Exsys EX-6100PoE User manual

Vers. 1.0 / 05.12.19
5 Port Gigabit Ethernet Metal Switch
with Poe Function
EX-6100PoE
5 Port Gigabit Ethernet Metall Switch
mit PoE Funktion
Manual
Anleitung

2
Deutsch EX-6100PoE
1. Beschreibung······················································································ 3
2. Lieferumfang ······················································································ 3
3. Aufbau, Anschlüsse & LED‘s································································4-5
3.1 Aufbau······································································································ 4
3.2 Anschlüsse & LED‘s··················································································4-5
4. Hardware Installation··········································································5-6
5. Reinigung ·························································································· 6
6. Technische Daten················································································ 6
7. Technische Zeichnung·········································································· 7
1. Description ························································································· 8
2. Extent of Delivery ················································································ 8
3. Layout, Connections & LED’s····························································· 9-10
3.1 Layout ······································································································ 9
3.2 Connections & LED’s·············································································· 9-10
4. Hardware Installation······································································ 10-11
5. Cleaning ···························································································11
6. Technical Information ··········································································11
7. Technical Drawing ··············································································12
Inhaltsverzeichnis
Index
© Copyright 2019 by EXSYS Vertriebs GmbH. All Rights Reserved

3
EX-6100PoE Deutsch
Der EX-6100PoE ist ein Metall Gigabit Ethernet Switch mit PoE Funktion für bis zu 4 End-
geräte. Der Switch ermöglicht Ihnen das Sie Strom und Daten über ein einziges Ethernet
Kabel an Ihre Ethernet Endgeräte im Netzwerk liefern können. Er unterstützt die
10/100/1000 Base-T Ethernet Standards. Vollständig IEEE 802.3at konformer PoE
(PSE=Power Source Equipment) Typ 1 und 2 Betrieb wird unterstützt. Die Maximalleis-
tung an den PoE Ports beträgt im Typ 1 13W und im Typ 2 25,5W. Durch die externe
Stromversorgung über den +48-57V Terminal Block kann problemlos die Leistung zur
Verfügung gestellt werden. Der EX-6100PoE gewährleistet eine sichere Datenübertra-
gung und exzellente Performance von bis zu 1000Mbit/s. Zusätzlich ist der EX-6100PoE
auch in dem erweitertem Temperaturbereich von -40C° bis +85C° einsetzbar. Der EX-
6100PoE kann problemlos mit dem im Lieferumfang enthaltenen DIN-Rail Kit auf einer
Trägerschiene in einem Serverschrank angebracht werden.
Merkmale:
• Kompatibel zu 10/100/1000Mbit/s Ethernet
• Maximalleistung: Typ 1: 13W / Typ 2: 25,5W
• Es werden alle Betriebssysteme unterstützt
• Erweiterter Temperaturbereich von -40C° bis +85C°
• Zertifiziert für
Bevor Sie den EX-6100PoE in Ihr Netzwerk einbinden, überprüfen Sie bitte zuerst den
Inhalt der Lieferung:
• EX-6100PoE
• DIN-Rail Kit (EX-6096)
• Anleitung
1. Beschreibung
2. Lieferumfang
© Copyright 2019 by EXSYS Vertriebs GmbH. All Rights Reserved

4
Deutsch EX-6100PoE
3.1 Aufbau
3. Aufbau, Anschlüsse & LED‘s
© Copyright 2019 by EXSYS Vertriebs GmbH. All Rights Reserved
4x PoE Anschluss
Datenausgang
3.2 Anschlüsse & LED‘s
Betriebs LED
+48-57 T-Block für
optionales externes Netzteil
+48-57V T-Block:
+48-57V GND (Ground)
ACHTUNG!!!
Schließen Sie niemals Strom an Ground an,
dadurch kann Ihre Hardware zerstört werden!!!
1x Anschluss
Dateneingang
RJ45 Anschluss:
RJ45 Anschluss
Pin Signal Pin Signal Pin Signal
1BI_DA+ 4BI_DC+ 7BI_DD+
2BI_DA- 5BI_DC- 8BI_DD-
3BI_DB+ 6BI_DB-

5
EX-6100PoE Deutsch
3. Aufbau, Anschlüsse & LED‘s
3.2 Anschlüsse & LED‘s
© Copyright 2019 by EXSYS Vertriebs GmbH. All Rights Reserved
Status LED‘s:
Anschluss Dateneingang Anschluss Datenausgang
Link/Active LED
Link/Active LED
PoE Power LED
Gigabit Mode LED
4. Hardware Installation
Beachten Sie bitte die folgenden Installationshinweise. Da es große Unterschiede zwi-
schen PC‘s gibt, können wir Ihnen nur eine generelle Anleitung zum Anschluss der EX-
6100PoE geben. Bei Unklarheiten halten Sie sich bitte an die Bedienungsanleitung
Ihres Computersystems.
1. Installieren Sie die EX-6100PoE an die Wand oder mit dem mitgelieferten DIN-Rail
Kit auf einer Tragschiene.
2. Verbinden Sie das RJ45 Netzwerkkabel mit dem Dateneingang Anschluss.
Löcher für
Wandmontage
Montage an
Tragschiene

