Fantic XEF 250 User manual

Introduction
USE AND MAINTENANCE MANUAL
INTRODUCTIONXEF 250 - Rev01 / 2020
1
FANTIC WANTS TO THANK YOU
for choosing one of its products.
We recommend that you read this manual before driving your vehicle. It contains information, advice and warnings on the vehicle
maintenance and use. The instructions in this manual have been prepared to give you a simple and clear guide for use. We are sure
that taking it into consideration you will gain confidence with your new vehicle, which you can use for a long time and with full
satisfaction.
MANUFACTURER DATA AND EDITION
Fantic Motor
Via Tarantelli, 7
31030 - Dosson di Casier (TV) Italy
Tel. [phone]
Fax [phone]
E-mail: [e-mail]
www.fanticmotor.it
Edition: 01/2020.

13 MotoreIntroduction
USE AND MAINTENANCE MANUAL
INTRODUCTIONXEF 250 - Rev01 / 2020
2
Introduction
This manual was prepared by Fantic Motor for use by Fantic Motor dealers and their specialized personnel. It is assumed that
those who use this documentation for repair and maintenance of Fantic Motor vehicles have a basic knowledge of the principles
and mechanical procedures regarding vehicle repair techniques. In the absence of these notions, repair or maintenance may be
inadequate or dangerous.
Fantic Motor is constantly committed in improving its production. Any significant modifications and changes introduced with regard
to vehicle characteristics and repair procedures will be brought to the attention of all Fantic Motor dealers and will be published in
future editions of the manual.
Fantic Motor reserves the right to modify and make changes, at any time and without notice, to the models described,
specifications and design data, guaranteeing the essential characteristics described and illustrated in this manual.
Operators have the obligation to read the manual and to scrupulously follow the instructions given. The manufacturer
is not responsible for damages caused to people and/or things and is not responsible for damages to the product, if the
instructions given in this manual are not observed.
This publication, or part of it, cannot be reduced or translated without the Fantic Motor’s approval. Reproduction of the
contents used in this manual without the Manufacturer’s permission is prohibited. Fantic Motor assumes no responsibility
for printing errors and omissions. All rights reserved.

INDEX
USE AND MAINTENANCE MANUAL
XEF 250 - Rev01 / 2020
3
1. General information ...............................................................................................................................7
1.1 Warnings .......................................................................................................................................................7
1.2 Symbols used in the manual .......................................................................................................................9
1.3 Behaviour and driving ............................................................................................................................... 10
Vehicle use .................................................................................................................................................. 10
Getting on ................................................................................................................................................... 10
Getting off ................................................................................................................................................... 10
1.4 Frame number ............................................................................................................................................ 11
1.5 Engine number ........................................................................................................................................... 11
1.6 Location of important labels ..................................................................................................................... 12
1.7 Vehicle component location ..................................................................................................................... 14
Handlebar components ............................................................................................................................ 14
Right and left side components ................................................................................................................ 15
1.8 Technical data ............................................................................................................................................ 16
1.9 Tightening torques ..................................................................................................................................... 18
Engine tightening torques ......................................................................................................................... 18
Chassis tightening torques ........................................................................................................................20
Electrical tightening torques .....................................................................................................................22
1.10 Maintenance limits ...................................................................................................................................23
Engine .........................................................................................................................................................23
Chassis ........................................................................................................................................................24
Electrical .....................................................................................................................................................27
1.11 Electrical system diagram ........................................................................................................................28
Cables colour coding ................................................................................................................................. 28
Key to the wiring diagram components ...................................................................................................29
Wiring diagram ...........................................................................................................................................30
1.12 Lamps ........................................................................................................................................................32
1.13 Fuses ..........................................................................................................................................................32
1.14 Recommended lubricants and liquids ...................................................................................................33
1.15 Maintenance intervals ..............................................................................................................................34
Periodic maintenance chart for the emission control system ...............................................................34
General maintenance and lubrication chart ............................................................................................34
Maintenance intervals for competition use .............................................................................................36
2. Use of the vehicle .................................................................................................................................39
2.1 Pre-operation inspection and maintenance ............................................................................................39
2.2 Running in .................................................................................................................................................. 39
2.3 Refuelling ....................................................................................................................................................40
2.4 Starting the engine ....................................................................................................................................40
Starting a cold engine ................................................................................................................................40
Starting a warm engine .............................................................................................................................40
2.5 Stop the engine .......................................................................................................................................... 41
2.6 Main components ...................................................................................................................................... 41
Engine stop switch ..................................................................................................................................... 41
Clutch lever ................................................................................................................................................ 41
Shift pedal .................................................................................................................................................. 41
Throttle grip ...............................................................................................................................................42
Front brake lever ........................................................................................................................................42

