EYC SD05 User manual

Operation Manual
eYc SD05 Integrated Signal Indicator
eYc SD05

www.eyc-tech.com
1
Integrated Signal Indicator
SD05 Signal / Meter / Instrumentation
Dispaly
Enter the page of parameter setting
Readout: Adj-
dP--
Adjustment of
decimal point
Readout :dP--
►: Skip
▲: Adjust span
▲: Adjust decimal point
►+▲: Okay(Note 3.)
Setting corresponding
readout
Readout:Decimal point
04--
dP00
Adjustment of
decimal point
Readout :04--
►: Skip
▲: Adjust span
►: Choose position of
decimal point
▲: Adjust value
►+▲: Okay(Note 3.)
Setting corresponding
readout
(Note 1.)
20--
0400
Adjustment of
decimal point
Readout :20--
►: Skip
▲: Adjust span
FIL-
2000
Display filter
Readout:
FIL-
►: Skip
▲: Adjust span
response time
►: Reduce
▲: Increase
►+▲:Okay
Readout response
time
(Note 2.)
END-
FIL0
►: Choose position of
decimal point
▲: Adjust value
►+▲: Okay(Note 3.)
Setting corresponding
readout
(Note 1.)
Exit
Readout: End-
(Note 4.)
►: Skip
▲: Exit
Dispaly
►+ ▲(2sec)
►
►
►
▲
►+ ▲
►
►
▲
►+ ▲
►
►
▲
►+ ▲
►
►
►+ ▲
▲
▲

www.eyc-tech.com
2
Integrated Signal Indicator
SD05 Signal / Meter / Instrumentation
A) Readout decimal point that you set.
B) Adjustment range: -1999 …9999.
Note 1.
C) Default:
4mA corresponding 400
20mA corresponding 2000
4
0
Fourth: 0 …9
Third: 0 …9
Second: 0 …9
First: -1, - , 0 …9
A) Adjustment of readout’s response
time. 0.5s/ Unit.
B) The range of response time:
( 0s …20s)
C) Default: 0s (s: second)
Note 2.
To save, please press ►+▲at the
same time after you finished setting,
and then it will skip to next
parameter.
Note 3.
If you didn’t press any key over 20s
during setting, it will exit setting
program and return to main manual
without save.
Note 4.
Diagram

www.eyc-tech.com
3
Integrated Signal Indicator
SD05 Signal / Meter / Instrumentation
