FARR 400UTV OWNER'S MANUAL

INTRODUCTION
Congratulations on your purchase of the 400UTV-EC. It represents the result of many years of
experience in the production of fine sporting, UTVs, and pacesetting racing machines. With the
purchase of this UTV, you can now appreciate the high degree of craftsmanshipand reliability.
This manual will provide you with a good basic understanding of the features and operation of
this UTV. This manual includes important safety information. It provides information about special
techniques and skills necessary to ride your UTV. It also includes basic maintenance and inspection
procedures. If you have any questions regarding the operation or maintenance of your UTV, please
consult the dealer.
AN IMPORTANT SAFETY MESSAGE
●READ THIS MANUAL TOGETHER WITH TIPS FOR THE UTV RIDER CAREFULLY AND COMPLETELY
BEFORE OPERATING YOUR UTV. MAKE SURE YOU UNDERSTAND ALL INSTRUCTIONS.
●PAY CLOSE A TTENTION TO THE WARNING AND CAUTION LABELS ON THE UTV.
●NEVER OPERATE A UTVWITHOUT PROPER TRAINING OR INSTRUCTION.
●THIS UTV, AND ANY OTHER UTV OVER 90cc, SHOULD NOT BE RIDDEN BY ANYONE UNDER 16 YEARS
OF AGE.

IMPORTANT MANUAL INFORMATION
FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SERIOUS
INJURY OR DEATH.
Particularly important information is distinguished in this manual by the following notations:
The SafetyAlert Symbol meansATTENTION!
YOUR SAFETY IS INVOLVED!
Failure to follow WARNING instructions could result in severe injury or
death to the machine operator, a bystander or a person inspecting or
repairing the machine.
A CAUTION indicates special precautions that must be taken to avoid
damage to themachine.
ANOTEprovides keyinformation to make procedures easier or clearer.
NOTE:

IMPORTANT NOTICE
Curve speed must be smaller than 30km/h.
This UTV hasbeen passed the EC certificate,itcan run on anypublic street, road, and highway.
Please check your local riding laws and regulations before operating thisUTV.
When the temperature is below -20℃(-4°F), please park the UTV in the place where the
temperature is higher than -20℃(-4°F). After the UTV has warmed up, the UTV can be started.
Please see page 6-3 on the warming up process.
When the temperature is higher than 38℃(100°F), and when you park the UTV after it run at high
speed, please keep engine running for 3 minutes at idle mode and make sure that the radiator fan
still work for 3 minutes to prevent cooling water from boiling. Then turn off the power switch to save
the battery.
Because in this UTV, its fuel tank setting position is lower than the carburetor, and it is supplied fuel
by negative pressure petrol pump, so for the consideration of safety, the factory will dispel all the
petrol in the carburetor, petrol pump and petrol pipe.When the customer has refueled the UTV and
start it for the first time,it will takelonger time to start the UTV. The starting requirement is as follows:
each starting time is 5 seconds, then stop by 15 seconds and restart, you need to start your UTV
5-10 times.

CONTENTS
1 LOCATION OF THE WARNING
2AND SPECIFICATION LABELS……1-1
2. SAFETY INFORMATION………………2-1
3. DESCRIPTIONAND VEHICLE
IDENTIFICATION………………………3-1
Identification Number Records…………3-3
Vehicle identification number and
Model label………………………………3-3
Verification sign of EC ……………………3-4
4.CONTROL UNCTIONS………………4-1
Ignition Switch……………………………4-1
Combination Switch……………………4-2
Turning light switch………………………4-3
Emergency light button…………………4-3
Horn button………………………………4-3
IndicatorandWarningLights……………4-4
Multi-Function Display Gauge…………4-7
Odometer and Trip Meter Modes………4-7
Clock Mode………………………………4-8
Fuel gauge………………………………4-8
On-Command Four-Wheel–Drive
And Differential Gear Lock Switches…4-9
Accelerator Pedal………………………4-13
Brake Pedal……………………………4-14
Parking brake pedal……………………4-14
Drive Select Lever……………………4-15
Fuel Tank Cap…………………………4-16
Starter……………………………………4-16
Seats……………………………………4-16
Seat belts………………………………4-18
Glove Compartment……………………4-20
Cargo Bed………………………………4-20
Opening and Closing the Tailgate……4-20
Lifting and Lowering the Cargo Bed…4-21
Front and Rear Shock Adjustment ……4-23
1

