USER’S INSTRUCTION MANUAL FOR THE INSTALLATION,
OPERATION & MAINTENANCE OF THE
FALLTECH

7275 6’ to 11’ ADJUSTABLE TRIPOD
WARNING
This is a design compatible component for a comprehensive FallTech personal fall arrest, work positioning or
rescue and evacuation system. Each component includes an instruction manual. These instructions must be
provided to the user of this equipment prior to use. AS A USER, YOU MUST READ, UNDERSTAND AND
FOLLOW THE MANUFACTURER’S INSTRUCTIONS, LABELS AND WARNINGS for each component
part of the complete system before using it. If you do not understand the instructions, labels and warnings for
the use and maintenance of this component, have them explained to you. ANY MISUSE OF THIS
COMPONENT, ANY ALTERATION OR MODIFICATION OF IT, OR FAILURE TO PROPERLY FOLLOW
THESE USER’S INSTRUCTIONS, MAY RESULT IN SERIOUS INJURY OR DEATH.
If any additional information is required to use this product, it will be supplied with this product. Fall arrest
equipment used in conjunction with the FallTech 7275 Adjustable Tripod will also be supplied with
instructions.
This manual is intended to meet industry standards, including OSHA 1910.146 and ANSI Z117.1 and should be
used as part of an employee training program. It should be read completely and used as part of the User’s
Training Program as required by OSHA (1910.66, Appendix C).

1.0 PRODUCT DESCRIPTION AND APPLICATIONS
FALLTECH Part Number: 7275 Adjustable Tripod
The FallTech 7275 Adjustable Tripod is designed to be used in applications where a fall hazard exists, but there
is no means of arresting a fall. The FallTech Tripod is designed to be part a comprehensive confined space
entry, retrieval, and rescue system. It provides a portable anchorage for a variety of different systems, such as
those available from FallTech. The tripod collapses down to 6 feet and can extend can extend to an overall
height of 11 feet. The telescoping legs have adjustment holes 5 inches. A built-in pulley at the head provides
smooth travel for the primary retrieval line. Additionally, three side mount anchor points are provided for
accessory pulleys and lifeline. The feet are shaped with a large point at one end, allowing the tripod to be driven
into loose ground surfaces for more stability. Three retention pins located at the head allow the legs to be locked
in place after set-up. A retention web assembly is looped through the feet to keep the legs from legs from
splaying out under extreme load. The legs are extruded and aluminum and anodized for protection. The tripod is
rated for 5,000 pounds as an anchorage connector.
This system has been designed and tested to be used with FallTech Personal Fall Arrest Equipment (PFAS)
only. It has been designed for personal fall arrest, material handling, work positioning or confined space rescue
and evacuation.
The following limitations must be considered when planning to use this product. Failure to do so may result in
serious injury or death:
•The FallTech 7275 Adjustable Tripod must be properly installed following the guidelines set forth in
Section 6.0
•The maximum working load for this Tripod is 310lbs
•PFAS used with this Tripod must meet applicable federal and state regulations set forth in Section 6.1
In addition to the above limitations, the following environmental and physical factors must also be considered
prior to use:
•High heat (metal cutting or welding slag)
•Sharp edges
•Electrical lines
•Caustic chemicals
•Corrosive environment (seawater)
Contact FallTech for any questions regarding applications of this equipment in areas where environmental or
physical hazards exist.
2.0 PRODUCT DESCRIPTION AND APPLICATIONS

