Express Water RO5DX User manual

INSTALLATION MANUAL

Optional Upgrade Filters
(Alkaline / Deionization / Ultraviolet)
Feed
Water
Adapter
Storage Tank
Valve
Water Storage Tank
RO
Unit
Kitchen
Faucet
RO
Faucet
Drain
Saddle
Leak
Stop
Valve
A
B
C
D
G
H
J
K
L
I
For installation videos go to youtube.com/expresswatervideo
2
CONNECTION POINTS
(See page 16 for more information.)
A to B Connect the RED Tubing to the Feed
Water Adapter Valve (A), then to the connection
marked as “IN” on the Leak Stop Valve (B).
C to D Connect the WHITE Tubing to the
connection marked as “OUT” on the Leak Stop
Valve (C), then to the Sediment Filter Housing’s
Male Elbow Fitting (D).
G to H Connect the BLACK Tubing to the Flow
Restrictor side indicated by the arrow on the
Restrictor (G), then to the Drain Saddle (H).
I to J Connect the YELLOW Tubing to the Inline
Post Carbon Filter’s Stem Run Tee (I), then to the
Storage Tank Valve (J).
K to L Connect the BLUE Tubing to the Stem
Elbow at the end of the Inline Post Carbon Filter
(K), then to your RO Faucet connection (L).

3
Introduction
Table Of Contents
Performance Data Sheet / Technical Specications
Conditions
In󰏭allation Notes & Components Li󰏭
Sy󰏭em Components
Tubing Quick Connect Guide
Feed Water Adapter Valve
RO Faucet
Drain Saddle
Automatic Shuto Valve
Housing Assembly
Elbow Fitting In󰏭allation
Gauge In󰏭allation
Ultraviolet Sterilizer In󰏭allation
Leak Stop Valve
Water Storage Tank
Sy󰏭em Connections
Sy󰏭em Startup
Sy󰏭em Maintenance
How to Sanitize your RO Sy󰏭em
Filter Change In󰏭ructions
Re󰏭arting The Sy󰏭em
FAQs
Troubleshooting
Express Water Upgrades & Accessories
Warranty
Replacement Filters / Replacements Table
P. 3
P. 3
P. 4
P. 5
P. 6
P. 7
P. 8
P. 9
P. 10-11
P. 12
P. 12
P. 13
P. 13
P. 14
P. 14
P. 15
P. 15
P. 16
P. 16
P. 17
P. 17
P. 18-19
P. 19
P. 20
P. 21
P. 22
P. 23
P. 24
SYSTEM STARTUP
INSTALLATION
INTRODUCTION
TABLE OF CONTENTS
You have purchased the ne󰏭 residential Reverse Osmosis Water
Sy󰏭em available for your home. Your drinking water is going to
be healthier and ta󰏭e better from now on, and nothing makes us
happier. When properly maintained this sy󰏭em will provide you with
years of great-ta󰏭ing, pure drinking water and trouble-free service.
Getting started is a breeze - most of your Reverse Osmosis System
is already assembled and every connection is color coded. We’ve
marked where the colored tubes will go with matching colored plugs
in each tting.
Please make sure to thoroughly read the in󰏭allation manual and
become familiar with the tools needed before proceeding with the
in󰏭allation. Also, please make sure to inspect the package for any
missing components or shipping damages.
If you nd any issues or have que󰏭ions please contact us at
1-800-992-8876 or visit our website at www.expresswater.com.

4
• Do not use this system with water that is microbiologically
unsafe or of unknown quality without adequate disinfection
before or after the system.
• Testing was performed under standard laboratory conditions,
actual performance may vary.
• See owner’s manual for general installation/operation/
maintenance conditions and needs as well as manufacturer’s
limited product warranty.
• Eciency rating means the percentage of the inuent water
to the system that is available to the user as reverse osmosis
treated water under operating conditions that approximate
typical daily usage.
• Recovery rating means the percentage of the inuent water
to the membrane portion of the system that is available to
the user as reverse osmosis treated water when the system is
operated without a storage tank or when the storage tank is
bypassed.
• This is a factory specication for membrane production.
Actual production rate and TDS rejection will depend on
temperature, water pressure, TDS level, membrane variation
and usage pattern.
Express Water RO5DX and RO10DX have been tested according to NSF/ANSI 58 for reduction of the substances listed
below. The concentration of the indicated substances in water entering the system was reduced to a concentration less
than or equal to the permissible limit for water leaving the system, as specied in NSF/ANSI 58.
NSF/ANSI
58 Substance
Avg. Inf.
mg/L
Avg.
E. mg/L
%
Reduction
Max. E.
mg/L
Inf. Challenge
Concentration mg/L
Max. Permissible
Concentration mg/L
TDS (RO5DX)
TDS (RO10DX)
RO System ION System ALK System UV System ALK & UV System
6-Stage
12.8 lbs
18 x 15.5 x 5
5-Stage
11.8 lbs
17 x 15.5 x 5
10-Stage
12.8 lbs
18 x 15.5 x 5
6-Stage
12.8 lbs
18 x 15.5 x 5
11-Stage
13.8 lbs
20 x 15.5 x 5
0.8 Gallons per Minute
1000 PPM (Parts Per Million) - Note: Mg./L is the same as PPM
50-100 Gallons per Day
45-80 PSI
40-100°F (5-38°C)
(Standard) 4 Gallon Volume / 3.2 Gallon Water Capacity / 12”x 17”H (Including stand and tank valve)
1-3 Gallons per Gallon Produced
1-Year Limited Warranty (excludes wear and tear components)
Filtration Stages
Weight
Dimensions (Inch)
Faucet Flow Rate
Max PPM
Production Rate
Pressure Range
Temperature Range
Water Tank Size
Water Discharge
Warranty
PERFORMANCE
DATA SHEET
Tested and Certied by NSF International against NSF/
ANSI 58 for TDS Reduction - Models RO5DX & RO10DX
Express Water RO5DX and RO10DX have been tested according to NSF/ANSI 58 for reduction of the substances listed below. The
concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the
permissible limit for water leaving the system, as specied in NSF/ANSI 58.
770
770
36
36
95.40%
95.40%
47.00
43.00
750 ±40 mg/L
750 ±40 mg/L
187
187
Model Operating
Pressure
Operating
Temperature
Recovery
Rating
Eciency
Rating
Daily
Production
RO5DX 50-100 PSI
344-689 kPa
40-100°F
5-38°C 16.17% 17.44% 12.22 GPD
RO10DX 50-100 PSI
344-689 kPa
40-100°F
5-38°C 17.10% 9.66% 21.89 GPD
TECHNICAL SPECIFICATIONS

