Experia Interactive LED Fanlite User manual

- 1 -
Instruction Manual
3+ years
WARNING:
CHOKING HAZARD –Small Parts
Not suitable for children under 3 years.
For optimal results, please read and follow
instructions carefully
Please keep for future reference
Interactive LED
Fanlite

- 2 -
Congratulations on the purchase of your LED Fanlite!
The LED Fanlite has been designed specifically for people with special needs
and should, if used in accordance with these guidelines offer years of switching
learning and fun!
The LED Fanlite offers endless opportunities to develop numerous skills
including vocalisation, colour recognition, cause and effect and many more.
The LED Fanlite is controlled by sound through its integral microphone or
external microphone (supplied).
It utilises the latest LED technology to ensure consistently bright lighting and
there is no requirement to change a lamp.
Please ensure you read and follow these Instructions carefully before
operating the unit. Please keep this manual for future reference.
Features
Wirefree Switching
Ergonomic Design
Latest LED Technology
No Lamp Change –LED
8 switching Modes (3 automatic, 5 sound activated)
Safe Low Voltage –(transformer supplied)
Easy maintenance
Integral Microphone
External Microphone Socket
External Microphone (supplied)
Sensitivity Control
Speed Control
Durable
Easy to use
2 Year Manufacturers Guarantee (Collect and Return)
Pack contents
1 x Interactive LED Fanlite
1 x Low Voltage Transformer
1 x Microphone (external)

- 3 -
Getting Started
1. Securely mount the LED Fanlite on a wall using an experienced electrician
or competent handyman.
2. Connect the round XLR connector from the Low Voltage transformer to
the socket on the side of the unit.
3. Connect the standard 3 pin plug to a mains outlet.
4. The LED Fanlite is now ready to use.
5. Press the mode select button to choose the program required. The mode
number can be seen on the LED display.
6. Adjust the sensitivity to suit a person’s voice/sound when using a sound
activated mode.
7. Adjust the speed control to increase/decrease the speed that the colours
change when using the automatic modes.
Please note: Only use the transformer supplied. Use of a different
transformer may result in damage to the product and void the warranty.
For warranty information please see separate warranty card supplied.
Additional Notes
An external microphone can be connected via the ¼ inch jack socket located on
the front of the LED Fanlite.
Cleaning and Maintenance
The LED Fanlite should be cleaned with a damp soft cloth. A non abrasive
cleaning agent may be used for stubborn stains. NO LIQUID MUST ENTER THE
LED FANLITE.
The LED Fanlite has been designed for use by people with special needs,
however this does NOT mean it is unbreakable. Every care must be taken to
ensure the LED Fanlite is not hit with anything and that the LED Fanlite is not
pushed or pulled.

- 4 -
Modes of Operation
There are 8 modes of operation, selected by pressing the mode button and
identified on the LED display available, as follows:
1. Automatic Mode –the light appears one section at a time working from the
left to the right.
2. Automatic Mode –the light appears one section at a time starting from the
left building to the right until all lights are illuminated. The lights then go
out one section at a time working back from the right to left.
3. Automatic Mode –the light appears one section at a time starting from
both sides working towards the centre and back out again.
4. Sound to light –whenever a sound is heard a light appears on the Fanlight
in a random manner.
5. Sound to light –the lights build up depending on the volume one section
at a time. The lights pause at the top then go back down and the lights
cease to display unless a further sound is heard.
6. Sound to light –the light builds up depending on volume numerous
sections at a time. The lights pause at the top then go back down and the
lights cease to display unless a further sound is heard.
7. Sound to light –light sections from the outside of the LED Fanlite
illuminate when sound is heard. When no sound is heard the lights will go
out slowly moving outward.
8. Sound to light –light sections from the inside of the LED Fanlite illuminate
when sound is heard. When no sound is heard the lights will go out slowly
moving inward.

- 5 -
Troubleshooting
Q. The LED Fanlite doesn’t work.
A1. Is it switched on? If so,
A2. Is it in the correct mode? If so,
A3. Is the sensitivity increased if in sound activated mode? If so,
A4. Is the speed increased if in automatic mode? If so,
A5. Please contact us.
Contact Details
For USA please email [e-mail]
For Canada please email [e-mail]
For UK and rest of the world email [e-mail]
Telephone: [phone].
Please note: email is our support teams preferred communication and this takes
precedence over telephone calls.
QUESTIONS & IDEAS?
If you have an idea on how to improve this product or want to see your product idea
realised, please email: [e-mail].
All ideas are presented to our OT, technical and finance department and if all
procedures are passed we will contact you to discuss your idea further.
We can’t promise to develop every product but if it’s a great idea, we’ll try!
Technical Specifications:
Product code –48 00 91
Supply –240vAC 13mA 50/60Hz
Load –9vAC 5A Max
Manufactured proudly in the UK by:
Experia
Acorn Phase III, High Street, Grimethorpe, Barnsley, South Yorkshire, S72 7BQ.
© Copyright 2010 Experia All rights reserved Experia. Experia is a registered trademark.
