INTRODUCTION
Thank you for purchasing Fabit waste oil
Evacuation Unit.
The waste oil collecting and draining
machine manufactured by our company is
using Compressed air as Power source, it’s
suitable to use in the Workplace of
anti-explosion.
Our product is with excellent sealing
property, with reliable functions of collecting
and draining oil.
The extending rod has two joints for
adjust, much easier for operating.
Measuring cup is with strong
material and anti-corrosion.
The special design of eccentric oil
pan makes the scope of collecting machine
larger than before.
Attention: Please according to the
type of your car / Machinery / Equipment, to
choose the right Diameter of Probe tube
when you use the machine to drain oil
directly from the tank.
READ THIS INFORMATION
CAREFULLY BEFORE USE
Please retain this instruction manual for
future reference.
Your safety is important to us. Please read
and follow all instructions listed below.
Some of these instructions alert you to the
potential for personal injury.
“Ca Cautions”throughout the manual advise
of potential practices or procedures
which may cause damage to your
equipment.
Make sure all operators have access to
adequate instructions about safe
operating and maintenance procedures.
Do not exceed the maximum oil
temperature of 120℃.
WASTE OIL EVACUATION SYSTEM 43075H

- 2 -
http://www.fabit.cn
ASSEMBLY PROCEDURE
1．Insert the handle into the fixed roll, tighten
the screws.
2．Connect the wheels to the axles, tighten
the screws, and insert steering wheels into the
installing holes, fixed the wheels one by one.
3．Install the finished assembling measuring
cup into the central hole, tighten the screw.
4．Fix the “vacuum generator”into the central
hole of measuring cup top, tighten the screw.
5．Insert the probe tube (with the cover) into
the loop on the side of oil tank, fix the tool box
into the right position of the tank’s mounting
seat.
6．Installation for the auto-balance measuring
cup:
1) Install the finished measuring cup
assembling into the central hole, tighten the
screw.
2) Insert the two air pipes into the hole,
tighten the screw.
WARNING
1. Before attempting any repairs or
maintenance of this product, disconnect the
air supply to release the air pressure.
2. Do not extract caustic or flamable products.
3. Do not modify any component of this
equipment.
OPERATION OF SUCTIONING OIL
Operational principle:
With the air compression principle, using the
special designed vacuum generator, vacummize
both the measuring cup and oil tank at the same
time, it will create the vacuum pressure
difference to draining the waste oil into the clean
measuring cup and oil tank.
1 ) Vacuumize oil tank & measuring cup.
Before evacuating the cup, please close all ball
valves. Quickly connect the nozzle of the clean
compressed air to the air inlet, and use a vacuum
generator to vacuum the measuring cup and oil
tank.
When evacuating, please carefully observe the
indicator of the vacuum gauge. When the
indicator reaches the red area, please cut off the
air supply to complete the vacuum. If the
vacuuming equipment is near the workstation,
you can vacuum and drain oil at the same time.
2) Draining oil:
a) Move the equipment to the place near the car
or machinery, check the actual oil suction
entrance’s dimension and structure, and choose
the suitable probe tube to drain oil .
b) Put the probe tube into the waste oil tank, then
open the ball valve near the handle, the oil will be
sucked to the clean measuring cup. When oil
suction finished, please turn off the ball valve
immediately.

- 3 -
http://www.fabit.cn
OPERATION OF DRAINING OIL
1. Turn on the ball valve Under the measuring
cup ,the oil will flow down from the cup into the oil
tank automatically.
2. Release the waste oil from the oil collecting
machine to the big collecting tank equipment.
1) Release oil automatically:
Turn on all the ball valves except the ball valve of the
elbow pipe, let the air get into the tank. Put the
elbow oil release pipe to the waste oil collecting tank
equipment, then turn on the ball valve of the oil tank
bottom, with the air pressure ,the waste oil will be
extracted into the collecting device.
(Attention: The exit of the elbow pipe should be
lower than the liquid lever of the oil tank.)
2) Release oil with air pressure:
Turn off the ball valve under the measuring cup and
turn off the ball valve under the extending rod. Put
the elbow oil release pipe to the waste oil collecting
tank equipment, turn on the ball valve of the oil
release pipe, collect 1Bar compressed air into the
tank, let the compressed air get into the tank, the
waste oil will be extracted to the collecting device
under the condition of air pressure.
When the air pressure of the tank is over 1bar, the
safety valve will open automatically, cut off the air
supply at this moment please.
Please hold the hook of oil release pipe tightly or fix it
during oil releasing.
PERIODICALLY CHECK
1. Check before working :
Before working, please turn off all the ball valves, and
vacuumize the oil tank and measuring cup. Then carefully
check the indicator’s change of the vacuum meter, to see
whether any part of the machine is with air leak or not. If any
leakage, please contact the sales agent, to avoid any property
damage or personal injure accident.
Attention: During vacuumizing, check the
indicator’s change of the vacuum flow meter
carefully. Cut off the compressed air supply when
the indicator reaches the red mark area, finish the
operation of vacuumizing.
2. Periodically check
1)Check for air leakage
2) Check for oil leakage
3) Please check if there is something wrong with
the soft pipe, metal joints and any other little
parts, i.e. damage, out of shape, wearing or blot
etc.
Attention: About this part, suggest to establish
the complete check system with professional
workers. Please consult the sales agent for details.
3. Check after finishing work
When finishing working, please clean the surface
of the machine, (e.g. Water, blot, oil etc. )
Anything unusual ,please contact the sales agent
immediately.
4. Attentions of other issues
1) Attentions about the periodically check:
a) Please do it according to the operation
manual’s instructions carefully for checking before
work & periodically inspection .
b) It is not allowed to use this machine as other
purpose which has no relation to collecting waste
oil.
2) Attentions about using:
a) Do not make this machine close to fire or
corrosive liquid.
b) Do not exceed the normal pressure rang
during operations.
WASTE OIL EVACUATION SYSTEM 43075H

- 4 -
http://www.fabit.cn
INSTRUCTION MANUAL
WASTE OIL EVACUATION SYSTEM 43075H

- 5 -
http://www.fabit.cn
TROUBLE SHOOTING
SPECIFICATION
TROUBLE
CAUSE
REMEDY
The degree of
vacuum can
not reach
Insufficient air pressure
Adjust the air pressure to reach the specified
pressure
Cup broken
Contact the seller to replace
Vacuum gauge damage
Contact the seller to replace
The ball valves are not turn
off except the valve of cup
inlet
Turn off all the ball valves except the one of cup
inlet
Vacuum generator damage
Contact the seller to replace
Slow draining
Insufficient vacuum
Do not use before vacuum achieve the specified
value
The O-ring of draining
needle tube damaged
Contact the seller to replace
Air leak
Contact with the vendor, to determine the
location of the leak under the guidance.
Tank Capacity
70L
Air pressure for vacuum
6-8bar/87-116psi
Max draining pressure
0.5bar/7psi
Suction speed
1.8-3.0L/min
Suction tube length
1.6m
Draining hose length
1.6m
Max temperature of waste oil
80℃