2.0 PRODUCT SPECIFICATIONS
Material of Construction Aluminum.
Diameter of Opening at 6 ft 51.5” between legs
Diameter of Opening at 11 ft 51.5” between legs
Leg Height Adjustment Increments 5 inches
Max Working Load-Personnel 310 lbs. (including tools)
Safe Working Load 800 lbs.
3.0 SYSTEM REQUIREMENTS
Anchorages
Anchorage points used for Personal Fall Arrest Systems must be designed to meet the requirements set forth by
ANSI Z359.1-1992, section 7.2.3, which is consistent with OSHA 1910.66 Appendix C. Anchorages must have
strength capable of supporting static loads, applied in the direction permitted by the PFAS, of at least:
(a) 3,600 lbs. when certification exists; or
(b) 5,000 lbs. in the absence of certification
If more than one personal fall arrest system is attached to an anchorage, the anchorage strengths set forth in (a)
and (b) of this section must be multiplied by the number personal fall arrest systems attached to the anchorage.
Compatibility of System
The FALLTECH Permanent Horizontal Lifeline System has been designed to be used only with FALLTECH
approved components. If FALLTECH equipment is used with other fall arrest equipment that is not compatible,
the integrity of the system may be jeopardized. If you have questions concerning equipment compatibility,
please contact your local field representative or FALLTECH at [phone].
Limitations Of System
System Capacity – 7275 6’ to 11’ Adjustable Tripod has a maximum capacity of three workers. There must
also be adequate clearance beneath the walking/working surface (see section titled clearance below) for the
system to function properly. The maximum worker’s weight, including tools, cannot exceed 310 pounds.
Consult your FALLTECH sales representative if you have any questions concerning your application.
Corrosion – Harsh environments can cause corrosion of metal parts. The Permanent Horizontal Lifeline
System should not be left in corrosive environments for extended periods of time. Additional inspections may
be necessary to verify that the lifeline and components are in good working condition.
Electrical Hazards – User should always use extreme caution when working near electrical sources.
Heat – Do not use this device in extremely high temperatures. When performing any type of metal work, such
as welding, cover fall arrest
Moving Machinery – If it is necessary to work above moving machinery, maintain a safe distance between the
moving parts and yourself, clothing, and personal protective equipment.

Sharp Edges – Fall arrest equipment should always be protected from sharp edges. Sharp or abrasive edges can
cause excessive wear to equipment. If it is necessary to work around these type of surfaces, always use a wear
pad or barrier.
Clearance – There must be sufficient clearance beneath the walking/ working surface to ensure that workers do
not contact an obstruction below.
Swing Falls – It is important to work as close as possible under the horizontal lifeline to minimize swing fall
hazards. A swing fall hazard is a result of a worker walking and/or working too far away from the horizontal
lifeline. In the event of a fall, a worker that is not close to the horizontal lifeline will swing in a pendulum like
motion and could hit an obstruction, causing a serious injury. To minimize this type of hazard, work as closely
as possible to the horizontal lifeline and carefully evaluate any obstructions below the working surface.
4.0 IMPORTANT DO’S AND DON’TS
NOTE: The components, materials and anchorage of a personal fall arrest system must be selected by a
competent person to match the system’s application, and workplace hazards and environment.
DO DON’T
Use this device only with compatible
components from FALLTECH

.
Don’t use this Tripod if two or more legs
are NOT level.
Inspect equipment before each use.
Repair or modify this device.
Store equipment in a safe, dry area.
Don’t use this tripod without locking the
head and legs with the retraction pins.
Keep all literature and instructions in a safe
place for easy, quick reference.
Don’t use this Tripod without the use of the
web leg retention assembly.
Keep all inspection documents updated.
Use this equipment unless you have been
fully trained by a competent person and
fully understand how to use this equipment.
Keep all labels on fall protection equipment
readable.
Use this device if it has been exposed to
corrosion, chemicals, excessive heat,
flames, electrical charge, or shows signs of
any physical damage or deformation.

