Extra 300L Quick setup guide

I N F O R M AT I O N M AN U AL
E X T R A 3 0 0 L
MANUFACTURER
EXTRA Flugzeugproduktions- und Vertriebs- GmbH
FlugplatzDinslaken
46569 Hünxe, Federal Republic of Germany
TITLE PAGE
W A R N I N G
This is an Information Manual and may be used for general purposes only.
This Information Manual is not kept current.
It must not be used as a substitute for the official FAA/EASA Approved Pilot's Operating
Handbook required for operation of the airplane.

Left blank intentionally

Page Date: 31. March 2009 i
Pilot´s Operating Handbook
EXTRA300L
LOGOFREVISIONS
Datesofissuefororiginalandrevisedpages:
Original .........................9.September1994
RevisionNo.1 .......................26.June1997
RevisionNo.2 .........................7.June1999
Edition No. 2 ......................... 20.April2002
Rev. No. 1, 2nd Ed. ...... 15.December2005
Rev. No. 2, 2nd Ed. ..... 20.September2006
Rev. No. 3, 2nd Ed. .................6.June2008
Rev. No. 4, 2nd Ed. ........ 5.December2008
Rev. No. 5, 2nd Ed. ............ 16.March2009
Rev. No. 6, 2nd Ed. ............ 31.March2009
Rev. No. 7, 2nd Ed. ..........08.October2009
Rev. No. 8, 2nd Ed. ............... 19.April2012
Rev. No. 9, 2nd Ed. ..........17.January2013
Rev.No. 10,2ndEd. ........31.October2013
Rev.No. 11,2ndEd. ........20.January2016
Dateandsignofapproval:
LBAapproved................... 31.January1995
LBAapproved.................... 27. August1997
LBAapproved........................23.June1999
LBAapproved...................30.October2002
EASA ApprovalN° ......... EASA.A.A.01101
DateofApproval ........... 20.December2005
EASA ApprovalN° ......... EASA.A.A.01319
DateofApproval ............20.November2006
EASA ApprovalN° ......... EASA.A.C.08351
DateofApproval .....................24.July2008
EASA ApprovalN° ......... EASA.A.C.10781
DateofApproval ............. 18.February2009
ApprovedundertheauthorityofDOA
N°EASA.21J.073(ECO:ÄM-300-09-07)
DateofApproval ......................6. April 2009
EASA ApprovalN° ..................... 10026766
DateofApproval .................. 7. August 2009
ApprovedundertheauthorityofDOA
N° EASA.21J.073 (FAA Validation Process
TD0306CE-A;P-EASA.CSV.A.01467)
DateofApproval ...............14.October2009
ApprovedundertheauthorityofDOA
N°EASA.21J.073 (ANACValidation
Process;EASAProjectN°0010011276)
DateofApproval ...............08.October2012
ApprovedundertheauthorityofDOA
N°EASA.21J.073 (ECO:ÄM-300-12-13)
DateofApproval ................. 04.March 2013
ApprovedundertheauthorityofDOA
N°EASA.21J.073(ANACValidation
Process&ECO:ÄM-300-12-13,
ÄM-300-13-03,ÄM-300-13-08)
DateofApproval ............14.November2013
ApprovedundertheauthorityofDOA
N°EASA.21J.073
DateofApproval ................. 11.March2016
Page Date: 20. January 2016

