Extra 300L Quick setup guide

I N F O R M AT I O N M AN U AL
E X T R A 3 0 0 L
MANUFACTURER
EXTRA Flugzeugproduktions- und Vertriebs- GmbH
FlugplatzDinslaken
46569 Hünxe, Federal Republic of Germany
TITLE PAGE
W A R N I N G
This is an Information Manual and may be used for general purposes only.
This Information Manual is not kept current.
It must not be used as a substitute for the official FAA/EASA Approved Pilot's Operating
Handbook required for operation of the airplane.

Left blank intentionally

Page Date: 20. April 2002 i
Pilot´s Operating Handbook
EXTRA 300L
MAIN TABLE OF CONTENTS
Section Page
0 PUBLICATION GUIDANCE..............................................................................................0-1
1 GENERAL......................................................................................................................... 1-1
2 LIMITATIONS ...................................................................................................................2-1
3 EMERGENCY PROCEDURES......................................................................................... 3-1
4 NORMAL PROCEDURES ................................................................................................ 4-1
5 PERFORMANCE..............................................................................................................5-1
6 WEIGHT AND BALANCE AND EQUIPMENT LIST.......................................................... 6-1
7 DESCRIPTION AND OPERATION OF AIRCRAFT AND SYSTEMS................................ 7-1
8 HANDLING, SERVICING AND MAINTENANCE .............................................................. 8-1
9 SUPPLEMENTS ...............................................................................................................9-1

ii Page Date: 20. April 2002
Pilot´s Operating Handbook
EXTRA 300L
THIS HANDBOOK SHALL ALWAYS BE CARRIED ON BOARD DURING FLIGHT.
PILOTS OPERATING HANDBOOK PREPARED THIS MANUAL IS FURNISHED TO
BY: THE CIVIL AVIATION AUTHORITIES
AS A PART OF THE CERTIFICATION-
EXTRA Flugzeugproduktions- und Vertriebs- GmbH MATERIAL FOR THIS MODEL.
.
Page Date: 15. December 2005

Section 0
Publication Guidance
Page Date: 20. April 2002 0 - 1
Pilot´s Operating Handbook
EXTRA 300L
SECTION 0
PUBLICATIONGUIDANCE
Table of Contents
Paragraph Page
SECTION 0 PUBLICATION GUIDANCE
1 INTRODUCTION................................................................................................................. 0-3
2 NOTES................................................................................................................................ 0-3
3 WARNINGS, CAUTIONS AND NOTES............................................................................... 0-4
4 LOG OF EFFECTIVE PAGES ............................................................................................. 0-5

Section 0
Publication Guidance
0 - 2 Page Date: 20. April 2002
Pilot´s Operating Handbook
EXTRA 300L
Left blank intentionally

Section 0
Publication Guidance
Page Date: 20. April 2002 0 - 3
Pilot´s Operating Handbook
EXTRA 300L
1 INTRODUCTION
This handbook contains 10 sections, and includes the material required to be furnished to
the pilot by FAR Part 23. It also contains supplementary data supplied by EXTRA Flugzeug-
produktions- und Vertriebs- GmbH .
2 NOTES
2.1 This Flight Manual applies only to the aircraft whose nationality and registration marks are
noted on the title page.
2.2 It is the responsibility of the pilot to be familiar with the contents of this Flight Manual
including revisions and any relevant supplements.
2.3 Pages of this Airplane Flight Manual must not be exchanged and no alterations of or
additions to the approved contents may be made without the EXTRA Flugzeugproduktions-
und Vertriebs- GmbH/LBA approval.
The editor has the copyright of this Flight Manual and is responsible for edition of revisions/
amendments and supplements.
2.4 Amendments, which affect the airworthiness of the aircraft will be announced in the
publication Lufttüchtigkeitsanweisung (airworthiness directive) issued by LBA, Luftfahrt-
Bundesamt, or by the manufacturer EXTRA Flugzeugproduktions- und Vertriebs- GmbH.
The owner is responsible for incorporating prescribed amendments and should make notes
about these on the records of amendments.
2.5 Should this Flight Manual get lost, inform EXTRA Flugzeugproduktions- und Vertriebs-
GmbH, Dinslaken 46569 Hünxe, Federal Republic of Germany.
2.6 Should this Flight Manual be found, kindly forward it to the civil board of aviation in the
country the aircraft is registered.
Page Date: 15. December 2005

Section 0
Publication Guidance
0 - 4 Page Date: 20. April 2002
Pilot´s Operating Handbook
EXTRA 300L
3 WARNINGS, CAUTIONS AND NOTES
The following definitions apply to Warnings, Cautions, and Notes:
WARNING
=> Operating procedures, techniques, etc which could result in personal
injury or loss of life if not carefully followed
CAUTION
=> Operating procedures, techniques, etc , which could result in damage to
equipment if not carefully followed.
NOTE
=> An operating procedures, technique, etc which is considered essential to
emphasize.
"Shall, "Will", "Should" and "May"
The words "Shall" or, "will" shall be used to express a mandatory
requirement. The word "should" shall be used to express nonmandatory
provisions. The word "may" shall be used to express permissible.

