoverview
Rear view
20
090-005502-EW501
25.11.2015
4.2.1 Operating elements in the machine
Figure 4-3
