Farpointe Data P-300-OSDP User manual

This Quick Start Guide is intended for experienced installing technicians. It is a basic reference to ensure all connections are properly made.
Models include P-300-OSDP, P-500-OSDP, P-530-OSDP, P-620-OSDP, P-640-OSDP, P-710-OSDP, P-900-OSDP, P-403-OSDP, P-405-OSDP,
P-410-OSDP, P-453-OSDP, P-455-OSDP, as well as variants supporting most industry leading card and tag technologies. For additional
information please reference Farpointe Data’s website, www.farpointedata.com.
1.0 Introduction
A key component of a physical security electronic access control
system, a proximity card reader is based on RFID technology. In
operation it is capable of reading data stored on a proximity credential
via radio frequency and without physical contact, and then passing the
data obtained to the physical access control system. Access control
systems typically manage and record the movement of individuals
through a protected area, such as a locked door.
2.0 Mounting Provisions
Each reader may be installed either indoors or outdoors. Mounting
options shown in the table below. Use supplied #6 mounting screws, or
equivalent security screws, for installation. P-400 Series readers are
supplied with #6 tamperproof screws. P-900 also comes with #10
screws for mounting on parking bollards and non-metallic flat surfaces.
Models
Mullion
Mount
Single-
Gang
Wall
Mount*
Double-
Gang
Wall
Mount*
Parking
Bollard
X-Mount*
European/
Asian
Wall
Mount*
P-300-OSDP •
P-403-OSDP •
P-405-OSDP •
P-410-OSDP •
P-453-OSDP •
P-455-OSDP •
P-500-OSDP •
P-530-OSDP •
P-620-OSDP •
P-640-OSDP •
P-710-OSDP •
P-900-OSDP • • •
*Plastic or metal
3.0 Cable Requirements
Cable, 4 conductor, 22 or 24 AWG [65 mm or 51 mm] twisted pair,
over-all shield and UL approved (Belden 8273, or equivalent).
Maximum bus length: 4,000 ft – 24 AWG (1,219 m)
Maximum distance between: 1,640 ft – 24 AWG (500 m)
4.0 Reader Wiring
OSDP
Twisted Pair Conductor Function
Pair 1
Red DC (5-16 VDC)
Black Ground
Pair 2
Green RS-485 Tx+
White RS-485 Tx-
5.0 Output Formats
The SIA standard OSDP protocol is supported for clear and secure
channel communication.
Default Address: 0
Default Baud rate: 9600bps (bits per second)
Default Secure Channel Key:
SCBK_D = 0x303132333435363738393A3B3C3D3E3F.
OSDP Protocol Technical Support:
SIA OSDP Application Profile: Basic Reader (OSDP v2.2 and higher)
6.0 Grounding
Shield (drain) continuity must run from the reader to the access panel.
Shield (drain) and reader ground must be tied together at the access
panel and connect to an earth ground at one point.
7.0 Power
Reader may be powered by the access panel. A linear power supply is
recommended for best operation.
8.0 Voltage
5 to 16 VDC. 12 VDC at the reader is recommended for best operation.
Model Current Draw
P-300-OSDP 30 - 75 mA
P-403-OSDP 30 - 75 mA
P-405-OSDP 30 - 75 mA
P-410-OSDP 35 - 75 mA
P-453-OSDP 30 - 75 mA
P-455-OSDP 30 - 75 mA
P-500-OSDP 35 - 75 mA
P-530-OSDP 30 - 75 mA
P-620-OSDP 70 - 110 mA
P-640-OSDP 70 - 110 mA
P-710-OSDP 215 - 600 mA
P-900-OSDP 290 - 500 mA
QUICK START GUIDE
125-kHz PROXIMITY CARD READERS
WITH OSDP SUPPORT

10.0 Read Mode
Reader (OSDP “PD”) operation is controlled by the access panel
(OSDP “ACU”) per the OSDP specification.
11.0 Connection
Connection must be done in accordance with NFPA 70. Do not
connect to a receptacle controlled by a switch. Connect to a power
limited DC voltage source.
12.0 Troubleshooting
1. When the reader is first powered on it will beep 4-times.
2. Presenting a supported access credential will result in the
reader beeping once.
3. OSDP communications with the panel will be established after the
reader has completed its start-up sequence. The panel can query
the reader for status using OSDP commands. Note, at this point,
the access panel controls the reader beeper and LED functionality.
If the reader does not recognize the card or tag (no beep, no LED
flash), refer to possibe OSDP communications errors detected at the
access control panel. Please see the table below for additional
possible causes and solutions.
Possible Cause Corrective Action
OSDP misconfiguration,
not configured for OSDP,
secure channel mismatch
Confirm panel is configured for
OSDP. Confirm panel and reader are
both configured for Secure Channel
(or both unencrypted.) Confirm PD
address and speed.
Incorrect cabling Verify gauge, connections and
cabling length
Not enough power 12 VDC recommended, 5 VDC
at reader is minimum
Incorrect card used Verify if card technology
is supported
Reader/access panel not
properly grounded
Earth ground needed—verify shield
and reader ground are tied at access
panel and connect to ground at
one point
Supply generating
interference
Linear power supply recommended,
verify switching power supply
before use
Should any of the corrective actions mentioned above not improve
performance, disconnect the reader from the access panel and power
it with a separate power supply or 9VDC battery, and re-test card
functionality, with an OSDP panel simulator if necessary. By powering
the readers separately, most variables that may lead to reduced
performance can be eliminated. OSDP issues often require a packet
trace, which the installer or panel vendor should be prepared to
provide if there are problems. Should the problem persist, please
contact Farpointe directly.
Operating Temperature: –31° F to +150° F (–35° C to +66° C)
Operating Humidity: 0% to 90% Relative Humidity
IP Rating: IP67
Many Farpointe Data Readers carry the following certifications:
FCC Compliance Statement: This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution: Changes or modifications not expressly approved by Farpointe Data could
void the user's authority to operate the equipment.
Product can be used without license conditions or restrictions in all European Union
countries, including Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania,
Luxembourg, Malta, Netherlands, Poland, Portugal, Romania, Slovakia, Spain,
Sweden, United Kingdom, as well as other non-EU countries, including Iceland,
Norway, and Switzerland.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause unde-sired operation of the device.
Cet appareil est conforme à Industrie Canada exempts de licence standard RSS (s).
Le fonctionnement est soumis aux deux conditions suivantes : (1) ce dispositif ne
peut pas provoquer d’interférences et (2) ce dispositif doit accepter toute
interférence, y compris les interférences qui peuvent causer un mauvais
fonctionnement du dispositif.
Note: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
For proper PIN security with keypad readers, please review our
PIN Best Practices Reference Document.
QUICK START GUIDE
125-kHz PROXIMITY CARD READERS
WITH OSDP SUPPORT
