Extron electronics Ethernet Control Interface IPL T PCS4 User manual

Specifications — IPL T PCS4, IPL T PCS4i
Ethernet control interface
Connectors .................................... 1 RJ-45 female connector
Data rate ........................................ 10/100Base-T, half/full duplex with autodetect
Protocols ....................................... ARP, DHCP, ICMP (ping), TCP/IP, UDP/IP, Telnet, HTTP, SMTP
Default settings ............................ Link speed and duplex level = autodetected
IP address = 192.168.254.254
Subnet mask = 255.255.0.0
Gateway = 0.0.0.0
DHCP = off
Web server .................................... Up to 200 simultaneous sessions
960 kB nonvolatile user memory
Program control ........................... Extron’s Simple Instruction Set(SIS™)
Global Viewer requirements ...... Microsoft®Internet Explorer ver. 6 or higher
AC control interface
Connectors
IPL T PCS4 ........................ 4 USA/Edison power connectors
IPL T PCS4i ....................... 4 IEC power connectors
Voltage
IPL T PCS4 ........................ 120 VAC, 50-60 Hz
IPL T PCS4i ....................... 220 VAC, 50-60 Hz
Minimum AC load
IPL T PCS4 ........................ 20 mA, 2.4 watts at 120 VAC
IPL T PCS4i ....................... 20 mA, 4.4 watts at 220 VAC
Maximum AC load, aggregate
IPL T PCS4 ........................ 10 A, 1200 watts at 120 VAC
IPL T PCS4i ....................... 10 A, 2200 watts at 220 VAC
Maximum AC load, individual
IPL T PCS4 ........................ 10 A, 1200 watts at 120 VAC
IPL T PCS4i ....................... 10 A, 2200 watts at 220 VAC
Current sense
Range ................................. 5 mA to 10 A
Resolution ......................... 0.1 mA steps from 5 mA to 99.9 mA
1 mA steps from 100 mA to 999 mA
10 mA steps from 1 A to 10 A
Tolerance ........................... ±20%
Alarm relay control
Quantity/type .............................. 1 normally open relay
Connector...................................... (1) 3.5 mm captive screw connector, 2 pole
Contact rating............................... 24 V, 1 A
General
Power input
PL T PCS4 ......................... 120 VAC, 50/60 Hz, 15 watts, internal
IPL T PCS4i ....................... 220 VAC, 50/60 Hz, 15 watts, internal
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Rack mount................................... Yes, with optional 1U 9.5" deep rack shelf kit, part #60-190-01
Also under-furniture mountable with optional bracket kit, part #70-077-01.
Enclosure type.............................. Metal
Enclosure dimensions ................. 1.7" H x 8.7" W x 9.5" D (1U high, half rack wide)
4.3 cm H x 22.0 cm W x 24.1 cm D
(Depth excludes connectors.)
1-2 IPL T PCS4, IPL T PCS4i • Specifications

Product weight ............................. 2.6 lbs (1.2 kg)
Shipping weight ........................... 5 lbs (3 kg)
Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
UL rated for use in a plenum air space: meets UL2043 and UL60950 for fire and
smoke.
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%
Specifications are subject to change without notice.
(7.51-020106-D7)
IPL T PCS4, IPL T PCS4i • Specifications 1-3
