Falcon 1 Series Manual

1 SERIES
User, installation and servicing instructions
6 ZONE INDUCTION
OVEN RANGE
E161i & E163i
Read these instructions before use
T101029
Rev 2
Published: 16/12/2019
DATE PURCHASED:
MODEL NUMBER:
SERIAL NUMBER:
DEALER:
SERVICE PROVIDER:

Falcon Foodservice Equipment
HEAD OFFICE
Wallace View, Hillfoots Road, Stirling. FK9 5PY. Scotland.
WEEE Directive Registration No. WEEE/DC0059TT/PRO
At end of appliance life, dispose of appliance and any replacement parts in a
safe manner, via a licensed waste handler. Appliances are designed to be
dismantled easily and recycling of all material is encouraged whenever
practicable.
Dear Customer
Thank you for choosing Falcon Foodservice Equipment.
This manual can be downloaded from www.falconfoodservice.com or scan
here:
IMPORTANT: Please keep this manual for future reference.

SYMBOLS
SCREWDRIVER
SPANNER
COOKING OIL
GREASE
WARNING
SPARK IGNITION
FLAME
VIEWPORT
ALLEN KEY
IGNITER
C SPANNER
REMOVE DEVICE
PLUG REMOVER
NON-IONISING
ELECTROMAGNETIC
RADIATION

This appliance may be discoloured due to testing.
These instructions are only valid if the country code appears on the appliance. If
the code does not appear on the appliance, refer to the technical instructions for
adapting the appliance to the conditions for use in that country.
Installation must meet national or local regulations. Attention must be paid to:
safety (installation & use) regulations, health and safety at work act, local and
national building regulations, fire precautions act.
To prevent shocks, this appliance must be earthed.
This unit is fitted with an equipotential connection at the rear on the base.
This appliance has been CE-marked on the basis of compliance with the Low
Voltage and EMC Directives for the voltages stated on the data plate.
This equipment is for professional use only and must be used by qualified
persons.
The installer must instruct the responsible person(s) of the correct operation and
maintenance of the appliance.
Unless otherwise stated, parts which have been protected by the manufacturer
must not be adjusted by the installer.
The appliance must be serviced regularly by a qualified person. Service intervals
should be agreed with the service provider.
Check that no damage has occurred to the appliance or supply cord during transit.
If damage has occurred, do not use this appliance.
Ensure the supply cord is routed free from the appliance to avoid damage.
The appliance has been designed and approved to use Falcon kick plates; non
Falcon kick plates could potentially adversely affect the performance of the
appliance by restricting the air to the appliance.
All apparatus connected to a potable water network and including water drain
device has to be provided with an air break before its discharge to the drainage
system. Type AA.

Training and competence
To help ensure the safe use of this appliance there is a requirement for you to provide
whatever information, instruction, training and supervision as is necessary to ensure, so
far as is reasonably practicable, the health and safety of all users.
For further help and information on training and competence we would refer you the
Health and Safety Executive website; www.hse.gov.uk document ref: health and safety
training INDG345. International customers should default to the health and safety
guidelines provided by your government body.
Risk assessment
As part of managing the health and safety of your business you must control any risks
identified in your commercial kitchen. To do this you need to think about what might
cause harm to people and decide whether you are taking reasonable steps to prevent
that harm. This is known as risk assessment. It is important to consider the environment
around the product as well as the product itself. For example oil or food spills will present
a significant risk so users so the need to immediately clean up such spills must be
reflected in staff training.
For further help and information on risk assessments we would refer you to you the
Health and Safety Executive website; www.hse.gov.uk document ref: risk assessment
INDG163. International customers should default to the health and safety guidelines
provided by your government body.