INDEX
USE AND MAINTENANCE MANUAL
XEF 250 - Rev01 / 2020
4
Start button ................................................................................................................................................42
Rear brake pedal ........................................................................................................................................42
Start knob (air valve) ..................................................................................................................................43
Sidestand ....................................................................................................................................................43
Locking device ...........................................................................................................................................43
2.7 Dashboard: basic functions .......................................................................................................................44
Function, setting instructions ................................................................................................................... 44
Meter size ....................................................................................................................................................45
Select button function instruction ...........................................................................................................45
Adjust button function instruction ...........................................................................................................45
The settings screen description ................................................................................................................46
Enter settings and function index menu ..................................................................................................46
Circumference and sensing pointsetting .................................................................................................46
RPM pulse setting .......................................................................................................................................47
Funzioni non attive ....................................................................................................................................47
Backlight brightness setting .....................................................................................................................47
Oil maintenance mileage setting .............................................................................................................. 48
Speed unit setting ......................................................................................................................................48
External ODO ..............................................................................................................................................48
Internal ODO ...............................................................................................................................................49
Trouble shooting ........................................................................................................................................49
Dashboard setting values ..........................................................................................................................49
3. Adjustments .........................................................................................................................................50
3.1 Brakes ..........................................................................................................................................................50
Front brake adjustment ............................................................................................................................. 50
Rear brake adjustment ..............................................................................................................................50
3.2 Clutch .......................................................................................................................................................... 51
Adjusting the clutch lever position ........................................................................................................... 51
Adjusting the clutch lever clearance ........................................................................................................ 51
3.3 Throttle control ..........................................................................................................................................52
Adjusting the throttle grip clearance ........................................................................................................52
3.4 Adjusting the engine idling speed ............................................................................................................52
3.5 Handlebar adjustment ..............................................................................................................................53
Handlebar installation and adjustment ................................................................................................... 53
3.6 Rear-view mirrors .......................................................................................................................................54
Rear-view mirror adjustment ....................................................................................................................54
3.7 Fork adjustment .........................................................................................................................................55
Rebound damping adjustment (return) ...................................................................................................55
Compression damping adjustment .........................................................................................................55
Relieving the front fork internal pressure ................................................................................................56
3.8 Rear shock absorber adjustment ............................................................................................................. 57
Rebound damping adjustment (return) ...................................................................................................57
Compression damping adjustment (low speed) .....................................................................................57
Compression damping adjustment (high speed) ...................................................................................58
3.9 Setting the SAG ...........................................................................................................................................58
Rear shock absorber sinking adjustment (SAG) ......................................................................................58

INDEX
USE AND MAINTENANCE MANUAL
XEF 250 - Rev01 / 2020
5
4. Maintenance .........................................................................................................................................60
4.1 Engine oil ....................................................................................................................................................60
Engine oil level check ................................................................................................................................60
Engine oil change and engine oil filter replacement ..............................................................................60
4.2 Coolant .......................................................................................................................................................62
Checking the coolant level ........................................................................................................................62
Coolant replacement .................................................................................................................................62
4.3 Air filter .......................................................................................................................................................63
4.4 Camshafts ...................................................................................................................................................65
Removal ......................................................................................................................................................65
Installation .................................................................................................................................................66
4.5 Valve clearance ...........................................................................................................................................69
Check ..........................................................................................................................................................69
Adjustment .................................................................................................................................................69
4.6 Cylinder head ............................................................................................................................................. 71
Removal ...................................................................................................................................................... 71
Check .......................................................................................................................................................... 71
Installation ................................................................................................................................................. 71
4.7 Cylinder and piston ....................................................................................................................................73
Removal ......................................................................................................................................................73
Cylinder check ............................................................................................................................................73
Piston check ...............................................................................................................................................73
Installation .................................................................................................................................................74
4.8 Soundproofing ...........................................................................................................................................75
4.9 Clutch ..........................................................................................................................................................75
Clutch removal ...........................................................................................................................................75
Check the clutch elements ........................................................................................................................77
Clutch installation ......................................................................................................................................78
4.10 Steering play control and adjustment .................................................................................................... 81
Steering play control ................................................................................................................................. 81
Steering play adjustment .......................................................................................................................... 81
4.11 Fork ............................................................................................................................................................82
4.12 Shock absorber ........................................................................................................................................82
4.13 Wheels .......................................................................................................................................................82
Spokes check and tightening ....................................................................................................................82
Wheel check ...............................................................................................................................................83
4.14 Brake pads ................................................................................................................................................83
Replace the front brake pads .................................................................................................................... 83
Replace the rear brake pads ......................................................................................................................84
4.15 Tyres ..........................................................................................................................................................86
4.16 Chain, crown and sprocket ......................................................................................................................86
Chain check ................................................................................................................................................86
Pinion and crown check ............................................................................................................................86
4.17 Cleaning and vehicle storage ..................................................................................................................87
4.18 Long time vehicle inactivity ....................................................................................................................87
5. Warranty and service ...........................................................................................................................89
Warranty ............................................................................................................................................................89