Use extreme caution when rigging this
equipment.
Use this device if your total combined
weight (body, clothing, tools, etc.) exceeds
310 lb.
Use this device when your clearance
distance is a minimum of 2 ft after you
have calculated the total fall distance.
Don’t use this Tripod with more than one
worker at a time.
Plan for a rescue if a worker becomes
unconscious or incapacitated and falls.
Rely on the sound of a closing snaphook.
Visually inspect it to ensure a proper
attachment.
Call FALLTECH at [phone] if the
device is damaged or does not function
according to the correct operation
explained in section 1 of this manual.
Use this system if you are pregnant, a
minor, or have reduced tolerance to fall
forces by reason of age, physical or medical
condition, or other pre-existing disorders.
DO NOT USE: This Device if it has been used as part of a system that has arrested a fall. If it has been used in
such a system, it must be removed from service immediately and sent to an authorized FallTech service location
for inspection and servicing.
5.0 FALL PROTECTION PLAN
As an employer, you must be aware of the factors which affect the safety of your workers before, during and
after a fall. Having a Fall Protection Plan ready before work is the best way to ensure the ultimate safety and
well-being of your employees.
Your Fall Protection Plan must include:
1. Proper Anchorage: A Properly selected anchorage point is critical to the success of a personal fall arrest
system (PFAS). The anchorage point must be rigid and capable if supporting 5,000 lbs.
2. Free Fall Limitations: Free fall distance must be taken into consideration when designing a fall protection
system. Potential free falls may not exceed 6 ft. To reduce free fall distance, keep anchorage points above
your working level. Note: ANSI A10.14 requires personal fall arrest systems to be rigged so that the
potential free fall is not greater than 5 ft.
3. Fall Clearance Distance: Measure the distance between the working level and the next obstruction. Then,
design a system that will not allow a worker to come in contact with the obstruction or next level.
4. Swing Falls: If a worker is not directly under an anchorage point, a swing fall may result. To minimize this
hazard, evaluate the entire situation, and plan accordingly for a safe clearance distance, or consider a
horizontal lifeline. Contact FALLTECH for assistance.
5. Rescue and evacuation plan. You must provide a means of rescue and evacuation for workers should a fall
occur.
6. Immediately dispose of equipment which has been subjected to fall arrest forces.
YOUR CONFINED SPACE ENTRY AND RESCUE PLAN MUST INCLUDE:
1. Proper Permits (If necessary)
2. List of Hazards for each entry point.

3. Worker Training
4. Proper Equipment
5. Proper Anchorage. When used for confined space entry and rescue, this FallTech tripod provides an
anchorage point capable of supporting a static load of 5,000 pounds for one attached worker 310 pounds
(worker with clothing, tools, etc.)
6. Means of Rescue.
6.0 OPERATION OF THE FALLTECH 7275 ADJUSTABLE TRIPOD
One complete tripod system includes the following components:
Item Number
Description
Qty
1
Tripod Head
1
2
Tripod Legs
3
3
Pulley
1
4
Tripod Foot
3
5
Tripod Foot Pad
3
* Not Shown
Tripod Tote Bag
1

The FallTech 7275 Tripod is intended to provide a portable anchorage mount for the mounting of lifeline
components of a comprehensive confined space entry, retrieval and rescue system. It should be erected above
the opening of the confined space. It will accommodate round openings up to 5 feet in diameter and up to 4 feet
square openings.
Steps to erect FallTech tripod:
1. Remove the tripod from its tote bag or other storage.
2. Lay tripod down on its side.
3. Remove all three adjustment pins from legs if extra height is needed.
4. Extend inner tube of leg out to desired length/height and insert adjustment pins into holes. Do not extend the
inner tube beyond the red markings near the top of the tube. For proper strength, the red markings must
remain in the top tubes.
5. Reinsert the leg adjustment pins fully into the proper holes.
6. Stand Tripod up vertically and spread legs out until the top of each leg comes in contact with the bottom of
the head.
7. Insert all three upper leg lock pins through head and legs. If the tripod is to be used at a height, you may
wish to swing out and lock the legs while the tripod is lying on the ground.
8. Insert web retention assembly through grooves in feet and tighten web assembly until taut.
9. Install any accessories (winches, 3-way retrieval units, etc.) to the Tripod.
10. If the tripod is to be used on loose ground surface (i.e. dirt or gravel) turn the point of the feet downward
and drive the tripod into the ground surface until it is stable.
11. If the Tripod is on a flat surface, make sure the bottoms of the feet are flat and the points of the feet are
pointing TOWARDS THE CENTER of the tripod.