CONDITIONS
READ THIS FIRST!
NOTE! Please make sure your
in󰏭allation location has enough room
for the RO Sy󰏭em and Water Storage
Tank.
(For UV Sy󰏭ems) The Ultraviolet
Sterilizer requires access to a 110V
power outlet; make sure you have safe
access to power for this sy󰏭em (not
to be shared with garbage disposal
- power surge protector highly
recommended). Do not look directly
at UV Bulb without protection!
NOTE! ACCEPTABLE WATER
SOURCES Potable community source
water or potable private well water
that is properly chlorinated to provide
proper microbiological protection. For
liability reasons RO manufacturers and
even UV Disinfection manufacturers
will not take responsibility for
giving you any microbiological
protection, and therefore leave it up
to you to be sure the water is r󰏭
properly disinfected with chlorine.
Performance will vary based on local
water conditions.
Incoming Water - Incoming water
pressure mu󰏭 be between 45 PSI
and 80 PSI. If your water pressure is
under 45 PSI you will need a boo󰏭er
pump for your sy󰏭em. If your water
pressure is above 80 PSI you will
need a pressure regulator for your
sy󰏭em. Te󰏭 your water pressure
occasionally to make sure the sy󰏭em
is performing.
Leaks - The Leak Stop Valve mu󰏭 be
in󰏭alled. Inspect all connections after
the in󰏭allation to make sure no leaks
occur, wait until after the sy󰏭em is
pressurized (turned on) to inspect
again. Check sy󰏭em occasionally after
in󰏭allation or maintenance to make
sure no leaks have developed. In󰏭all
the sy󰏭em in a location with adequate
drainage.
General - This RO Sy󰏭em unit is
for climate controlled indoor use
only. Exposure to overly high or low
temperature ranges will damage
the unit. Follow all of your 󰏭ate
and local laws and codes regarding
plumbing even if they dier from
what is 󰏭ated in this manual. If your
󰏭ate law requires it or you prefer to
we recommend using a professional
licensed in󰏭aller or plumber who
meets the requirements of this
sy󰏭em. All O-Rings, ttings, lter
cartridges, lter cani󰏭ers, and Teon
tape wear out after a certain period of
time. The lifetime of your components
are subject to change with the quality
of the water supplied. Do not handle
an unwrapped lter directly with your
bare hands as this can cause early
lter failure. Use appropriate eye and
face protection when performing any
drilling.
Sy󰏭em & tank in󰏭allation location is
recommended to be no more than
10ft away from the RO faucet and any
other P.O.U. (ie. fridge) to prevent loss
of pressure. Tubing extended more
than 10ft away from the RO tank and
faucet may not create enough back
pressure to shut sy󰏭em o.
Maintenance - The owner / user is
obligated to properly maintain the RO
Sy󰏭em when necessary, at lea󰏭 every
1 year. This includes the following:
• Replace the O-rings on the lter
housings, membrane housing, ttings,
and lter cartridges.
• Replace any connectors and lter
housings with proper replacement
parts.
• Maintain & check tank pressure at
7-10 PSI on an empty tank.
• Sanitize your sy󰏭em as often as
needed (how often changes with the
prole of your area’s incoming water).
• Always use proper replacement lter
cartridges with the correct size and
length replacements.
• Replace the Teon Tape on all
threaded connections and ttings.
NOTE! If your water is
microbiologically unsafe or of
unknown quality do not use
this sy󰎣em without adequate
disinfection before or after the
sy󰎣em. Extremely hot or cold
incoming water will damage the
sy󰎣em and cannot be used.
Copyright © 2022 by Express Water Inc. All rights reserved. No part of this publication may be
reproduced, di󰏭ributed, or transmitted in any form or by any means, including photocopying,
recording, or other electronic or mechanical methods, without the prior written permission of the
publisher, except in the case of brief quotations embodied in critical reviews and certain other
noncommercial uses permitted by copyright law.
5
Please pay attention to the following in󰎣allation and safety
recommendations read the manual before in󰎣alling this sy󰎣em.

Your new Reverse Osmosis Water Sy󰏭em should include
the following items. If any item is missing please contact
Express Water. Please take a few moments to check all
the following components:
INSTALLATION NOTES
& COMPONENTS LIST Tools Required - Before you begin please make
sure you have all of the following tools ready to use:
• Power Drill
• Tube Cutter
• Teon Tape
• Box Cutter
RO Faucet Kit
See pages 10-11
5 ft Yellow 2 ft White5 ft Red 5 ft Blue 5 ft Black
Color Coded Tube ¼” OD
Drain Saddle Package
Foam Gasket2 Drain Clamp Halves
2 Nuts
2 Bolts
Connections
Faucet Adapter
¼” QC x ” FNPT
Male Elbow
¼” QC x ¼” THD
Male Elbow
& Red Plug
2
Screws
¼” Locking
Clip Bag
Tank Valve
¼” QC x ¼” FNPT
3½”
Housing
Wrench
2 Mounting Screws
NOTE! In the
package you will
nd the Tank Stand
screwed to the
top of the tank.
Unscrew it and place
it underneath for a
󰏭eady position.
Pressurized
Storage Tank
Preset at 7-10
PSI (on an
empty tank)
Tank Stand
¼“ Thread
Air Valve
3 Replacement
Pads (¾”)
Leak Stop Valve
Pressurized RO Storage Tank
Water Storage Tank
Tank Stand
Feed Water
Adapter Valve
⅜” x ½”
Teon
Tape
6
• ¼” Drill Bit (for Drain Saddle Valve)
• ½” Drill Bit (for RO Faucet)
• Phillips-Head Screwdriver
• Adju󰏭able Wrench
¼” QC ¼”QC
716
3”
Membrane
Wrench
(Faucet design may vary)
¼” QC

1
2
333
4
4
5
13
14
12
181920
7
9
17
16
15 22
8
6
6
21
10
11
Optional Upgrade Filters
(See right)
7
1. Feed Water Adapter Valve PRTFAV3812
2. Leak Stop Valve PRTLKS14Q
3. Filter Housing PRTHSF10DB14
4. Male Elbow ¼” PRTFITME14M14Q
5. Automatic Shut-O Valve PRTASV14Q
6. Male Elbow ⅛” PRTFITME14M18Q
7. RO Membrane Housing PRTFLTMHQ18
8. Check Valve ⅛” PRTFITCV1418Q
9. Drain Flow Restrictor
50 GPD PRTFLO30014Q
100 GPD PRTFLO60014Q
10. Drain Saddle PRTDS14Q
11. Stem Run Tee PRTFITSRT14Q14Q
12. Tank Valve PRTVT14F38Q
13. Water Storage Tank RO132-TNK
14. Tank Stand
15. Stem Elbow PRTFITSE14Q
16. QC Faucet Connector PRTFA14Q
17. RO Faucet See pages 10-11
18. SED Filter FLTSED0501
19. GAC Filter FLTGAC0501
20. ACB Filter FLTCAR0501
21. RO Membrane
50 GPD FLTMEME50
100 GPD FLTMEME100
22. Inline PAC Filter FLTIN01PKQ
23. ION Filter FLTDI10J
24. ALK Filter FLTALK10Q
25. UVS Housing FLTUV110BCH
26. UVS Bulb FLTUV110B1PK
15
22
11
15
23
15
5
15
22
11
15
24
15
5
15
22
11
5
4
25
4
26
24
15
15
15
22
11
5
4
25
4
26
Deionization
Alkaline
UV
Alkaline & UV
SYSTEM
COMPONENTS