6
Deutsch EX-6100PoE
© Copyright 2019 by EXSYS Vertriebs GmbH. All Rights Reserved
5. Reinigung
Zur Reinigung des Gerätes verwenden Sie bitte ausschließlich ein trockenes nicht fa-
serndes Tuch und entfernen Sie die Verschmutzung mit leichtem Druck. Im Bereich der
Anschlüsse bitte darauf Achten, dass keine Fasern des Tuchs in der Buchse hinterlas-
sen werden. Verwenden Sie bitte zu Reinigung in keinem Fall ein feuchtes oder
nasses Tuch!
4. Hardware Installation
3. Schließen Sie jetzt den Stromanschluss des optionalen Netzteils an den Terminal
Block des Hubs an und stecken Sie den Netzstecker des Netzteils in eine Steckdose.
4. Schließen Sie nun Ihre PoE-PD-Gerät an die PoE Anschlüsse an. Die gelbe PoE
Power LED sollte aufleuchten, wenn das PD korrekt erkannt und vom Ethernet-Switch
versorgt wurde.
6. Technische Daten
Datentransfer-Rate: 10/100/1000Mbit/s
Anschlüsse: 1x RJ45 LAN Anschluss, 4x RJ45 PoE Anschlüsse
1x +48-57V Terminal Block
Hardwaresystem: Ethernet 10/100/1000Mbit/s
Betriebssystem: Alle Betriebssysteme
Betriebstemperatur: -40° bis 85° Celsius
Lagertemperatur: -40° bis 85° Celsius
Rel. Luftfeuchtigkeit: 5% bis 95%
Schutzklasse: IP30
Stromversorgung: +48-57 Volt
Abmessung: 133,00 x 61,50 x 43,20 mm
Gewicht: 300g

7
EX-6100PoE Deutsch
© Copyright 2019 by EXSYS Vertriebs GmbH. All Rights Reserved
7. Technische Zeichnung

8
English EX-6100PoE
The EX-6100 is a metal Gigabit Ethernet switch for 4 devices. The switch enables you
to deliver power and data to your Ethernet devices on the network via a single Ethernet
cable. It supports the 10/100/1000 Base-T Ethernet standards. Fully IEEE 802.3at com-
pliant PoE (PSE=Power Source Equipment) Type 1 and 2 operation supported. The
maximum power at the PoE ports are for Type 1 13W and for Type 2 25,5W. The exter-
nal power supply via the +48-57V terminal block makes it easy to provide the required
power. It uses data transfer rates up to 1000Mbit/s. It provides a secure and very high
data transfer on each single port. In addition, the EX-6100PoE can also be used in the
extended temperature range from -40C° to +85C°. The EX-6100PoE can easily be
mounted on a carrier rail in a server rack by using the supplied DIN-Rail kit.
Features:
• Compatible for 10/100/1000Mbit/s Ethernet
• Maximum Output: Typ 1: 13W / Typ 2: 25,5W
• All Operating Systems are supported
• Extended Temperture Range from -40C° bis +85C°
• Certificate for
Before you integrate the EX-6100PoE into your network, you should first check the con-
tents of the delivery:
• EX-6100PoE
• DIN-Rail Kit (EX-6096)
• Manual
1. Description
2. Extent of Delivery
© Copyright 2019 by EXSYS Vertriebs GmbH. All Rights Reserved

9
EX-6100PoE English
© Copyright 2019 by EXSYS Vertriebs GmbH. All Rights Reserved
3.1 Layout
3. Layout, Connections & LED‘s
4x PoE Connection
Data Output
3.2 Connections & LED‘s
Power LED
+48-57 T-Block for optional
external Power Supply
+48-57V T-Block:
+48-57V GND (Ground)
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
1x Connection
Data Input
RJ45 Port:
RJ45 Port
Pin Signal Pin Signal Pin Signal
1BI_DA+ 4BI_DC+ 7BI_DD+
2BI_DA- 5BI_DC- 8BI_DD-
3BI_DB+ 6BI_DB-

10
English EX-6100PoE
© Copyright 2019 by EXSYS Vertriebs GmbH. All Rights Reserved
3. Layout, Connections & LED‘s
3.2 Connections & LED‘s
Status LED‘s:
Connection Data Input Connection Data Output
Link/Active LED
Link/Active LED
PoE Power LED
Gigabit Mode LED
4. Hardware Installation
Please observe the following installation instructions. Because there are big differences
between PC's, we can only give you a general guide for connecting the EX-6100PoE. If
you have any questions, please refer to the operating instructions of your computer
system.
1. Install the EX-6100PoE on the wall or on a mounting rail by using the supplied DIN-
Rail kit.
2. Connect the RJ45 network cable to the data input connector.
Holes for
Wall Installation
Installation on
DIN-Rail

11
EX-6100PoE English
© Copyright 2019 by EXSYS Vertriebs GmbH. All Rights Reserved
5. Cleaning
For cleaning please use only a dry fluff less cloth and remove the dirt with gently pres-
sure. In the area of the connectors please make sure that no fibres from the cloth re-
main in the connectors. Attention! Never use a moist or wet cloth for cleaning!
4. Hardware Installation
3. Now connect the power connector of the optional power supply to the terminal block of
the switch and plug the power plug of the power supply nto an electrical outlet.
4. Now connect your PoE-PD device to the PoE connectors. The yellow PoE Power LED
should light up when the PD is correctly detected and powered by the Ethernet switch.
6. Technical Information
Data Transfer Rate: 10/100/1000Mbit/s
Connectors: 1x RJ45 LAN Port, 4x RJ45 PoE Port,
1x +48-57V Terminal Block
Hardware System: Ethernet 10/100/1000Mbit/s
Operating System: All Operating Systems
Operating Temperature: -40°F to 185°Fahrenheit
Storage Temperature: -40°F to 185°Fahrenheit
Rel. Humidity: 5% bis 95%
Protection Class: IP30
Power: +48-57 Volt
Size: 133,00 x 61,50 x 43,20 mm
Weight: 300g

12
English EX-6100PoE
7. Technical Drawing