INDEX
USE AND MAINTENANCE MANUAL
XEF 250 - Rev01 / 2020
6
Warranty period .........................................................................................................................................89
Warranty conditions ..................................................................................................................................89
Exclusions from the warranty ...................................................................................................................90
Additional warranty provisions ................................................................................................................90
Request for intervention under warranty ................................................................................................90
Warnings for maintenance and care ........................................................................................................90
Warranty data .................................................................................................................................................... 91
Service ...............................................................................................................................................................92

1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
7
1
1.1 WARNINGS
Carbon monoxide
The exhaust fumes contain carbon monoxide, a poisonous gas that can cause death. Therefore, for certain operations,
make sure you are in an open space, or in a suitable and well-ventilated room, never in enclosed spaces. If operating in
enclosed spaces, use an evacuation system for the exhaust fumes.
Fuel
The fuel used is extremely flammable and can become explosive under certain conditions. Refuelling and maintenance
operations must be carried out in a ventilated area and with the vehicle switched off. Do not smoke during refuelling and
near fuel vapours; avoid contact with open flames, sparks and any other source that could cause ignition or explosion.
Do not disperse in the environment and keep away from children.
Hot components
The engine and certain components become very hot and remain hot for a while even when the engine is off. Before
carrying out any operation near the engine or exhaust system, wear insulating gloves or wait for their cooling.
Used engine and gearbox oil
Used engine and gearbox oil is harmful to health, whether it is inhaled or swallowed. It is also irritating and can cause
serious consequences if it comes into contact with the skin.
Spreading and dispersion into the environment is prohibited.
If swallowed, do not induce vomiting, but go urgently to a first aid centre, indicating the cause and how the accident
occurred.
In case of contact with the skin, immediately wash the affected part with soap and water, repeating the operation until
the affected part is free from residues.
In case of contact with eyes and ears, immediately rinse the affected parts with plenty of water and urgently go to a first
aid center, indicating the cause and how the accident occurred.
In case of contact with clothing, undress and wash thoroughly with soap and water. Change the dirty cloths which must
be specifically washes as soon as possible.
Always use gloves suitable to protect your hands during the maintenance operations.
Keep out of the reach of children.
Used engine and gearbox oil must be collected in a sealed container, and delivered to the nearest service station or at a
waste oil collection centre where you will find personnel authorized to dispose of it.
Brakes
Brake fluid may damage the vehicle painted, plastic or rubber surfaces. Protect these components with a clean rag when
performing certain operations.
Always wear protective glasses and in case of accidental contact of the brake fluid with eyes, rinse immediately with
plenty of clean, fresh water and consult a doctor immediately. Keep out of the reach of children.
Clean the brake pads in a ventilated environment, directing the compressed air jet so as not to inhale the dust produced
by the wear of the friction material. Although the latter does not contain asbestos, inhaling dust is however harmful.
Electrolyte and hydrogen gas from the battery
The electrolyte of the battery is toxic and caustic. In contact with skin it can cause burns, as it contains sulphuric acid.
Wear gloves and protective clothing.
If the electrolyte liquid comes into contact with the skin, wash it thoroughly with fresh water.
Protect your eyes, as battery fluid can cause blindness. If it comes into contact with the eyes, wash thoroughly with
water for fifteen minutes and promptly contact an eye specialist.

