Federal LPRSS Series Installation instructions

E2915-3 Rev. A 09/01/2018
Installation & Operation Instructions
Refrigerated LPRSS & ELPRSS Models
Federal Industries
215 Federal AVE
Belleville, WI 53508
Toll Free: [phone]
WI Phone: [phone]
Fax: [phone]

Page 2 of 40
Contents
(1) Introduction ..................................................................................................................................... 4
1.1 Serial Number............................................................................................................................... 4
(2) Warning Labels & Safety Instructions.............................................................................................. 5
(3) Pre-Installation Procedures ............................................................................................................. 6
3.1 Inspection for Shipping Damage .................................................................................................. 6
(4) General Electrical & Grounding ....................................................................................................... 7
4.1 Cord Connected............................................................................................................................ 7
4.2 Permanent Connected (Option)................................................................................................... 7
(5) Installation Instructions ................................................................................................................... 8
5.1 Locating the Display Case............................................................................................................. 8
5.2 Removing Case From Shipping Skid and General Installation ..................................................... 8
5.3 Cleaning........................................................................................................................................ 8
5.4 Center Panel Joining (Option) ...................................................................................................... 8
5.5 Refrigeration System.................................................................................................................. 10
5.5.1 Self Contained Models............................................................................................................ 10
5.5.2 Remote Models ...................................................................................................................... 10
5.6 Evaporator Condensate Drain Tube........................................................................................... 10
5.7 Condensate Pump ...................................................................................................................... 11
(6) Shelving Installation & Removal .................................................................................................... 13
6.1 Metal Shelves ............................................................................................................................. 13
6.2 Glass Shelves .............................................................................................................................. 14
6.3 Optional Shelf Lights (ELPRSS).................................................................................................... 15
(7) Plastic End Removal & Installation ................................................................................................ 16
(8) Rear Doors (Options) ..................................................................................................................... 17
(9) Night Curtain.................................................................................................................................. 18
(10) Security Night Curtain (Option) ..................................................................................................... 19
(11) Operating Instructions................................................................................................................... 20
11.1 User Controls Overview ............................................................................................................. 20
11.2 Using the electronic control....................................................................................................... 21
11.2.1 Button and Display Overview ................................................................................................. 21
11.2.2 Powering on control ............................................................................................................... 21
11.2.3 Adjusting the set point ........................................................................................................... 22
11.2.4 Entering manual defrost mode............................................................................................... 22
11.2.5 Error codes.............................................................................................................................. 22
11.3 Initial Startup.............................................................................................................................. 23
11.4 Placing Product in Case .............................................................................................................. 24
(12) Maintenance.................................................................................................................................. 26
12.1 Light Replacement...................................................................................................................... 26
(13) Periodic Maintenance.................................................................................................................... 27
13.1 Cleaning Condenser Coil............................................................................................................. 27

Page 3 of 40
(14) Cleaning Instructions ..................................................................................................................... 28
14.1 Daily Cleaning............................................................................................................................. 28
14.2 Weekly Cleaning......................................................................................................................... 28
(15) Sale & Disposal............................................................................................................................... 31
15.1 Owner Responsibility ................................................................................................................. 31
(16) Service Information........................................................................................................................ 32
16.1 Pre-Service checklist................................................................................................................... 32
16.1.1 Case does not operate............................................................................................................ 32
16.1.2 Lights do not operate ............................................................................................................. 32
16.1.3 Case temperature too warm (product is exceeding 41°F) ..................................................... 32
16.2 Special Service Instructions........................................................................................................ 33
16.3 Refrigeration & Electrical Data................................................................................................... 33
16.4 Electronic Control Operation ..................................................................................................... 33
16.4.1 Operation................................................................................................................................ 33
16.4.2 Defrost Cycle........................................................................................................................... 34
16.5 Control Parameters.................................................................................................................... 34
16.6 Error Codes................................................................................................................................. 34
16.7 Refrigeration Operation............................................................................................................. 35
16.7.1 Self Contained Models............................................................................................................ 35
16.7.2 Remote Models ...................................................................................................................... 35
(17) Wiring Diagrams............................................................................................................................. 37
17.1 Self Contained ............................................................................................................................ 37
17.2 Remote....................................................................................................................................... 37
(18) Replacement Parts......................................................................................................................... 38
Tables
Table 1- Shelf Loading Limits .................................................................................................................... 24
Table 2 - Electrical Ratings ........................................................................................................................ 33
Table 3 - Control Parameters.................................................................................................................... 34
Table 4 - Error Codes and Resolutions...................................................................................................... 34
Table 5 - Temperature Probe Common Resistance Chart........................................................................ 35

