Farpointe Data Delta3 User manual

This Quick Start Guide is intended for experienced installing technicians. It is a basic reference to ensure all connections are properly made.
Models include Delta3, Delta5, Delta5.3, Delta6.2, Delta6.4, Delta403, Delta405, Delta410, as well as variants supporting most industry lead-
ing card and tag technologies. For additional information please reference Farpointe Data’s website www.farpointedata.com.
1.0 Introduction
A key component of a physical security electronic access control
system, a contactless smartcard card reader is based on RFID
technology. In operation it is capable of reading data stored on a
proximity credential via radio frequency and without physical contact,
and then passing the data obtained to the physical access control
system. Access control systems typically manage and record the
movement of individuals through a protected area, such as a
locked door.
2.0 Mounting Provisions
Each reader may be installed either indoors or outdoors.Mounting
options shown in the table below. Use supplied #6 mounting screws,
or equivalent security screws, for installation. Delta 400 Series
readers are supplied with #6 tamperproof screws.
Models
Mullion
Mount
Single-
Gang Wall
Mount*
Double-
Gang Wall
Mount*
European/
Asian Wall
Mount*
Delta3 •
Delta5 •
Delta5.3 •
Delta6.2 •
Delta6.4 •
Delta403 •
Delta405 •
Delta410 •
*Plastic or metal
3.0 Reader Wiring
Wiegand Magstripe
Conductor Function Conductor Function
Red DC (8-14 VDC) Red DC (8-14 VDC)
Black Ground Black Ground
Green Data 0 Green Clock
White Data 1 White Data
Brown Red LED aBrown Red LED
Orange Green LED bOrange Green LED
Yellow Card Present Yellow Card Present
Blue Beeper Blue Beeper
Violet Read Mode Violet Read Mode
Drain Shield Ground Drain Shield Ground
4.0 Cable Requirements
24 AWG minimum, multi-conductor stranded with an overall foil shield,
for example Belden 9535 or similar, supporting the five conductors
comprising the physical layer of the Wiegand interface (power, ground,
data 0, data 1, and/or beeper and LED). Alternatively, Belden 9539 or
similar, for all reader functions. Contact your access control system
manufacturer for their specific requirements. Per the SIA’s Wiegand
specification, maximum cable length is 500 feet (152 m).
5.0 Output Formats
• Wiegand (industry standard 26-bit Wiegand
and custom Wiegand formats)
• Magnetic Stripe (ABA Track II, clock and data,
with card present)
6.0 Grounding
Shield (drain) continuity must run from the reader to the access panel.
Shield (drain) and reader ground must be tied together at the access
panel and connect to an earth ground at one point.
7.0 Power
Reader may be powered by the access panel. A linear power supply is
recommended for best operation.
8.0 Voltage and Current
Voltage: 8 to 14 VDC
Current Draw: 135mA typical at 12 VDC
9.0 Read Mode
For sector (access control) reads, pull the purple conductor low.
10.0 Connection
Connection must be done in accordance with NFPA 70. Do not
connect to a receptacle controlled by a switch. Connect to a power
limited DC voltage source.
QUICK START GUIDE
13.56-MHz CONTACTLESS
SMARTCARD READERS
WIRING NOTES:
aSingle Line LED: This is the standard operating mode and does not make use of the
Orange conductor. The LED is Red when the reader is idle and flashes when a card is
presented. The LED turns Green when the Brown Conductor is pulled low by the access
control panel.
bDual Line LED: This mode makes use of both the Brown and Orange conductors. The
Brown conductor controls the Red LED and the Orange conductor controls the Green
LED. LED states are determined by the access control system option and capability.
Unused conductors should be trimmed, isolated and taped back to prevent unintended
current flows. Apply positive voltage only to the Red DC Conductor.

11.0 Troubleshooting
1. When the reader is first powered on it will beep 4-times,
and the LED will shine red.
2. Presenting a supported access credential will result in the
reader beeping and the LED flashing once.
NOTE: The access panel controls LED functionality,
such as switching the LED to green.
If the reader does not recognize the card or tag (no beep, no LED
flash) or exhibits short read range, please see the table below for
possible causes and solutions.
Possible Cause Corrective Action
Incorrect cabling Verify gauge, connections and
cabling length
Not enough power 12 VDC recommended, 8 VDC at
reader is minimum
Incorrect card used Verify if card technology
is supported
Reader/access panel not
properly grounded
Earth ground needed—verify shield
and reader ground are tied at access
panel and connect to ground at
one point
Supply generating interference Linear power supply recommended,
verify switching power supply
before use
Should any of the corrective actions mentioned above not improve
performance, disconnect the reader from the access panel and power
it with a separate power supply or 9VDC battery, and re-test card
functionality. By powering the readers separately, most variables that
may lead to reduced performance can be eliminated. Should the
problem persist, please contact Farpointe directly.
IP Rating: IP67
Many Farpointe Data Readers carry the following certifications:
FCC Compliance Statement: This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution: Changes or modifications not expressly approved by Farpointe Data could
void the user's authority to operate the equipment.
Product can be used without license conditions or restrictions in all European Union
countries, including Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania,
Luxembourg, Malta, Netherlands, Poland, Portugal, Romania, Slovakia, Spain,
Sweden, United Kingdom, as well as other non-EU countries, including Iceland,
Norway, and Switzerland.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause unde-sired operation of the device.
Cet appareil est conforme à Industrie Canada exempts de licence standard RSS (s).
Le fonctionnement est soumis aux deux conditions suivantes : (1) ce dispositif ne
peut pas provoquer d’interférences et (2) ce dispositif doit accepter toute
interférence, y compris les interférences qui peuvent causer un mauvais
fonctionnement du dispositif.
Note: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
For proper PIN security with keypad readers, please review our
PIN Best Practices Reference Document.
QUICK START GUIDE
13.56-MHz CONTACTLESS SMARTCARD READERS
© 2012-2021 Farpointe Data, Inc. All rights reserved. Farpointe Data®,
Pyramid Series Proximity®, Delta®, Ranger®, and CONEKT®are the registered
U.S. trademarks of Farpointe Data, Inc. All other trademarks are the property
of their respective owners.
www.farpointedata.com P/N: 01101-001 ∙ Rev. 1
Farpointe Data, Inc.
2195 Zanker Road
San Jose, CA 95131 USA
Office: [phone]
Fax: [phone]
[email protected]
Farpointe Data reserves the right to
change specifications without notice.
Mar-2-2021
