Exhausto VEX200 series User manual

VEX240H
Mechanical assembly
EXact2 control
Product information........................................ Chapter 1 + 6
Mechanical assembly..................................... Chapter 2 + 3
Electrical installation.......................................Chapter 4
Maintenance...................................................Chapter 5
Unit supplied with (factory fitted):
The following accessories are supplied
separately:
Rotor with standard temperature efficiency
Rotor with high temperature efficiency
Compact filters FP
Bag filter FB
Trim damper and blowout zone, TB240
OD (roof for outdoor)
Webserver
MLON
HCW heating coil
HCE heating coil
CCW cold water coil
DX cooling/heating coil
Mounting base, MSVEX240H
Closing damper, LS315-24, (LSA exhaust)
Closing damper, LS315-24, (LSF outdoor)
Closing damper, LSR315-24, with
spring-return (LSFR outdoor)
pieces, Fire thermostat, BT40
pieces, Fire thermostat, BT50
pieces, Fire thermostat, BT70
pieces, Control panel, HMI
pieces, Motion sensor MIO-PIR
pieces, Constant pressure control, MPT-DUCT
Humidity sensor, MIO-RH
CO2-sensor, MIO-CO2-DUCT
CO2-sensor, MIO-CO2-ROOM
Temperature sensor, MIO-TS-DUCT
Temperature sensor, MIO-TS-ROOM
Control for external cooling unit, MXCU
Control for external heating coil, MHCW
Control for external cold water coil, MCCW
Serial no.:
Prod. order no.:
Sales order no.:
Original instructions
3005007-2018-02-22 VEX240_EXact2
EXHAUSTO A/S
Odensevej 76
DK-5550 Langeskov
Tel. [phone]
Fax: [phone]
[email protected]
www.exhausto.com

1. Product information
1.1. Model overview...................................................................................................... 5
Model overview................................................................................................ 5
1.2. Designations used in these instructions.............................................................7
1.3. Application............................................................................................................. 8
1.4. Location requirements.......................................................................................... 8
1.4.1. Spatial requirements........................................................................................ 8
1.4.2. Requirements for underlying surface.............................................................. 8
1.4.3. Requirements for duct system......................................................................... 8
1.5. Description............................................................................................................. 9
1.5.1. The VEX unit design....................................................................................... 9
1.6. Principal dimensions...........................................................................................13
VEX240, V1....................................................................................................13
VEX240, V2....................................................................................................14
2. Handling
2.1. Unpacking.............................................................................................................15
2.2. Transport.............................................................................................................. 15
2.2.1. Weight...........................................................................................................16
2.2.2. Passage through openings .......................................................................... 16
2.2.3. Internal transport with reduced weight.......................................................... 17
3. Mechanical assembly
3.1. Installing the unit................................................................................................. 19
3.1.1. Installed directly onto the floor....................................................................... 19
3.1.2. Installing on mounting base........................................................................... 19
4. Electrical installation
4.1. Electrical installation........................................................................................... 20
5. Maintenance
5.1. Operating readings via the HMI panel................................................................21
5.2. Maintenance chart............................................................................................... 21
5.3. Service.................................................................................................................. 22
5.3.1. Filter change.................................................................................................. 22
5.3.2. Servicing and cleaning...................................................................................22
6. Technical data
6.1. Weight, corrosion class, temperature ranges, etc............................................24
6.2. Compact filters.....................................................................................................26
6.3. Bag filters............................................................................................................. 27
6.4. Capacity diagram................................................................................................. 28
6.5. Ordering spare parts........................................................................................... 28
3005007-2018-02-22
2/32

Symbols, terms and warnings
Prohibition symbol Failure to observe instructions marked with a prohibition symbol
may result in serious or fatal injury.
Danger symbol Failure to observe instructions marked with a danger symbol
may result in personal injury and/or damage to the unit.
Scope This instruction manual is for use with EXHAUSTO VEX-type air handling units.
Please refer to the product instructions regarding accessories and extra equip-
ment.
The instructions must be fully observed to ensure personal safety and to protect
the equipment and ensure its correct operation. EXHAUSTO A/S accepts no liabil-
ity for accidents caused by equipment not used in accordance with the manual’s
instructions and recommendations.
Supply air/extract
air
These instructions use the following terms as given in DS447-2013:
● Supply air (air blown in)
● Extract air (air removed)
● Outdoor air
● Exhaust air
Left/Right The term R for Right, indicates the supply air is to the right of the cooling unit, as
seen from the operating side. The term L for Left, indicates the supply air is to the
left.
Front page: Acces-
sories
The front page of the instruction manual contains a checklist, detailing the acces-
sories delivered with the VEX unit.
NB When retrofitting EXHAUSTO accessories, please update the checklist on
the front page.
Warnings:
Opening the unit Do not open the service doors before the supply voltage has been dis-
connected at the isolation switch and the fans have stopped. The isola-
tion switch is positioned on the left side of the connection box on top
of the unit.
3005007-2018-02-22
3/32