13 Motore1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
8
The battery emits explosive gases, it is advisable to keep away flames, sparks and any other source of heat. Provide
adequate ventilation when servicing or recharging the battery.
Keep out of the reach of children.
The battery fluid is corrosive. Do not pour it or spread it, especially on plastic parts.
Provide for regular disposal.
Coolant
Under certain conditions, the ethylene glycol present in the engine coolant is combustible and its flame is not visible. If
ethylene glycol is ignited, its flame is not visible but it is able to cause serious burns.
Avoid pouring engine coolant to the exhaust system or on engine parts. These parts may be hot enough to ignite the
liquid which then burns without visible flames. Coolant (ethylene glycol) can cause skin irritation and is poisonous if
swallowed. Keep out of the reach of children. Do not remove the radiator cap when the engine is still hot. Coolant is
under pressure and may cause burns.
Keep hands and clothes away from the cooling fan as it starts automatically.
Precautions and general warnings
The clothing of the operator performing the repair operations must be adequate to avoid the risk of injury when working
on moving parts (for example, too wide clothes that can get caught).
Do not wear personal items (e.g. rings, wristwatches, etc.) while performing repairs on the vehicle, and in particular on
the electrical system.
Keep the work area tidy, to avoid that elements left on the ground interfere with the repair operations.
Clean the floors of the working areas from oil, grease or other residual fluids, to avoid slipping.
Perform compression or decompression operations on the springs, using only suitable tools to prevent the operations
from causing damage to the operator.
Avoid inhalation of vapours from cleaning fluids: they can be highly toxic. Make sure the work area is properly ventilated.
Use suitable cleaning products for each operation, making sure that they are approved.
Wear eye protection when using electrical tools such as drills, grinders or milling machines.

1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
9
1
1.2 SYMBOLS USED IN THE MANUAL
Within this manual there will be technical warnings and annotations preceded by the following symbols according to the reference
topic:
Warning regarding the procedure described and the specific safety rules: indicates procedures that must be followed to
prevent damage to the vehicle or possible injuries to vehicle repairers.
Information note on the procedure described and on the characteristics of the vehicle: it provides useful information to
make the procedure easier and clearer.
Tightening torque: note showing one or more tightening torques values referred to the procedure described.
Measurement data: note showing the values of one or more measurements to be complied with or verified for the
procedure described.
Equipment: note that informs the user of the need to use particular tools for the procedure described.
Consumable: note that illustrates the names, types and/or quantities of consumables (such as oil, fuel, sealants,
additives, etc.) to be used for the procedure described.
All left or right indications refer to the direction of travel of the motorcycle.
This manual contains images illustrating some disassembling sequences, using the following symbols to identify the characteristics
of the type of intervention.
Apply and/or lubricate using engine oil.
Apply and/or lubricate using gear oil.
Apply and/or lubricate using molybdenum disulphide oil.
Apply and/or lubricate using brake fluid.
Apply a product that is not specified or specified separately.
Apply wheel bearing grease.
Apply lithium soap based grease.
Apply molybdenum disulphide grease.
Apply and/or lubricate using silicone grease.
Apply a threadlocker (LOCTITE®).
Replace with a new component.

