Extron electronics Two Output 13W3 Sun and SGI Distribution Amplifier 13W3... User manual

Sun/SGI Workstation
Extron
13W3 DA2
Distribution
Amplier
OUTPUT 2
Projector
www.extron.com
© 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
USA West
+1.714.491.1500 / +800.633.9876
+1.714.491.1517 FAX
USA East
+1.919.863.1794 / +800.633.9876
+1.919.863.1797 FA X
China
+86.21.3760.1568 / +400.883.1568
+86.21.3760.1566 FAX
Japan
+81.3.3511.7655
+81.3.3511.7656 FA X
Europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050 FAX
Dubai
+971.4.2991800
+971.4.2991880 FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664 FAX
www.extron.com
© 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
USA West
+1.714.491.1500 / +800.633.9876
+1.714.491.1517 FAX
USA East
+1.919.863.1794 / +800.633.9876
+1.919.863.1797 FA X
China
+86.21.3760.1568 / +400.883.1568
+86.21.3760.1566 FAX
Japan
+81.3.3511.7655
+81.3.3511.7656 FA X
Europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050 FAX
Dubai
+971.4.2991800
+971.4.2991880 FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664 FAX
sPeCifiCAtions
viDeo
Gain ................................ Unity
Bandwidth ........................ 300 MHz (-3 dB), fully loaded
viDeo inPut
Number / Signal type........... 1 Sun/SGI RGBHV, RGBS, RGsB, RsGsBs
Connectors ....................... (1) 13W3 male cable (built-in)
Nominal level .................... 0.7 Vp-p for RGB
Minimum / Maximum levels. . . Analog: 0.3 V to 1.5 Vp-p with no offset at unity gain
Impedance........................ 75 ohms
Horizontal frequency............ 15 kHz to 145 kHz
Vertical frequency............... 30 Hz to 170 Hz
Return loss ....................... <-42 dB @ 5 MHz
viDeo outPut
Number / Signal type........... 2 RGBHV, RGBS, RGsB, RsGsBs
Connectors ....................... (2) 13W3 D female
Nominal level .................... 0.7 Vp-p for RGB
Minimum / Maximum levels. . . Analog: 0.3 V to 1.5 Vp-p
Impedance........................ 75 ohms
Return loss ....................... <-50 dB @ 5 MHz
DC offset .......................... ±10 mV maximum with input at 0 offset
synC
Input type ......................... RGBHV, RGBS, RGsB, RsGsBs
Output type ....................... RGBHV, RGBS, RGsB, RsGsBs
Output level ...................... TTL: 4.5 Vp-p
Input impedance ................ 510 ohms
Output impedance .............. 75 ohms
Max. propagation delay ........ H & V: 60 ns
Max. Rise / Fall time............ 4 ns
Polarity ............................ Positive or negative
GenerAL
External power supply ......... 100 VAC to 240 VAC, 50/60 Hz, external, universal; to 9 VDC, 1 A,
regulated (attached)
Rack mount ...................... No
Enclosure type ................... Metal
Enclosure dimensions.......... 1.75" H x 4.6" W x 4.7" D (1U high, quarter rack wide)
4.4 cm H x 11.7 cm W x 11.9 cm D (Depth excludes connectors.)
Product / Shipping weight..... 1.6 lbs (0.7 kg) / 3 lbs (2 kg)
13W3 DA2
Two Output 13W3 Sun and SGI Distribution Amplifier
computer & rGb Distribution Amplifiers
feAtures
•Input: Male 13W3 cable attached
•Output: Two female 13W3 buffered outputs
•300 MHz (-3 dB) RGB video bandwidth, fully loaded
•Compatible with Sun and Silicon Graphics workstations
•ID bit termination suitable for Sun and SGI workstation monitors in all resolutions
•Compact and durable metal enclosure
•External universal power supply included, part # 70-055-01
DesCriPtion
The Extron 13W3 DA2 is a one input, two output Sun and Silicon Graphics, 13W3 distribution
amplifier. The 13W3 DA2 provides two separately buffered female 13W3 output connectors
allowing two Sun or SGI monitors to be connected to one host workstation. It also allows
for the connection of Sun and SGI computers to a compatible display, while viewing the
workstation monitor. The outputs of the 13W3 DA2 may be extended to distances up to 100 feet
(30 meters).
moDeL version DesCriPtion PArt #
13W3 DA2 1x2 13W3 ................................................................................................ 60-128-02
oPtionAL ACCessories moDeL DesCriPtion PAGe PArt #
MBU 129 1U, 1/2 Rack Width Under-Desk Mount Kit for Four-Piece Enclosure ............page 816 70-219-01