To Cut Tubing
Make your cuts again󰏭 a at cutting surface with a razor blade, or use a handheld tube cutter. Any cuts to your Tubing mu󰏭 be
perfectly 󰏭raight.
NOTE! Improperly cut Tubing may leak water or fail to lock into Fittings.
Wait until all elements of your RO Sy󰏭em are in their nal locations before cutting your Tubing. Make sure you measure the
length you will need before cutting in order to avoid unnecessarily lengthy tubing.
Attach Tubing
Push Tubing in 󰏭raight and level with
the Collet. The Tubing will go ⅝” into the
Collet before the lock is activated. Pull out
on the Tube to make sure the lock has
activated and the Tubing is secure.
NOTE! Once connected, make sure to
check tubing is secure.
Insert or Remove Locking Clips
To lock a Tube in place make sure the
Tubing is fully inserted then slide the open
end of the Clip between the Collet and
Fitting. The Clip mu󰏭 be removed before
the Tubing can be removed. To remove
the Clip pull away until it slides out from
between the Collet and Fitting.
NOTE! Make sure to remove any plugs
before attempting to insert tubing.
The tubing in your RO Sy󰏭em uses a Quick
Connect locking mechanism to lock the
Color Coded Tubing in place. Be careful not
to damage your tubing as you unpack it.
TUBING QUICK
CONNECT GUIDE
Release Tubing / Plugs / Fittings
If there is a Locking Clip on the Collet it
mu󰏭 be removed before the Tubing can
be released. Push and hold the Collet in to
release the lock while pulling out on the
Tube / Plugs / Fittings.
NOTE! Collet mu󰎣 be held down while
pulling up on the tube to release it.
8
Plug
Collet
Locking
Clip
Fitting
⅝”
⅝”
Unlocked Locked
Hold
Down Pull
Up

9
NOTE! If your Cold Water Valve is too old or weak to connect to directly
Option Ayou can connect at the top of the line where the faucet connects
Option B(if applicable, some sinks do not have this connection point).
1. Locate the Cold Water Valve underneath the sink and turn it o
completely. Next, open the cold water handle on your sink to release any
pressure by expelling any exi󰏭ing water. Check to make sure the water has
󰏭opped owing completely before proceeding.
Do Not Connect To Hot Water Line!
NOTE! On single-handle faucets the hot water may have to be turned o
to prevent hot water crossover (only during your r󰏭 in󰏭allation).
If water 󰏭ill continues to come out of the faucet with the Cold Water Valve
turned o, then the main water supply mu󰏭 be turned o as well.
B
A
Hot Water
Line
Cold Water
Line
⅜” Connection½” Connection
FEED WATER
ADAPTER VALVE
CAUTION!CAUTION! The water supply to the unit MUST be from the COLD
WATER LINE. Using HOT WATER will severely damage your RO Sy󰎣em.
Using the Feed Water Adapter Valve
During in󰏭allation leave your Feed Water Adapter Valve
in the “CLOSED” position until Sy󰏭em Startup. The Feed
Water Adapter Valve controls all water coming into your
RO Sy󰏭em. If for any reason you need to 󰏭op incoming
water turn the Feed Water Adapter Valve to the “CLOSED”
position. Always turn this valve o before replacing lters,
if a leak is discovered, or when shutting down the sy󰏭em.
CLOSEDOPEN
WARNING! INCOMING WATER PRESSURE
SHOULD NOT EXCEED 80 PSI
Next, use an adju󰏭able wrench to secure the Adapter
Valve either directly to the Cold Water Valve Option A
or further up in the line before the faucet Option B (if
applicable). Make sure your Adapter Valve is in the closed
position when in󰏭alling it.
NOTE! Do Not Use Teon Tape! Use your wrench to
tighten the connection, be careful not to over tighten.
Adapter Nut
Adapter Nut
2. As shown below, the Feed Water Adapter Valve can be
used for ⅜” or ½” feed line plumbing.
Simply switch the Adapter Nut (see left image) from one
side of the Adapter Valve to the other.
CLOSED
CLOSED

RO FAUCET
The RO Faucet may be in󰏭alled on any
at surface. Check the underside of
your in󰏭all location for interference by
making sure that drilling a hole will not
damage any pipes or wiring underneath
the counter top or sink. Check to be
sure there is enough room for the
Threaded Faucet Stem.
NOTE! For drilling you mu󰏭 use an
appropriate drill bit and drilling method
for the material of your sink and counter
top. Dierent drill bits are required for
󰏭ainless 󰏭eel, porcelain, granite, etc.
You may use an exi󰏭ing hole in your
counter or sink or drill a new hole (if
using an exi󰏭ing hole begin at Step 2).
Make sure the Base Plate is big enough
to cover the hole you use.
Porcelain Sink
A proper porcelain ½” drill bit is 󰏭rongly
recommended to prevent chipping if
you are drilling on a porcelain sink. Drill
slowly to avoid chipping during the
initial cutting of the porcelain.
Stainless Steel Sink
1. Use a proper ½” drill bit (depending
on your sink/counter material) to make
a hole for your RO Faucet.
2. Insert the small rubber washer, then
the base plate, then the large rubber
washer (see image on next page) onto
the Threaded Faucet Stem at the base of
the RO Faucet. Then put the Threaded
Faucet Stem through the newly drilled
or preexi󰏭ing hole. Make sure the RO
Faucet sits in the center of your new or
exi󰏭ing hole.
3. Under the sink in󰏭all Pla󰏭ic Washer,
Lock Washer, and Hex Nut (see image
on next page) onto the Threaded Faucet
Stem. Make sure they are in󰏭alled all
the way up the 󰏭em.
Closed Open
10
4. Faucet Connection Line
See connection type A or B
NOTE!NOTE! You can use either connection
type (A or B) - NOT BOTH.