13 Motore1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
10
1.3 BEHAVIOUR AND DRIVING
Some safety tips are given below to avoid damage to people and/or things and to use your vehicle with an easier and safer drive.
Vehicle use
To use the vehicle it is necessary to meet all the law requirements.
It is advisable, in order to acquire a good knowledge of the vehicle, to use the vehicle in areas without traffic or unpopulated stretches
of road.
It is advisable to always respect the highway code while driving, to avoid sudden or dangerous manoeuvres keeping both hands on
the handlebar and always keeping your feet on the appropriate footrests. Pay close attention while riding.
Do not ride the vehicle while drunk, under the influence of drugs, after taking certain medicines or in a state of physical
fatigue and drowsiness. Failure to comply with these rules is considered extremely dangerous and could cause serious
damage to property and/or people.
Evaluate and keep in consideration the conditions of the road surface, visibility and weather. In a situation not suitable for safe
driving, reduce the speed and drive carefully.
The braking effect in wet roads without ever having applied the brakes is initially less; under these conditions it is advised to
periodically operate the brakes.
In case the vehicle is used on roads dirty with sand, mud, snow mixed with salt, we recommend checking and if necessary cleaning
the brake discs with special non-aggressive detergents, so as to prevent the formation of abrasive agglomerates inside the holes and
an early wear of the brake pads.
The getting on and off from the vehicle must be in complete freedom of movement and without impediments.
Go up and down only from the left side of the vehicle and with the kickstand down to prevent unbalancing or loss of balance, causing
falls or overturns.
The rider is always the first to go on and the last to go down as he/she has to govern the stability of the vehicle.
Getting on
The passenger must make the movements to get on with the utmost caution, avoiding to unbalance the rider and the vehicle.
Place your feet on the ground and hold the vehicle in running position.
Getting off
Stop the vehicle in an area suitable for stopping or parking, ensuring that the ground is stable and free of obstacles. Fully extend the
kickstand using the left foot.
Tilt the vehicle making the kickstand touch the ground. Get off the vehicle and turn the handlebar completely to the left.
Make sure that the vehicle is stationary and stable.
Do not lift the vehicle grasping the license plate holder frame, in order to avoid damage.Qui di seguito vengono elencati
alcuni consigli sulla sicurezza al fine di evitare danni a persone e/o cose e per utilizzare il proprio veicolo con una guida
più tranquilla e sicura.

1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
11
1
B
A
Fantic Motor vehicles are equipped with frame and engine
identification numbers.
These numbers that identify the motorcycle model
must be mentioned for the request for spare parts.
1.4 FRAME NUMBER
The frame number “A” is punched on the steering tube on
the right side.
1.5 ENGINE NUMBER
The engine number “B” is punched on the left side of the
engine crankcase.

13 Motore1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
12
2 1
5
43
6
1.6 LOCATION OF IMPORTANT LABELS
1. Pressurised gas hazard label
2. Usable petrol quality label
3. Chassis number punching
4. Vehicle data plate
5. “Choke” symbol
6. Tyre pressure label

1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
13
1
5
90/90-21
80/100-21
140/80-18
130/90-19
ON-ROAD USE OFF-ROAD USE
PRESSURE [kPa]
AXLE SIZE
200
200
220
220
100
100
100
100
120/90-18 220 100
6
34
1
E5 E10
PETROL FUEL TYPE
2

13 Motore1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
14
2
1 11 143 4 6
12 10 9 8 13 5 7
1.7 VEHICLE COMPONENT LOCATION
Handlebar components
Ref. Component
1 High beam flashing button
2 Clutch lever
3 “SELECT” button
4 “ADJUST” button
5 Engine stop switch
6 Front brake lever
7 Throttle grip
8 Radiator cap
9 Fuel tank cap
10 Speedlight switch
11 Horn button
12 Low beam/high beam light switch
13 Starter switch
14 Dashboard

1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
15
1
20
21 22 23
24 25
18 1917
15
16
Right and left side components
Ref. Component
15 Headlight
16 Radiator
17 Rear brake pedal
18 Inspection window for oil level check
19 Coolant drain bolt
20 Front fork
21 Fuel tank
Ref. Component
22 Air filter
23 Taillight
24 Shift pedal
25 Drive chain

