Specifications — CVDA 6 MX, CVDA 6 MX Dual
Video
Bandwidth .....................................
Video input
Number/signal type
CVDA 6 MX ......................
CVDA 6 MX Dual ............
Connectors ...................................
Nominal level ...............................
90 MHz (-3 dB)
1 composite video
2 composite video
1 or 2 BNC female (depending on the model)
1 Vp-p for composite video
Minimum/maximum levels....... Analog: 0.4 V to 1.4 Vp-p with no offset at unity gain
Impedance .................................... 75 ohms
Return loss .................................... <-30 dB @ 5 MHz
Maximum DC offset.................... ±5 mV
Video output
Number/signal type
CVDA 6 MX ...................... 1 x 6 composite video
CVDA 6 MX Dual ............ 2 x 6 composite video
Connectors ................................... (1 or 2) x 6 BNC female
Nominal level ............................... 1 Vp-p for composite video
Minimum/maximum levels ....... Analog: 0.4 V to 1.4 Vp-p
Impedance .................................... 75 ohms
Sync
Standards ...................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
General
Power ............................................ 100 VAC to 240 VAC, 50/60 Hz, 10 watts, internal, autoswitchable
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Rack mount .................................. Yes, with optional 1U rack shelf, part #60-190-01 or 60-604-01
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.75" H x 8.7" W x 9.4" D (1U high, half rack wide)
4.4 cm H x 22.1 cm W x 23.9 cm D
Product weight
CVDA 6 MX ...................... 2.5 lbs (1.1 kg)
CVDA 6 MX Dual ............ 2.9 lbs (1.3 kg)
Shipping weight ........................... 5 lbs (3 kg)
Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A
MTBF ............................................. 30,000 hours
Warranty....................................... 3 years parts and labor
All nominal levels are at ±10%.
Specificationsare subjectto changewithout notice.
(7.51-082004-D4)
1-2 CVDA 6 MX, CVDA 6 MX Dual Distribution Amplifiers • Specifications