Insert
Sleeve
Compression
Nut
Faucet
Adapter
1/4" Blue
Color Tube
Add the Compression Nut, with the more
open end facing outwards, and Sleeve
to the Blue Tubing near one of the ends.
Add the Insert into the opening at the
same end of the Tubing, then bring this
end to the Threaded Faucet Stem. Screw
the Compression Nut onto the Threaded
Faucet Stem with an adju󰏭able wrench.
Be careful not to over tighten.
Add the Faucet
Adapter to one
end of the Blue
Tubing. Screw
the Faucet
Adapter onto
the Threaded
Faucet Stem.
1/4" Blue
Color Tube
Connection Type A Connection Type B
(Deluxe Only)
Rubber Washer
(Small)
(Deluxe Only)
Base Plate
(Deluxe Only)
Rubber Washer
(Large)
(Modern Only)
Base Plate & Rubber
Washer (Pre-Assembled)
Pla󰏭ic Washer Lock Washer Hex Nut Insert Sleeve Compression Nut
COMPONENTS
Plastic Washer
Lock Washer
Hex Nut
Threaded Faucet
Stem ( ”)
Rubber Washer
(Large)
Base Plate
Rubber Washer
(Small) Base Plate &
Rubber Washer
(Pre-Assembled)
COUNTER TOP
Deluxe
RO Faucet
Modern
RO Faucet
11
716
Under

12
The Drain Saddle is used to
connect the Black Drain Line to
the drain pipe under the sink,
to allow the sy󰏭em to ush
contaminants down the drain.
The Drain Saddle is designed
to t around a 󰏭andard 1½”
OD (outer diameter) drain pipe.
The Drain Saddle should always
be in󰏭alled above (before) the
P-Trap and on a 󰏭raight vertical
or horizontal section of pipe.
To avoid clogging the drain
line with debris do not in󰏭all
the Drain Saddle after the drain
pipe meets a garbage disposal
or dishwasher drain. Refer to
the image below to see ideal
Drain Saddle locations.
Please contact us if you need
help locating a drain saddle
placement.
1. Once you have found where
your Drain Saddle will go on the
Drain Pipe make a mark for the
opening there with a marker or
pencil.
2. Use your drill and an
appropriate ¼” (6.35mm) drill
bit to drill a hole at your mark.
Be careful to drill through one
side of the pipe and 󰏭abilize
your pipes while drilling to
avoid damaging them.
3. Find the half of the Drain
Clamp with a hole in its center.
Then remove the backing from
the Foam Gasket (the foam
circle at the center of the Gasket
is disposable). Make sure to
align the Foam Gasket hole with
the Drain Clamp hole and 󰏭ick
the adhesive side of the Gasket
to the inner wall of the Drain
Clamp half.
4. Take the half of the Drain
Clamp without the Foam Gasket
and insert a nut into the recess
on each side.
5. Position both halves of
the Drain Clamp on the drain
pipe with the clamp’s opening
aligned over the drilled hole.
The Foam Gasket will be
between the drain clamp and
the drilled hole. Push your ¼”
drill bit through both holes (the
Drain Clamp hole and the hole
in the Drain Pipe) and remove
to verify that the clamp is
properly aligned with the hole
you drilled.
6. Secure the Drain Clamp
halves together in place on
the Drain Pipe. Screw the bolts
through the Drain Clamp half
with the Foam Gasket and into
the half you in󰏭alled the nuts
into (Do not over tighten. Make
sure there is equal space on
both sides between the Drain
Clamp halves).
NOTE! Please make sure drain
line is free owing, and ow
is not re󰎣ricted in any way.
OK
Mount drain
saddle at
either location
X
WARNING!
Never mount
here!
P-Trap
Garbage
Disposal
X
X
OK
OK
Drain Pipe
Nut
Black Tube /
Drain Line
Foam
Gasket
Drain
Clamp
¼”
Hole
Bolt
DRAIN SADDLE
AUTOMATIC SHUTOFF VALVE
Also known as the brain of the sy󰏭em, the Automatic Shuto Valve
reads the back pressure from the RO Tank once it’s full, and shuts
the sy󰏭em o automatically to 󰏭op draining. As the RO Tank water
󰏭orage depletes, the Automatic Shuto Valve will open and initiate
the sy󰏭em to 󰏭art purifying the water, ensuring that you have RO
water readily available.
The Automatic Shuto Valve activates when back pressure builds
up in the product line due to a full, pressurized bladder tank.
To conserve water, the back pressure from the full tank will be
detected by the Automatic Shuto Valve and shut o the incoming
water to the RO Membrane.
SCREWS
SIDE VIEW
IN OUT

Prepare Prelters
Leave the lters wrapped until
you need them. When in󰏭alling
be careful not to touch the lter
portion with your hands.
Remove the pla󰏭ic wrap from the
3 Filter Housings and 󰏭and them
upright. Make sure each Housing
has two O-Rings rmly in place at
the top of the Housing and in the
Housing’s lower groove.
Food grade lubricant pre-applied
on O-rings. Please do not wipe o
to prevent over-tightening.
NOTE! Reference image to
place each of the prelters in the
correct order:
• The yellow SED Filter will be
on the far right (under the label
“TO FEED”).
• The blue ACB Filter will be on
the opposite side, the far left.
• The green GAC Filter will be
in the center. The white washer
will be facing up for correct
placement.
Filter
Housing
O-Rings
Filter
Housing
HOUSING
ASSEMBLY
1. Screw a Male Elbow Fitting
into the rightmo󰏭 Filter
Housing (Sediment) marked
“IN”. Screw until tightened
and the arm of the Elbow is
facing downward.
2. Secure the White Tubing
into the Male Elbow Fitting.
Push hard enough on the
tubing to make sure the
Quick Connect has locked
before moving on.
3. Screw the other Male
Elbow Fitting (with red
plug) into the leftmo󰏭 Filter
Housing (Carbon Block)
marked “OUT”. Screw until
tightened and the arm of the
Elbow is facing upwards at
an 11 o’clock angle (use the
above image for reference).
4. Remove the Red Plug.
Secure the Red Tubing into
the Male Elbow Fitting. Push
hard enough on the tubing
to make sure the Quick
Connect has locked before
moving on.
ELBOW FITTING
INSTALLATION
1
2
1. The RO Membrane is already inside
the ROM Housings on the sy󰏭em. To
make sure the cap is secure, tighten the
RO Membrane Housing Cap clockwise by
hand, then use Wrench to reinforce seal.
2. Use your hands to screw each Filter
Housing onto the RO Sy󰏭em. Finish
tightening each housing using the lter
wrench. DO NOT OVER TIGHTEN!
ATTENTION
Top Part Of
The Unit
3rd 2nd 1󰎣
13
NOTE!NOTE! Teon is preapplied to Elbows for your convenience.
However, if necessary, apply 8-10 rounds of Teon tape to the Elbows.