CONTENTS
1.0 APPLIANCE INFORMATION.....................................................................................1
2.0 OPERATION..............................................................................................................2
2.1 COMPONENT PARTS............................................................................................3
2.2 CONTROLS............................................................................................................4
2.3 USING THE APPLIANCE .......................................................................................5
2.4 HOB SETTINGS 1-9...............................................................................................6
2.5 POWER BOOST.....................................................................................................6
2.6 AUTOMATIC HEAT UP CONTROL (AHC): ............................................................6
2.7 CONTROL LOCK FUNCTION ................................................................................6
2.8 PAN DETECTION...................................................................................................7
2.9 RESIDUAL HEAT DISPLAY ...................................................................................7
2.10 DIGITAL DISPLAY CODES.................................................................................7
2.11 USING THE OVEN..............................................................................................7
3.0 CLEANING AND MAINTENANCE.............................................................................8
3.1 CLEANING .............................................................................................................9
3.2 MAINTENANCE......................................................................................................9
4.0 SPECIFICATION......................................................................................................10
4.1 APPLIANCE WEIGHT TABLE ..............................................................................10
4.2 TECHNICAL DATA TABLE(S)..............................................................................10
5.0 DIMENSIONS / CONNECTION LOCATIONS.......................................................... 11
6.0 INSTALLATION.......................................................................................................11
6.1 SITING / CLEARANCES.......................................................................................12
6.2 ASSEMBLY ..........................................................................................................13
6.3 ELECTRIC SUPPLY & CONNECTION.................................................................14
6.4 COMMISSIONING................................................................................................16
6.5 INSTRUCTION TO USER.....................................................................................16
7.0 SERVICING .............................................................................................................17
7.1 CONTROL PANEL REMOVAL .............................................................................17
7.2 DOOR REMOVAL.................................................................................................17
7.3 CONTROL SWITCHES REMOVAL ......................................................................18
7.4 INDUCTION GENERATOR REMOVAL................................................................18
7.5 HOB COOLING THERMOSTAT REMOVAL.........................................................20

7.6 REAR COOLING FAN REMOVAL........................................................................21
7.7 OVEN THERMOSTAT AND OVEN FAN SWITCH................................................21
7.8 OVEN LIGHT (PUSH BUTTON) ...........................................................................22
7.9 OVEN ELEMENTS REMOVAL.............................................................................22
7.10 OVEN FAN REMOVAL......................................................................................22
7.11 SAFETY AND OPERATION RELAY REMOVAL...............................................22
7.12 OVEN AND REAR COOLING FAN CONTROL FUSES ....................................23
7.13 OVEN SAFETY TRIP SWITCH REPLACEMENT..............................................23
7.14 OVEN SAFETY TRIP SWITCH REPLACEMENT (FRONT ACCESS)...............24
7.15 OVEN LIGHT BULB REPLACEMENT...............................................................24
7.16 OVEN LAMP ASSEMBLY REPLACEMENT......................................................24
7.17 CIRCUIT DIAGRAMS........................................................................................25
7.18 WIRING DIAGRAMS.........................................................................................27
8.0 ACCESSORIES.......................................................................................................29
9.0 FAULT FINDING...................................................................................................... 29
9.1 ERROR CODES...................................................................................................29
10.0 SPARE PARTS........................................................................................................31
11.0 SERVICE INFORMATION........................................................................................ 32

1
1.0 APPLIANCE INFORMATION
This appliance has been CE-marked on the basis of compliance with the relevant EU
directives for the heat inputs, gas pressures and voltages stated on the data plate.
A - Serial No
B - Model No
C - Flue Type
D - Gas Category
E - Gas Pressure
F - Gas Type
G - Gas Rate
H - Total Heat Input
I - Electrical Rating
J - Total Electrical Power
K - Magnetic Field Frequency
L - Electrical Phase Loading

