exline K2.NLC1 User manual

K2.NLC1 Assembly Instructions
Attach lower column to base plate with (2) Short Knobs;
Attach upper column to canopy with (2) Short Knobs;
Cover with Gusset Caps
Step 1:
Connect the upper column to the lower column
using (2) Short Knobs
Step 2:
Gusset Cap
Short Knob
Short Knob

K2.NLC1 Assembly Instructions
Begin assembling NLC counter; Attach the front
and side panels using (2) Long Knobs
Step 3:
Long Knob
Step 4:
Attach the wings to the columns using Gripper
Knobs

K2.NLC1 Assembly Instructions
Attach the other side panel with (2) Long Knobs
Long Knob
Reaching through the opening on top; Connect
the door panel with (4) Long Knobs
Step 5:
Step 6:
Long Knob

K2.NLC1 Assembly Instructions
Lower the shelves into position
Step 7:
Reaching through the door; Lower the counter
top into position and secure with (2) Long Knobs
Step 8:
Long Knob

K2.NLC1 Assembly Instructions
Place the NLC counter into position
Step 9:
Finished
