Factor Electronics PA-1000 Operating manual

PA-1000/PA-2000
Professional Stereo Power Amplifiers
User and Installation Manual

www.factorelectronics.com [e-mail]
SAFETY INSTRU TIONS
RISK OF ELECTRIC SHOCK
DO NOT OPEN
IMPORTANT SAFETY INSTRUCTIONS
• Read and keep these instructions.
• Heed all warnings and follow all instructions contained within this manual.
• Do not use this unit near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators heat registers stoves or other apparatus (including amplifiers) that produce
heat.
• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs convenience receptacles and the point where they exit
from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Unplug this apparatus during lightning storms or when unused for long periods of time.
• Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as when
the power-supply cord or plug is damaged, liquid has been spilled or ob ects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
• Operate the product only with the voltage specified on the unit. Fire and/or electric shock may result if a higher voltage is used.
• Do not modify kink or cut the power cord. Do not place the power cord in close proximity to heaters and do not place heavy ob ects
on the power cord and/or the product itself, doing so may result in fire or electrical shock.
• Replace the protective cover over the speaker terminals after installation. Do not touch the speaker terminals as electric shock may
result.
• Ensure that the safety ground terminal is connected to a proper ground. Never connect the ground to a gas pipe, as a severe explosion
and/or fire may result.
• Be sure the installation of this product is stable avoid slanted surfaces as the product may fall and cause in ury, property damage,
electrocution and/or fire.
• Note when the unit is turned off it is not completely disconnected from the wall AC power outlet. Do not open the cover. REFER ALL
SERVICE TO A QUALIFIED SERVICE TECHNICIAN
WARNING! TO REDU E THE RISK OF
FIRE OR ELE TRI SHO K, DO NOT
EXPOSE THIS APPLIAN E TO RAIN
OR MOISTURE.
CAUTION! TO REDU E THE RISK OF
SHO K, DO NOT REMOVE THE OVER,
NO USER SERVI ABLE PARTS INSIDE.
REFER SERVI E TO A QUALIFIED
SERVI E TE HNI IAN.
2
2

www.factorelectronics.com [e-mail]
PRODUCT OVERVIEW
Thank you for choosing the Factor Electronics PA-1000/2000 Professional Stereo Amplifier. The PA-1000/2000 amplifiers are
designed to provide ultra high quality amplification for multiple professional applications. The PA-1000/2000 employ high current
switching mode power supplies SMPS which reduce the amplifier weight, heat, distortion, noise and power consumption while increasing
amplifier power output and overall performance. The PA-1000/2000 provide state of the art protection circuitry like thermal, short circuit,
output D offset and power ON/OFF muting to eliminate pops and thumps when powering your audio system. A switchable limiter is also
provided which protects the amplifier and connected speakers from input overload conditions. The PA-1000/2000 amplifiers provide front
panel LED status indicators for signal present, signal clip, protect mode, parallel mode, bridge mode and power ON mode. Please read
this entire manual to get the most from your PA-1000/2000 professional power amplifier.
PA-1000/2000 AMPLIFIER FRONT PANEL
The PA-1000/2000 ki includes he following par s:
1. 1 x PA-1000/2000 Amplifier
2. 1 x Rack mounting ears
3. 1 x 14awg 115V power cable and extra A mains fuse
4. 4 x Amplifier rubber feet (for table top operation)
5. 1 x Installation Guide/Operation Manual
PROT, lights red upon power
ON sequence (approx 20 sec)
If the PROT lights constantly
power the amplifier OFF
hannel A/B input level control
LIP LED's flash at
-3dB before clipping
If the LIP LED's
light solid reduce the
channel input level
Master power
ON/OFF
SIG signal present
LED's light when an
input signal is active
The PAR LED lights when the
back panel PAR switch is ON
H-A input will be broadcast to
amp outputs A & B simultaneously
This is INPUT PARALLEL mode
The BRI LED lights when the
back panel BRI switch is ON
H-A input will be broadcast.
Amps A & B will be combined
(see speaker connections on the next page)
This is BRIDGE mode
3
3

