Faber FVC D-CYCLONE 600 User manual

HANDHELD CORDED VACUUM
HANDHELD CORDED VACUUM
FVC D-CYCLONE 600
PLEASE READ THIS INSTRUCTIONS MANUAL CAREFULLY BEFORE USING THIS PRODUCT
VOLTAGE : 220-240V FREQUENCY : 50/60Hz
INSTRUCTIONS MANUAL

CONTENT
1. IMPORTANT SAFETY INSTRUCTIONS
2. PRODUCT PARAMETER
3. PRODUCT PARTS LIST
4. OVERVIEW
5. GENERAL USAGE & SAFETY GUIDELINE

IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precaution should always READ ALL
INSTRUCTIONS BEFORE USING (THIS APPLIANCE)
1. The Vacuum Cleaner is an electric appliance. It must be used in accordance
with the operating conditions of the instructions. This instructions should be kept
properly for future reference.
2. Check and conrm that the vacuum cleaner voltage must be consistent with
the supply voltage.
3. It is strictly forbidden to inhale the following objects, otherwise it may damage
the vacuum cleaner or cause re.
- heating objects, such as carbon re etc
- large cuts of sharp fragments, such as glasses etc
- harmful substances, water & liquids ( solvents, corrosive, etc )
- ammable and explosive goods, such as gasoline, alcohol products
4. When cleaning, repairing or temporarily not use the vacuum cleaner, the
power supply must be turn o. When the power supply is cut o, pull the power
cord and pull the plug out by holding the plastic part of the plug by hand.
5. Remember do not immerse the main vacuum cleaner in water, avouid
approaching to heating equipment or exposure to the sun to avoid re.
6. Do not let children play with the vacuum cleaner to avoid accidents
7. In the following cases, do not use vacuum cleaner
- Fall and obvious damange or abnormal movement.
- Power line is damaged
When these happens, do not turn on the machine and send it to the maintenance
service department designated by our company in time.
8. Avoid running for a long time in the condition of the suction inlet is bloacked,
to avoid damage to the motor and heat generation of the vacuum cleaner.
9. If the soft wire of the power supply is damaged, in order to avoid a danger,
it must be replaced by professional manufacturer, its maintenance department
or similar department.
SAVE THESE INSTRUCTIONS
when using the appliance, do not cover cord with throw rugs, runners, or similar
coverings. Do not route cord under furniture or appliances. Arrange cord away
from trac area and where it will not be tripped over.
Always unplug when not in use, do not around cord.

PRODUCT PARTS LIST
1. MAIN BODY 2. POWER CORD BUTTON 3. POWER CORD
4. HEPA 5. FILTER NET 6. DUST CUP
7. DUST CUP RELEASE BUTTON 8. CONNECTION TUBE BUTTON
9. CONNECTION TUBE ASSEMBLY 10. SWIVEL HEAD
11. FLOOR BRUSH 12. SOFA BRUSH 13. NOZZLE
14. ADAPTER (OPTIONAL) 15. WALL HOLDER
13
14
12
3

GENERAL USAGE & SAFETY GUIDELINE
Before use : make sure that all products packaging has been removed.
Vacuuming Function :
HOW TO USE
- The appliance’s grip is deisgned in such a way that it allows the insertion of the following
accessories (use the combination that best meets your requirements)
- Extension tube : designed to provide access to surfaces which are out of reah and make oor
cleaning comfortable
- Floor brush : specially designed for cleaning oors (both rugs, carpets and hard oor)
- Lance : specially designed for getting into cracks and dicult corners
- Multi-use brush : specially designed for multipurpose use. For instance to clean a sofa.
- Connector pipe : connect the accessories and the main body
INSERTION OF ACCESSORIES INTO THE APPLIANCE’S GRIP :
- Fit the extension tube and oor brush to the vacuum cleaner
- To disconnect the extension tube from the vacuum cleaner, press the button to disconnect
the tube from the main body where is situated in the rear side and pull the extension tube.

GENERAL USAGE AND SAFETY GUIDELINES
- Introduce connector pipe in the vacuum hole
- Introduce the accessories (lance or multi-use brush) in the connector pipe
INSERTION OF THE ACCESSORIES :
- Connect the appliance to the mains
- Turn the appliance on, by using the ON/OFF button
USE :
- Turn the appliance OFF using the ON/OFF button
- Unplug the appliance from the mains
- Clean the appliance
ONCE YOU HAVE FINISHED USING THE APPLIANCE :

- The appliance has a handle on the upper part of the body, which facilitates comfortable
transportation
Disconnect the appliances from the mains and allow it to cool before undertaking any cleaning
task
- Clean the equipment with a damp cloth with a few drops of washing-up liquid and then
dry
- Do not use solvents, or products with an acid or base pH such as bleach, or abrasive
products, for cleaning the appliance
- Never submerge the appliance in water or any other liquid or place it under running water
CLEANING :
- Empty the dust collector when it is full (observation facilitated by transparent windows),
or when vacuuming power is notably reduced.
- Disconnect the dust collector from the appliance
- Extract the lters from the dust collector and empty the contents into the appropriate waste
disposal receptacle
- Check the condition of the dust collector lter
- Resemble the lters and the dust collector
EMPTYING THE DUST COLLECTOR :
CARRY HANDLE :
GENERAL USAGE AND SAFETY GUIDELINES

FOR EU PRODUCT VERSIONS AND/OR IN CASE THAT IT IS REQUESTED IN YOUR
COUNTRY : ECOLOGY AND RECYCLABILITY OF THE PRODUCT
- The materials of which the packaging of this appliance consisits are included in a collection, classication
and recycling system. Should you wish to dispose of them, use the appropriate public recycling bins for each
type of material
- The product does not contain concentrations of substances that could be considered harmful to the
environment.
Air entry lter, it is advisable to be changed at least once a year or every 50 hours of the
appliance’s use.
CHANGING THE FILTERS :
- Disconnect the dust collector from appliance
- Extract lters rom the dust collector
- Reassemble the lters and the dust collector
TO REMOVE THE FILTERS :
Supplies can be acquired from distributors and authorise establishments ( such as lters, etc... )
for your appliance model
- Always use original supplies, designed specically for your appliances model
- These supplies are available in service center
SUPPLIES :
- Take the appliance to an authorise technical support service if the product is damaged or
other problems arise.
- Do Not attempt to disassemble or repair the appliance yourself as this may be
dangerous.
ANOMALIES AND REPAIR
GENERAL USAGE AND SAFETY GUIDELINES

CIRCUIT DIAGRAM
This symbol means that in case you wish to dispose of the product once its
working life has ended; take it to an authorized waste agent for the selective
collection of Waste from Electric and Electronic Equipment (WEEE)
This appliance complies with Directive 2014/35/EC on Low Voltage, Directive 2014/30/EC on
Electromagnetic Compatibility, Directive 2011/65/EU on the restrictions of the use of certain
hazardous substances in electrical and electronic equipment and Directive 2009/125/EC on
the eco design requirements for energy-related products
SPECIFICATIONS
GENERAL USAGE AND SAFETY GUIDELINES
Rated Voltage A C 230V Rated Frequency 50/60H z
Rated pow er 600W M ax suction 16Kpa
N oise < 78dB C apacity ofdustbox 0.9L
230V

Dibuat untuk dan diedarkan oleh :
FIMACO SDN BHD
8-2, WISMA FIAMMA,
No.20, Jalan 7A/62A,
Bandar Manjalara, 52200 Kuala Lumpur, Malaysia.
CUSTOMER CARE CENTRE : [phone]