13 Motore1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
16
1.8 TECHNICAL DATA
All the values indicated refer to the approved version.
Technical data Value(s)
Overall length: 2175 mm (85.6 in)
Overall width: 825 mm (32.5 in)
Overall height: 1270 mm (50.0 in)
Seat height: 955 mm (37.6 in)
Wheelbase: 1480 mm (58.3 in)
Minimum ground clearance: 320 mm (12.60 in)
Weight in running order: 116 kg (255.7 lb)
Weight at full load: 176 kg (388.0 lb)
Maximum allowable weight: 250 kg (551.2 lb)
Engine type Liquid cooled, 4-stroke, gasoline
Cylinder arrangement Single cylinder
Displacement 250 cm3
Bore × stroke 77.0 x 53.6 mm (3.03 x 2.11 in)
Compression ratio: 13.8 : 1
Valve train DOHC
Starting system Electric starter
Lubrication system Wet sump
Transmission oil:
Recommended type
Periodic oil change
With oil filter removal
Total amount
10W-40, 10W-50, 15W-40, 20W-50 API service SG type or higher,
JASO standard Ma
0.73 L (0.64 Imp qt, 0.73 US qt)
0.75 L (0.66 Imp qt, 0.75 US qt)
0.95 L (0.84 Imp qt, 1.00 US qt)
Oil filter:
Oil filter type Cartridge
Cooling system:
Coolant quantity (including all routes)
Radiator cap valve opening pressure
0.93 L (0.82 Imp qt, 0.98 US qt)
107.9–137.3 kPa (1.08–1.37 kgf/cm2, 15.6–19.9 psi))
Air filter oil Air Filter Special Oil
Brake oil Synthetic Brake Fluid DOT 4
Air filter Wet element
Fuel:
Type
Tank capacity
Reserve amount
Premium unleaded gasoline only
7.9 L (1.70 Imp gal, 2.10 US gal)
2.0 L (0.44 Imp gal, 0.53 US gal)
Fuel pump:
Pump type
Maximum consumption amperage
Electrical
2.4 A
Fuel injector (resistance) 12.0 
Throttle body BAK1 00
Spark plug:
Type/Manufacturer
Gap
NGK/LMAR8E-J
0.6–0.7 mm (0.024–0.028 in)
Clutch type Wet, multiple-disc
Primary reduction system Gear
Primary reduction ratio 3.353 (57/17)

1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
17
1
Technical data Value(s)
Final drive Chain
Secondary reduction ratio 3.923 (51/13)
Transmission type Constant mesh, 6-speed
Operation Left foot operation
Gear ratio:
1a
2a
3a
4a
5a
6a
2.385 (31/13)
1.813 (29/16)
1.444 (26/18)
1.143 (24/21)
0.957 (22/23)
0.815 (22/27)
Seats 1
Frame Semi double cradle
Caster angle 27.2°
Trail 116 mm (4.6 in)
Wheels (original equipment):
Front
Rear
Front inflation pressure (road use)
Rear inflation pressure (road use)
Front/rear inflation pressure (“Racing” use)
90/90-21
130/90-18
2 bar (200 kPa - 29 PSI)
2,2 bar (220 kPa - 32 PSI)
1 bar (100 kPa - 15 PSI)
Wheels (alternative sizes):
Front
Rear
Front inflation pressure (road use)
Rear inflation pressure (road use)
Front/rear inflation pressure (“Racing” use)
80/100-21
140/80-18, 120/90-18
2 bar (200 kPa - 29 PSI)
2,5 bar (250 kPa - 36 PSI)
1 bar (100 kPa - 15 PSI)
Brake:
Front brake type
Operation
Rear brake type
Operation
Hydraulic single disc brake
Right hand operation
Hydraulic single disc brake
Right foot operation
Suspension:
Front suspension
Rear suspension
Telescopic fork
Swingarm (link suspension)
Shock absorber:
Front shock absorber
Rear shock absorber
Coil spring/hydraulic damper
Coil spring/gas-hydraulic damper
Wheel travel:
Front wheel travel
Rear wheel travel
310 mm (12.2 in)
317 mm (12.5 in)
Ignition system TCI
Turn signals 12 V – 6 W
High/low beam light Led
Position/brake light Led
License plate light Led
Fuses:
Battery fuse
Electrical wiring fuse
15.0 A
5.0 A