ii Page Date: 31. March 2009
Pilot´s Operating Handbook
EXTRA300L
Page Date
Title.................................... 31.March2009
i thru iii............................. 20.January2016
iv ........................................... 19.April2012
v....................................... 20.January2016
vi ........................................ 31.March2009
1-1 ..................................... 16.March2009
1-2 ........................................ 20.April2002
1-3 ..................................... 31.March2009
1-4 ........................................ 19.April2012
1-5 ..................................... 31.March2009
1-6 ........................................ 20.April2002
1-7 ..................................... 31.March2009
1-8 ..................................... 16.March2009
2-1 ................................... 20.January2016
2-2 ........................................ 20.April2002
2-3 ..................................... 31.March2009
2-4 ................................... 20.January2016
2-5 .....................................8.October2009
2-6thru2-8 ...................... 20.January2016
2-9 ..................................... 16.March2009
2-10 ............................. 15.December2005
2-11 ................................... 16.March2009
2-12 ...................................... 19.April2012
2-13 ............................. 15.December2005
2-14 ................................. 20.January2016
3-1thru3-2 ........................... 20. April 2002
3-3 ................................... 20.January2016
3-4 ..................................... 16.March2009
3-5thru3-6 ...................... 20.January2016
3-7 ..................................... 16.March2009
3-8 ..................................... 31.March2009
4-1 ................................... 20.January2016
4-2 ........................................ 20.April2002
4-3thru4-4 ........................... 19. April 2012
4-5thru4-6 ........................... 20. April 2002
4-7 ................................... 20.January2016
4-8 ..................................... 31.March2009
4-9 ..................................... 16.March2009
4-10thru4-12................... 20.January2016
5-1thru5-2 ........................... 20. April 2002
5-3thru5-4 ........................ 16.March2009
5-5 ........................................ 20.April2002
5-6thru5-9 ........................ 16.March2009
5-10thru5-12........................ 20.April2002
5-13 ................................. 20.January2016
5-14 ................................... 16.March2009
6-1thru6-2 ........................... 20. April 2002
6-3 .............................. 20.September2006
6-4 ..................................... 31.March2009
6-5thru6-6 ........................... 20. April 2002
6-7 ..................................... 31.March2009
6-8 ........................................ 20.April2002
LOGOFEFFECTIVEPAGES
6-9thru6-16..................... 20.January2016
7-1 .............................. 20.September2006
7-2 ........................................ 20.April2002
7-3thru7-4 ........................ 31.March2009
7-5thru7-8 ........................... 20.April2002
7-9 ..................................... 31.March2009
7-10 ............................. 15.December2005
7-11 ................................. 20.January2016
7-12thru7-13............... 15.December2005
7-14 ...................................8.October2009
7-15thru7-16........................ 20.April2002
8-1thru8-4 ........................... 20.April2002
9-1 ................................. 5.December2008
9-2 ................................... 20.January2016
9-3 ..................................... 31.March2009
9-4 ........................................ 20.April2002
901-1thru901-4 .................... 20. April 2002
902-1thru902-3 .................... 20. April 2002
902-4..................................8.October2009
903-1thru903-10 .................. 20. April2002
904-1thru904-4 .................... 20. April 2002
904-5................................ 20.January2016
904-6thru904-8 .................... 20. April 2002
905-1................................ 20.January2016
905-2..................................... 20.April2002
905-3thru905-5 ............... 20.January2016
905-6..................................... 20.April2002
906-1thru906-2 .................... 20. April 2002
906-3thru906-6 .................... 19. April 2012
907-1.................................. 16.March2009
907-2thru907-3 .................... 20. April 2002
907-4.................................. 16.March2009
907-5................................ 20.January2016
907-6thru907-6 ................. 16.March2009
908-1thru908-2 .................... 20. April 2002
908-3................................ 20.January2016
908-4.................................. 16.March2009
908-5................................ 20.January2016
908-6thru908-8 ................. 16.March2009
909-1................................ 20.January2016
909-2..................................... 20.April2002
909-3thru909-8 ............... 20.January2016
910-1thru910-2 .................... 20. April 2002
910-3thru910-5 ................. 16.March2009
910-6thru910-8 .................... 20. April 2002
911-1thru911-2 .................... 20. April 2002
911-3.................................. 31.March2009
911-4..................................... 20.April2002
912-1thru912-6 ........... 15.December2005
912-7................................ 20.January2016
912-8............................ 15.December2005
913-1thru913-6 ........... 15.December2005
Page Date
Page Date: 20. January 2016