2. Put the small
bottom end of
the Stem Tee
into the Male
Elbow of the RO
Membrane Cap.
Use Blue Locking
Clips to secure all 3
connection points
as shown.
GAUGE
INSTALLATION
NOTE!NOTE! Not all RO Sy󰎣ems include a Pressure Gauge. If
your sy󰎣em does include a Gauge we will in󰎣all it now.
ULTRAVIOLET STERILIZER*
1. Put the end of
the Pressure Gauge
into one of the top
arms of the Stem
Tee. Then, put the
Red Tubing into
the opposite end as
shown. Both will go
about ⅝” into the
tee to secure.
14
1. Unscrew the Metal Cap
counter clockwise from the
Ultraviolet Sterilizer Housing.
2. Put the O-Ring around the
open end of the Quartz Tube
(not the bulb) about ½” away
from the end.
3. Insert the open end of the
Quartz Tube into the Metal
Cap. The O-Ring will re󰏭
again󰏭 the cap.
4. Carefully insert the closed
end of the Quartz Tube into
the open end of the UV
Housing with the Metal Cap
over the end.
5. Screw the Cap clockwise
onto the UV Housing. Use an
adju󰏭able plier or adju󰏭able
wrench to nish tightening,
do not over tighten. Do not
use Teon tape on UV Cap
Connection.
6. Connect the 4 pin electric
socket (of the power cord)
onto the Ultraviolet Bulb.
7. Carefully insert the UV Bulb
through the opening in the
Metal Cap into the Quartz
Tube. You will need to remove
the housing from its holding
clips.
8. Firmly push the Black
Pla󰏭ic Cover (attached to the
power cord) in place over the
Metal Cap.
½
12
NOTE!NOTE! DO NOT TOUCH UV BULB DIRECTLY, USE THE
WHITE CERAMIC PORTION TO MOVE THE BULB!
*Only applicable to UV Syems.
UV Housing
Quartz Tube 4 Pin Socket Pla󰎣ic Cover Power Cord
O-Ring UV Bulb Metal Cap UV Balla󰎣

NOTE! Please avoid contact of any liquid to the compressed textile pad. Failure to do so will activate the textile pad and shut the
incoming water. Textile pad will not work if pla󰎣ic wrap is not removed. Please do not re-use Leak Stop pads once activated.
Flow Closed
Position
NOTE! Do not tamper with the air valve on the lower side of the Water Storage
Tank. It has been preset at 7-10 PSI on an empty tank.
1. Open the Water Storage Tank box
and unscrew the Tank Stand from the
threaded 󰏭em at the top of the Tank.
2. Wrap the threaded 󰏭em 8-10 times
with Teon Tape.
3. Screw the Tank Valve onto the
threaded 󰏭em. Make sure it is tight, but
do not over tighten.
4. Place the Water Storage Tank near
the RO Sy󰏭em in the desired location.
The Tank can 󰏭and up 󰏭raight or lie on
its side.
5. Connect the Yellow Tubing to the
Stem Run Tee of the Inline Po󰏭 Carbon
Filter, then to the Tank Valve (See I to J
on Page 16).
6. Keep the Tank Valve in the Closed
Position until Sy󰏭em Startup.
Tank Stand
LEAK STOP
VALVE
15
NOTE! If after 3-5 hours your tank does not ll: Connect the tank directly to the cold
water supply (bypassing the RO Sy󰏭em) and allow the tank to ll for about 1 minute.
Then reconnect to your sy󰏭em as normal and empty the tank through faucet. This
will help prime the tank bladder for more water 󰏭orage capacity.
Tank Bladder Stretching - If your tank does not hold the expected amount of
water, connect your water supply to the inlet of the tank valve. Allow tank to ll for
one minute. Completely drain the tank then connect your ltration system to the
tank. Open your water supply and allow the tank to ll (2-4 hours) then drain tank
completely. Your tank is now ushed and ready for normal use.
NOTE! The Tank Valve
only controls water
leaving the Water Storage
Tank. To 󰏭op all incoming
water use the Feed Water
Adapter Valve.
Tank Thread
Tank Valve
OPEN
POSITION
CLOSED
POSITION
WATER
STORAGE TANK
INOUT INOUT
1. Position the RO Sy󰏭em in the desired permanent
location.
2. Position the Leak Stop Valve on the oor of
the same cabinet (so any leaking water will make
contact with the valve) beside the sy󰏭em and use
the two screws to secure the Valve to the cabinet
oor (Valve should be at the same level as the
sy󰏭em or below, in order to detect moi󰏭ure).
3. Connect one end of the Red Tubing into the
Feed Water Adapter Valve and connect the other
end of the Red Tubing into the hole marked “IN” on
the Leak Stop Valve. Then connect one end of the
White Tubing into the hole marked “OUT” on the
Leak Stop Valve and connect the other end of the
White Tubing into the Male Elbow Fitting attached
to the Sediment Filter Housing marked “IN”.
4. Take the pla󰏭ic wrap o of the Compressed
Textile Pad, then place the Textile Pad inside the
Leak Stop Valve as shown (you may wish to insert
the Compressed Textile Pad after Sy󰏭em Startup is
complete in case of early monitored leaks).
5. Turn the Stop Switch down and the Leak Stop
Valve is ready.
1 2
3
4 5
Helps detect water leaks if coming from the RO Sy󰎤em - if textile pad is activated by a
leak, incoming water is shut o, preventing any additional water entering the sy󰎤em.
INOUT
Flow Open
Position

NOTE! Do not send water through your
fridge until ushing is complete, carbon
particles ushed during 󰎣artup will clog
your refrigerator.
NOTE! Do not drink water from your new
sy󰎣em until you have completed Sy󰎣em
Startup. The ushing process is needed for
your lters to begin working.
Time E󰏭imate: 8-12 hours (We recommend
running 4 full tanks of water through your
new sy󰏭em. Each tank should take 2-3 hours,
depending on your home’s water pressure
levels).
1. Check all connections and ensure they are
secure.
2. Turn the Tank Valve to the Closed position
(refer to page 15).
3. Open the water supply to the RO Sy󰏭em (use
Cold Water Supply and Feed Water Adapter
Valve refer to page 9) (Make sure the main water
supply is also on).
4. Open handle on the RO Faucet (refer to pages
10-11) and wait up to 10 minutes for water to
󰏭art dripping from faucet. Let the water drip for
30 minutes.
5. Close the handle on the RO Faucet and wait
10 minutes for pressure to build. Then carefully
check your RO Sy󰏭em for any leaks (Feel or
visually inspect every connection point for leaks.
If a leak occurs, turn the Feed Water Adapter
Valve OFF, refer to page 9).
6. Turn the Tank Valve to the Open position.
7. Allow the Water Storage Tank to ll
completely (this takes about 2-3 hours
depending on your incoming water pressure).
8. Flush the sy󰏭em by opening the RO Faucet
handle until the 󰏭ored water is completely
emptied and the ow is reduced to a trickle
(about 3-5 minutes).
9. Close the RO Faucet handle and allow the
Tank to ll again.
10. Repeat 󰏭eps 7-9 two more times (about 4-6
hours). (Occasionally check for leaks during this
time)
11. Let the tank ll one nal time and sit
overnight (8+ hours) before ushing the water
12. After the 5th tank is lled you may drink the
water.
13. Check for leaks daily during the 1󰎣 week
of use and periodically thereafter.
NOTE! You may notice that the water has a
milky color during the 1󰎣 week. This is an
indication of air bubbles in the water. This is
normal during this period and the water is
safe to drink.
16
SYSTEM
CONNECTIONS
A
BC
D
G H
J
L
K
I
E
F
SYSTEM
STARTUP
Additional Filters
(ION / ALK / UV)
You may have already completed some or all of these
connections in previous 󰏭eps. Make sure to remove any
plugs before in󰏭alling Tubing. Use the provided Lock
Clips to secure any Tubing connections.
A to B Connect the RED Tubing to
the Feed Water Adapter Valve (A),
then to the hole marked as “IN” on
the Leak Stop Valve (B).
C to D Connect the WHITE Tubing
to the hole marked as “OUT” on
the Leak Stop Valve (C), then to
the Sediment Filter Housing’s Male
Elbow Fitting (D).
E to F The RED Tubing is already
connected to the Automatic Shut-
O Valve (E), connect the loose end
to the Carbon Block Filter Housing’s
Male Elbow Fitting (F).
G to H Connect the BLACK Tubing
to the Flow Re󰏭rictor side indicated
by the arrow on the Re󰏭rictor (G),
then to the Drain Saddle (H).
I to J Connect the YELLOW Tubing
to the Inline Po󰏭 Carbon Filter’s
Stem Run Tee (I), then to the Water
Storage Tank’s Tank Valve (J).
K to L Connect the BLUE Tubing to
the Stem Elbow at the end of the
Inline Po󰏭 Carbon Filter (K), then to
your RO Faucet connection (L).
M
M (UV Sy󰎣ems only)
Connect the power cord
from the UV Sterilizer to an
appropriate 110V outlet.