2
2.0 OPERATION
IF GLASS-CERAMIC TOP IS CRACKED OR BROKEN IMMEDIATELY
DISCONNECT APPLIANCE FROM POWER SUPPLY AND CONTACT
YOUR SERVICE AGENT.
THE AIR INTAKE FILTER MUST BE IN POSITION DURING
OPERATION IT SHOULD BE CLEANED REGULARLY AND DO NOT
OBSTRUCT AIR FILTER ENTRY BELOW.
USERS MUST BE MADE AWARE THAT INDIVIDUALS FITTED WITH
A PACEMAKER SHOULD CONSULT THEIR DOCTOR IF IN A CLOSE
PROXIMITY TO THIS UNIT. THIS INDUCTION UNIT EMANATES AN
19 KHz TO 35 KHz OUTPUT THAT MAY AFFECT OLDER TYPES OF
PACEMAKER.
USE OF THE CORRECT TYPE OF PAN IS ESSENTIAL FOR
CORRECT OPERATION.
DO NOT PLACE ANY METAL OBJECTS, SUCH AS KITCHEN
UTENSILS, CUTLERY, ALUMINIUM FOIL, OR PLASTIC VESSELS,
ON THE GLASS CERAMIC TOP.
THE USER MUST ALSO BE AWARE OF POTENTIAL TO HEAT
JEWELLERY AND DISRUPT ELECTRONIC EQUIPMENT PLACED
OVER THE INDUCTION ZONES MAGNETIC FIELD.
DO NOT PLACE CREDIT CARDS, ETC, ON THE GLASS-CERAMIC
TOP AS DATA COULD BE WIPED OFF.
NEVER LEAVE THE INDUCTION HOB UNSUPERVISED WHEN IN
USE. THE GLASS-CERAMIC TOP MUST NOT BE USED FOR
STORAGE.
NEVER LEAVE THE INDUCTION HOB UNSUPERVISED WHEN IN
USE. THE GLASS-CERAMIC TOP MUST NOT BE USED FOR
STORAGE.
DAMAGED PANS CAN REDUCE APPLIANCE EFFICIENCY.

3
2.1 COMPONENT PARTS
A -
Left hand door
F -
Oven temperature control
B -
Right hand door
G -
Glass
C -
Drip tray
H -
Rear up stand
D -
Shelf
I -
Filter
E -
Hob zone control
J-
Oven shelf hanger

4
2.2 CONTROLS
A -
Circuit 1 power neon (red)
F -
Oven temperature control
B -
Circuit 2 power neon (red) Only on E161i model
G -
Oven light switch
C -
Induction zone Indicator
H-
Induction zone digital display
D -
Induction control
E -
Oven heat neon (amber)

5
2.3 USING THE APPLIANCE
2.3.1 Ensure you use the correct size of pot.
<Ø120
Ø120 –Ø250
2.3.2 Ensure the pots are central in the cooking zone.
2.3.3 Ensure you use the correct type of pot.
2.3.4 Ensure you use a clean flat bottom pan.

6
2.4 HOB SETTINGS 1-9
2.4.1 Each cooking zone is controlled by a marked, variable control from 1 (lowest) to 9
(highest)..Table below gives guidance on the power for each setting and relevant time
limits for each operation.
Power Level
Low temp
hold
1
2
3
4
5
6
7
8
*9
Power %
n/a
3%
5%
8%
12%
18%
28%
42%
64%
100%
Time limit (mins)
120
520
402
318
260
212
170
139
113
90
*On Model E161i: Due to power management restrictions setting 9 may not available
on both zones simultaneously. Unit will switch to setting 8 on this occasion.
2.4.2 Melt function is indicated by a single bar. This heats the pot to approx 45 Degrees.
2.4.3 Keep warm is indicated by 2 bars. This heats the pot to approx 70 Degrees.
2.4.4 Simmer function is indicated by 3 bars. This heats the pot to approx to 94 Degrees.
2.5 POWER BOOST
2.5.1 This is activated by turning the control knob clockwise from level 9. Only one zone per
front to back pair can be boosted at a time. It may be boosted again if the system
internal temperatures are satisfactory. Boost will run for a maximum of 10 minutes.
2.6 AUTOMATIC HEAT UP CONTROL (AHC):
2.6.1 AHC will give a maximum power of setting 9 to the zone for a pre set time before
reducing to a lower power level set by the control.
(1) To activate the control turn anti clockwise from the “Off” position briefly to “A”..
(2) Whilst the “A” symbol is illuminated on the glass turn the control knob clockwise to
the required final setting (1-8).
(3) The display reverts to the “A” symbol and the hob will run at maximum power for
the time shown in the below table before reducing power to the final setting.
Power level setting
1
2
3
4
5
6
7
8
Pre-set time (secs)
40
72
120
176
256
432
120
192
2.7 CONTROL LOCK FUNCTION
2.7.1 This function prevents unwanted operation of the hob. When the control lock is active
the “L” symbol is shown. It operates in pairs of controls (Left, centre and right). It is
activated by turning control knobs anticlockwise to control lock position and held for
approximately 5 seconds.

