Campbell DIGITAL WORKSHOP WEATHER STATION User manual

Assembly Guide
DIGITAL WORKSHOP
WEATHER STATION

Once you’ve received the equipment, please set it up as described and power up the system. The data
logger will automatically start sending data to Campbell CLOUD and enable Campbell Scientific to confirm
the operation of the system. A follow-up email will be sent with further instructions for you to log into
Campbell CLOUD and verify the data is flowing as expected.
Note: The data logger has been configured for the UTC time zone to support the needs of the workshop.
Please leave the time zone at this setting.
Important Information

Parts Included
ClimaVUE™50 Sensor
Mounting Plate
–CR1000X
–Cellular Module
Sensor Stand
Antenna
Cables
–Micro USB
–ClimaVUE50 Cable
–SC12 Cable

Install stand and mount ClimaVUE50 sensor
Assembly Instructions

Connect ClimaVUE50 cable to sensor

Plug ClimaVUE50 sensor cable into CR1000X datalogger

Plug in CR1000X power cable

Plug micro USB into CR1000X

Install SC12 into CR1000X and cellular module

Install antenna into cellular module

Finished Model