7.0 MAINTENANCE & STORAGE
This FallTech Tripod should be kept clean and free from any dirt, corrosives, abrasive or any other material that
may damage it. Clean the tripod as necessary with a mild soap and water, rinsing thoroughly afterward. Do not
use other chemicals or solvents to clean this tripod. Allow the tripod to dry completely before storing. The built-
in pulley should also kept clean and free from any large debris that may inhibit its function. The pulley shaft
may be lubricated with a small amount of oil. When not in use the FallTech Tripod should be stored in its
Tripod bag in a clean, dry area.
1. Inspection must be carried out by a competent person trained in the inspection and replacement of the
system. A record log of all servicing and inspection dates for this system should be maintained by the
company safety officers at intervals of no less than twice per year. This system and all components must be
withdrawn from service if subjected to fall arresting forces. Only original FALLTECH Replacement parts
are approved for use in this device. Contact your FALLTECH distributor or FALLTECH Customer Service
Department at [phone] if you have any questions.
2. Maintenance and storage of equipment shall be conducted by the user’s organization in accordance with
FALLTECH instructions. Unique issues which may arise due to conditions of use shall be addressed with
FALLTECH.
3. Equipment which is in need of or scheduled for maintenance shall be tagged “DO NOT USE” and removed
from service.
4. Hardware should be wiped clean with a rag to remove dirt and grease. Lubricate with a light oil to insure
good working order and protect against corrosion. Wipe off excessive amounts of oil to avoid the
accumulation of dirt.
5. Store in a clean, dry area free from excessive heat, steam, sunlight, harmful fumes, corrosive agents and
rodents.
WARNING: Do not use Fall Protection equipment that has not been maintained and stored properly.
8.0 INSPECTION
Inspection procedures for in field visual inspection:
1. The FALLTECH Systems shall be inspected by the user before each use and additionally by a Competent
Person other than the user at intervals of no less than twice a year. If equipment is in a very harsh and/or
corrosive environment, additional inspections may be necessary. Detailed inspections must be recorded. A
comprehensive Inspection Checklist is included with all FALLTECH instructions..

2. If an inspection reveals defects that could affect the function of the Personal Protective Equipment, remove
from service immediately and discard. Fall Protection equipment, damage, or inadequate maintenance of
the system, the components affected shall be permanently removed from service to undergo adequate
corrective maintenance before return to service.
3. Remove the system from service if:
•The system has arrested a fall;
•The system has not been inspected in the last six months.
•The label is missing or illegible;
•Alteration of any components;
•Inspection reveals excessive wear, cracks, or signs of deformation.
Only FALLTECH manufacturing personnel or entities authorized in writing by the manufacturer shall make
repairs to the equipment. No authorized repairs or modifications are allowed.
INSPECTION GUIDELINES:
Inspection procedure for Falltech Tripod:
1. Check the head for any cracks, dents, deformation, or any other damage.
2. Check the legs for dents, cuts, excessive wear, or other damage. If any of these conditions exist, remove the
Tripod from service.
3. Check the web retention assembly. Check the condition of the webbing and the cam buckle. Check for cuts,
tears, excessive wear, burns and other damage. If web retention assembly is missing or damaged, remove the
tripod from service until a replacement is obtained.
4. Check all leg adjustment pins. Ensure that all pins are straight, retention balls in place and keeper lanyards
are attached.
5. Check all upper leg lock pins. Ensure that all pins are straight, retention balls in place and keeper lanyards
are attached.
Inspection Guidelines for Full Body Harnesses:
Inspect webbing on FALLTECH full body harnesses. The entire length of webbing should be free of tears,
fraying, burns, chemical wear or other signs of wear and damage. All sewn terminations should be secure,
complete and not visibly damaged.
Check D-rings for rough or sharp edges, cracks, dents or other deformation.
Maintenance:
1. Inspect all hardware for distortion and deformation. Check for visible cracks, excessive wear and tear,
corrosion and chemical erosion. Also, remove hardware if there are sharp edges.
2. Inspect anchor points for physical damage, wear or corrosion that could affect their function in the event of a
fall.
3. Inspect carabiners and snaphooks to ensure that gate operates properly.
4. Inspect all hardware for correct operation, broken or missing pieces, and loose or missing items.
5. Inspect all synthetic lifelines for cuts, fraying, fluffing, abrasion, melting and chemical wear.

6. Inspect synthetic harnesses and lanyards for the same items outlined in #5, in addition to inspecting for
discoloration, damaged stitching, and exposed warning labels.
7. Inspect all labels to ensure that the Personal Fall Protection equipment has been inspected by a Competent
Person. Labels must be readable at all times.
INSPECTION LOG
Manufacturer: __________________________
Model No: _____________________________
Mfg. Date: ____________________________
Inspection
Date
Inspector
Comments
Pass/Fail
Corrective
Action
Taken
Approved
By
WARRANTY

Fall protection equipment manufactured by FALLTECH is warranted against any factory defects in our material
and/or workmanship for a period of one year from installation date or use date by the owner providing that not
more than two years from shipment date have passed.