Page Date: 31. March 2009 iii
Pilot´s Operating Handbook
EXTRA300L
913-7................................ 20.January2016
913-8............................ 15.December2005
914-1thru914-2 ........... 15.December2005
914-3................................ 20.January2016
914-4thru914-6 ........... 15.December2005
915-1thru915-2 ........... 15.December2005
915-3................................ 20.January2016
915-4.............................. 5.December2008
915-5............................ 15.December2005
915-6.............................. 5.December2008
915-7thru915-8 ........... 15.December2005
916-1thru916-2 ........... 15.December2005
916-3.................................. 31.March2009
916-4thru916-6 ........... 15.December2005
917-1thru917-2 ................. 31.March2009
917-3................................ 20.January2016
917-4thru917-8 ................. 31.March2009
918-1thru918-3 ........... 15.December2005
918-4thru918-5 ............... 20.January2016
918-6............................ 15.December2005
919-1thru919-3 ........... 15.December2005
919-4................................ 20.January2016
919-5thru919-8 ........... 15.December2005
920-1thru920-3 ................. 31.March2009
920-4................................ 20.January2016
920-5thru920-10 ............... 31.March2009
921-1................................ 20.January2016
921-2.............................. 5.December2008
921-3..................................8.October2009
921-4thru921-5 ............... 20.January2016
921-6..................................... 19.April2012
921-7................................ 20.January2016
921-8thru921-9 .................... 19. April 2012
921-10.............................. 20.January2016
921-11thru921-16 ................ 19.April2012
922-1thru922-3 ............. 5.December2008
922-4................................ 20.January2016
922-5thru922-8 ............. 5.December2008
923-1thru923-2 ............. 5.December2008
923-3................................ 20.January2016
923-4thru923-8 ............. 5.December2008
924-1thru924-2 ................. 31.March2009
924-3................................ 20.January2016
924-4thru924-11 ............... 31.March2009
924-12..............................31.October2013
925-1thru925-8 ................. 31.March2009
926-1thru926-1 ................. 31.March2009
926-3..................................... 19.April2012
926-4.................................. 31.March2009
926-5..................................... 19.April2012
926-6................................ 20.January2016
926-7thru926-8 ................. 31.March2009
Page Date
Page Date: 20. January 2016
927-1................................31.October2013
927-2..................................... 19.April2012
927-3................................31.October2013
927-4thru927-6 .................... 19. April 2012
928-1thru928-4 ............... 17.January2013
929-1thru929-16 ............. 20.January2016
Page Date

iv Page Date: 31. March 2009
Pilot´s Operating Handbook
EXTRA300L
INTRODUCTION
This handbook contains 9 sections, and includes the material required to be furnished to the
pilot by FAR Part 23. It also contains supplementary data supplied by EXTRA Flugzeug-
produktions-undVertriebs-GmbH.
THISMANUALISFURNISHEDTOTHECIVILAVIATIONAUTHORITIESASAPARTOFTHE
CERTIFICATIONMATERIALFORTHISMODEL.
NOTES
This Flight Manual applies only to the aircraft whose nationality and registration marks are
noted on the title page.
ThisFlightManual is onlyvalidinconnection with thelatestapprovedrevision. Refer tothe
EXTRAHomepage(directlink:http://www.extraaircraft.com/techservice.php),wherethePOH
RevisionIndexalwaysshowsthecurrentrevisionstatus.
It is the responsibility of the pilot to be familiar with the contents of this Flight Manual
includingrevisionsandanyrelevantsupplements.
Pages of this Airplane Flight Manual must not be exchanged and no alterations of or
additionstotheapprovedcontentsmaybemadewithouttheEXTRAFlugzeugproduktions-
undVertriebs-GmbH/EASAapproval.
Theeditor hasthe copyright of this FlightManual andis responsible for edition ofrevisions/
amendmentsandsupplements.
Amendments,whichaffect the airworthiness oftheaircraftwillbe announced in the
mandatoryServiceBulletinsissuedbythemanufacturerEXTRAFlugzeugproduktions-und
Vertriebs-GmbHcomingalongwiththe"AirworthinessDirective"(AD)publicationissuedby
theEASA. Theownerisresponsiblefor incorporatingprescribedamendmentsandshould
make notes about these on the records of amendments.
ShouldthisFlightManualgetlost,informEXTRAFlugzeugproduktions-undVertriebs-GmbH,
FlugplatzDinslaken46569Hünxe,FederalRepublicofGermany.
Should this Flight Manual be found, kindly forward it to the civil board of aviation in the country
theaircraftisregistered.
Page Date: 19. April 2012