www.factorelectronics.com [e-mail]
PA-1000/2000 AMPLIFIER REAR PANEL
BREAKER operates like a fuse protecting
the amplifier from damage.
Press the breaker switch to re-set after
an A overload condition
A input socket
Twist lock speaker connectors
hannel A/B
Use the Factor Electronics
SPK-4P type connector here
0
hannel A/B speaker
output terminals accept
direct wire-in or speaker
Banana Jacks
Use the Factor Electronics
Banana-R or B connectors
Balanced XLR female line level audio
input connectors channels A/B
Pin 1 – ground/shield
Pin 2 - + positive
Pin 3 - - negative
Balanced/Unbalanced TRS female line level
audio input connectors channels A/B
Tip - + positive
Ring – negative
Sleeve – ground/shield
NOTE: The TRS inpu jacks are paralleled o he
XLR inpu jacks. Do no use XLR & TRS inpu s
simul aneously. Using he TRS as an inpu jack
allows he XLR jack o be used as an ou pu which
can be connec ed o an addi ional amplifier inpu
Limiter ON/OFF
ON limits all input
levels to max 0dB
MODE SWIT H
PAR- PARALLEL: Input A will
broadcast in outputs A & B
STE – STEREO: Input A will
broadcast in output A
Input B will broadcast in
output B
BRI- BRIDGE: Input A will
broadcast in outputs
+ A & + B
Amplifier chassis vents
Do not block vents
4
4

www.factorelectronics.com [e-mail]
PA-1000/2000 INSTALLATION INSTRU TIONS
IMPORTANT: The PA-1000/2000 should be situated in a well ventilated location or position. Do not block the vents on the front/back of the
chassis. Proper ventilation is required for normal operation. Do not expose the unit to excessive dust and do not allow dust to build up
on the unit and block the vent holes in the chassis. Do not place the PA-1000/2000 directly above or below heat-generating components
such as another audio amplifier. Be sure to leave at least 2 inches of space to the sides of the chassis with open air flow above and below
the unit.
INSTALLATION:
1. The PA-1000/2000 can be mounted in an equipment rack using the rack kit that is included with the unit.
2. Always disconnect the A power cord before making any connections.
3. Use good quality 12-14awg 2 conductor stranded copper speaker wire for all speaker connections.
4. Use good quality balanced input cables like the Factor Electronics PRO-XLR cables.
S ereo configura ion using four 8ohm speakers. Set the MODE switch to
STE – STEREO. Each channel of the amplifier can broadcast independent
sources from input A or B or be used as a high power stereo amplifier.
Parallel configura ion using four 8ohm speakers. Set the MODE switch to
PAR – PARALLEL. Input source A will broadcast to both amplifier outputs.
Use this configuration when all speakers must be driven from the same
source.
5
5

www.factorelectronics.com [e-mail]
PA-1000/2000 INSTALLATION INSTRU TIONS
BRIDGE MONO opera ion. Set the MODE switch to BRI – BRIDGE.
The two independent internal amplifiers will be combined to create a
single high power amplifier. This is useful when powering a professional
sub woofer. In bridge mode input channel A is used as the source
(channel B controls are disabled). NOTE: Minimum speaker impedance
is 4ohms in bridge mode. Speaker wires must be connected to the
+ H-A (positive) and + H-B (negative)
Dual Amplifier BRIDGE MONO opera ion. Set the MODE switch to
BRI – BRIDGE. The two independent internal amplifiers will be combined
to create a single high power amplifier. This is useful when powering a
professional sub woofer. In bridge mode input channel A is used as the
source (channel B controls are disabled). onnect the TRS input to
H-A on amp 1 and connect an XLR cable to H-A on amp 2.
NOTE: Minimum speaker impedance is 4ohms. Speaker wires must
be connected to the + H-A (positive) and + H-B (negative)
6
6