Page 4 of 40
(1) INTRODUCTION
Thank you for purchasing a Federal Industries display case. This manual contains important instructions for
installing and servicing the LPRSS refrigerated self-service merchandisers. A repair parts list and wiring diagram
are also included in the manual. Read all of these documents carefully before installing or servicing your case.
NOTICE
Read this manual before installing your case. Keep this manual and refer to it
before doing any service on the equipment. Failure to do so could result in
personal injury or damage to the case.
NOTICE
Installation and service of the electrical components in the case must be
performed by a licensed electrician.
The portions of this manual covering components contain technical instructions
intended only for persons qualified to perform electrical work.
DANGER
Improper or faulty hookup of electrical components in the case can result in
severe injury or death.
All electrical wiring hookups must be done in accordance with all applicable local,
regional, or national standards.
1.1 SERIAL NUMBER
Record the model and serial numbers of the case for easy reference. Always refer to both model and serial
numbers in your correspondence with Federal regarding the case.
Case Model__________________________ Serial Number______________________
Condensing Unit Model________________ Serial Number______________________
This manual cannot cover every installation, use, or service situation. If you need additional information, call
or write us:
WARRANTY/TECHNICAL SERVICE DEPARTMENT
Federal Industries
215 Federal AVE
Belleville, WI 53508
Toll Free [phone] / WI Phone [phone]

Page 5 of 40
(2) WARNING LABELS & SAFETY INSTRUCTIONS
This is the safety-alert symbol. When you see this symbol on your case or in the
manual, be alert to the potential for personal injury or damage to your
equipment.
Be sure you understand all safety messages and always follow recommended precautions and safe operating
procedures.
NOTICE TO EMPLOYERS:
You must make sure that everyone who installs, uses, or services your case is
thoroughly familiar with all safety information and procedures.
Important safety information is presented in this section and throughout the manual. The following signal
words are used in the warning and safety messages:
DANGER:
Severe injury or death will occur if you ignore the message.
WARNING:
Severe injury or death can occur if you ignore the message.
CAUTION:
Minor injury or damage to your case can occur if you ignore the message.
NOTICE:
This is important installation, operation, or service information. If you ignore the
message, you may damage your case.
The warning and safety labels shown throughout this manual are placed on your Federal Industries case at the
factory. Follow all warning label instructions. If any warning or safety labels become lost or damaged, call our
customer service department at [phone] for replacements.
This label is located on the back of the display
case
This label is located below the display pan.

Page 6 of 40
(3) PRE-INSTALLATION PROCEDURES
3.1 INSPECTION FOR SHIPPING DAMAGE
You are responsible for filing all freight claims with the delivering truck line. Inspect all cartons and crates for
damage as soon as they arrive. If damage is noted to shipping crates, cartons, or if a shortage is found, note
this on the bill of lading (all copies) prior to signing.
If damage is discovered when the case is uncrated, immediately call the delivering truck line and follow up the
call with a written report indicating concealed damage to your shipment. Ask for an immediate inspection of
your concealed damage item. Crating material must be retained to show the inspector from the truck line.

Page 7 of 40
(4) GENERAL ELECTRICAL & GROUNDING
DANGER:
Improper or faulty hookup of electrical components in the display case can result
in severe injury or death.
4.1 CORD CONNECTED
All standard models are supplied with a power cord that is properly sized to the amperage
requirements of the case. See the electrical data plate located on the rear left interior of the case for
the proper circuit size for each case.
The cord is factory installed protruding from the bottom rear corner of the case.
A separate circuit for each display case is required to prevent other appliances on the same circuit from
overloading the circuit and causing malfunction.
4.2 PERMANENT CONNECTED (OPTION)
Only a licensed electrician must perform all case electrical connections.
All electrical wiring hookups must be done in accordance with all applicable local, regional, or national
electrical standards.
A separate circuit for each display case is required to prevent other appliances on the same circuit from
overloading the circuit and causing malfunction.
The electrical service must be grounded upon installation.
See the electrical data plate located at the rear of the case for proper circuit size and wire ampacity.
The electrical connection box is accessible from the rear of the case with rear grill removed.
FIELD CONNECTION BOX
POWER CORDOR
CONDUIT CONNECTION
HOLE (7/8"O)
REAR BASE
PANEL
(6) REAR BASE
PANEL SCREWS