Page Date: 31. March 2009 v
Pilot´s Operating Handbook
EXTRA300L
NOTESANDSAFETYNOTES
Safetynotesinthismanualaremarkedbyaboxedtextmarkerinthemiddleofthepageandwritten
insemi-boldcharacters.Thismanualdistinguishesthreewarninglevels:
D A N G E R
Indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
W A R N I N G
Indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
C A U T I O N
Indicates a hazardous situation which, if not avoided, could result in minor or mode-
rate injury.
Additionalinformationgiveninthismanualarealsomarkedbyboxedtextmarkersinthemiddle
ofthepage and arewritteninsemi-bold characters:
N O T I C E
Is used to address practices not related to physical injury.
N O T E
Represents an useful or remarkable hint.
TERMINOLOGIE
The words "shall", "must" or "will" are used to express a mandatoryrequirement.
Theword"should"isusedtoexpressnonmandatoryprovisions.
The word "may" is used to express permissible.
Page Date: 20. January 2016

vi Page Date: 31. March 2009
Pilot´s Operating Handbook
EXTRA300L
MAINTABLEOFCONTENTS
Section Page
1 GENERAL 1-1
2 LIMITATIONS 2-1
3 EMERGENCYPROCEDURES 3-1
4 NORMALPROCEDURES 4-1
5 PERFORMANCE 5-1
6 WEIGHT&BALANCE/EQUIPMENTLIST 6-1
7 AIRPLANE&SYSTEMSDESCRIPTIONS 7-1
8 AIRPLANEHANDLING,SERVICE&MAINTENANCE 8-1
9 SUPPLEMENTS 9-1

Page Date: 20. April 2002 1 - 1
Pilot´s Operating Handbook
EXTRA 300L
Section 1
General
SECTION 1
GENERAL
Table of Contents
Paragraph Page
SECTION 1 GENERAL
1.0 DESCRIPTION ....................................................................................................................... 1-3
1.1 SPECIFICATION OF CLASS ................................................................................................. 1-3
1.2 MANUFACTURER .................................................................................................................. 1-3
1.3 TECHNICAL DATA................................................................................................................. 1-3
1.3.1 3-View Drawing ...................................................................................................................... 1-3
1.3.2 Main Data............................................................................................................................... 1-3
1.3.3 Wing ...................................................................................................................................... 1-4
1.3.4 Horizontal Tail ......................................................................................................................... 1-4
1.3.5 Elevator .................................................................................................................................. 1-4
1.3.6 Vertical Tail............................................................................................................................. 1-4
1.3.7 Rudder ................................................................................................................................... 1-4
1.4 ENGINE .................................................................................................................................. 1-4
1.5 PROPELLER ......................................................................................................................... 1-5
1.5.1 Exhaust Systems (Optional) .................................................................................................. 1-5
1.6 FUEL ...................................................................................................................................... 1-5
1.7 OIL ......................................................................................................................................... 1-5
1.8 LOADING ............................................................................................................................... 1-6
1.9 TERMINOLOGY ..................................................................................................................... 1-6
1.10 SECONDARY TERMINOLOGY .............................................................................................. 1-7
1.11 CONVERSION TABLE ........................................................................................................... 1-8
Page Date: 16. March 2009

1 - 2 Page Date: 20. April 2002
Section 1
General
Pilot´s Operating Handbook
EXTRA 300L
Left blank intentionally

Page Date: 20. April 2002 1 - 3
Pilot´s Operating Handbook
EXTRA 300L
Section 1
General
1.0 DESCRIPTION
The airframe of the EXTRA 300L is built of a tig-welded steel-tube construction. Wings,
empennage and landing gear are manufactured of composite material.
The aircraft is a two-seater with the rear seat instrumented for pilot in comand.
1.1 SPECIFICATION OF CLASS
The aircraft is certified in normal and acrobatic category (T.C.D.S. EASA.A.362).
1.2 MANUFACTURER
EXTRA Flugzeugproduktions- und Vertriebs- GmbH,
Flugplatz Dinslaken
46569 Hünxe,
Federal Republic of Germany.
1.3 TECHNICAL DATA
1.3.1 3-VIEW DRAWING
Page Date: 31. March 2009

