EXCEL DRYER, INC 1.413.525.4531 1.800.255.9235 (US/CN) EXCELDRYER.COM
ADMIN@EXCELDRYER.COM 357 CHESTNUT STREET, EAST LONGMEADOW, MA 01028 2/2021 2
SUGGESTED MOUNTING HEIGHT
from oor to bottom of dryer:
Men 45" (114 cm)
Women 43" (109 cm)
Teenagers 41" (104 cm)
Small Children 35" (89 cm)
Accessible 37" (94 cm)
MOUNTING HARDWARE
Recommended Fastener (not supplied):
Masonry Wall ½” Expansion Sleeve with ¼” Lag Bolt
Hollow Wall ¼” Wing Type Toggle Bolt
Wooden Wall ¼” Lag Screw With Washer
2
TABLE 1 TABLE 2
WARNING: For proper electrical connections, check your local building codes.
Your unit must be installed by a qualied, licensed electrician.
PRE-INSTALLATION WIRING
• Check that the electrical supply corresponds to that shown
on the rating sticker of unit. If the dryer is connected to any
electrical supply other than that stated on the rating sticker of
the unit, permanent damage or improper, unsafe operation of
the unit may result.
• Make sure electricity is switched off at the main panel before
installing, maintaining or cleaning this hand dryer. Dryer
must be installed in accordance with current local wiring and
building regulations.
• Dryer is intended to be permanently connected to power
supply, and must be properly grounded.
SAFETY
• Troubleshooting and internal maintenance must be performed
by qualied service personnel.
• Do not use any power wash equipment for cleaning on or
near this unit.
• Do not use for drying hair.
• Do not obstruct air inlets or outlets.
1. Disconnect the power source previously brought to the hand
dryer location (see pre-installation wiring above).
2. Use the Tamper-Proof Wrench supplied and remove the
Tamper-Proof Bolt on bottom of cover lifting upwards to
remove cover from base plate.
3. If electrical wiring entry is to be made from the rear, remove
the appropriate pre-formed knockout on the base plate. If
entry is to be made from the side, knock out the preformed
area on the right side of cover for your supply connection
using knockout gasket provided. A rigid conduit must be
used. For models with metal covers, if the side entry for
conduit is required, this must be specied in advance and
the side entry can be pre-cut and proper grommet applied by
the manufacturer.
4. Select the appropriate mounting height for dryer (Table 1)
and fastener, as recommended (Table 2). There should
be no obstruction between the hand dryer and the oor.
If mounting over a countertop, distance from counter to dryer
must be 15” (381 mm) minimum.
CAUTION: Do not use Base Plate as a guide when drilling.
Make sure no pipe work (gas, water, air) or any electrical cables
or wires are located directly behind the area to be drilled.
5. Attach Base Plate at the four corners to smooth wall.
Use one of 2 knockouts provided for service entry on back of
Base Plate. If using surface wiring use knock out in right side
of cover. Use Knockout Gasket supplied around conduit for
water seal. See Mounting Details.
6. Identify the voltage of your dryer from the rating sticker of
the unit. Then connect to a circuit per your local wiring and
building regulations.
7. Secure electrical wiring to terminals as indicated by the
schematic afxed to blower housing. An identied ground
connection point is supplied on the Base Plate for your
equipment ground wire. Dryers should be installed per local
code requirements.
8. In multiple installations, make sure the serial number marked
on the inside matches the cover number. Then carefully
replace Cover by inserting top of cover over bracket and
tilting downward. Use Tamper-Proof Bolt previously
removed in step 2.
9. Restore power and test for proper operation.
10. Return Tamper-Proof Wrench to owner.
1
INSTALLATION INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
PLEASE SEE OUR WEBSITE, www.exceldryer.com FOR WARRANTY, TROUBLESHOOTING, AND PARTS INFORMATION
TIME TO THROW IN THE TOWEL
®
