Explore Scientific WSH4002 User manual

EN INSTRUCTION MANUAL...............2
IT ISTRUZIONI PER L’USO.............. 16
DE BEDIENUNGSANLEITUNG .......... 30
FR MODE D‘EMPLOI....................... 44
ES MANUAL DE INSTRUCCIONES.... 58
Art.No.: WSH4002
WEATHER STATION
STAZIONE METEO
WETTERSTATION
STATION MÉTÉO
ESTACIÓN METEOROLÓGICA
*Radio-controlled clock function not available in every territory / Funzione di orologio radiocontrollati non disponibile in ogni territorio / Funkuhrfunktion nicht in jederm Gebiet verfügbar / La fonction
d‘horloge radio-piloté n‘est pas disponible dans tous les territoires / La función de reloj radiocontrolado no está disponible en todos los territorios

2
ABOUT THIS INSTRUCTION
MANUAL
These operating instructions are to be considered
a component of the device.
Please read the safety instructions and the operating
instructions carefully before use.
Keep these instructions for renewed use at a later date.
When the device is sold or given to someone else, the
instruction manual must be provided to the new owner/
user of the product. The device is intended only for
indoor use.
GENERAL WARNINGS
•Risk of electric shock — This device contains
electronic components. Only use the device as
described in the manual; otherwise, you run the
risk of an electric shock.
• Choking hazard —Children should only use the
device under adult supervision. Keep packaging
material, like plastic bags and rubber bands, out
of the reach of children, as these materials pose a
choking hazard.
• Risk of chemical burn —Keep batteries out of the
reach of children! Make sure you insert the bat-
teries correctly. Leaking battery acid can lead to
chemical burns. Avoid contact of battery acid with
skin, eyes and mucous membranes. In the event
of contact, rinse the affected region immediately
with a plenty of water and seek medical attention.
• Risk of re/explosion —Do not expose the device
to high temperatures. Use only the recommended
batteries. Do not short-circuit the device or batter-
ies, or throw them into a re. Excessive heat or im-
proper handling could trigger a short-circuit, a re,
or an explosion.
• Do not disassemble the device. In the event of a
defect, please contact your dealer. The dealer will
contact the Service Centre and can send the de-
vice in to be repaired, if necessary.
• Use only the recommended batteries. Always re-
place weak or empty batteries with a new, com-
plete set of batteries at full capacity. Do not use
batteries from different brands or with different
capacities. The batteries should be removed from
the unit if it has not been used for a long time.

3
EN
IT
DE
FR
ES
SCOPE OF DELIVERY
Weather station, Outdoor sensor, Operating instruc-
tions, 2x AA batteries, 2x AAA batteries.
BEFORE YOU BEGIN
• We recommend using alkaline batteries. If temper-
atures regularly fall below 0°C (32°F), we recom-
mend using lithium batteries.
• Avoid using rechargeable batteries. (Rechargeable
batteries cannot maintain correct power require-
ments.)
• Insert batteries before rst use, matching the polar-
ity in the battery compartment. 2x AA Batteries are
required for the Weather station and 2x AAA Batter-
ies are required for the Outdoor sensor.

4
PRODUCT OVERVIEW
1. Press [
LIGHT / SNOOZE
] to activate the backlight
for 5 seconds or to activate the snooze function
to delay the alarm by 8 minutes.
2. Press and hold [ ] to enter time and date
setting mode.
3. While in setting mode, press [ ] to increase
one unit, press and hold to increase rapidly.
4. While in setting mode, press [ ] to decrease
one unit, press and hold to decrease rapidly.
5. Press [
MEM
] to toggle the display among
current, maximum and minimum recording of
temperature/humidity. Press and hold to clear
the max/min memory records.
6. Press [ ] to turn on/off the alarm.
7. Press [ ] to toggle between time and
alarm display. Press and hold to enter alarm
setting mode.
8. While in normal display mode, press [ ]*
to initiate RCC receiving. Press and hold to set
RCC on or off.
  
   

LIGHT / SNOOZE

*Radio-controlled clock function not available in every territory

5
EN
IT
DE
FR
ES
9. Press [ ] to toggle between outdoor sensor
channel 1-3. Press and hold to initiate outdoor
sensor search.
10. Wall Mount.
11. Battery compartment.
12. Table stand.
AA 1.5V LR6 / R6
AA 1.5V LR6 / R6
 

OUTDOOR SENSOR
1. Battery compartment door.
2. Battery compartment.
3. TX (Initiate main unit search).
4. Channel switch.





