HP120 Hanging Pendant Light Fixture Instructions Sheet
1. Before discarding packing materials, be certain all parts
have been removed.
CAUTION
Do not install or use fixture if any part is damaged or
missing. This product is designed to use only those
parts supplied with this product and/or any accessories
designated specifically for use with this product by
Fanimation. Substitution of parts or accessories not
designated for use with this product by Fanimation
could result in personal injury or property damage.
Contact your retail store for missing or damaged parts.
Electrical Requirements
Your new light fixture will require a grounded
electrical supply line of 120 volts AC, 60 Hz, 15
amp circuit.
Maintainance Requirements
Periodic light dusting of the light fixture and glass is
recommended. A feather duster will work best. Avoid
using water, cleansers, or harsh rags, which can ruin
the finish and fixture.
How To Order Parts
When ordering repair parts, always
give the following information:
• Part Number
• Part Description
• Fan Model Number
Contact your retail store for repair parts.
2
1
NOTE: The illustration shown is not to scale or its actual
configuration may vary
Item # Description Qty. Part #
1 Light Fixture 1 HP120
Support, 1-foot section 3
Base, Support 1
2 Hardware Parts, contains 1 HDWSF120
Crossbar w/ Gnd Screw 1
Screw, junction box 2
Rod, Threaded 2
Hex Nut 1
Knurled Nut 2
Lockwasher 2
Wire Connector 2
Parts List
HP120AB with
G239 (sold seperately)

10983 Bennett Parkway
Zionsville, IN 46077
[phone]
FAX [phone]
Outside U.S. call [phone]
Visit Our Website www.fanimation.com
1. Assemble two (provided) Threaded
Rods on the Crossbar. (Figure 1)
2. Mount assembled Crossbar to
junction box with screws (provided
with your junction box) (Figure 2).
6. Securely connect the bare copper
(Ground) wire to the (hex-head)
screw located on the Crossbar.
Securely connect the white lamp
wire to the white supply (neutral)
wire using wire nut supplied.
Securely connect the black lamp
wire wire to the black supply (hot)
wire using wire nut supplied.
(Figure 9)
3. Carefully screw 1-foot tube
section onto the light fixture while
suspending the assembly upside
down to prevent wires from binding
and twisting within the support tube,
do not over tighten. (Figure 3)
Copyright 2004 Fanimation
Figure 2
Figure 1
Figure 7
Figure 6
7. After connections have been
made, carefully push leads into the
outlet box. Carefully fasten the
Fixture over the Threaded Rods with
the Lockwashers and Knurled Nuts
provided. (Figure 7)
NOTE: Be sure that the electrical
wires are completely inside the
junction box and not pinched
between the fixture and the ceiling.
9. You have now completed the
assembly of your Hanging Pendant
lighting fixture. Restore power and
operate your light fixture with your
standard on/off light switch.
2004/12
Figure 3
Figure 4
4. Assemble other two 1-foot support
tube sections. (Figure 4)
Figure 5
5. Assemble the base assembly.
(Figure 5)
8. Install 2¼˝glass (sold seperately)
with “glass nut”. (Figure 8a)
Install 100 watt max light bulb (not
included). (Figure 8b)
Figure 8a Figure 8b
