Solvent filter cleaning
XT10/XT10I and XT15/XT15I
Service Procedure XTS016
JAD 1/19/2018
ANKOM Technology •2052 O’Neil Road •Email: [e-mail] •Phone: [phone] •Fax: [phone]
pg. 1 of 4
1.
Remove the back cabinet.
a. Remove the eight screws (four on each side of
the instrument) that secure the back cabinet
onto the instrument using a 1/8” Allen wrench.
Set aside the screws for later use.
b. Lift up then pull back so the handles on each
side slide out of the notched groove.
Figure 1
Figure 2
2.
Unscrew the compression fitting using a 9/16 wrench.
Figure 3
Notched
groove
Screws

Solvent filter cleaning
XT10/XT10I and XT15/XT15I
Service Procedure XTS016
JAD 1/19/2018
ANKOM Technology •2052 O’Neil Road •Email: [e-mail] •Phone: [phone] •Fax: [phone]
pg. 2 of 4
3.
Unscrew the filter body using two ¾ wrenches.
4.
Remove the filter body.
5.
Using a small flat head screw driver, pull the PTFE
washer (part # 198) away from body to make sure that
it seals properly when you re-install the filter.
6.
Remove the Solvent Filter Element (part # 146.1) by
unscrewing it from the body.
One to unscrew
One to hold body

Solvent filter cleaning
XT10/XT10I and XT15/XT15I
Service Procedure XTS016
JAD 1/19/2018
ANKOM Technology •2052 O’Neil Road •Email: [e-mail] •Phone: [phone] •Fax: [phone]
pg. 3 of 4
Correct Installation Incorrect Installation
7.
Clean the Solvent Filter Element thoroughly.
a. Blow air through the element to remove particles.
b. If blowing air does NOT fully clean the element, wash it in hot soapy water. Rinse the element
thoroughly and dry it before re-installing.
c. Replace the element if it is damaged or cannot be cleaned.
8.
Re-install the Solvent Filter Element.
a. Re-install the Solvent Filter Element.
b. Re-install the filter body.
c. If the fitting on the body installs past vertical it’s
time to replace the PTFE washer (see the
procedure on the next page).

Solvent filter cleaning
XT10/XT10I and XT15/XT15I
Service Procedure XTS016
JAD 1/19/2018
ANKOM Technology •2052 O’Neil Road •Email: [e-mail] •Phone: [phone] •Fax: [phone]
pg. 4 of 4
How to replace the PTFE washer (if necessary)
a. Separate the washer from the body using a
small screw driver.
b. Slide the washer over the mesh screen to
remove it from the instrument.
c. Install a new washer by sliding it over the
mesh screen and placing it next to the body.