7
2.8 PAN DETECTION
2.8.1 This prevents the zones being turned on without a pan being present. It also switches
the zone off as soon as a pan is removed.
Also if the pan is made from the wrong type of material for induction equipment the
digital display will read the no pan present symbol on the glass.
2.9 RESIDUAL HEAT DISPLAY
2.9.1 When the temperature of the hob exceeds 60 Degrees after removal of a pan the “H”
symbol will appear on the glass display, this indicates hot surface. When shown the
induction generator will engage its cooling fans. Do not switch off and allow cooling to
occur. When “H”Symbol disappears either continue operation or switch off.
2.10 DIGITAL DISPLAY CODES
Melt, Keep warm and simmer functions.
Power level settings (1-9)
Power boost function.
Automatic heat up control.
Controls lock function.
Pan detection (no pan present).
Residual heat display.
Error codes for generator.
Error rotary control (lightning symbol).
2.11 USING THE OVEN
2.11.1 To use oven, turn temperature control knob clockwise to desired temperature Ensure
heat demand (amber) light illuminates.
2.11.2 When oven has reached temperature, the heat demand (amber) light will extinguish
the light will then illuminate and extinguish at regular intervals as the oven cycles.

8
3.0 CLEANING AND MAINTENANCE
When removing heavy items to aid cleaning or maintenance particular care should be taken.
A manual handling risk assessment is the best way to determine the level of risk to anyone
using or maintaining this equipment. To help with such an evaluation we have included the
weights of individual components that may present significant risk.
For further help and information on manual handling and associated risk assessment we
would refer you to you the Health and Safety Executive website; www.hse.gov.uk document
ref: manual handling at work INDG143. International customers should default to the health
and safety guidelines provided by your government body.
The cleaning of fryers or other products that use hot oil present significant risks to end users
and particular care should be taken. Cold water and hot oil for example are an explosive mix
and should be avoided at all costs.
Other useful references for health and safety issues:
www.hse.gov.uk
Essentials of health and safety at work ISBN978
Noise at work INDG362
Safe systems of work
Other notes added to the body of the instructions
BEFORE ANY CLEANING IS UNDERTAKEN,
ISOLATE THE APPLIANCE FROM MAINS POWER SUPPLY
AT ISOLATOR SWITCH.
E161i MODEL HAS TWO POWER SUPPLIES. ENSURE BOTH
SUPPLIES HAVE BEEN ISOLATED.
SUITABLE PROTECTIVE CLOTHING MUST BE WORN WHEN
CLEANING THIS APPLIANCE.
THE APPLIANCE MUST NOT BE STEAM CLEANED. DO NOT
USE ACID OR HALOGEN-BASED (E.G. CHLORINE)
DESCALING LIQUIDS, FLAMMABLE LIQUIDS, CLEANING
AIDS OR CLEANING POWDERS.
FAILURE DUE TO LACK OF PROPER CLEANING IS NOT
COVERED BY WARRANTY.
NOTE: All surfaces are easier to clean if spillages are removed before becoming burnt on,
and the appliance is cleaned daily.
It should be noted that certain scouring pads including nylon types can easily mark stainless
steel. Care should be exercised during cleaning process. When rubbing stainless steel with
a cloth, always rub in the direction of the grain.

