ezDISK EZ610S User manual





















EZ610S User Manual

English
1

Warnings
1. Please backup all data on hard drive before installing EZ610S. All
datawillbeerasedandunrecoverableafterinitiatinginstallationon
harddrive.
2. Pleaserememberthepasswordyouset.Theharddriveis
automaticallyencryptedandlossofpasswordwillresultinthe
storeddatabeingirretrievable.
3. Duringtheprocessofreadingorwritingdataonthepublicpartition,
donottrytotypethepasswordtounlockthesecurepartitionin
caseofdamagingthedatacontained. 













English
2

Attention
1. Donotdisassembleormodifythedevicewithoutcompany
authorization.
2. EZ610Sisn’twater‐proof.Donotplaceoutsideonarainyday,neara
swimmingpool,beachoranyotherlocationswherewatermay
comeincontact.
3. Donotdropthedeviceincaseofdamagingit.
4. Donotplaceheavyobjectsontheharddriveenclosure.Doingso
mayresultinaccidentallypressingthenumericbuttons,switchingto
initialmodeandalldatabeingerased.
5. Thepasswordyousetwillbestoredintotheharddrive.Ifthedevice
malfunctionsafterprolongedusage,simplyhaveitrepairedor
purchaseanewoneandtypeinthesamepassword.Therepairedor
purchasedharddrivewillfunctionnormallyafterwards.


















English
3

ThankyouforpurchasingezDISKEZ610S.Pleasemakesurethekit
includesallofthefollowingcontents.

 EZ610SUSB3.0dataprotectionharddriveenclosure×1
 USB3.0cable×1
 Productusermanual×1
 Warrantycard×1


















English
4

●Features




















Passwordinput
buttons
Bottomcover
 (Harddrivecover)
LEDindicator

English
5

●Harddriveinstallation
1. Slidetheharddrivecoverbackwardsuntilcompletelyseparated
fromthemaincase.Thebottomcovercanbeeasilyremoved
afterwards.





English
6

2.Insertharddriveintoharddriveslotandensureitisfirmly
connectedtotheSATAconnectorwithintheenclosure. 








Harddrive
SATAConnector

English
7

3.Presstheharddrivedownwardsuntilfirmlysnappedinplace.The
protrudingpointswithintheslotshouldwedgeintocorresponding
screwholesonbothendsoftheharddrive.














English
8

4.Replacethebottomcoverbyaligningitwiththetoppartfirstthen
pressingitbackintoplace.Theharddriveinstallationiscomplete.









English
9

●LEDindicators

① ②③④

①Green②Orange
 ON: 
Poweron
 Blink:
Transferringdata
 ON:
Passwordsettingorchanginginprogress
 Blink:
HDDsuccessfullyinitialized
③Blue④Red
 ON:
HDDinunlockmode
 Blink:
Everytimeabuttonhasbeenpressed
 ON:
HDDinlockmode
 Blink:
Erroroccurred




English
10

●FirsttimeusingtheEZ610Sharddriveenclosure
Initializingtheharddisk.
1. ConnecttheMicroBconnectoroftheUSBcabletotheUSB
connectoroftheharddiskenclosure.
2. Pressandholddownbuttons1and3(Donotrelease).





English
11

3. Whilestillholdingdownbuttons1and3,connecttheotherendof
theUSBcabletocomputerUSBhost.Thegreenandredindicators
shouldlightup. 
4. After5seconds,theorangeLEDindicatorwillstarttoblinkand
button1and3cannowbereleased.Harddriveinitializationis
complete.



















English
12

Settingtheunlockingpassword
1. AftercompletingtheinitializationandwiththeUSBcablestill
connected,pressbuttonC(Cancel)for5consecutivesecondsthen
releaseafterorangeindicatorturnson. 