www.factorelectronics.com [e-mail]
PA-1000/2000 ONSTANT VOLTAGE SYSTEMS
IMPORTANT: The PA-1000/2000 amplifiers are capable of driving constant voltage high impedance speaker systems in BRIDGE MONO
Mode (PA-1000) or in STEREO MODE using the PA-2000 where each channel is capable of 1000 watts output per channel. onstant
voltage systems are more commonly referred to as 25 volt or 70 volt systems or commercial sound systems. With this type of system all
speakers must be connected to a 25 volt or 70 volt transformer which reflects a higher impedance back to the amplifier. This allows
multiple speakers to be connected in parallel to the amplifier without exceeding the minimum impedance rating of the amplifier.
The PA-1000/2000 amplifiers are capable of driving a minimum of 4 ohm speaker loads in bridge mono mode. Never connect a
combination of 8ohm (no transformer) speakers and 25/70 volt speakers to the same amplifier. Never connect the Left & right channels
of the amplifier together. Never combine the – negative channels of the amplifier together. Improper speaker installation can damage the
amplifiers and void the warranty. If you are unsure how to connect speakers to the PA-1000/2000 always contact a qualified Factor
Electronics technician before connecting speakers to the amplifiers.
INSTALLATION: Connec ing 25/70 vol speakers o he PA-1000/2000 in BRIDGE MONO MODE
Use good quality 14-18awg stranded copper speaker wire. Never run speaker wires parallel to A wires. If you must cross A wires
always cross at a 90 degree angle. Trim approx 1/4” of insulation from the speaker wire and twist the copper ends. We recommend using
the Factor Electronics SPK-4P twist lock speaker wire connectors to avoid shorts in the speaker wire.
1. Set the MODE switch to BRI (BRIDGE)
2. onnect the source to input H-A.
3. onnect the speaker wires to the SPK-4P connector as follows: positive + to 1+/ negative – to 2+. Now insert and twist the connector.
4. Use parallel wiring to connect the transformer coupled speakers.
5. Each 70 volt speaker reflects an impedance of 5000ohms @ 1 watt, 500ohms @10 watts, 250ohms @ 20 watts & 166ohms @30 watts
6. Divide the number of speakers in the system by the impedance to calculate the minimum impedance of the entire load.
70 Vol ransformer coupled speakers apped @ 10 wa s / 60 speakers max = 8.33ohms 70 Vol ransformer coupled speakers apped @ 20 wa s / 30 speakers max = 8.33ohms
7
7

www.factorelectronics.com [e-mail]
PA-1000/2000 SPE IFI ATIONS & WARRANTY
In an effor o cons an ly provide our valued cus omers
wi h he la es advancemen s in echnology, Fac or
Elec ronics specifica ions are subjec o change from
ime o ime wi hou no ice.
ontact Information:
Factor Electronics
#108-19232 Enterprise Way
Surrey B. . anada V3S-6J9
PH: 778-574-3883
E-Mail: [e-mail]
Web: www.factorelectronics.com
Warran y
Factor Electronics amplifiers are warranted
to be free from defects in workmanship and
materials for a period of three (3) years from
the date of purchase without charge for parts
or labour. This warranty applies only to the
original owner. The owners responsibilities
are to provide proof of purchase from an
authorized Factor Electronics dealer
/distributor and transportation to the dealer/
distributor the unit was purchased from or
Factor Electronics. This warranty does not
apply to units that have been subject to
misuse, abuse, neglect or improper installation,
and does not apply to repairs or alterations
made by unauthorized Personnel. This warranty
specifically excludes responsibility for
consequential damage. Retention of your
original bill of sale is required to obtain service
under the terms of this warranty.
©2012 Factor Electronics. All rights reserved.
All trademarks are the property of their
respective owners. Specifications are su ject
to change without notice. Factor Electronics
is not responsi le for typographical errors or
omissions.
PA-1000 PA-2000
8 OHMS STEREO 300 WATTS RMS 600 WATTS RMS
4 OHMS STEREO 500 WATTS RMS 1000 WATTS RMS
2 OHMS STEREO 750 WATTS EIA 1500 WATTS EIA
8 OHMS BRIDGE 1000 WATTS 2000 WATTS
4 OHMS BRIDGE 1500 WATTS 3000 WATTS
INPUT SENSITIVITY 0.9-1.1V (+0/-1dBV) 0.9-1.1V (+0/-1dBV)
INPUT IMPEDAN E 20K OHMS BALAN ED
10K OHMS UNBALAN ED
20K OHMS BALAN ED
10K OHMS UNBALAN ED
FREQUEN Y RESPONSE 20Hz-20kHz +/- 1dB 20Hz-20kHz +/- 1dB
VOLTAGE GAIN 33 +/-0.5dB 37 +/- 0.5dB
THD + N <0.1% <0.1%
S/N RATIO >100dB >100dB
ROSSTALK >70dB >70dB
DAMPING FA TOR >500 >500
AMPLIFIER UR UIT SMPS LASS A/B SMPS LASS 2H
PROTE TION IR UITRY SHORT IR UIT,OPEN IR UIT,
THERMAL, ULTRASONI , ROWBAR
RF, REA TIVE MISMAT HED LOADS
ON/OFF MUTING
SHORT IR UIT,OPEN IR UIT,
THERMAL, ULTRASONI , ROWBAR
RF, REA TIVE MISMAT HED LOADS
ON/OFF MUTING
WARRANTY 3 YEARS 3 YEARS
DIMENSIONS W X H X D 19” 438mm 18.1” 460mm 3.49” 88.8mm 19” 438mm 18.1” 460mm 3.49” 88.8mm
RA KING HEIGHT 2U 2U
SHIPPING WEIGHT 19LB - 9 KG 24LBS – 11 KG