Page 8 of 40
(5) INSTALLATION INSTRUCTIONS
5.1 LOCATING THE DISPLAY CASE
The case should be located where it is not subjected to the direct rays of the sun, heating ducts, grills,
radiator, or ceiling fans, nor should it be located near open doors or main door entrances. Also, avoid
locations where there are excessive air movement or air disturbances.
The case requires a minimum of 6 inches of clearance at the rear of the unit for air discharge. Do not locate
case with back tight against the wall. The louvers located on front of base must remain clear for air intake. If
rear clearance or front clearance is not possible see a Federal representative for air intake and discharge kit
options.
No clearance is needed on sides of the unit.
5.2 REMOVING CASE FROM SHIPPING SKID AND GENERAL INSTALLATION
CAUTION:
Do not push or pull against the top panel, plastic end, end glass, or door frames when
removing the case from the skid or moving the case. Case damage or glass breakage could
result.
1. Remove crate top and sides and note missing or damaged items as explained in the pre-installation
procedures outlined above.
2. Move the case as near as possible to the final location and before removing it from the shipping skid.
3. Remove the (4) brackets that secure the case to the shipping skid.
4. Prepare cabinet according to instructions in this section that pertain to your model.
5. Lift the case off of skid and into required position. Only lift the case from under the rear lip and front
bottom trim channel above the base. Note: Do not push or pull on front bottom trim channel or lift
using the plastic end panel.
6. The case must be level for proper drainage of defrost condensate to the condensate evaporator. Using
the wrench provided level and square the case as needed by adjusting the leg leveler in each corner of
base. The 6ft cases also have a set of leg levelers in the center. These must be adjusted so the base is
flat.
7. The leveled case must be sealed to the floor using a NSF listed sealant.
5.3 CLEANING
For initial setup, clean the case as outlined in the “Weekly Cleaning” section of this manual.
5.4 CENTER PANEL JOINING (OPTION)
If your cases where ordered with the Center Panel Joining Option you will need to perform the following
installation procedures.

Page 9 of 40
FRONT JOINING
BRACKET
REAR JOINING TRIM
CENTER PANEL
BASE MOUNTING
HOLES (4)
RIGHT CASE
LEFT CASE
LEFT CASE REAR
BASE PANEL
LEFT CASE FRONT
BASE PANEL
TOP JOINING
BRACKET
INTERIOR JOINING FLANGE
1. Place the right case into desired location and level case by adjusting leg levelers with provided
wrench.
2. Remove the front base panel (4) screws and rear base panels (6) screws from the left case. Push
the left case end tightly against the right case end. The rear joining trim on the right case must be
behind the back panel of the left case and the front joining bracket on the right case must be inside
the front aluminum trim channel of the left case.
3. Adjust the leg levelers on the left case so it is level and exactly aligned with the right case. The (4)
base mounting hole in the right case panel must align with the (4) mounting holes located in base
compartment of left case.
4. Push the cases together as tightly as possible and the gap between the cases must be tight and
even. If the gap is larger at the top or the bottom adjust leg levelers accordingly. HOLD CASES
TOGETHER AS TIGHT AS POSSIBLE WHILE ATTACHING ALL JOINING BRACKETS AND DO NOT OVER
TIGHTEN SCREWS OR SCREWS WILL STRIP OUT.
5. Attach the bottom of the left case to the right case center panel base mounting holes through the
holes located inside of the left case base. Use the (4) large 10-12x1/2 screws provided.
6. Attach the rear top of left case through the holes in the rear joining bracket using the (3) black
#10-12x1/2 self drilling screws provided.
7. Attach the front of left case through the holes in the front joining bracket using the (2) smaller
#8-12x1/2 self drilling screws provided.
8. Attach the top of left case through the holes in the top joining bracket using the (2) smaller
#8-12x1/2 self drilling screws provided.
9. Attach the interior of left case through the holes in the interior joining flange using the (3) smaller
#8-12x1/2 self drilling screws provided
10. If any there are any gaps along the joining seam fill them with NSF black silicone.
11. Reinstall front and rear grills.