English
13

2. TypeinthepasswordyouwishtosetandpressbuttonE(Enter).The
orangeLEDindicatorwillturnoffsubsequently.
3. RetypethepasswordthenpressbuttonE(Enter)again.
4. Ifthetwopasswordsmatch,theredindicatorwillturn 
offandblueturnonwhilethegreenwillblink3timesthenstayon
whichmeanspasswordissuccessfullyset.Thesystemwillsoon
detectthesecurepartitionandnotifythatreadingandwriting
optionsarenowpermitted.Ifthetwopasswordsdon’tmatch,the
orangeindicatorwilllightupandtheredwillblinktwicethenstay
on.Theprocesswillreverttostep2andrequestforthepasswordto
bekeyedinagain.

















English
14

Unlockasecurepartition
1. ConnecttheMicroBconnectoroftheUSBcabletotheUSB
connectoroftheharddiskenclosure.
2. ConnecttheotherendoftheUSBcabletothecomputerUSBhost.
ThegreenandredLEDindicatorsshouldsubsequentlyturnon.
3. TypeintheunlockingpasswordandthenpressbuttonE(Enter).
4. Ifthepasswordyoutypediscorrect,theredindicatorwillturnoff
andblueturnonwhilethegreenwillblink3timesthenstayon.This
meansthatharddrivehasbeensuccessfullyunlocked.Thesystem
willnowdetectthesecurepartitionandnotifythatreadingand
writingoptionsarenowpermitted.Ifthepasswordisincorrect,the
redindicatorwillblink3timesthenstayonagain.



















English
15

Changingtheunlockingpassword
1. ConnecttheMicroBconnectoroftheUSBcabletotheUSB
connectoroftheharddiskenclosure.
2. PressandholddownbuttonC(Cancel)withoutreleasing.
3. WhilestillholdingdownbuttonC,connecttheotherendoftheUSB
cabletothecomputerUSBhost.ThegreenandredLEDindicators
shouldsubsequentlyturnon.
4. TheorangeLEDindicatorwillblinkafter5secondsandbuttonC
(Cancel)cannowbereleased.
5. TypeintheoriginalunlockingpasswordthenpressbuttonE(Enter).
Ifthepasswordiscorrect,theorangeindicatorwillturnoff.Ifthe
passwordisincorrect,theorangeindicatorwillremainonandthe
passwordneedstobetypedagain.
6. KeyinyournewpasswordthenpressbuttonE(Enter).Theorange
LEDindicatorshouldturnoff.
7. KeyinthenewpasswordagainthenpressbuttonE(Enter).
8. Ifthetwopasswordsmatch,theredindicatorwillturnoffandblue
turnonwhilethegreenwillblink3timesthenstayon.Password
changingisnowcompleteandthesystemwilldetectthesecure
partitionandnotifythatreadingandwritingoptionsarenow
permitted.Ifthetwopasswordsdon’tmatch,theorangeLED
indicatorwillturnonwhiletheredwillblinktwicethenremainon.
Theprocesswillreverttostep6andrequestforpasswordkey‐in
again.

English
16

Lockingtheharddrive
Theharddrivewilllockitselfautomaticallyundertheseconditions:
1. EZ610Sisdisconnectedfromthecomputer.
2. Theharddrivehasbeenidleforover15minutesandisinsleep
mode.






























English
17

Formattingthesecurepartition
Pleaseformatthesecurepartitionaccordingtothestepsbelow(The
devicewillautomaticallydividetheharddiskinto1publicand1secure
partition,eachaccountingfor50%ofthetotalharddrivecapacity).

1. Rightclickon“Mycomputer”thenselect“Management”followed
by“Diskmanagement”.Disk1isthedefaultpublicpartitionand
Disk2isthedefaultsecurepartition.Clickon“Diskmanagement”
andawizardwillpopupforDisk2initialization.Press“OK”.





English
18

2. RightclickonDisk2thenselect“NewSimpleVolume”.
















English
19

3. Press“Next”asinthefollowingscreen.