6
BUTTON
MODE
LIGHT / SNOOZE
MEM
Standard
mode
PRESS
Turn on backlight
for 8 seconds
(SNOOZE when
alarm is ringing)
_______ _______ _______
Toggle the display
among current,
maximum and
minimum record-
ing of tempera-
ture/humidity
Turn Alarm
on/off
Stop alarm
(ringing)
Toggle
between time
and alarm
display
Initiate
RCC
receiving
Toggle between
outdoor sensor
channel 1-3.
HOLD _______
Enter into
time
and date
setting
_______ _______ Clear the max/min
memory records. _______ Enter into alarm setting
Turn RCC
on/off
Initiate outdoor
sensor search.
Time
setting
mode
PRESS _______ Conrm
setting Increase Decrease _______ _______ _______ _______ _______
HOLD _______ _______ Quick
Increase
Quick
Decrease _______ _______ _______ _______ _______
Alarm
setting
mode
PRESS _______ _______ Increase Decrease _______ _______ _______ _______ _______
HOLD _______ _______ Quick
Increase
Quick
Decrease _______ _______ _______ _______ _______

7
EN
IT
DE
FR
ES
LCD DISPLAY
1. Weather Forecast symbols
2. Outdoor Temperature display
and Indoor Temperature display
3. Outdoor humidity
4. Indoor humidity
5. Calendar
6. Time/Alarm display
[ ] Ice alert indicator
[MAX/MIN] Max/Min
temperature/humidity
indicator
[] Low battery indicator
[] RF Indicator
[] Outdoor channel indicator
[] Indoor indicator
[] Time zone indicator
[] RCC signal indicator
[] Alarm
 





8
GETTING STARTED
INSERT BATTERIES
1.Remove the battery door from the back.
2.Insert 2x AA (LR6)/1.5V batteries. Please ensure
the polarities (+/-) of the batteries match upon in-
stallation.
3.Reattach the battery door.
NOTE: Replace batteries when [ ] displays, or
when the display is dim.
OUTDOOR SENSOR
The main unit can receive data from up to 3 outdoor
sensors. 1 Sensor is included with delivery.
1.Remove the battery door from the back.
2.Select a channel, then press TX.
3.Insert 2x AAA (LR03)/1.5V batteries. Please ensure
the polarities (+/-) of the batteries match upon in-
stallation.
4.Reattach the battery door.
5.Place the sensor within 30 m (98 ft) of the main unit
using the table stand or wall mount.
TO SEARCH FOR A SENSOR:
The main unit will automatically search for a new sen-
sor after the batteries are installed. To manually initi-
ate a outdoor sensor search, press and hold [ ].
NOTE: The transmission range may vary depending
on many factors. You may need to experiment with
various locations to get the best results.
CLOCK
CLOCK RECEPTION
1.When you insert or replace the batteries, RCC recep-
tion is initiated. To manually start RCC reception
press the [ ] button.
2.The receiving process duration is 7 minutes.
3.During receiving process, the RCC signal symbol
shows: [ ].
4.If the RCC receiving process is successful, a com-
pleted RCC symbol [ ] will be shown in the display
and the date and time will be set automatically. If it
fails within 7 minutes, RCC setting will quit automati-
cally. If that happens, press and hold the [ ] but-
ton to re-initiate RCC receiving.

9
EN
IT
DE
FR
ES
5.RCC receiving will automatically start at 2:03, 3:03,
4:03, 5:03 every night. Auto receiving function will
cease if it is successful.
6.To stop RCC reception, press and hold the [ ]
button.
7.If the device is still not receiving the signal, please
proceed to set the time manually.
SET THE CLOCK MANUALLY
1. Press and hold [ ] button to enter into time and
date setting.
2.The setting parameter will flash.
3.Press [+] button once, the figure will increase 1
unit. Press and hold the [+] button, the figures will
increase rapidly.
4.Press [–] button once, the figure will decrease 1
unit. Press and hold the [–] button, the figures will
decrease rapidly.
5.Press [ ] button to confirm setting and enter to
next parameter.
6.Sequence of setting: Time zone 12/24h format
Hour Minute Year Calendar format (day-
month/month-day) Month Day Temperature
unit (°C/°F)  Exit
7. If there is no action in 20 seconds or if you press and
hold [ ] button, the setting will be saved and you
will exit the setting mode.
TIME ZONE SETTING
To set a different time zone, proceed as follows:
1.Press and hold [ ] button to enter time setting.
2.The setting parameter will flash.
3.Press [+] button to increase or [–] button to decrease
the Time zone offset.
4.Press and hold [ ] button to confirm setting and
exit.
°C/°F SETTING
1. Press and hold [ ] button to enter time setting.
2. Press [ ]button several times until you reach
the Temperature unit setting.
3.Press [+] or [-] button to switch Celsius (°C) / Fahr-
enheit (°F).
4.Press and hold [ ] button to confirm setting and
exit.