1 - 4 Page Date: 20. April 2002
Section 1
General
Pilot´s Operating Handbook
EXTRA 300L
1.3.2 MAIN DATA
- Length 6,96 m (22,83 ft)
- Height 2,62 m ( 8,60 ft)
- Span 8,00 m (26,25 ft)
- Wheel-base 5,07 m (16,63 ft)
- Wheel-track 1,80 m ( 5,91 ft)
1.3.3 WING
- Wing span 8,0 m (26,25 ft)
- Wing-area 10,7 m² (115,17 ft²)
- Airfoil Root: MA 15 S. Tip, MA 12 S
- Chord Root: 1,85 m. Tip, 0,88 m
- MAC 1,404 m ( 4,61 ft)
- Aileron area 2 x 0,855 m² (2 x 9,20 ft²)
- Aileron deflection up/down 30°, tolerance ± 2°
1.3.4 HORIZONTAL TAIL
- Span 3,20 m (10,50 ft)
- Area 2,56 m² (27.56 ft²)
- Airfoil Wortmann FX 71-L-150/30
1.3.5 ELEVATOR
- Area 0,77 m² (8,29 ft²)
- Elevator-deflection up/down 25°, tolerance ±2°
- Trim-tab-deflection up 40°, down 50°, tolerance ±5°
1.3.6 VERTICAL TAIL
- Area 1,39 m² (14,96 ft²)
- Airfoil Wortmann FX 71-L-150/30
1.3.7 RUDDER
- Area 0,51 m² ( 5,49 ft²)
- Rudder deflection left/right 30°, tolerance ±2°
Page Date: 19. April 2012

Page Date: 20. April 2002 1 - 5
Pilot´s Operating Handbook
EXTRA 300L
Section 1
General
1.4 ENGINE
Manufacturer: Textron-Lycoming Williamsport Plant PA 17701 USA.
a) Type Lycoming AEIO-540-L1B5
b) Type Lycoming AEIO-540-L1B5D
Rated power: 300 HP @ 2700 RPM; 270 HP @ 2400 RPM
1.5 PROPELLER
Manufacturer: MT-Propeller Entwicklung GmbH, Federal Republic of Germany.
a) Type MTV-9-B-C/C 200-15 3-blade constant speed.
b) Type MTV-14-B-C/C 190-17 4-blade constant speed.
1.5.1 EXHAUST SYSTEMS (OPTIONAL)
Manufacturer: Gomolzig Flugzeug- und Maschinenbau GmbH, Federal Republic of Germany
Exhaust Silencer for standard system: PN: EA 300 NSD GO3-606500.
Complete 6 in 1 System with integrated Silencer: PN: EA 300-606000
1.6 FUEL
Fuel type AVGAS 100/100 LL (for alternate fuel grades see later issues of Textron Lycoming
S.I. No 1070)
Minimum 100/130 octane. Maximum 115/145 octane.
Total fuel capacity: 171 L (45.1 US.gal)
- Wingtanks (2 x 60 L): 120 L (31.7 US.gal)
- Acro & center tank: 51 L (13.4 US.gal)
Usable fuel capacity in the system: 165.5 L (43.7 US.gal)
Usable fuel capacity for acrobatic: 45.5 L (12.0 US.gal)
1.7 OIL
Maximum sump capacity: 16 US.qt
Minimum sump capacity: 9 US.qt
Average ambient air Mil-L6082 Mil-22851
temperature grades ashless dispersant grades
All temperatures ---- SAE 15W50 or 20W50
> 27°C (80°F) SAE 60 SAE 60
> 16°C (60°F) SAE 50 SAE 40 or 60
- 1°C til 32°C SAE 40 SAE 40
(30°F - 90°F)
Page Date: 31. March 2009