1. Before you begin you will need a new SED Filter, GAC Filter, ACB Filter, RO Membrane, Inline PAC Filter, and the Filter Housing
Wrench (as well as ION, ALK, and UV lters if applicable). We also sugge󰏭 using a bucket or bin large enough for the sy󰏭em to sit
in (the sy󰏭em will release a lot of water when it is disassembled).
2. Close any incoming water (Feed Water Adapter Valve page 9).
3. Open the RO Faucet handle and drain the sy󰏭em completely (wait until water ow 󰏭ops completely), then close the Faucet
handle.
4. Use the Filter Housing Wrench to open the Filter Housings, then remove and dispose of ONLY the following lter cartridges:
NOTE! Leave the Inline PAC lter (and ION lter, ALK lter and UV housing without bulb if applicable) in place! You will
replace it after sanitizing the sy󰎣em.
5. Mix 1 gallon of water with 2 tbsp of household bleach. Do not add bleach directly to the lter housing.
6. Fill up the Prelter Housings (SED, GAC, and ACB Housings) with your mixed solution and close the housings using your Filter
Housing Wrench. Leave tank valve open to sanitize tank.
7. Open the incoming water to the sy󰏭em (Feed Water Adapter Valve page 9) and let it run for 10 minutes.
8. Open the RO Faucet handle and let it drain for 10 minutes.
9. Close the RO Faucet handle and wait for 10 minutes then open the Faucet handle again and wait for it to drain completely, until
bleach smell is gone. (If you smell bleach from your RO Faucet repeat 󰎣eps 7-9)
10. You are now ready to replace all lters and re󰏭art your sy󰏭em. Please refer to pages 18-19 for detailed in󰏭ructions, ignore
any additional sanitation 󰏭eps therein.
17
SYSTEM
MAINTENANCE
These recommendations are intended for
maximum eciency of your RO Sy󰎣em.
HOW TO SANITIZE YOUR RO SYSTEM Recommended once
every 12 months
Sediment
Filter (SED)
Granular Activated
Carbon Filter (GAC)
Activated Carbon
Block Filter (ACB)
Reverse Osmosis
Membrane (ROM)
Filter and RO Membrane Storage
• Store unopened lters in an airtight container to prevent
them from absorbing air. This prolongs the shelf life of the
lters and avoids any possible odors or contamination from
the air.
• Using this method it is okay to 󰏭ore lters for several years.
Store in a cool, dry, dark place (avoid heat and moi󰏭ure
contamination).
Extended Sy󰎣em Non-Use (Vacation Mode)
When you plan to not use your RO Sy󰏭em for 2 weeks or
more it should be Turned O.
Locate the red Feed Water Adapter Valve connected to your
Cold Water Supply (refer to page 9).
Turn O Sy󰏭em: Turn the red Feed Water Adapter Valve to
point away from the Red Tubing connection (in the Closed
position, page 9) to close the water supply to the sy󰏭em (for
UV Sy󰏭ems, unplug the power cord from the power outlet).
Turn On Sy󰏭em: Turn the red Feed Water Adapter Valve
to point towards the Red Tubing connection (in the Open
position, page 9) to open the water supply to the sy󰏭em (for
UV Sy󰏭ems, plug the power cord back into the power outlet).
Flush 2-3 tankfuls to reactivate lters.
For Deactivation Of 1 Month Or More:
1. Shut o the incoming water supply and drain entire sy󰏭em
of water through the RO faucet.
2. Remove each lter and place vertically on a clean surface
until dry.
3. Place each lter individually in a sealed, airtight pla󰏭ic
wrap and place in the refrigerator for the duration (if lter is
reusable and less than 3 months old).
4. You may leave the Sy󰏭em and Filter Housings
disassembled to ensure it 󰏭ays dry to prevent bacteria
growth.
5. You should wash the lter housings before replacing the
lters, when you are ready to re󰏭art the sy󰏭em. Flush 2-3
tankfuls to reactivate lters.
NOTE! Depending on your area’s water, you may not be
able to reuse some or all of your lters. Please contact us
if you need more information.