10
ALARM
SETTING/ADJUSTING ALARM TIME
1. Press [ ] to display the alarm.
2. Press and hold [ ] button to enter alarm setting
mode.
3. The setting parameter will flash.
4. Press [+] or [-] button to set the desired data.
5. Press [ ] button to confirm setting and exit.
6. Alarm will turn on automatically when alarm setting
is finished.
TURN ON/OFF ALARM
Press the [ ] button to turn on/off the alarm.
OPERATION
1.At the set time, alarm signal rings.
2.During the alarm, press the [
LIGHT / SNOOZE
] button
to delay the alarm by 8 minutes.
3.If you do not press any button to stop the alarm, it
will automatically turn off after 2 minutes.
4. To stop the alarm, press [ ] or any other button,
except for SNOOZE.
5. The alarm will start again at the next alarm time,
unless you switch off the alarm function by press-
ing the [ ] button until the alarm is set to off.
WEATHER FORECAST
This device forecasts the next 12-24 hours of weather
within a 30-50 km (19-31 mile) radius with a 75% ac-
cuarcy.
SYMBOL DESCRIPTION
Sunny
Sunny to cloudy
Cloudy
Cloudy to rain
Cloudy to snow

11
EN
IT
DE
FR
ES
ICE ALERT
If the channel 1 sensor falls between 3°C to -2°C
(37°F to 28°F), the ice alert indicator [ ] will dis-
play, and will disappear once the temperature is out
of this range.
TEMPERATURE AND HUMIDITY
The indoor temperature is always displayed in the right
corner of the screen. To receive outdoor temperature
you can connect up to 3 outdoor sensors to the main
unit.
Press the [ ] button to toggle between Channel 1-3.
MAX/MIN MEMORY
To toggle between current, minimum and maximum
records for the selected sensor press [
MEM
] repeat-
edly. To clear records, press and hold [
MEM
].
NOTE: When the indoor temperature is lower than -5 °C
(23.0 °F), the screen displays LL.L. When the tempera-
ture is higher than 50 °C (122.0 °F), the screen displays
HH.H.
BACKLIGHT
Press [
LIGHT / SNOOZE
] to activate backlight for 5 sec-
onds.
SPECIFICATIONS
MAIN UNIT:
Dimensions
185 x 26 x 121 mm (L x W x H)
Weight
280 g (Exclude batteries)
Power:
2x AA (LR6) 1.5V batteries
TEMPERATURE:
Indoor temperature display range:
-5°C to +50°C (23°F to 122°F)
Outdoor temperature display range:
-20°C to +60°C (-4°F to 140°F)

12
Accuracy:
+/- 1°C to +40°C: other +/- 2°C
Resolution:
0.1°C (0.2°F
HUMIDITY:
Indoor/outdoor humidity range:
25% - 95% RH
Accuracy:
+/- 5% (40%-80%), other +/-7%
OUTDOOR SENSOR:
Dimensions:
48 x 31 x 96 mm (L x W x H)
Weight:
45 g (Exclude batteries)
Transmission range:
30 m (98 ft)
Temperature range:
-20°C to 60°C (-4°F to 140°F)
Signal frequency:
433 MHz
Maximum transmission power:
under 10mW
Power:
2x AAA (LR03) 1.5V batteries

13
EN
IT
DE
FR
ES
EC DECLARATION OF CONFORMITY
Hereby, Bresser GmbH declares that the
equipment type with part number:
WSH4002 is in compliance with Directive:
2014/53/EU. The full text of the EU declaration of
conformity is available at the following internet ad-
dress: www.bresser.de/download/WSH4002/CE/
WSH4002_CE.pdf
RCM DECLARATION OF CONFORMITY
The product complies with electrical
safety, EMC and radio spectrum regulatory
requirements for products supplied to the
Australia or New Zealand market.
NOTES ON CLEANING
• Remove the batteries before cleaning.
• Only use a dry cloth to clean the exterior of the
device. To avoid damaging the electronics, do not
use any cleaning uid.
• Protect the device from dust and moisture.
DISPOSAL
Dispose of the packaging materials properly,
according to their type, such as paper or card-
board. Contact your local waste-disposal ser-
vice or environmental authority for information on the
proper disposal.
Do not dispose of electronic devices in the
household garbage!
As per the Directive 2002/96/EC of the Euro-
pean Parliament on waste electrical and electronic
equipment and its adaptation into German law, used
electronic devices must be collected separately and
recycled in an environmentally friendly manner.
In accordance with the regulations concern-
ing batteries and rechargeable batteries, dis-
posing of them in the normal household
waste is explicitly forbidden. Please make sure to
dispose of your used batteries as required by law — at
a local collection point or in the retail market. Dis-
posal in domestic waste violates the Battery Direc-
tive. Batteries that contain toxins are marked with a sign
and a chemical symbol.