Section 0
Publication Guidance
Page Date: 20. April 2002 0 - 5
Pilot´s Operating Handbook
EXTRA 300L
4 LOG OF EFFECTIVE PAGES
Datesofissuefororiginalandrevisedpages:
Original ........................ 9. September 1994
Revision No. 1 ..................... 26. June 1997
Revision No. 2 ....................... 7. June 1999
Edition No. 2 .........................20. April 2002
Rev. No. 1, 2nd Ed. ...... 15.December2005
Rev. No. 2, 2nd Ed. ..... 20.September2006
Rev. No. 3, 2nd Ed. .................6.June2008
Dateandsignofapproval:
LBAapproved................. 31. January 1995
LBAapproved...................27. August 1997
LBAapproved...................... 23. June 1999
LBAapproved................. 30. October 2002
EASA ApprovalN° ......... EASA.A.A.01101
DateofApproval ........... 20.December2005
EASA ApprovalN° ......... EASA.A.A.01319
DateofApproval ............20.November2006
EASA ApprovalN° ......... EASA.A.C.08351
DateofApproval
Page Date: 6. June 2008

Section 0
Publication Guidance
0 - 6 Page Date: 20. April 2002
Pilot´s Operating Handbook
EXTRA 300L
Page Date
Title.............................. 15.December2005
i ............................................ 20.April 2002
ii................................... 15.December2005
0-1thru0-2 ........................... 20.April2002
0-3 ............................... 15.December2005
0-4 ........................................ 20.April2002
0-5thru0-6 .............................6.June2008
1-1 ............................... 15.December2005
1-2 ........................................ 20.April2002
1-3 ............................... 15.December2005
1-4 ........................................ 20.April2002
1-5 ............................... 15.December2005
1-6thru1-8 ........................... 20.April2002
2-1thru2-3 ........................... 20.April2002
2-4thru2-5 .................. 15.December2005
2-6 ........................................ 20.April2002
2-7 ............................... 15.December2005
2-8 .............................. 20.September2006
2-9thru2-11................. 15.December2005
2-12 ...................................... 20.April 2002
2-13thru2-14............... 15.December2005
3-1thru3-4 ........................... 20.April2002
3-5 ............................... 15.December2005
3-6 ........................................ 20.April2002
3-7 ............................... 15.December2005
3-8 ........................................ 20.April2002
4-1thru4-12.......................... 20. April 2002
5-1thru5-14.......................... 20. April 2002
6-1thru6-2 ........................... 20.April2002
6-3 .............................. 20.September2006
6-4thru6-9 ........................... 20.April2002
6-10thru6-14..........................6.June2008
7-1 .............................. 20.September2006
7-2 ........................................ 20.April2002
LOG OF EFFECTIVE PAGES (cont.)
Page Date: 6. June 2008
7-3 ............................... 15.December2005
7-4thru7-9 ........................... 20.April2002
7-10thru7-14............... 15.December2005
7-15thru7-16........................ 20.April2002
8-1thru8-4 ........................... 20.April2002
9-1 ..........................................6.June2008
9-2 ........................................ 20.April2002
9-3 ............................... 15.December2005
9-4 ........................................ 20.April2002
901-1thru901-4 .................... 20.April2002
902-1thru902-4 .................... 20.April2002
903-1thru903-10 .................. 20.April2002
904-1thru904-8 .................... 20.April2002
905-1thru905-2 .................... 20.April2002
905-3............................ 15.December2005
905-4thru905-6 .................... 20.April2002
906-1thru906-6 .................... 20.April2002
907-1thru907-6 .................... 20.April2002
908-1thru908-8 .................... 20.April2002
909-1........................... 20.September2006
909-2..................................... 20. April 2002
909-3thru909-8 .......... 20.September2006
910-1thru910-8 .................... 20.April2002
911-1thru911-4 .................... 20.April2002
912-1thru912-8 ........... 15.December2005
913-1thru913-8 ........... 15.December2005
914-1thru914-6 ........... 15.December2005
915-1thru915-8 ........... 15.December2005
916-1thru916-6 ........... 15.December2005
917-1thru917-8 ........... 15.December2005
918-1thru918-6 ........... 15.December2005
919-1thru919-8 ........... 15.December2005
920-1thru920-10 ......... 15.December2005
921-1thru921-6 ......................6.June2008
Page Date

