Expobar BRILLIANCE Installation guide

EVERY WEEK
Insert the card in the card reader with the chip downwards,
toggle through the menus using "-" or "+" until CLEANING
WITH TABLET is shown on the display, press "enter" to start
the operation. Remove the card when the display shows OPEN
DOOR ADD TABLET. The display on the machine gives you
step-by-step information of what to do. The function cleans the
inside of the espresso group, the lters and pipes. The cleaning
programme takes about 10 minutes and about 1 litre of water
mixed with detergent comes out from the drain. Finally, make
one cup of coffee and throw it away!
EVERY DAY
Insert the card in the card reader with the chip downwards,
toggle through the menus using "-" or "+" until RINSING is
shown on the display, press "enter" to start the operation.
Rinsing performs a routine rinsing of the machine feeding
pipes. First, the mixer pipes are rinsed and the espresso
group pipes last. You can interrupt the process by pressing
"canc". The rinsing takes about 1.5 minutes and about 150 ml
of water comes out from the drains.
Rinsing and cleaning
Fill ingredients
Hygiene and maintenance - Expobar Brilliance
1.- Open the door of the machine.
2.- Open the top lid.
3.- Remove the ingredients containers (to avoid unnecessary
spillage in the machine).
4.- Lift the lid and ll the ingredient containers.
5.- Ret the lids and close the covers.
1.- Open the door of the machine.
2.- Open the top lid.
3.- Open the lid of the coffee funnel.
4.- Fill the funnel with coffee.
Check that the feeding pipes from the ingredients containers are directed straight into the steam
trap (A). Attention! Always use soluble powder drinks suitable for automated vending machines.
If other types of soluble powders are used, the mixer may be clogged and water may leak out.
Attention! Use only natural, roasted coffee beans. Coffee beans of an
inferior quality (roasted with a small amount of added sugar) may clog the
bean funnel.
CLEANING WITH
TABLETS
RINSING
REV. 100318
QUICK MANUAL EN
Product number 1750017

1. Loosen the drain
hose (A) and turn
the selector (B)
anticlockwise.
2. Loosen the
mixer bowl. Pull
straight out (C).
3. Loosen the
whisk (D) by
pulling it straight
out.
4. Loosen the
xing plate. Turn
the selector
anticlockwise (E)
until it stops.
5. Clean with a
moist cloth and
wipe dry.
6. Wash these
parts: Mixer bowl,
condensation trap,
whisk, xing plate.
7. Fit the xing plate
by turning the selector
clockwise. Check all
seals!
8. Ensure that the
plane side of the
whisk motor shaft
corresponds with
the plane side of the
whisk. See(G)
9. Ret by push-tting the
whisk until a click sound can
be heard (H).
10. Fit the mixer bowl
and the condensation
trap as per (J) See
image.
11. Push-t the mixer bowl as per (K) and x
with lever (L). Fit the drain hose (M).
(Attention! ensure that all water hoses have
been tted.)
Cleaning the mixer system
Important with cleaning!
It is important to clean some of the machine parts
regularly. This is important for the functioning of the
machine, for the quality of the drinks and to full the
requirements for cleanliness. Maintenance work must
be done with the power switched off. Cleaning must
be done every week. Sometimes even more often
depending on how often the machine is used. Neutral
detergents must be used (avoid detergents that may
harm colour or plastic). Never clean the machine by
spraying water directly at it.
Check all seals
Check all seals