FILTER CHANGE
INSTRUCTIONS
This RO Sy󰎣em contains Filters that mu󰎣 be replaced at regular intervals
to maintain proper performance. Use only authentic Express Water lters.
Prelters (ACB, GAC, SED)
18
RO Membrane
NOTE! Make sure you have
shut down the RO Sy󰎣em
(Step 2 in Prelters section).
1. Open the RO Membrane
Housing by unscrewing
the cap. Pull out the RO
Membrane with a pair of
pliers. Be sure to note which
side is the front and which
side is the back.
2. Wash out the RO
Membrane Housing. In󰏭all
the new RO Membrane
in the Housing in the
correct direction you noted
earlier. Make sure to push
the Membrane in rmly,
then close the Housing by
tightening the cap with your
hand, and use Wrench to seal
securely.
If this is the only / la󰏭 lter
you are replacing continue
to the Re󰏭arting the Sy󰏭em
section (page 19).
1. You will need a clean cloth, dish soap,
lter housing wrench and appropriate
SED, GAC, & ACB lters.
(We also recommend a bucket or bin
large enough for the sy󰏭em to sit
in - water will be released when it is
disassembled.)
2. Turn o the Cold Water Supply
connected to the RO Sy󰎣em and the
Feed Water Adapter Valve (page 9).
Then open the RO Faucet handle to
release pressure, and empty tank.
Close handle when the ow of water
󰎣ops, then close tank (page 15) (for
UV sy󰎣ems, unplug the power cord
from the power outlet).
3. Place the RO Sy󰏭em in the bucket and
unscrew the 3 Prelter Housings using
the Filter Housing Wrench. Remove old
lters and dispose of them.
4. Wash the Prelter Housings with dish
soap then proceed to rinse until all soap
is removed.
5. Ensure that your hands are washed
clean before unwrapping the new lters.
After unwrapping, place the new lters
inside their correct housings (page 13).
Make sure the O-Rings are in their proper
locations.
6. Tighten the Prelter Housings using
the Filter Housing Wrench. Do not over
tighten.
If these are the only lters you are
replacing continue to the Re󰏭arting the
Sy󰏭em section on (page 19).
Change about every 12 monthsChange about every 6 months
Make sure the O-Ring
is in place before
you tighten
the Membrane
Housing Cap.
NOTE! If you are having less than the
normal 0.8 gallons a minute ow from
the RO Faucet, it may be due to the
Tank Air Pressure or the incoming water
pressure being too low. If you have an
incoming water pressure of 50-80 PSI, we
ask that you check the pressure inside the
tank to verify that there is 󰎤ill between
8-10 PSI of air in the tank WHEN THE
TANK IS EMPTY.
Please lift the RO Tank and let us know
if it produced a full tank of water or no
water at all. If so, please check the tank
pressure. We recommend emptying the
water from the Tank. Once empty, please
add up to 10 PSI max into the Tank. This
should help increase the water pressure
coming out of the Tank. Do not add any
more than 10 PSI or you will not have
any room for water 󰎤orage as it will be
mo󰎤ly air pressure.
You may check the air inside the tank
using the air valve in the bottom of the
tank and a regular pressure gauge (as
you would with car tires).
MAKE SURE THE
CAPACITY (GPD) OF
YOUR OLD AND NEW
MEMBRANES MATCH.

Inline PACAlkaline Deionization
19
Ultraviolet
Change about every 6-12 months
NOTE! Make sure you have
shut down the RO Sy󰎣em
(Step 2 in Prelters section).
MUST HAVE POWER
SURGE PROTECTOR.
1. Unplug the power cord
from the power outlet.
NOTE! Do Not Unscrew the
Metal Cap!
2. Carefully and slowly pull
the black pla󰏭ic cap o the
UV Sterilizer (the bulb may
come out with the cap, if it
does not tilt the sy󰏭em until
the white ceramic portion is
accessible).
3. Unplug the power cord
from the UV Bulb and dispose
of old bulb.
4. Connect the new UV Bulb
to the power cord.
5. Carefully insert the new
UV Bulb into the UV Housing
though the opening in the
metal cap. Then slowly push
the black pla󰏭ic cap back
onto the Sterilizer Metal Cap.
6. Reconnect the power cord
to power outlet. If this is
the only / la󰏭 lter you are
replacing continue to the
Re󰏭arting the Sy󰏭em section.
1. Check all connections, including all lter
housings, and ensure they are secure.
2. Fully open the Feed Water Adapter Valve
and Cold Water Supply (page 9). Leave
tank closed (for UV Sy󰏭ems, make sure the
power cord is plugged into power outlet).
3. Open the RO Faucet handle and wait
5-10 minutes for water to 󰏭art owing, let
water run for 15-30 minutes, then turn the
faucet handle o.
4. Open tank, and let the sy󰏭em rell with
water (this takes 2-3 hours). You can open
the RO Faucet briey to release any air
trapped inside the sy󰏭em while it’s lling
(Be sure to check for new leaks during the
r󰏭 24 hours after re󰏭arting).
5. After the Water Storage Tank has lled
drain the entire sy󰏭em by opening the RO
Faucet until the water ow is reduced to a
slow trickle. Then close the Faucet.
6. Repeat 󰏭eps 4 and 5 three times to fully
ush the sy󰏭em (6-9 hours).
Change about every 6 months Change about every 6 months Change about every 12 months
NOTE! Make sure you have
shut down the RO Sy󰎣em
(Step 2 in Prelters section).
1. Fir󰏭 disconnect the Stem
Elbows from each side of the
Alkaline Filter.
2. Note the orientation of
the old lter, in󰏭all the new
lter in the same orientation.
Remove the old lter from its
holding clips and discard it.
Remove plugs on new lter.
Then, insert the new lter into
the holding clips and connect
the Stem Elbows to the new
Alkaline Filter (check page 7
for layout).
If this is the only / la󰏭 lter
you are replacing continue
to the Re󰏭arting the Sy󰏭em
section.
NOTE! Alkaline lters help
add benecial minerals to
your water. These elements
result in higher TDS.
NOTE! Make sure you have
shut down the RO Sy󰎣em
(Step 2 in Prelters section).
1. Fir󰏭 disconnect the Stem
Elbows from each side of the
Deionization Filter.
2. Note the orientation of
the old lter, in󰏭all the new
lter in the same orientation.
Remove the old lter from its
holding clips and discard it.
Remove plugs on new lter.
Then, insert the new lter into
the holding clips and connect
the Stem Elbows to the new
Deionization Filter (check
page 7 for layout).
If this is the only / la󰏭 lter
you are replacing continue
to the Re󰏭arting the Sy󰏭em
section.
NOTE! Make sure you have
shut down the RO Sy󰎣em
(Step 2 in Prelters section).
1. Fir󰏭 disconnect the Stem
Elbow and Stem Tee from the
sides of the Inline Po󰏭 Carbon
Filter.
2. Note the orientation of the
old lter, in󰏭all the new lter
the same way. Remove the
old lter from the holding
clips and discard. Next, insert
the new lter into the holding
clips and connect the Stem
Elbow and Stem Tee to the
new Inline Po󰏭 Carbon Filter
(check page 7 for layout).
If this is the only / la󰏭 lter
you are replacing, continue
to the Re󰏭arting the Sy󰏭em
section.
RESTARTING THE SYSTEM
NOTE! If the RO Sy󰎣em is connected to a refrigerator, do not drain the sy󰎣em
through the refrigerator water dispenser. The excess carbon nes from the new
carbon lter will clog the internal fridge lter.
DO NOT TOUCH
THE BULB DIRECTLY.
HANDLE WITH THE
WHITE CERAMIC
AREA. DO NOT LOOK
DIRECTLY AT THE UV
BULB WITHOUT EYE
PROTECTION!

