EYEZONE AV USB 2.0 PRO User manual

EYEZONE AV USB 2.0 PRO
User Manual
Feb 26, 08
F3443100
The information in this document is subject to change without notice and does not
represent a commitment on the part of the developer.
This document contains materials protected by copyright. All rights are reserved.
No part of this manual may be reproduced or transmitted in any form, by any
means or for purpose without express written consent.
Federal Communications Radio Frequency Interference Statement.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, Pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and if not installed and used in accordance
with the instruction manual may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio
of television reception, which can be determined by turning the equipment off or on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
zReorient or relocate the receiving antenna.
zIncrease the separation between the equipment and receiver.
zConnect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
zConsult the dealer or an experienced radio TV technician for help.
Notice :
(1) The changes or modifications not expressly approved by the party responsible
for compliance could void the user authority to operate the equipment.
(2) Shielded interface cables and AC power adapter, if any must be used in order
to comply with the emission limits.
CE DECLARATION
This device complies with CE class B.
Technical Standard : EMC DIRECTIVE 89/336/EEC
EN55022 / EN55024
Printed in Taiwan R.O.C.
All contents are subject to change without notice.
All trademarks are the property of their respective owner.

1. Package Contents……………………..…………………….. 1
2. Introduction………………………………….……………... 1
3. System Requirements...…………………..………………… 1
4. Features…………………………………..………………… 2
4.1 Hardware Features….………………………………..…. 2
4.2 Software Features...………….………………………… 2
5. Hardware Overview…………………………….…………... 2
6. Software Installation….………………………..……..…….. 3
6.1 Install the Microsoft DirectX 9..…..………………..…. 3
6.2 Install the Driver…..………….………………………… 3
6.3 Install the CyberLink PowerDirector...………………… 5
7. Using the CyberLink PowerDirecotr...……………………... 6
7.1 Capture Limit Options...……………………………..…. 6
7.2 Profile Options...…….………………………………… 7
7.3 Snapshot Function...………..………………………..… 7
7.4 Capture Function….………………….…….……….… 7
7.5 Hot Key……….………………………………….…….. 7
8. Troubleshooting…………….………………………………. 8
CONTENTS
1
1. AV USB 2.0 PRO
2. User Manual
3. Driver CD
The Eyezone AV USB 2.0 PRO is a compact size USB 2.0 capture box allows you to
bring it to anywhere with your notebook. The Eyezone AV USB 2.0 PRO is the best solution to
digitalize your memories. Thru the high speed USB 2.0 interface, you can easily capture picture
and directly real-time record video and audio to DivX file format from videotape, DVD, VCD
or V8 thru Video, S-Video input. The Eyezone AV USB 2.0 PRO makes you to digitize your
home video easily.
Operating System: Microsoft Windows XP/ Vista.
Processor
- Pentium 4 2.4GHz or above (running on Windows XP/ Vista 32bit)
- Pentium D 3GHz or above (running on Windows Vista 64bit)
RAM
- 512MB RAM or above (running on Windows XP/ Vista 32bit)
- 1GB RAM or above (running on Windows Vista 64bit)
One USB 2.0 Port.
3. SYSTEM REQUIREMENTS
2. INTRODUCTION
1. PACKAGE CONTENT

2
4.1 Hardware Features
External USB 2.0 real-time video capture box.
Video and audio recording by USB 2.0 interface.
Supports Video, S-Video and Audio input.
Suitable for NTSC/ PAL/ SECAM video input signals.
Compatible with Windows XP (32bit / 64bit)/ Vista (32bit / 64bit).
The Eyezone AV USB 2.0 PRO has passed Microsoft's WHQL and Windows DTM
(VISTA) certification.
4.2 Software Features
Bundled CyberLink PowerDirector Software
Preview and real-time record video and audio to DivX file format.
Supports snapshot and video editing function.
Supports Image Recording Format：
160x20/ 320x240/ 352x240/ 352x480/ 640x480/ 720x480.
Multi-language OSD Display：Traditional Chinese, Simplified
Chinese, English, Japanese, German, Spanish, Italian, French
and Korean.
4. FEATURES
5. HARDWARE OVERVIEW
3
6.1 Install the Microsoft DirectX 9
Microsoft DirectX 9 must be installed on your operating system, install Microsoft DirectX 9
from Driver CD first. (If you already have Microsoft DirectX 9 installed, it’s not necessary.)
6.2 Install the Driver
Windows XP
Step 1: Plug the EyezoneAV USB 2.0 PRO into the USB port of PC, then the following dialog
“Found New Hardware Wizard” will appear. Select “No, not this time”, and click the “Next”
button.
Step 2: Select “Install from a list or specific location [Advanced]”, then click the “Next” button.
Step 3: Select “Included this location in the search” and click “Browse” button to choose your CD
ROM and select the BDA32 or BDA64 folder. Click “Next” to install..
NOTE: If your system type of PC is 32bits, select the BDA32 folder to install.
If your system type of PC is 64bits, select the BDA64 folder to install.
6. SOFTWARE INSTALLATION

