USER GUIDE
Digital Light Meter
Model LT300
www. .com [e-mail]1.800.561.8187

LT300-EU-EN V2.3 2/13
2
Introduction
Congratulations on your purchase of the Extech LT300 Digital Light Meter. The LT300 measures
light level (illuminance) to 400,000 Lux (40,000 Fc). The LT300 offers a backlit display, MAX/MIN,
Data Hold, Relative, Peak, and Reset features. This instrument is shipped fully tested and calibrated
and, with proper use, will provide years of reliable service. Please visit our website
(www.extech.com) to check for the latest version of this User Guide, Product Updates, and
Customer Support.
Meter Description
1. Sensor cable
2. Analog bargraph
3. Numerical display
4. RANGE button
5. ON/OFF button
6. MAX/MIN button
7. RESET button
8. LCD Backlight button
9. LUX button
10. Fc foot candle button
11. Protective rubber jacket
12. RELATIVE button
13. Data HOLD button
14. PEAK button
15. Photo sensor dome
Notes: Protective sensor cap not shown. Battery compartment, Tilt Stand, and Tripod Mount
are located on the rear of the instrument. The protective rubber jacket must be removed
from meter to access battery compartment.
www. .com [e-mail]1.800.561.8187

LT300-EU-EN V2.3 2/13
3
Operation
Light sensor
1. The light sensor is permanently attached to
the meter by the coiled cable.
2. Remove the protective cap by unsnapping it
to expose the white domed light sensor.
When the  sensor s protective cap is removed, the white domed light sensor lens will begin to
capture light. Replace the cap when the meter is not in use.
Turn Power ON or OFF
Press the button to turn power on or off. If the display does not switch on, check that the 9V
battery is installed and is fresh.
Selecting Lux or Foot candle units of measure
Press the LUX button to select lux units or the Fc button to select foot candle units.
Measurement Procedure
1. Remove the protective cap from the sensor so that the white domed light sensor is exposed
to the light. For overhead lighting, the sensor can be placed on a desk or table top. A tripod
mount and a tilt stand are located on the rear of the meter for convenience.
2. The display will indicate the light level in Fc or Lux.
3. Press the RANGE button to select the range that provides the maximum resolution. If the
 
OL appears the light measurement is out of range. Select another range using the RANGE
button.
4. Press the backlight button to illuminate the LCD display if needed.
MAX/MIN
The Max/Min function allows for recording and display of the maximum and minimum light
levels over time.
1. Press the MAX/MIN button. The MAX display icon will appear and meter will now display
and hold only the highest reading. The display will update only when a higher reading is
measured.
2. Press MAX/MIN button. The MIN display icon will appear and meter will now display and
hold only the lowest reading. The display will update only when a lower reading is measured
3. Press MAX/MIN again. The MAX MIN display icons will appear flashing and meter will now
display the current reading, but will continue to record the highest and lowest values.
4. Press MAX/MIN again to cycle through MAX and MIN displays.
5. To exit the MAX MIN mode, press and hold the MAX/MIN button until the MAX and MIN
icons completely disappear.
Data Hold
Press the HOLD button to freeze the displayed reading. The MANU  HOLD hold icon will appear
on the display. Press the HOLD button again to return to normal operation. When the Data Hold
function is enabled the analog bar graph will continue to display level changes.
www. .com [e-mail]1.800.561.8187

LT300-EU-EN V2.3 2/13
4
www. .com [e-mail]1.800.561.8187

LT300-EU-EN V2.3 2/13
5
Maintenance
Cleaning and storage
1. The white plastic sensor dome should be cleaned with a damp cloth when necessary. Use
only a mild soap if needed. Do not use solvents, abrasives, or harsh detergents to clean the
dome.
2. Store the meter in an area with moderate temperature and humidity (refer to the operating
and storage range in the   Specifications section).
Battery Replacement
When the battery power begins to fail the low battery symbol  will appear on the LCD. Replace
the 9V battery by first removing protective jacket that encases the meter. Remove the rear
(center) battery compartment screw to access the battery compartment. Ensure that the
compartment cover is securely fastened and that the protective jacket is properly installed
before using the meter.
Never dispose of used batteries or rechargeable batteries in household waste.
As consumers, users are legally required to take used batteries to appropriate
collection sites, the retail store where the batteries were purchased, or wherever
batteries are sold.
Disposal: Do not dispose of this instrument in household waste. The user is
obligated to take end of life devices to a designated collection point for the disposal
of electrical and electronic equipment.
Other Battery Safety Reminders
Never dispose of batteries in a fire. Batteries may explode or leak.
Never mix battery types. Always install new batteries of the same type.
www. .com [e-mail]1.800.561.8187