Page Date: 20. April 2002 1 - 1
Pilot´s Operating Handbook
EXTRA 300L Section 1 General
Page Date: 15. December 2005
SECTION 1
GENERAL
Table of Contents
Paragraph Page
SECTION 1 GENERAL
1.0 DESCRIPTION.................................................................................................................... 1-3
1.1 SPECIFICATION OF CLASS .............................................................................................. 1-3
1.2 MANUFACTURER .............................................................................................................. 1-3
1.3 TECHNICALDATA.............................................................................................................. 1-3
1.3.1 3-ViewDrawing ................................................................................................................... 1-3
1.3.2 Main Data............................................................................................................................ 1-4
1.3.3 Wing.................................................................................................................................... 1-4
1.3.4 HorizontalTail...................................................................................................................... 1-4
1.3.5 Elevator ............................................................................................................................... 1-4
1.3.6 Vertical Tail .......................................................................................................................... 1-4
1.3.7 Rudder ................................................................................................................................ 1-4
1.4 ENGINE .............................................................................................................................. 1-5
1.5 PROPELLER ...................................................................................................................... 1-5
1.5.1 Exhaust Systems (Optional) ................................................................................................ 1-5
1.6 FUEL................................................................................................................................... 1-5
1.7 OIL ...................................................................................................................................... 1-5
1.8 LOADING............................................................................................................................ 1-6
1.9 TERMINOLOGY ................................................................................................................. 1-6
1.10 SECONDARYTERMINOLOGY .......................................................................................... 1-7

1 - 2 Page Date: 20. April 2002
Section 1
General Pilot´s Operating Handbook EXTRA 300L
Left blank intentionally

Page Date: 20. April 2002 1 - 3
Pilot´s Operating Handbook
EXTRA 300L Section 1 General
1.0 DESCRIPTION
This description belongs to aircraft type EXTRA 300/L with nationality and registration
marks:
D - E J X A
Manufacturing
The airframe is built of tig-welded steel-tube construction. Wings, rudder and landing gear are
manufactured of composite material.
The aircraft is a two-seater with the rear seat instrumented for pilot in comand.
1.1 SPECIFICATIONOFCLASS
The aircraft is certified in normal and acrobatic category. LBA - Certificate No. 1086.
1.2 MANUFACTURER
Manufacturer EXTRA Flugzeugproduktions- und Vertriebs- GmbH, Flugplatz Dinslaken
46569 Hünxe, Federal Republic of Germany.
1.3 TECHNICALDATA
1.3.1 3-VIEWDRAWING
Page Date: 15. December 2005

1 - 4 Page Date: 20. April 2002
Section 1
General Pilot´s Operating Handbook EXTRA 300L
1.3.2 MAINDATA
- Length 6,96 m (22,83 ft)
- Height 2,62 m ( 8,60 ft)
- Span 8,00 m (26,25 ft)
- Wheel-base 1,80 m ( 5,91 ft)
- Wheel-track 5,45 m (17,88 ft)
1.3.3 WING
- Wing span 8,0 m (26,25 ft)
- Wing-area 10,7 m² (115,17 ft²)
- Airfoil Root: MA 15 S. Tip, MA 12 S
- Chord Root: 1,85 m. Tip, 0,88 m
- MAC 1,404 m ( 4,61 ft)
- Aileron area 2 x 0,855 m² (2 x 9,20 ft²)
- Aileron deflection ± 30°, tolerance ± 2°
1.3.4 HORIZONTALTAIL
- Span 3,20 m (10,50 ft)
- Area 2,56 m² (27.56 ft²)
- Airfoil Wortmann FX 71-L-150/30
1.3.5 ELEVATOR
- Area 0,77 m² (8,29 ft²)
-Elevator-deflection up 25°; down 25°; tolerance ± 2°
- Trim-tab-deflection ± 15°, tolerance ± 2°
1.3.6 VERTICALTAIL
- Area 1,39 m² (14,96 ft²)
- Airfoil Wortmann FX 71-L-150/30
1.3.7 RUDDER
- Area 0,51 m² ( 5,49 ft²)
- Rudder deflection left 30°; right 30°; tolerance ± 2°