14
Cd¹ Hg² Pb³
1battery contains cadmium
2battery contains mercury
3battery contains lead
WARRANTY & SERVICE
The regular guarantee period is 2 years and begins
on the day of purchase. To benet from an extended
voluntary guarantee period as stated on the gift box,
registration on our website is required.
You can consult the full guarantee terms as well
as information on extending the guarantee period
and details of our services at www.bresser.de/
warranty_terms.
Would you like detailed instructions for this product
in a particular language? Then visit our website via
the link below (QR code) for available versions.
Alternatively you can also send an email to
[e-mail] or leave a message on +49 (0)
28 72 – 80 74-220*. Please always state your name,
precise address, a valid phone number and email
address, as well as the article number and name.
*Number charged at local rates in Germany (the amount
you will be charged per phone call will depend on the tariff
of your phone provider); calls from abroad will involve
higher costs.
www.bresser.de/warranty_terms

15
EN
IT
DE
FR
ES

16
INFORMAZIONI SUL MANUALE DI
ISTRUZIONI
Il presente manuale è parte integrante del prodot-
to.
Non azionare il dispositivo prima di aver letto attenta-
mente le istruzioni di sicurezza e le istruzioni per l'uso
in esso contenute.
Il manuale deve essere conservato in modo che sia
possibile consultarlo anche in seguito. Nel caso in cui il
dispositivo venga venduto o ceduto a terzi, dovrà essere
fornito al nuovo possessore del dispositivo. Il disposi-
tivo può essere utilizzato esclusivamente in ambienti
interni.
AVVERTENZE GENERALI
•RISCHIO DI FOLGORAZIONE — Questo apparec-
chio contiene componenti elettronici azionati da
una sorgente di corrente (alimentatore e/o batte-
rie). L’utilizzo deve avvenire in stretta conformità
con quanto prescritto nel presente manuale. In
caso contrario, non sarà possibile escludere il ri-
schio di infortuni elettrici.
• PERICOLO DI SOFFOCAMENTO —I bambini pos-
sono utilizzare il dispositivo solo sotto la vigilanza
di un adulto. I materiali di imballaggio, i sacchetti
di plastica e le fasce in gomma possono causare
soffocamento e, pertanto, devono essere conser-
vati in modo che i bambini non riescano a raggiun-
gerli.
• RISCHIO DI USTIONE CHIMICA —Tenere le bat-
terie fuori dalla portata dei bambini. Accertarsi di
installare le batterie nel modo corretto. La fuoriu-
scita di acido dalle batterie può causare ustioni
chimiche. Evitare che l’acido venga a contatto con
pelle, occhi e mucose. In caso, lavare immedia-
tamente le parti interessate con un’abbondante
quantità di acqua e rivolgersi a un medico.
• RISCHIO DI INCENDIO/ESPLOSIONE —Non
esporre il dispositivo a temperature elevate. Utiliz-
zare solo le batterie consigliate. Evitare che pos-
sano vericarsi corto-circuiti a carico del disposi-
tivo o delle batterie. Non gettare il dispositivo o le
batterie nel fuoco. Il surriscaldamento o l’impiego
inappropriato potrebbe generare un cortocircuito,
un incendio o un'esplosione.