9
3.1 CLEANING
3.1.1 Switch off appliance and cool down
CLEAN THE AIR INTAKE FILTER REGULARLY. FAILURE TO
CLEAN THE FILTER REGULARLY MAY CAUSE PROBLEMS
WHICH WILL NOT BE COVERED BY WARRANTY. THE AIR
INTAKE FILTER MUST BE IN-PLACE DURING OPERATION.
DO NOT ATTEMPT TO REPAIR OR REPLACE ANY PART OTHER
THAN THE AIR INTAKE FILTER. REFER TO THE ERROR CODE
LIST TO DEBUG THE PROBLEM.
3.1.2 The air filter is located at the rear of the unit. It can be removed by sliding upwards
from the guide. Clean using hot soapy water and refit after drying.
3.1.3 Clean the Ceran-glass hob with hot soapy water and a soft cloth. DO NOT USE metal
scrapers.
3.1.4 Enamelled surfaces within oven chamber approved cleaning agents which bear the
Vitreous Enamel Development Centre (VEDC) mark are recommended.
3.1.5 With regards the oven chamber, Wipe enamelled surfaces clean while still warm. Use
a soft cloth and hot soapy water. Badly stained removable parts should be soaked in
hot water with an approved detergent using nylon or scotch cleaning pads will provide
good results.
3.2 MAINTENANCE
3.2.1 Oven door catch may need to be occasionally lubricated. Push down on roller and
apply high melting point lubricate inside the catch and onto roller itself.
3.2.2 If there are issues with closing of the door, try adjusting the catch Use your hands or
an appropriate implement to push down on the roller 1as shown. Whilst holding it
down, turn it right 2to adjust it down, or left 3to adjust it up as shown.

10
4.0 SPECIFICATION
4.1 APPLIANCE WEIGHT TABLE
APPLIANCE
UNIT WEIGHT (kg)
PACKED WEIGHT (kg)
E161i
116
137
E163i
116
137
4.2 TECHNICAL DATA TABLE(S)
MODEL: E161i (SINGLE PHASE DUAL SUPPLY)
CURRENT
POWER
PHASE
MIN (A) @
230V
MAX (A) @
230V
ACTUAL (A) @
230V
(kW) @ 230V
L
27.36
31.92
30.4
7
L
23.49
27.41
26.1
6
MODEL: E163i (THREE PHASE)
CURRENT
POWER
PHASE
MIN (A) @
230V
MAX (A) @
230V
ACTUAL (A) @
230V
(kW) @ 230V
L1
27
31.5
30
7
L2
27
31.5
30
7
L3
14.49
16.91
16.1
4
IF ANY CURRENT IS OUT WITH THESE TOLERANCES, THE
CAUSE MUST BE INVESTIGATED AND RECTIFIED.

11
5.0 DIMENSIONS / CONNECTION LOCATIONS
6.0 INSTALLATION
Electrical Safety and Advice Regarding Supplementary Electrical Protection
Commercial kitchens and foodservice areas are environments where electrical
Appliances may be located close to liquids, or operate in and around damp conditions
Or where restricted movement for installation and service is evident.
The installation and periodic inspection of the appliance should only be undertaken by a
qualified, skilled and competent electrician; and connected to the correct power
Supply suitable for the load as stipulated by the appliance data label.
The electrical installation and connections should meet the necessary requirements to the
local electrical wiring regulations and any electrical safety guidelines.
We recommend:-
Supplementary electrical protection with the use of a residual current device (RCD)
Fixed wiring appliances incorporate a locally situated switch disconnector to connect
to, which is easily accessible for switching off and safe isolation purposes. The
switch disconnector must meet the specification requirements of IEC 60947.

12
6.1 SITING / CLEARANCES
CAUTION: WALLS CLOSER THAN 150mm TO THE APPLIANCE
MUST BE NON COMBUSTIBLE. IF SUITING THE NECESSARY
CLEARANCES TO ANY COMBUSTIBLE WALL MUST BE THE
LARGEST FIGURE GIVEN FOR INDIVIDUAL APPLIANCES
INSTRUCTIONS.

13
6.2 ASSEMBLY
6.2.1 Position the appliance and level using feet adjusters as shown below.
TAKE CARE WHEN MOVING AN APPLIANCE FITTED WITH
CASTORS.