13 Motore1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
18
1.9 TIGHTENING TORQUES
Engine tightening torques
“◊” = marked portion shall be checked for torque tightening after break-in or before each race.
Item
Thread size Quantity
Tightening torque Remarks
Camshaft cap bolt M6 8 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Spark plug M10 1 13 Nm (1.3 kgf•m, 9.6 lb•ft)
Cylinder head stud bolt (exhaust pipe) M6 2 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Oil passage plug (cylinder head) M6 1 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Cylinder head bolt M9 4 See tip at page 20.
Cylinder head nut M6 2 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Cylinder head cover bolt M6 2 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Cylinder bolt M6 1 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Oil pressure check bolt M6 1 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Balancer weight plate screw M6 2 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Balancer weight gear nut M14 1 50 Nm (5.0 kgf•m, 37 lb•ft)
Balancer nut M10 1 38 Nm (3.8 kgf•m, 28 lb•ft)
Timing chain guide stopper plate (exhaust
side) M6 1 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Timing chain tensioner cap bolt M6 1 6 Nm (0.6 kgf•m, 4.4 lb•ft)
Timing chain tensioner bolt M6 2 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Coolant drain bolt M6 1 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Radiator hose clamp screw M6 8 1.5 Nm (0.15 kgf•m, 1.1 lb•ft)
Radiator bolt M6 4 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Radiator pipe joint bolt M6 1 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Radiator fan bolt M6 3 8 Nm (0.8 kgf•m, 5.9 lb•ft)
Water pump housing cover bolt M6 4 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Water pump impeller M8 1 14 Nm (1.4 kgf•m, 10 lb•ft)
Oil pump bolt M5 2 5 Nm (0.5 kgf•m, 3.7 lb•ft)
Oil pump cover screw M4 1 2.0 Nm (0.20 kgf•m, 1.5 lb•ft)
Oil strainer bolt M6 1 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Throttle cable cover bolt M5 1 3.5 Nm (0.35 kgf•m, 2.6 lb•ft)
Throttle body joint bolt M6 2 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Throttle body joint clamp screw M5 1 3.0 Nm (0.30 kgf•m, 2.2 lb•ft)
Air filter case joint clamp screw M5 1 3.0 Nm (0.30 kgf•m, 2.2 lb•ft)
Air filter case bolt M6 3 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Clutch cable locknut (clutch cable adjuster) M6 1 4.3 Nm (0.43 kgf•m, 3.2 lb•ft)
Clutch cable locknut (engine side) M8 1 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Exhaust pipe nut M6 2 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Exhaust pipe protector screw M6 2 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Exhaust pipe bracket bolt M8 1 20 Nm (2.0 kgf•m, 15 lb•ft)
Silencer bolt (front) M8 1 30 Nm (3.0 kgf•m, 22 lb•ft)
Silencer bolt (rear) M8 1 30 Nm (3.0 kgf•m, 22 lb•ft)
Exhaust pipe clamp bolt M8 2 12 Nm (1.2 kgf•m, 8.9 lb•ft)
Spark arrester bolt M5 4 9 Nm (0.9 kgf•m, 6.6 lb•ft)
Silencer cap screw M5 6 5 Nm (0.5 kgf•m, 3.7 lb•ft)

1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
19
1
Item
Thread size Quantity
Tightening torque Remarks
Oil nozzle bolt M5 1 5 Nm (0.5 kgf•m, 3.7 lb•ft)
Engine oil drain bolt M10 1 20 Nm (2.0 kgf•m, 15 lb•ft)
Crankcase bolt M6 12 12 Nm (1.2 kgf•m, 8.9 lb•ft)
Clutch cable holder bolt M6 2 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Crankshaft end accessing screw M36 1 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Timing mark accessing screw M14 1 6 Nm (0.6 kgf•m, 4.4 lb•ft)
Drive sprocket cover bolt M6 2 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Crankcase bearing cover plate screw M8 4 22 Nm (2.2 kgf•m, 16 lb•ft)
Bearing plate cover bolt (left side of the drive
axle) M6 2 12 Nm (1.2 kgf•m, 8.9 lb•ft)
Plate bolt M6 4 12 Nm (1.2 kgf•m, 8.9 lb•ft)
Clutch cover bolt M6 6 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Crankcase cover bolt (left) M6 7 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Crankcase cover bolt (right) M6 9 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Oil filter element cover bolt M6 2 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Starter clutch screw M6 8 12 Nm (1.2 kgf•m, 8.9 lb•ft)
Primary drive gear nut M16 1 105 Nm (10.5 kgf•m, 77 lb•ft)
Clutch spring bolt M6 6 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Clutch boss nut M20 1 95 Nm (9.5 kgf•m, 70 lb•ft) Stake.
Drive sprocket nut M18 1 75 Nm (7.5 kgf•m, 55 lb•ft) Use a lock washer.
Segment M8 1 30 Nm (3.0 kgf•m, 22 lb•ft)
Shift guide bolt M6 2 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Stopper lever bolt M6 1 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Shift pedal bolt ◊M6 1 12 Nm (1.2 kgf•m, 8.9 lb•ft)
Generator rotor nut M12 1 65 Nm (6.5 kgf•m, 48 lb•ft)
Stator coil screw M5 3 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Crankshaft position sensor bolt M6 2 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Stator coil assembly lead holder bolt M5 1 8 Nm (0.8 kgf•m, 5.9 lb•ft)
Coolant temperature sensor M10 1 14 Nm (1.4 kgf•m, 10 lb•ft)
Gear position switch bolt M5 2 3.5 Nm (0.35 kgf•m, 2.6 lb•ft)
Rectifier/regulator bolt M6 2 7 Nm (0.7 kgf•m, 5.2 lb•ft)
ECU bolt M5 2 3.8 Nm (0.38 kgf•m, 2.8 lb•ft)
Ignition coil bolt M6 2 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Starter motor bolt M6 2 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Nut (holder) M6 1 8 Nm (0.8 kgf•m, 5.9 lb•ft)
Throttle position sensor screw M5 1 3.5 Nm (0.35 kgf•m, 2.6 lb•ft)
Intake air pressure sensor screw M6 1 3.5 Nm (0.35 kgf•m, 2.6 lb•ft)