Trailer Hitch Bracket……………………4-25
Auxiliary DC Jack………………………4-25
5 PRE-OPERATION CHECKS…………5-1
Brakes……………………………………5-2
Front and Rear Brakes Brake Pedal…5-2
Brake Fluid Level………………………5-3
Brake Operation…………………………5-3
Fuel………………………………………5-4
Gasohol…………………………………5-5
Engine Oil………………………………5-6
Coolant……………………………………5-6
Final Gear Oil……………………………5-7
Differential Gear Oil……………………5-7
Throttle Pedal……………………………5-8
Throttle Free play………………………5-9
Throttle Free play Inspection……………5-9
Throttle Free play Adjustment…………5-9
Steering Wheel Inspection……………5-10
Seat Belts………………………………5-10
Fittings and Fasteners…………………5-10
Lights……………………………………5-10
Switches………………………………5-10
Tires……………………………………5-11
How To Measure Tire Pressure………5-13
Tire Wear Limit…………………………5-14
Tires for Public use……………………5-14
6．OPERATION………………………………6-1
Starting a coldengine……………………6-1
Starting a warm engine…………………6-3
Jump-starting……………………………6-3
Warming Up………………………………6-5
Drive Select Lever Operation And
Reverse Driving…………………………6-5
Parking……………………………………6-9
Parking On A Slope……………………6-10
Accessories and loading………………6-11
7DRIVING YOUR VEHICLE……………7-1
Getting To Know Your Vehicle…………7-1
Learning To Operate Your Vehicle……7-5
Turning Your Vehicle……………………7-6
Operating Improperly in Reverse………7-7
Braking……………………………………7-8
Going Uphill………………………………7-8

Going Downhill…………………………7-10
Crossing Through Shallow Water……7-11
Vehicle Immersion……………………7-13
Rear Axle Differential Lock …………7-14
Riding Over Rough Terrain……………7-15
Riding In Brush Or Wooded
Areas……………………………………7-16
Encountering Obstacles On The
Trail………………………………………7-17
8. PERIODIC MAINTENANCE AND
ADJUSTMENT…………………………8-1
Periodic Maintenance Chart For
The Emission Control System…………8-3
General MaintenanceAnd
LubricationChart…………………………8-4
Hood………………………………………8-6
To Open…………………………………8-6
To Close…………………………………8-6
Engine Oil And Oil Filter Cartridge……8-7
To Check Engine Oil Level……………8-7
To Change the Engine Oil (With orWith-out
Oil Filter Cartridge Replacement) ……8-8
Final Gear Oil
Checking the Final Gear Oil Level……8-11
Changing the Final Gear Oil…………8-12
Differential Gear Oil……………………8-13
Checking the Differential Gear Oil Level … 8-13
Changing the Differential Gear Oil … 8-14
Coolant…………………………………8-15
Checking the Coolant Level…………8-15
Changing the Coolant…………………8-16
Axle Boots………………………………8-17
Spark Plug Inspection…………………8-18
Removal…………………………………8-18
Inspection………………………………8-18
Installation………………………………8-19
Cleaning The engineAirFilter
Elements………………………………8-20
Cleaning The Spark Arrester…………8-24
Valve Clearance………………………8-25
Front Brake Pad Check………………8-26
Rear Brake Pad Check………………8-26
Checking The Brake Fluid Level……8-27
Brake Fluid Replacement……………8-28
Checking The Brake Pedal……………8-28

Brake Light Switch Adjustment………8-30
Cable Inspection And Lubrication……8-31
Brake PedalAndAccelerator
Pedal Lubrication………………………8-32
Rear KnuckleUpperAnd Lower
Pivot Lubrication………………………8-32
Steering Shaft Lubrication……………8-33
Wheel Removal………………………8-34
Wheel Installation………………………8-34
Battery…………………………………8-35
Battery Maintenance…………………8-37
Fuse Replacement……………………8-37
ReplacingAHeadlightBulb……………8-40
Tail/BrakeLightBulb
Replacement……………………………8-42
Check and solution to Common
Problems in Vehicle……………………8-44
CLEANING AND STORAGE…………9-1
A. Cleaning……………………………9-1
B. Storage………………………………9-3
SPECIFICATIONS……………………10-1
9
10

1-1
LOCATION OF THE WARNING AND SPECIFICATION LABELS

1-2
Read and understand all of the labels on your vehicle. They contain important information for
safe and proper operation of your vehicle.
Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a
replacement label is available from your dealer.
①

1-3
②
③
④
⑤

1-4
⑥
⑦
⑧

1-5
⑨
⑩

2-1
This utility vehicle handles differently from other vehicles including cars and UTVs.
SEVERE INJURY OR DEATH can result if you do not follow these instructions:
●Read this manual and all labels carefullyand follow the operating procedures described.
●This vehicle is designed to carry the driver and three passengers.
NEVER CARRYPASSENGERS IN THE CARGO BED.
●Always be sure the driver and passengers are wearing seat belts.
●Never give a ride to a passenger who is too small to reach and hold the handgrip fixed before
the seat.
●Always avoid operating the vehicle on any paved surfaces, including sidewalks, driveways,
parkinglots, and streets.
●Never operate this vehicle on any public street, road, or highway, even a dirt or gravel one.
●Never operate this vehicle without wearing an approve motorcycle helmet that fits properly. You
should also wear eye protection (goggle or a face shield), gloves, over-the-ankle boots,
long-sleeved shirt or jacket, and long pants.
●Never consume alcohol or drugs before or while operating this vehicle.
●Never operate at speeds too fast for your skills or the conditions. Always go at a speed that is
proper for the terrain, visibility, operating conditions, and your experience.
●Never attemptjumps of other stunts.
●Always inspect your vehicle each time you use it to be sure it is in safe operating condition,
SAFETY INFORMATION

