Extron electronics IP Link Accessory Power over Ethernet Inserter IPA T... User manual

COM1
LAN
UID# 093012052
POWER
12V
.5A MAX
COM1
TXRXTXRX
COM2
COM2
LAN IN
10/100Mps
ETHERNETONLY
POWEREDLAN
OUT
PWR
NOTE:
LAN
POWER
12V
.5AMAX
LAN LAN LAN LAN
TCP/IP
Network
Extron
IPL T S2
Ethernet Control
Interface
Extron
IPA T IPA
PoE-Power over
Ethernet Inserter
Ethernet
Switch
Powered
LAN Out
Projector
RS-232
Extron
12V power supply
External
Power Supply
www.extron.com
© 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
USA West
+1.714.491.1500 / +800.633.9876
+1.714.491.1517 FAX
USA East
+1.919.863.1794 / +800.633.9876
+1.919.863.1797 FAX
China
+86.21.3760.1568 / +400.883.1568
+86.21.3760.1566 FAX
Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050 FAX
Dubai
+971.4.2991800
+971.4.2991880 FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664 FAX
www.extron.com
© 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
USA West
+1.714.491.1500 / +800.633.9876
+1.714.491.1517 FAX
USA East
+1.919.863.1794 / +800.633.9876
+1.919.863.1797 FAX
China
+86.21.3760.1568 / +400.883.1568
+86.21.3760.1566 FAX
Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050 FAX
Dubai
+971.4.2991800
+971.4.2991880 FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664 FAX
sPEcIfIcAtIons
GEnErAL
Connectors ....................... 1 RJ-45 female connector for pass-through input
1 RJ-45 female connector for power and pass-through output
Data rate .......................... 10/100Base-T, half/full duplex with autodetect
Power input ...................... Supplied by an attached external power supply: 100 VAC to 240 VAC, 50/60 Hz,
external, universal; to 48 VDC, 0.3 A, regulated
Power output..................... 48 VDC, IEEE 802.3af
Temperature / Humidity........ Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Rack mount ...................... Yes, with optional 1U 9.5" deep rack shelf kit, part #60-190-01; or
the 1U 3.5" deep VersaTools®rack shelf kit, part #60-190-20.
Also under-furniture mountable with optional bracket kit #70-212-01
or projector mountable with optional bracket kit #70-217-01
Enclosure type ................... Metal
Enclosure dimensions.......... 1.7" H x 2.2" W x 3.0" D (1U high, one-eighth rack wide)
4.3 cm H x 5.6 cm W x 7.6 cm D (Depth excludes connectors.)
Product / Shipping weight..... 0.7 lbs (0.3 kg) / 3 lbs (2 kg)
Vibration .......................... ISTA 1A in carton (International Safe Transit Association)
Listings............................ UL, CUL (UL rated for use in a plenum air space: meets UL2043 and UL60950
for fire and smoke.
Compliances ..................... CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF .............................. 30,000 hours
Warranty .......................... 3 years parts and labor
NOTE: All nominal levels are at ±10%. Specifications are subject to change without notice.
I P L I n k ®AccessorIes
IPA T IPA
IP Link®Accessory Power over Ethernet Inserter
fEAturEs
•Inserts power into LAN cable to remotely power Extron IP Link®products
•PoE Power over Ethernet IEEE 802.3af compliant
•Intelligent operation - only provides power when connected to IEEE 802.3af
compatible devices
•Supports 10/100Base-TX Ethernet
•UL/CUL listed and CE compliant
dEscrIPtIon
The Extron IPA T IPA is an IP Link®Accessory Power over Ethernet Inserter that inserts power
into LAN cable to remotely power Extron IP Link products. The IPA T IPA is Power over Ethernet,
IEEE 802.3af, compliant and offers intelligent operation — it only inserts power when connected
to IEEE 802.3af compatible devices. It supports 10/100BaseTX Ethernet only.
Power over Ethernet is a technology for wired Ethernet local area networks that allows the
electrical current necessary for the operation of each device to be carried by the data cables
rather than by power cords. This minimizes the number of wires that must be strung in order
to install the network, resulting in lower cost, less downtime, easier maintenance, and greater
installation flexibility than with traditional wiring.
modEL VErsIon dEscrIPtIon PArt #
IPA T IPA LAN Power Inserter...................................................................................... 60-545-01
oPtIonAL AccEssorIEs modEL dEscrIPtIon PAGE PArt #
RSU 129 1U 9.5" Deep Universal Rack Shelf Kit ............................................. page 819 60-190-01
RSF 123 1U 3.5" Deep VersaTools ® Rack Shelf Kit.......................................... page 818 60-190-20
MBU 123 VersaTools®Mini Under-Desk Mount Kit............................................ page 815 70-212-01
PMK 100 One VersaTools®, 1/4 Rack Width Mini Projector Mounting Kit ...................page 813 70-217-01