EN
IT
DE
FR
ES
17
• Non smontare il dispositivo. Qualora dovesse ri-
levarsi difettoso, rivolgersi al proprio rivenditore
autorizzato. Il rivenditore provvederà a contattare
il Centro assistenza e, se necessario, spedirà il di-
spositivo in riparazione.
• Utilizzare solo le batterie consigliate. Le batterie
scariche o esaurite devono essere sempre sostituite
con una serie completa di batterie nuove di capacità
massima. Non utilizzare batterie di marche o capaci-
tà diverse. Rimuovere le batterie dall’unità se questa
rimarrà inutilizzata per un periodo prolungato.
ACCESSORI IN DOTAZIONE
Stazione meteo, sensore per esterni, istruzioni per
l’uso, due batterie di tipo AA, due batterie di tipo AAA.
PRIMA DI INIZIARE
• Si consiglia l'uso di batterie alcaline. Se le tempe-
rature tendono regolarmente a scendere sotto 0 °C
(32 °F), tuttavia, potrebbe essere preferibile l’impie-
go di batterie al litio.
• Evitare di utilizzare batterie ricaricabili (le batterie
ricaricabili non soddisfano i requisiti di alimenta-
zione appropriati).
• Al primo utilizzo, avere cura di inserire le batterie in
modo da rispettare la polarità indicata nel relativo
vano. Sono necessarie due batterie AA per la sta-
zione meteo e due batterie AAA per il sensore per
esterni.

18
INFORMAZIONI GENERALI SUL
PRODOTTO
1. Premere [
LIGHT / SNOOZE
] per attivare la retroil-
luminazione per 5 secondi o per attivare lo snoo-
ze e ritardare la sveglia di 8 minuti.
2. Premere e tenere premuto [ ] per accede-
re all’impostazione dell’ora e della data.
3. In modalità impostazione, premere il tasto [ ]
per aumentare il valore di una unità; tenerlo pre-
muto per incrementare il valore rapidamente.
4. In modalità impostazione, premere il tasto [ ]
per ridurre il valore di una unità; tenerlo premu-
to per decrementare il valore rapidamente.
5. Premere [
MEM
] per visualizzare alternati-
vamente i record dei valori di temperatura/
umidità corrente, massima e minima. Tenere
premuto per cancellare dalla memoria i record
relativi ai valori di massima/minima.
6. Premere [ ] per attivare/disattivare la sveglia.
7. Premere [ ] per passare dalla visualiz-
zazione dell'ora a quella della sveglia e vice-
versa. Tenendo premuto il tasto, è possibile
  
   

LIGHT / SNOOZE


EN
IT
DE
FR
ES
19
modicare l’impostazione della sveglia.
8. Premere [ ]* per avviare la ricezione RCC.
Tenere premuto per accendere o spegnere
l'RCC.
9. Premere [ ] per alternare i canali 1-3 del
sensore per esterni. Tenere il tasto premuto
per avviare la ricerca del sensore per esterni.
10. Montaggio a parete.
11. Vano batterie.
12. Supporto da tavolo.
SENSORE PER ESTERNI
1. Sportello del vano batterie
2. Vano batterie
3. TX (avvio della ricerca dell’unità principale)
4. Interruttore per il canale




AA 1.5V LR6 / R6
AA 1.5V LR6 / R6
 
 
*Funzione di orologio radiocontrollati non disponibile in ogni territorio

20
TASTO
MODALITÀ
LIGHT / SNOOZE
MEM
Standard
PREMERE
PER
Accendere la
retroilluminazione
per 8 secondi
(SNOOZE mentre
la sveglia suona)
_______ _______ _______
Visualizzare al-
ternativamente i
record dei valori
di temperatura/
umidità corren-
te, massima e
minima
Attivare o
disattivare
la sveglia
Interrompere
la sveglia
(mentre
suona)
Passare dalla
visualizzazio-
ne dell’ora a
quella della
sveglia e
viceversa
Avviare la
ricezione
RCC
Alternare i
canali 1-3
del sensore
per esterni
TENERE
PREMUTO
PER
_______
Accedere alla
impostazione
dell'ora e
della data
_______ _______
Cancellare
dalla memoria i
record relativi ai
valori di massi-
ma/minima
_______
Accedere alla
modalità
impostazione
della sveglia
Accen-
sione/
spegni-
mento
dell'RCC
Avviare la
ricerca del
sensore per
esterni
Impo-
stazione
dell'ora
PREMERE
PER _______ Confermare l'ora Aumentare Diminuire _______ _______ _______ _______ _______
TENERE
PREMUTO
PER
_______ _______ Aumentare
rapida-
mente
Diminuire
rapida-
mente
_______ _______ _______ _______ _______
Impo-
stazione
dell'ora
di sveglia
PREMERE
PER _______ _______ Aumentare Diminuire _______ _______ _______ _______ _______
TENERE
PREMUTO
PER
_______ _______ Aumentare
rapida-
mente
Diminuire
rapida-
mente
_______ _______ _______ _______ _______