Prohibited The VEX unit is not to be used to transport solid particles or in
areas where there is a risk of explosive gases.
No duct connection If one or more of the spigots is not connected to a duct: Fit a
protective net to the spigots with a maximum mesh width of 20
mm (in accordance with EN294).
Lock the air han-
dling unit during
operation
The VEX unit must always be locked
during operation:
● Use the cylinder lock in the han-
dle. Remember to remove the key
from the lock.
● Or use a padlock. Use the han-
dle’s built-in padlock fixture.
Lock
Padlock fitting
Rating plate The VEX unit rating plate shows:
● VEX unit, type (1)
● production number (2)
1
2
NB Always have the production number ready when contacting EXHAUSTO A/S.
3005007-2018-02-22
4/32

1. Product information
1.1 Model overview
Model overview
Positioning of fan,
motor (M) and mo-
tor control (MC)
Fan placement 1 (V1)
RD12178-01
M2
MC2
M1
MC1
Fan placement 2 (V2)
RD12179-01
M1
MC1
M2
MC2
Elements Description
RD12767-01
Fan
RD12763-01
Compact filter
RD12762-01
Bag filter
1,1,A or B Extract air spigot
1,2,A or B Exhaust air spigot
2,1,A or B Outdoor air spigot
2,2,A or B Supply air spigot
11
Air direction, extract air
22
Air direction, supply air
3005007-2018-02-22 Product information
5/32

Optional spigot positions in relation to fan placement and filter type
Fan placement
and airflows
Compact filters
RD12763-01
Bag filters
RD12762-01
Fan placement 1,
Right
RD12178-01
1
2
RD12979-01
RD12980-01
Fan placement 1, Left
RD12178-01
1
2
RD12981-01
RD12982-01
Fan placement 2,
Right
RD12179-01
2
1
RD12983-01
RD12984-01
Fan placement 2, Left
RD12179-01
2
1
RD12985-01
RD12986-01
3005007-2018-02-22 Product information
6/32

1.2 Designations used in these instructions
The simplified diagram shows a VEX unit with LEFT fan placement.
Component Function
BT40/BT501) Fire thermostat, 40°C/50°C (extract air)
BT701) Fire thermostat 70°C (supply air)
MC1 Motor control, motor 1 (extract air)
MC2 Motor control, motor 2 (supply air)
HMI1) Control panel
LS1) Closing damper, outdoor air/exhaust air
M1 Fan motor 1
M2 Fan motor 2
MIO-CO2-DUCT1) CO2 sensor, duct
MIO-CO2-ROOM1) CO2 sensor, room
MIO-PIR1) PIR sensor
MIO-RH-ROOM1) Humidity sensor
MIO-TS-ROOM1) Temperature sensor, room
MIO-TS-DUCT1) Temperature sensor, extract air (external)
MPT1, P1 Airflow control, supply air
MPT1, P2 Filter monitor, extract air
MPT2, P1 Airflow control, extract air
MPT2, P2 Filter monitor, outdoor air
MPTDUCT1) Pressure transmitter, constant pressure regulation
DRHX Control unit for the rotary heat exchanger
TE11 Temperature sensor, extract air
TE12 Temperature sensor, exhaust air
TE21 Temperature sensor, outdoor air
TE22 Temperature sensor, supply air
1)Accessory. See checklist on the front page of these instructions.
3005007-2018-02-22 Product information
7/32

1.3 Application
Comfort ventilation EXHAUSTO VEX is used for comfort ventilation tasks. Operating temperature
range for the unit – see section "Technical data".
Prohibited uses The VEX unit is not to be used to transport solid particles or in areas where there
is a risk of explosive gases.
1.4 Location requirements
Positioning The air handling unit is designed for indoor fitting. The air handling unit can be or-
dered for outdoor installation (accessory Outdoor, OD).
1.4.1 Spatial requirements
The drawing below indicates how much space is needed for servicing, replacing fil-
ters, cleaning, etc.
1550
755
805
RD11665-01
NB: A free height of at least 200 mm is required above the unit’s connection box.
1.4.2 Requirements for underlying surface
When fitting the unit directly to an existing surface - i.e. without using the mounting
base (accessory) - the surface must be:
● level
● horizontal (±3 mm per metre
● hard
● vibration-resistant
1.4.3 Requirements for duct system
Silencers The duct system must be fitted with silencers specified by the Project Manager,
which meet the requirements of the operating area.
3005007-2018-02-22 Product information
8/32