1 - 6 Page Date: 20. April 2002
Section 1
General
Pilot´s Operating Handbook
EXTRA 300L
1.7 OIL (Cont.)
Average ambient air Mil-L6082 Mil-22851
temperature grades ashless dispersant grades
- 18°C til 21°C SAE 30 SAE 30,40 or 20W40
(0°F - 70°F)
- 18°C til 32°C SAE 20W50 SAE 20W50 or 15W50
(0°F - 90°F)
< -12°C (10°F) SAE 20 SAE 30 or 20W30
(single or multi - viscosity aviation grade oils see latest issue of Textron Lyc. S.I. No. 1014)
1.8 LOADING
Wing loading 88,8 kg/m² Normal
76,6 / 81,3 kg/m² Acrobatic (1 seat / 2 seats)
Power loading 3,17 kg/hp Normal
2.73 / 2.90 kg/hp Acrobatic (1 seat / 2 seats)
1.9 TERMINOLOGY
Air Speeds
CAS Calibrated Air Speed. CAS is the same as TAS
(True Air Speed) in standard atmospheric condition at sea level
KCAS Calibrated speed in knots
GS Ground speed
IAS Indicated air speed
KIAS Indicated speed in knots
TAS True air speed. It's the same as CAS compensated for altitude,
temperature and density
VAManeuvering speed
VNE Never exceed speed
VNO Maximum structural crusing speed
VSStalling speed or minimum steady flight speed
VXBest angle-of-climb speed
VYBest rate-of-climb speed

Page Date: 20. April 2002 1 - 7
Pilot´s Operating Handbook
EXTRA 300L
Section 1
General
Meteorological terminology
ISA International standard atmospheric condition
OAT Outside air temperature
1.10 SECONDARY TERMINOLOGY
fpm Feet/minute
ft Feet = 0.3048 m
in inch = 2.54 cm
m Meter
L Litres
US.gal US (liquid) gallon = 3.79 litres
US.qt US (liquid) quart = 0.946 litres
hp Horse power (english)
h Hour
kts Knots (nm/h) = 1.852 kilometer per hour
km/h Kilometer per hour
lbs English pound = 0.4536 kg
hPa hekto Pascal
inHg Inches of mercury
MP Manifold pressure
PA Pressure altitude (ft)
nm Nautical miles = 1.852 km
rpm Revolutions per minute
CG Center of gravity
Arm Arm is the horizontal distance from reference datum
Moment is the product of weight of an item multiplied by its arm.
Page Date: 31. March 2009

1 - 8 Page Date: 20. April 2002
Section 1
General
Pilot´s Operating Handbook
EXTRA 300L
1.11 CONVERSION TABLE
Page Date: 16. March 2009

Page Date: 20. April 2002 2 - 1
Pilot´s Operating Handbook
EXTRA 300L Section 2 Limitations
SECTION 2
LIMITATIONS
Table of Contents
Paragraph Page
SECTION 2 LIMITATIONS
2.1 GENERAL........................................................................................................................... 2-3
2.2 AIR SPEED (IAS) ............................................................................................................... 2-3
2.3 CROSS-WIND COMPONENT............................................................................................. 2-3
2.4 ENGINE .............................................................................................................................. 2-3
2.4.1 Fuel ..................................................................................................................................... 2-4
2.4.2 EngineLimitations ............................................................................................................... 2-4
2.5 PROPELLER ...................................................................................................................... 2-5
2.6 WEIGHT LIMITS ................................................................................................................. 2-5
2.7 WEIGHT AND C.G. ENVELOPE ......................................................................................... 2-5
2.7.1 Normal Flight....................................................................................................................... 2-5
2.7.2 Acrobatic Flight (1 Seat) ...................................................................................................... 2-5
2.7.3 Acrobatic Flight (2 Seats) .................................................................................................... 2-6
2.8 ACROBATIC MANEUVERS................................................................................................ 2-6
2.8.1 Normal Flight....................................................................................................................... 2-6
2.8.2 Acrobatic Flight.................................................................................................................... 2-6
2.9 LOAD FACTOR................................................................................................................... 2-7
2.9.1 Normal Flight....................................................................................................................... 2-7
2.9.2 Acrobatic Flight.................................................................................................................... 2-8
2.10 FLIGHT CREW LIMITS ...................................................................................................... 2-8
2.11 KINDS OF OPERATIONAL LIMITS .................................................................................... 2-8
2.11.1 Structural Temperature/Colour Limitation............................................................................. 2-8
2.12 MAXIMUM OPERATINGALTITUDE................................................................................... 2-8
2.13 TIRE PRESSURE ............................................................................................................... 2-8
2.14 MARKINGSAND PLACARDS ............................................................................................ 2-8
2.14.1 Aircraft Identity Placards...................................................................................................... 2-8
2.14.2 OperatingPlacards.............................................................................................................. 2-9
2.14.3 Instrument Markings.......................................................................................................... 2-12
2.15 KINDS OF OPERATION EQUIPMENT LIST .......................................................................2-13
Page Date: 20. January 2016