4
Step 4：Click the “Finish” button to finish and close the dialog.
Step 5：Check the “Device Manager”, if the device driver has been install correctly, there should be
a “AV USB 2.0 PRO” display under “Sound, video and game controllers”.
Windows Vista
Step 1：Plug the Eyezone AV USB 2.0 PRO into the USB port of PC, then the following dialog
“Found New Hardware” will appear. Please click “Locate and install driver software
(recommended)”.
5
Step 2：Click “Don’t search online”, then click “I don’t have the disc. Show me other option.”
and click “Next”.
Step 3：Click “Browse my computer for driver software (advanced)”, then click “Browser” to
choose your CD ROM and select the BDA32 or BDA64 folder. Click “Next” to install.
NOTE：If your system type of PC is 32bits, please select the BDA32 folder to install.
If your system type of PC is 64bits, please select the BDA64 folder to install.
Step 4：Click “Close” to close the dialog box, then check the “Device Manager”, if the device
driver has been install correctly, there should be a “AV USB 2.0 PRO” display under “Sound, video
and game controllers”.
6.3 Install the CyberLink PowerDirector
Insert the CD provided into the CD ROM driver on your PC, then click (Setup) and follow the
on screen instructions to install the CyberLink PowerDirector on your PC.

6
NOTE：Confirm you have successfully connected your video device to the Eyezone AV USB 2.0
PRO, and the Eyezone AV USB 2.0 PRO has already connected to USB port of PC.
Step 1：Click the icon on your desktop to launch the CyberLink PowerDirector.
Step 2：The first time you run the PowerDirector, the “Activation” dialog box will appear. Enter the
CD-key, then click “Next”. (You CD-Key can be found on the CD cover.)
Step 3：After the PowerDirector is launched, click the “Capture” button to enter the capture mode,
and the PowerDirector will detect the Eyezone AV USB 2.0 PRO automatically and the video from
your video device will be displayed in the preview window. (If the Eyezone AV USB 2.0 PRO don’t
be detected, please refer to 6.1)
7.1 Capture Limit Options
You can set limits on the size or duration of video that PowerDirector captures. When the limit you
set is reached, capture automatically stops.
7. USING THE CyberLink PowerDirecto
r
7
7.2 Profile Options
Click the “Profile” to open the Profile Setup dialog box. You can set the format and quality of the
capture video here.
7.3 Snapshot Function
Click <Edit> → <Preferences>, then the Preferences dialog box will appear.
- Click “Browse” of Export directory to change the destination folder.
-Click tochangethesnapshot file format (BMP/ JPG/ GIF).
Click the button, to capture the current images, then enter a name in the dialog box that
appears. The image you have captured appear in the Captured Clips area.
7.4 Capture Function
Click <Edit> → <Preferences>, then the Preferences dialog box will appear. Please click
“Browse” of Export directory to change the destination folder.
Click to begin capture, and click to stop capture.
Enter a name in the dialog box that appears. The clips you have captured appear in the
Captured Clips area.
PS. Refer to PowerDirector Help for details and editing function about PowerDirector. You can
also download manual in your language from CyberLink’s website.
PowerDirector Help

8
Situation Check Point
No Video Picture 1. Connect and disconnect the cables, then try again
2. Make sure all the cables are connected correctly.
The message appears-
“High Speed
device plugged
into Full Speed
USB Port….”
1. Make sure your system features USB 2.0 support.
2. Ensure the EyezoneAV USB 2.0 PRO is plugged into a
USB 2.0 port.
3. Make sure the operating system, the EyezoneAV USB
2.0 PRO only supports Windows XP/ Vista.
Important NOTE
1. Make sure the driver for the EyezoneAV USB 2.0 PRO
has been properly installed (refer to 6.2).
2. Make sure the operating system, the EyezoneAV USB
2.0 PRO only supports Windows XP/ Vista.
8. TROUBLESHOOTING
