Specifications — MLP 101, MLP 101 AAP, MLP 101 D
Audio
Gain ............................................... Adjustable, +25 dB to + 72 dB
Frequency response ..................... 20 Hz to 20 kHz, ±0.1 dB
THD + Noise (with a 10 Hz to 80 kHz bandwidth filter)
0.03% when input is -48 dBV and output is +4 dBu.
0.14% when input is -60 dBV and output is -10 dBV
S/N ................................................ 92 dB at maximum output (unweighted, with a 10 Hz to 80 kHz bandwidth filter)
CMRR ............................................ >70 dB @ 20 Hz to 20 kHz
Low cut filter ................................ 75 Hz (18 dB per octave)
Equivalent input noise ................ <126 dBV (unweighted, with a 10 Hz to 80 kHz bandwidth filter)
Audio input
Number/signal type ................... 1 mono, balanced
Connectors
MLP 101 ............................ (1) 3.5 mm captive screw connector, 3 pole
MLP 101 AAP, MLP 101 D 1 female 3-pin XLR
Impedance .................................... 2k ohm balanced
Nominal level ............................... -60 dBV or -48 dBV
Maximum level ............................ -1.5 dBu, (balanced) at 1% THD+N
0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV 2 dBu
Audio output
Number/signal type ................... 1 mono, balanced
Connectors .................................... (1) 3.5 mm captive screw connector, 3 pole
Impedance .................................... <150 ohms balanced
Maximum level (Hi-Z) ................ >+25 dBu, balanced at 1% THD+N
Maximum level (600 ohm) ......... >+20 dBu, balanced at 1% THD+N
Control/remote — preamp
Contact closure ............................ (1) 3.5 mm captive screw connector, 3 pole
Contact closure pin configurations 1 = +10 VDC, 2 = volume/mute (variable voltage), 3 = GND
Volume control voltage range ... 0 V (mute) to 10 V (maximum volume)
Extron remote key pad control .. (1) 3.5 mm captive screw connector, 3 pole
General
External power supply ............... 100 VAC to 240 VAC, 50/60 Hz, external; to 12 VDC, 1 A, regulated
Power input requirements ......... 12 VDC, 0.3 A
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling .......................................... Convection, unvented
Rack mount
MLP 101 ............................ Yes, with optional 1U, 9.5" deep rack shelf, part #60-190-01 (RSU 129) or 60-604-01
(RSB 129); or VersaTools®1U, 3.5" deep rack shelf, part #60-190-20 (RSF 123) or
60-604-20 (RSB 123); or VersaTools Back of the Rack mount kit, part #70-367-01
(MBB 100)
Furniture-mountable with optional VersaTools mini under-desk mounting kit ,
part #70-212-01 (MBU 123)
Projector mountable with optional kit PMK 100, part #70-217-01.
MLP 101 AAP ................... Yes, with optional faceplate or frame
MLP 101 D ........................ No, but wall or furniture mountable in a Decora -style opening
Enclosure type .............................. Metal
1-2 Extron MLP 101, MLP 101 AAP, MLP 101 D Microphone to Line Preamps • Specifications

Enclosure dimensions
MLP 101 ............................ 1.7" H x 2.2" W x 3.0" D (1U high, one-eighth rack wide)
(4.3 cm H x 5.6 cm W x 7.6 cm D)
(Depth excludes connectors.)
MLP 101 AAP
Faceplate ................... 1.4" H x 3.5" W x 0.1" D
(3.5 cm H x 8.9 cm W x 0.3 cm D)
(double space high AAP plate)
Device ........................ 1.1" H x 2.75" W x 1.8" D (2.8 cm H x 7.0 cm W x 4.6 cm D)
(Depth excludes connectors.)
MLP 101 D
Faceplate ................... 2.6" H* x 1.3" W x 0.1" D
(6.6 cm H* x 3.3 cm W x 0.3 cm D)
(Fits the opening in a 1 gang Decora faceplate.)
*Height is 3.8" (9.7 cm) including mounting tabs.
Device ........................ 2.75" H x 1.1" W x 1.8" D
(7.0 cm H x 2.8 cm W x 4.6 cm D)
(Depth excludes connectors.)
Product weight ............................. 0.3 lbs (0.1 kg)
Shipping weight ........................... 2 lbs (1 kg)
Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
(7.53-102907-D8)