LT300-EU-EN V2.3 2/13
6
Specifications
Ranges and Resolution Accuracy
Lux
40.00, 400.0, 4000, 40.00k, 400.0kLux ± (5% Rdg + 0.5% Full Scale)
Foot candle (Fc)
40.00, 400.0, 4000, 40.00kFc ± (5% Rdg + 0.5% Full Scale)
General Specifications
Display Multi function 3 3/4 (3999) digit LCD with Bargraph indicator
Over range indication LCD displays   OL
Spectral response CIE photopic (CIE human eye response curve)
Spectral accuracy CIE V function (f16%)
Measurement Repeatability ±2%
Temperature coefficient ±0.1% per oC
Sampling rate 13.3 times per second (bargraph); 1.3 times per second (digital
display)
Photo detector Silicon photo diode with spectral response filter
Peak Hold Capture light peaks to 10µS
Operating conditions Temperature: 0 to 40oC (32 to 104oF); Humidity: < 80% RH
Storage conditions Temperature: 10 to 50oC (14 to 140oF); Humidity: < 80% RH
Dimensions 165 x 76 x 43mm (6.5 x 3.0 x 1.7")
Weight Approx. 403g (14.2 oz.) with battery installed
Low battery indication   appears on the LCD
Power supply 9V battery
Copyright ©2013 FLIR Systems, Inc.
All rights reserved including the right of reproduction in whole or in part in any form
ISO 9001 Certified
www. .com [e-mail]1.800.561.8187

LT300-EU-EN V2.3 2/13
7
Appendix
Typical Light Levels
Lux Foot
Candles
Lux Foot
Candles
Factories Home
20 75 2 7 Emergency Stairs, Warehouse 100 150 10 15 Washing
75 150 7 15 Exit/Entrance Passages 150 200 15 20 Recreational
Activities
150 300 15 30 Packing Work 200 300 20 30 Drawing Room,
Table
300 750 30 75 Visual Work: Production Line 300 500 30 50 Makeup
750 1,500 75 150 Typesetting: Inspection Work 500 1,500 50 150 Reading, Study
1,500 3,000 150 300 Electronic Assembly, Drafting 1,000 2,000 100 200 Sewing
Office Restaurant
75 100 7 10 Indoor Emergency Stairs 75 150 7 15 Corridor Stairs
100 200 10 20 Corridor Stairs 150 300 15 30 Entrance,
Wash Room
200 750 20 75 Conference,
Reception Room
300 750 30 75 Cooking Room,
Dining Table
750 1,500 75 150 Clerical Work 750 1,500 75 150 Show Window
1,500 2,000 150 2000 Typing, Drafting
Store Hospital
75 150 7 15 Indoors 30 75 3 7 Emergency Stairs
150 200 15 20 Corridor/Stairs 75 100 7 10 Stairs
200 300 20 30 Reception 100 150 10 15 Sick Room,
Warehouse
300 500 30 50 Display Stand 150 200 15 20 Waiting Room
500 750 50 75 Elevator 200 750 20 75 Medical Exam Room
750 1,500 75 150 Show Window,
Packing Table
750 1,500 75 150 Operating Room
1,500 3,000 150 300 Storefront, Show Window 5,000 10,000 500 1000 Eye Inspection
Spectral Sensitivity
400 450 500 550 600 650 700
Wavelength (nm)
- - - - - Light Meter Response _____ CIE Response
R
e
l
a
t
i
v
e
R
e
s
p
o
n
s
e
1
0.8
0.6
0.4
0.2
0