2-2
Always follow the inspection and maintenance procedures and schedules described in this
manual.
●Always keep both hands, arms, feet, and legs inside the vehicle at all times during operation.
Keep your feet on the floorboard. Never hold onto the enclosure. Otherwise, your hands could
be injured if itis caught between the enclosure and anobstacle outside the vehicle.
●Always keepboth hands on the steering wheel when driving.
●Never wrap your thumbs and fingers around the steering wheel. This is particularly important
when driving in rough terrain. The front wheels will move right and left as they respond to the
terrain, and this movement will be felt in the steering wheel. A sudden jolt could wrench the
steering wheel around, and your thumbs or fingers could be injured if they are in the way of the
steering wheel spokes.
●Always go slowly and be extra careful when operating on unfamiliar terrain. Always be alert to
changing terrain conditions when driving the vehicle.
●Never operate on excessively rough, slippery, or loose terrain until you have learned and
practiced the skills necessary to control the vehicle on such terrain. Always be especially
cautious on these kinds of terrain.
●Never turn at excessive speed. Practice turning at slow speeds before attempting to turn at
faster speeds. Do not attempt turns on steep inclines.
●Never operate the vehicle on hills that are too steep for itor for your abilities. Go straight up and
down hills where possible.Maximum slope angle: 15°.
●Never operate on hills that are slippery or ones where you will not be able to see far enough
ahead of you. Never go over the top of a hill at speed if you cannot see what is on other side.

2-3
●Always follow properprocedures for going uphill. If you lose control and cannotcontinue up a hill,
back down the hill with the engine in reverse gear. Use engine braking to help you go slowly. If
necessary, use the brakes gradually to help you go slowly.
●Always check terrain before going down hills. Go as slowly as possible. Never go down a hill at
high speed.
●Always check for obstacles before operating in a new area.
●Never operate the vehicle in fast flowing water or water deeper than the floorboards on this
model. Remember that wet brakes may have reduced stopping ability. Test your brakes after
leaving water. If necessary, apply the brake several times to letfriction dry out the linings.
●Always be sure there are no obstacles or people behind you when you operate in reverse.
When it is safe to proceed in reverse, go slowly.
●Do not brake abruptly when carrying loads in the cargo bed.
●Always use the size and type of tires specified in this manual.
●Always maintain proper tire pressure as described in this manual.
●Never exceed the stated load capacity. Cargo should be as far forward in the bed as possible,
and distributed evenly from side to side. Be sure cargo is secured so that it cannot move around
during operation. Reduce speed and follow instructions in this manual for carrying cargo or
pulling a trailer.Allow greater distance for braking.

2-4
WARNING
POTENTIAL HAZARD
Improper handling of gasoline.
WHAT CAN HAPPEN
Gasoline can catch fire and you could be burned.
HOW TOAVOID THE HAZARD
Always turn off the engine when refueling. Do not refuel right after the engine has been
running and is still veryhot. Donot spill gasoline on the engineor exhaustpipe（ormuffler）
when refueling. Never refuel while smoking, or while in the vicinity of sparks, open flames,
or other sources of ignition such as the pilot lightof water heaters and clothes dryers.
When transporting the vehicle in another vehicle, be sure it is kept in an upright
position. Otherwise, fuel mayleak out of the carburetor or fuel tank.
WHAT CAN HAPPEN
Gasoline is poisonous and can cause injuries.
HOW TOAVOID THE HAZARD
If you should swallow some gasoline or inhale a lot of gasoline vapor, or get some gasoline
in your eyes, see your doctor immediately. If gasoline spills on your skin, wash with soap
and water. If gasoline spills on your clothing, change your clothes.

2-5
WARNING
POTENTIAL HAZARD
Starting or running the engine in a closed area.
WHAT CAN HAPPEN
Exhaust fumes are poisonous and may cause loss of consciousness and death within a
short time.
HOW TOAVOID THE HAZARD
Always operate your vehicle in an area with adequate ventilation.

3-1
DESCRIPTION AND VEHICLE IDENTIFICATION
1. Headlights
2. Frontshockabsorberassembly
3. Brakefluid reservoir
4. Rear mirror
5. IgnitionSwitchAssembled
6. Driverseat
7. Battery
8. Fuses
9. Left body protection plate
10. Driverseat belt
11. Airfilterelement
12. Cargobed
13. Tail/brakelights
14. Turning-light,Rear
15. Sparkarrester
16. Rear shock absorber assembly
17. CVT-beltcase
18. Fuel tank cap
19. Passenger seat belt
20. Rightbodyprotection plate
21. Sparkplug
22. Oilfiltercartridge
23. Radiator cap
24. Coolantreservoir
25. Turning-light, Front