13 Motore1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
20
Tip : Cylinder head bolt
– Tighten all the cylinder head tightening bolts evenly in the tightening order to 30 Nm (3.0 kgf•m, 22 lb•ft).
– Remove the one bolt according to the tightening order. When doing so, do not remove the other bolts.
– Retighten the bolt to 15 Nm (1.5 kgf•m, 11 lb•ft), and then tighten it further to reach the specified angle (60°).
– Remove the remaining bolts one by one in the same manner and retighten them.
– Finally, tighten all the bolts to reach the specified angle (60°).
Total tightening angle: 60° + 60° = 120°.
The first and second time, be sure to apply molybdenum disulfide oil to the bolt threads and seats as well as to both
sides of the lock washers.
32
4
1
FWD
Chassis tightening torques
“◊” = marked portion shall be checked for torque tightening after break-in or before each race.
Item
Thread size Quantity
Tightening torque Remarks
Upper bracket pinch bolt ◊M8 4 21 Nm (2.1 kgf•m, 15 lb•ft)
Lower bracket pinch bolt ◊M8 4 21 Nm (2.1 kgf•m, 15 lb•ft)
Steering stem nut ◊M24 1 145 Nm (14.5 kgf•m, 107 lb•ft)
Upper handlebar holder bolt ◊M8 4 28 Nm (2.8 kgf•m, 21 lb•ft)
Lower handlebar holder nut ◊M10 2 40 Nm (4.0 kgf•m, 30 lb•ft)
Engine stop switch screw M3 1 0.5 Nm (0.05 kgf•m, 0.37 lb•ft)
Start switch M3 1 0.5 Nm (0.05 kgf•m, 0.37 lb•ft)
Mode switch (Except for Canada) M3 1 1.3 Nm (0.13 kgf•m, 0.95 lb•ft)
Lower ring nut ◊M28 1 See tip at page 22.
Damper assembly (front fork) M51 2 30 Nm (3.0 kgf•m, 22 lb•ft)
Inner tube and Adjuster M22 2 55 Nm (5.5 kgf•m, 41 lb•ft)
Base valve (front fork) M42 2 28 Nm (2.8 kgf•m, 21 lb•ft)
Adjuster (damper assembly) M12 2 29 Nm (2.9 kgf•m, 21 lb•ft)
Bleed screw (front fork) M5 2 1.3 Nm (0.13 kgf•m, 0.95 lb•ft)
Front fork protector bolt ◊M6 6 5 Nm (0.5 kgf•m, 3.7 lb•ft)
Speed sensor bolt M6 1 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Plate bolt ◊M5 2 3.8 Nm (0.38 kgf•m, 2.8 lb•ft)
Throttle grip cap screw M5 2 3.8 Nm (0.38 kgf•m, 2.8 lb•ft)
Clutch lever holder bolt M5 2 3.8 Nm (0.38 kgf•m, 2.8 lb•ft)
Clutch lever nut M6 1 4.0 Nm (0.40 kgf•m, 3.0 lb•ft)
Front brake master cylinder holder bolt ◊M6 2 9 Nm (0.9 kgf•m, 6.6 lb•ft)
Front brake master cylinder reservoir cap
screw M4 2 1.5 Nm (0.15 kgf•m, 1.1 lb•ft)
Front brake lever pivot bolt M6 1 6 Nm (0.6 kgf•m, 4.4 lb•ft)
Front brake lever pivot nut M6 1 6 Nm (0.6 kgf•m, 4.4 lb•ft)