FAQs Que󰎣ions? Call us at 1-800-992-8876 or visit www.expresswater.com
20
Does this sy󰎣em lter Fluoride, Lead,
Pharmaceuticals, and Arsenic?
Yes, as well as Cyanide, Phosphate, Pe󰏭icides,
Sodium, Cadmium, Sulfates, and many other
contaminants up to certain levels. Depending
on incoming water quality, you may need
pretreatment for high levels of certain
contaminants.
What PSI do I need? What is the operating
pressure?
The minimum PSI for the sy󰏭em is 45 and
the maximum PSI is 80. If your PSI is too low
you can purchase a Boo󰏭er Pumps to aid
your sy󰏭em. If your PSI is too high you can
purchase a Pressure Regulator to reduce your
pressure to acceptable levels. Let us walk you
through these options.
Does it 󰎣op lling automatically when
lled? Why is the drain line con󰎣antly
owing?
The RO Sy󰏭em does 󰏭op lling automatically
when tank is lled (2-3 hours). If your drain
line is con󰏭antly owing this is a sign that
your incoming water pressure is too low, or if
lters need replacing.
Can I in󰎣all this sy󰎣em in the basement?
If so, will it aect the eciency of the RO
Sy󰎣em?
Yes, the RO Sy󰏭em can be in󰏭alled in a
basement. However, if you do not have
adequate water pressure you may need to
purchase a Demand Delivery Pump. Contact
Express Water and we’ll help you nd your
solution.
What is the discharge rate?
The typical discharge range is one to three
gallons for every one gallon produced. Your
water pressure, incoming water quality,
and water temperature will aect your RO
Sy󰏭em’s discharge rate.
Why does it take so long to ll up the
tank?
The purication process takes some time on
its own. However, some water takes longer to
process. Your water pressure, incoming water
quality, and water temperature will all aect
how quickly your RO Sy󰏭em lls the Water
Storage Tank.
How often do I change Filters? Is there an
indicator?
The Sediment, Granular Activated Carbon,
Activated Carbon Block, Deionization and
Alkaline Filters should be changed every 6
months. The RO Membrane and Inline Po󰏭
Activated Carbon Filter should be changed
every 12 months at the same time as the
second change of the 6 month lters. The
UV Bulb of the Ultraviolet Sterilizer should
be changed every 6-12 months. If the UV
bulb needs to be changed early it will alert
you with either a red light or beeping noise
from the black box (electric balla󰏭 on the
power cord). There is no direct indicator for
lter changes. However, if you notice a drop
in water quality before the 6 or 12 month
mark this may mean that due to your water
quality you lter has degraded. If you reach
6 or 12 months without noticing a change in
ta󰏭e you should 󰏭ill change your lter at this
point, as they are no longer viable.
What is the dierence between GAC and
ACB carbon lters?
GAC and ACB lters are both made with
100% Organic Coconut Shell Carbon, the only
dierence is the formation of each lter. ACB
Block lters are much more tightly packed,
while the GAC is granular loose carbon. The
compact nature of the ACB means that even
the smalle󰏭 particles and contaminants
cannot pass through the lter and placed as
the Po󰏭 lter on the bottom
Will the Coconut Shell Carbon Filter
trigger a coconut allergy?
Depending on the severity of the allergy, the
carbon lter may trigger an allergic reaction.
Can I add additional lters to my current
sy󰎣em?
Yes, each sy󰏭em is fully upgradeable. Check
the Upgrades and Accessories section
on page 22 or on our website for more
information.
Can I connect this sy󰎣em to a refrigerator
or ice maker?
Yes, you may need an Express Water
Refrigerator Kit to do so. In some cases, your
situation may require a separate tank or
Delivery Pump depending on how far away
your refrigerator is from the sy󰏭em. Contact
Express Water and we’ll help you nd your
solution.
How do I get clear ice?
Lower freezer intensity slightly to allow water
to freeze slower and allow trapped air to
escape during freezing.
Can I reuse discharge water?
Never consume discharge water. With
proper in󰏭allation it is possible to utilize your
discharge water. Contact Express Water to
speak with a qualied representative who can
give you more information based on your
situation.
How long does the sy󰎣em la󰎣? How long
does the tank la󰎣?
With proper maintenance and average water
quality an RO Sy󰏭em should la󰏭 5-10 years.
The water 󰏭orage tank usually la󰏭s 3-5 years
before we recommend replacing it.
Can I change my 50 GPD (Gallons Per Day)
sy󰎣em to 100 GDP? If so, how?
Yes, to do so, you will need dierent parts
(such as the RO Membrane and Flow
Re󰏭rictor). Contact Express Water and we will
help you arrange your upgrade.
Why are there bubbles in the water?
(NOTE - For Alkaline Sy󰏭ems it is normal to
have more bubbles in your water because of
the higher oxygen content.)
Bubbles in your water is a common issue,
but they only aect the appearance of your
water and pose no risk. There can frequently
be air trapped inside any plumbing sy󰏭em,
so the air may be coming from your home’s
plumbing and not the RO Sy󰏭em. Trapped
air happens frequently when you change a
lter, when there is a leak in your sy󰏭em or
plumbing, uctuation in pressure, or even
when there is con󰏭ruction in your area.
Check your sy󰏭em carefully for any leaks
or unexplained moi󰏭ure. You may need to
carefully tilt the sy󰏭em various directions
then set it back in place to help release
trapped air.
Does this produce aquarium safe water?
RO Deionization Sy󰏭em - The Deionized
water is safe for appropriate aquatic life. Be
sure to te󰏭 your water regularly to make sure
it is safe for your aquarium.
All other sy󰏭ems - We sugge󰏭 in󰏭alling our
Deionization Filter Upgrade to create water
for aquatic life.
Why do I need to ush the sy󰎣em?
The ushing process helps activate lters and
open pores for ecient ltration. In addition,
new lters (or lters that have experienced
extended disuse) can develop carbon residue.
We recommend emptying the Water Storage
Tank four times (which can take 8-12 hours)
to release any extra carbon before the water
is safe to drink.
How much water can the 󰎣andard Water
Storage Tank hold?
The maximum capacity of the tank is 3.2
gallons. However, the typical tank reaches
2-2.5 gallons. Your Water Storage Tank’s
capacity depends on your incoming water
pressure. Lower water pressure means the
tank will hold less water.
What should I do in a boil water advisory?
As long as all of your lters are working
properly you can drink water from your RO
sy󰏭em without boiling. You MUST replace all
of your lters after the order is lifted. While
the sy󰏭em will lter large amounts of harmful
agents, it can damage your lters and
cause bacteria to grow. You should follow
sanitization in󰏭ructions when replacing the
lters.
Does this sy󰎣em soften water?
Your RO Sy󰏭em will soften water. However,
hard water does reduce the lifespan of your
Filters.
What if I need to produce more water?
There are a lot of solutions to this problem;
it’s possible to upgrade your drinking water
sy󰏭em with some specialty equipment, or
we can help you with other solutions. Ju󰏭
contact us and we can help you nd the
solution that be󰏭 ts your home.