2 - 2 Page Date: 20. April 2002
Pilot´s Operating Handbook
EXTRA 300L
Section 2
Limitations
Left blank intentionally

Page Date: 20. April 2002 2 - 3
Pilot´s Operating Handbook
EXTRA 300L Section 2 Limitations
SECTION 2
LIMITATIONS
2.1 GENERAL
This section includes operating limitations, instrument markings, and basic placards
necessary for the safe operation of the aircraft, its engine, standard systems, and standard
equipment.The limitations includedinthis section havebeen approved bytheEASA.
Observanceoftheseoperatinglimitationsisrequiredbynationalaviationregulations.
N O T E
In case of an aircraft equipped with specific options additional information required
for safe operation will be contained in Section 9 "Supplements".
Instrument markings and placards are provided for the acrobatic category only; for normal
categoryrefertocorrespondinglimitations.ThisaircraftiscertifiedunderTypeCertification
DataSheet (T.C.D.S. EASA.A.362).
Any exceedance of given limitations has to be reported by the pilot so that necessary
inspectionor maintenance proceduresaccording tothe SERVICE MANUALEA 300/L canbe
performed.
2.2 AIR SPEED (IAS)
NeverExceedSpeed VNE 220 knots (407km/h)
Max.StructuralCruisingSpeed(NormalCat.) VNO 140 knots (259km/h)
Max. Structural Cruising Speed (Acro I , Acro II) VNO 158 knots (293km/h)
ManeuverSpeed(NormalCat.) VA140 knots (259km/h)
ManeuverSpeed(AcroI,AcroII) VA158 knots (293km/h)
2.3 CROSS-WIND COMPONENT
Max.demonstrated cross-wind component fortake-off and landingis15 knots (27km/h).
2.4 ENGINE
Engine-typeTextron-LycomingAEIO-540-L1B5/AEIO-540-L1B5Dwithratedmaximum
300 HP @ 2700 RPM.
Page Date: 31. March 2009

2 - 4 Page Date: 20. April 2002
Pilot´s Operating Handbook
EXTRA 300L
Section 2
Limitations
2.4.1 FUEL
Minimumgradeaviationgasoline:100/100LL;foralternatefuelgradessee
latest revision of Lyc. S.I. No. 1070
Total fuel capacity: 171 L (45.1 US.gal).
Usable fuel capacity: 165.5 L (43.6 US.gal).
For acrobatic flight wing tanks must be empty.
Total fuel capacity for acrobatic: 51 L (13.4 US.gal) in acro & center tank.
Usable fuel capacity for acrobatic: 45.5 L (12.0 US.gal) in acro & center tank.
2.4.2 ENGINELIMITATIONS
a) Rotational Speed
-MaximumTake-OffandMaximumContinuous 2700rpm
b) Oil-temperature
-Max 118°C 245°F
c) Oil capacity
-Maximum sump capacity: 15.13L 16 US.qt
-Minimum sump capacity: 8.51 L 9 US.qt
d) Oil pressure
-MinimumIdling 172 kPa 25 Psi
-Normal 379 - 655 kPa 55 - 95 Psi
-Starting,Warmup,
TaxiandTake-Off 793 kPa 115 Psi
W A R N I N G
It is normal for the oil pressure to "flicker" from 10 to 30 psi (69 to 207 kPa) when
going from upright to inverted flight. During knife edge flights and zero-g flights oil
pressure may drop and the oil system may not scavenge resulting in engine failure
or damage if flight is prolonged.
Knife edge and zero-g flight should not exceed 10 seconds.
W A R N I N G
If oil pressure drops to 0 psi (kPa) the propeller pitch changes automatically to
coarse (high) pitch with a corresponding decrease in RPM.
Apply positive g to avoid engine stoppage.
e) Fuel pressure
-Max 276 kPa 40 Psi
-Min 124 kPa 18 Psi
-MinIdle 83 kPa 12 Psi
Page Date: 20. January 2016