Page Date: 20. April 2002 1 - 5
Pilot´s Operating Handbook
EXTRA 300L Section 1 General
1.4 ENGINE
Manufacturer Textron-Lycoming Williamsport Plant PA 17701 USA.
a) Type Lycoming AEIO-540-L1B5
b) Type Lycoming AEIO-540-L1B5D
Rated power: 300 HP @ 2700 RPM; 270 HP @ 2400 RPM
1.5 PROPELLER
Manufacturer MT-Propeller Entwicklung GmbH, Federal Republic of Germany.
a) Type MTV-9-B-C/C 200-15 3-blade constant speed.
b) Type MTV-14-B-C/C 190-17 4-blade constant speed.
1.5.1 EXHAUST SYSTEMS (OPTIONAL)
Manufacturer Gomolzig Flugzeug- und Maschinenbau GmbH, Federal Republic of Germany
Exhaust Silencer for standard system: PN: EA 300 NSD GO3-606500.
Complete 6 in 1 System with integrated Silencer: PN: EA 300-606000
1.6 FUEL
Fuel type AVGAS 100/100 LL (for alternate fuel grades see later issues of Textron
Lycoming S.I. No 1070)
Minimum 100/130 octane. Maximum 115/145 octane.
Total fuel capacity 171 liters (45.1 US Gallon)
- Wingtanks (2 x 60 l) 120 liters (31.7 US Gallon)
- Acro tank 51 liters (13.4 US Gallon)
Usable fuel capacity in the system 165.5 liters (43.7 US Gallon)
Usable fuel capacity for acrobatic 45.5 liters (12.0 US Gallon)
1.7 OIL
Maximum sump capacity: 16 qts.
Minimum sump capacity: -Acrobatic: 12 qts.
-Normal: 9 qts.
Average ambient air Mil-L6082 Mil-22851
temperature grades ashless dispersant grades
All temperatures ---- SAE 15W50 or 20W50
> 27°C (80°F) SAE 60 SAE 60
> 16°C (60°F) SAE 50 SAE 40 or 60
- 1°C til 32°C SAE 40 SAE 40
(30°F - 90°F)
Page Date: 15. December 2005

1 - 6 Page Date: 20. April 2002
Section 1
General Pilot´s Operating Handbook EXTRA 300L
1.7 OIL (Cont.)
Average ambient air Mil-L6082 Mil-22851
temperature grades ashless dispersant grades
- 18°C til 21°C SAE 30 SAE 30,40 or 20W40
(0°F - 70°F)
- 18°C til 32°C SAE 20W50 SAE 20W50 or 15W50
(0°F - 90°F)
< -12°C (10°F) SAE 20 SAE 30 or 20W30
(single or multi - viscosity aviation grade oils see latest issue of Textron Lyc. S.I. No. 1014)
1.8 LOADING
Wing loading 88,8 kg/m² Normal
76,6 / 81,3 kg/m² Acrobatic ( 1 seat / 2 seats )
Powerloading 3,17 kg/hp Normal
2.73 / 2.90 kg/hp Acrobatic ( 1 seat / 2 seats )
1.9 TERMINOLOGY
Air Speeds
CAS Calibrated Air Speed. CAS is the same as TAS
(True Air Speed) in standard atmospheric condition at sea level
KCAS Calibrated speed in knots
GS Ground speed
IAS Indicated air speed
KIAS Indicated speed in knots
TAS True air speed. It's the same as CAS compensated for altitude,
temperature and density
VA Maneuveringspeed
VNE Never exceed speed
VNO Maximum structural crusing speed
VS Stalling speed or minimum steady flight speed
VX Best angle-of-climb speed
VY Best rate-of-climb speed

Page Date: 20. April 2002 1 - 7
Pilot´s Operating Handbook
EXTRA 300L Section 1 General
Meteorological terminology
ISA International standard atmospheric condition
OAT Outside air temperature
1.10 SECONDARYTERMINOLOGY
FPM Feet/minute
ft Feet = 0.3048 m
inch inch = 2.54 cm
m Meter
L Litres
Gal US gallon = 3.79 litres
Qts US quart = 0.946 litres
hp Horse power (english)
h Hour
kts Knots (NM/h) = 1.852 kilometer per hour
Lbs English pound = 0.4536 kg
hPA hekto Pascal
IN HG Inches of mercury
MP Manifold pressure
PA Pressure altitude (ft)
NM Nautical miles = 1.852 km
RPM Revolutions per minute
CG Center of gravity
Arm Arm is the horizontal distance from reference datum
Moment is the product of weight of an item multiplied by its arm.

1 - 8 Page Date: 20. April 2002
Section 1
General Pilot´s Operating Handbook EXTRA 300L