Bends A duct bend may be fitted immediately after the unit, because the airflow in the
spigot has a uniformly moderate speed profile, which results in negligible system
pressure loss.
Insulation The duct system must be insulated against:
● condensation
● sound leakage
● heating/cooling losses
Condensation Condensation in the ducts may occur when the exhaust/outdoor air has high hu-
midity. EXHAUSTO recommends a condensation outlet is also fitted at the lowest
point in the ducts.
No duct connection If one or more of the spigots is not connected to a duct: Fit a
protective net to the spigots with a maximum mesh width of 20
mm.
1.5 Description
1.5.1 The VEX unit design
VEX200L - V1 The drawing below illustrates the construction of the unit (without service doors).
RD11694-02
2,1,A
1,2,A
1,1,A
2,2,A
1 2201614
12 10 5 37
18 1513
11
19
49 86
17
3005007-2018-02-22 Product information
9/32

VEX200L - V2
2,1,A
1,2,A
1,1,A
2,2,A
RD11695-02
435610
13 16 20 217
19 1511
14
18
1987
12
VEX200R - V1 The drawing below illustrates the construction of the unit (without service doors).
RD11696-02
2,1,A
1,2,A
1,1,A
2,2,A
12111054
20 16 137
18 153 19
149 812
6
17
3005007-2018-02-22 Product information
10/32

VEX200R - V2
2,1,A
1,2,A 1,1,A
2,2,A
RD11697-02
13
14
1620117 1521918
410128117935 6
Pos. no. Part Function
1 Spigot 2.1.A Outdoor air spigot The spigot can also be positioned on the
top or in the bottom of the unit (2,1,B) – though only on
units with compact filters
2 Closing damper LS Closing damper, outdoor air, LSF (accessory)
3 Closing damper LS Closing damper, exhaust air, LSA (accessory)
4 Spigot 1.2.A Exhaust air spigot The spigot can also be positioned at the
bottom of the air handling unit (1.2.B).
5 Fan unit For extract air/exhaust air
6 MPT1 Measurement of pressure in extract air duct
7 Rotary heat exchanger Conducts heat from extract air to supply air
8 Step motor Drives the rotary heat exchanger via the drive belt
9 Rotor control Controls and monitors the step motor
10 Extract air filter Filters extract air.
11 Trim damper The trim damper (accessory) ensures there is pressure bal-
ance across the rotor and seals to prevent extract air from
entering the supply air. Used with blowout zone (accessory)
12 Spigot 1.1.A Extract air spigot The spigot can also be positioned in the
bottom of the unit (1,1,B) – though only on units with com-
pact filters.
13 Heating coil Heats supply air if heat recovery is insufficient (accessory)
14 Spigot 2.2.A Supply air spigot. The spigot can also be positioned on the
top of the air handling unit (2.2.B)
15 HMI panel Operation of the control system
16 Fan unit For outdoor air/supply air
3005007-2018-02-22 Product information
11/32

Pos. no. Part Function
17 MPT2 Measures pressure in supply air duct
18 Connection box Connection box for supply voltage, external ventilation
components, HMI panel, BMS and Ethernet
19 Control system Positioning of control system components
20 Outdoor air filter Filters outdoor air
Cabinet The inside and outside of the cabinet is made of Aluzinc® and insulated with 50
mm mineral wool.
Ventilators The unit has a centrifugal fan for extract air and a centrifugal fan for supply air
Rotary heat ex-
changer
The rotary heat exchanger is driven by a step motor with rotor control, which con-
trols the rotor's speed.
Filters There are built-in compact filters (as shown on the drawings on the previous pa-
ges) or bag filters on both the extract air and supply air side.
3005007-2018-02-22 Product information
12/32

1.6 Principal dimensions
VEX240, V1
MN
N
M
62 273
554,5 381
1490
62273
62 273 62273
330
805
860 10
105
12
62
O
315
O315
430
62
O
315
O
315
330
12
430
285
789
1062
285
789
RD11666-01
*)
*)
NB The drawing shows all of the spigot positioning options. Spigot positioning
marked with * is not available for VEX units with a bag filter.
3005007-2018-02-22 Product information
13/32

VEX240, V2
MN
N
M
1490
860 10
554,5 381
62 273 62273
62 273 62273
O
315
O
315
O
315
O
315
330
62
12
62
428
805
105
430
12
330
285
789
1062
285
789
RD11667-01
*)
*)
NB The drawing shows all of the spigot positioning options. Spigot positioning
marked with * is not available for VEX units with a bag filter.
3005007-2018-02-22 Product information
14/32

2. Handling
2.1 Unpacking
Supplied compo-
nents
The following components are supplied:
● VEX unit
● Supplied with accessories (as indicated in the checklist on the front page of
the instructions)
Packaging The unit is delivered attached to a disposable pallet and packed in clear plastic.
NB Once the plastic has been removed, the unit must be protected against dirt
and dust:
●The covers on the spigots must not be removed until the spigots are
connected to the ventilation ducts.
●Whenever possible, keep the unit closed during fitting.
The unit should be
cleaned before it is
used.
Once the VEX unit is fitted, it must be checked and thoroughly cleaned. All dust,
debris and metal shavings must be vacuumed up.
2.2 Transport
Transport equip-
ment
Transport the VEX unit in one of the following ways:
Method Drawing
Manual transport:
Lifting brackets for
manual transport can
be fitted as shown on
the drawing:
RD10541-01
RD10542-01
3005007-2018-02-22 Handling
15/32

Method Drawing
Using pallet truck or
fork-lift truck:
Lift the VEX unit on the
disposable pallet.
IMPORTANT: If the
disposable pallet can-
not be used, the forks
on the lifting equipment
must be long enough
to prevent damage to
the bottom of the unit.
RD12463-01
Crane:
Never lift the
VEX unit
with the lift-
ing brackets
by using a
crane.
Use straps and lifting
yokes to prevent dam-
age to the unit.
RD13029-01
2.2.1 Weight
The unit weighs 267 kg
2.2.2 Passage through openings
Height The unit's height is 1,167 mm
Width The list (below) shows how wide an opening has to be for the unit to pass through:
If the opening width is* Then
Less than 815 mm the unit will not pass through
Between 815 and 868 mm remove doors, see relevant section
Greater than 868 mm the unit can pass through
* Measurements are based on the exact dimensions of the VEX unit.
3005007-2018-02-22 Handling
16/32

2.2.3 Internal transport with reduced weight
Weight reduction The weight can be reduced during transport by removing the service doors and
fan units.
Removing the serv-
ice doors
To remove the service doors:
Detail A
A
RD12580-01
A
● Open both doors
● Tap the hinge door pin out using a small
pin bolt or similar
● Lift the doors off
3005007-2018-02-22 Handling
17/32

To remove the fan
unit
RD11568-01
Step Action
1 Remove the fixing screws on the sliding rail (out towards the oper-
ating side)
2 Loosen the bindings on the motor cable and the measuring hose
3 Pull the fan unit out to the end-stop (a screw on each rail acts as a
stop)
4 Remove the supply cable and modbus cable in the motor control
box
5 Remove the measuring hose which is fixed to the intake
6 Remove the two end-stop screws (one on each rail). The fan unit
can now be lifted off.
NB: A single fan unit weighs 20 kg.
3005007-2018-02-22 Handling
18/32

3. Mechanical assembly
3.1 Installing the unit
Description The VEX unit is installed so that it is horizontal.
3.1.1 Installed directly onto the floor
The requirements for the floor surface must be met, see the section entitled "Re-
quirements for underlying surface", chapter 1.
NB After installation, check the VEX unit is completely level.
3.1.2 Installing on mounting base
The EXHAUSTO mounting base enables the air handling unit to be installed correct-
ly. The base is equipped with adjustable levelling screws, so that the air handling unit
can be fitted horizontally on a surface that is not level ( +/- 20 mm per metre). See
diagram no. 3002646 for installing on the mounting base.
Diagram showing
levelling screw po-
sitions
1492
804,5 754,5
1442
RD12464-01
3005007-2018-02-22 Mechanical assembly
19/32

4. Electrical installation
4.1 Electrical installation
See the attached instructions “VEX240-250 Electrical installation guide for EXact2
control system”:
VEX240/250
El-installationsguide
for EXact2 automatik
El-installation.....................................................Kapitel 1 + 2
Original brugsanvisning
3005067-2014-06-18 El-guide til VEX240-250H
EXHAUSTO A/S
Odensevej 76
DK-5550 Langeskov
Tel. [phone]
Fax [phone]
[email protected]
www.exhausto.dk
3005007-2018-02-22 Electrical installation
20/32