Page 10 of 40
5.5 REFRIGERATION SYSTEM
5.5.1 Self Contained Models
The self-contained models are shipped from the factory with a completely operational 404A
refrigeration system and require no modifications or adjustments upon installation. Case must be
installed as per the installation section of this manual to provide proper condensing air cooling.
5.5.2 Remote Models
The remote models are designed to use 404A refrigerant and shipped from the factory with the
evaporator coil, expansion valve, sight glass, service valves and refrigerant solenoid valve. Installation
must be performed by a licensed Refrigeration Technician. See the Service section of this manual for
installation requirements.
5.6 EVAPORATOR CONDENSATE DRAIN TUBE
WARNING TO INSTALLER:
Evaporator Condensate Drain Tube may become dislodged during shipping. Installer must
check Evaporator Condensate Drain Tube upon installation to be sure drain tube is properly
seated and installed correctly.
Evaporator Drain Tube must be attached to tube protruding from bottom of Evaporator Tub and must either
be inside the Condensate Pan area or inside of hole of Condensate Pump.

Page 11 of 40
5.7 CONDENSATE PUMP
A condensate pump is Standard on some models and Optional on all models. Installer must check unit to see if
a condensate pump has been provided with case.
WARNING TO INSTALLER:
Installer must determine if case was provided with condensate pump. Failure to hook up
pump hose to drain will cause water on floor and cause a slip hazard.

Page 12 of 40
Instead of using heat energy to remove condensate run off from the evaporator coil a condensate pump
moves the water to a nearby drain.
•The Condensate Pump is provided with 50ft of clear 1/2in OD x 3/8in ID tubing that must be run out of
the base area to a drain.
•There are several drain tube exit locations provided in the base as noted in the drawing above. Plugs or
caps will need to be removed in the desired exit location.
•The hose can be run the entire 50ft in any direction as required, but no higher than 20ft from the
pump base. A check valve is provided in the pump to prevent water from flowing back into the
reservoir. For best efficiency extend the hose level below the level of the pump base to create a
siphoning effect. Never run the hose to or through an area below freezing (32°F, 0°C) or freezing water
will block the tube.

Page 13 of 40
(6) SHELVING INSTALLATION & REMOVAL
6.1 METAL SHELVES
SHORTER TOP SHELF
WIDER BOTTOM SHELF
SHORTER TOP SHELF BRACKET
LONGER BOTTOM SHELF BRACKET
SHELF NOTCH
SHELF BRACKET FRONT TAB
1. Follow the instructions in the illustration below and insert (1) of the shelf brackets in the desired shelf
standard slot on one side of the case. Place the additional bracket in the same shelf standard slot on the
opposite end of case. If the case was supplied with shelf light option (ELPRSS), the bracket with a clear
plastic cord retainer clip must be on the side with the shelf light. For LPRSS case with (2) shelves repeat
for shorter top shelf brackets.
0vNOTCH
6vNOTCH
4
1
2
3
4
INSTALLATION REMOVAL
23
1
TOP HOOK
BOTTOM TAB
SHELF BRACKET
SHELF STANDARD
1. Place shelf bracket top hook into desired shelf
standard slot.
2. Lift shelf bracket top hook to allow shelf bracket
bottom tab to clear shelf standard slot.
3. Swing shelf bracketbottom tab into shelf standard
slot.
4. Place the desired shelf bracket notch of 0, 6, or 12
degrees onto bottom of shelf standard slot.
1. Lift shelf bracket up to allow shelf bracket notch
to clear the bottom of shelf standard slot.
2. Swing shelf bracket bottom tab out of shelf
standard slot.
3. Drop shelf bracket down to allow shelf bracket top
hook to clear top of shelf standard slot.
4. remove shelf bracket top from shelf standard slot.
CLEAR BUMPER
TOWARDS END PANEL
2. Place the longer bottom shelf on top of the longer bottom shelf brackets with the flanges on each end of
the shelf overhanging the outside of the bracket. Place the front tab of the shelf bracket into the notch
located on the front of the shelf.

Page 14 of 40
3. On the LPRSS case with (2) shelves place the shorter top shelf on top of the shorter top shelf brackets
with the flanges on each end of the shelf overhanging the outside of the bracket. Place the front tab of
the shelf bracket into the notch located on the front of the shelf.
4. If shelf includes optional light (ELPRSS), plug the cords into the plug receptacle located toward rear of
case.
6.2 GLASS SHELVES
SHORTER GLASS TOP SHELF
LONGER GLASS BOTTOM SHELF
SHORTER TOP SHELF BRACKETS
LONGER BOTTOM SHELF BRACKETS
SHELF BRACKET FRONT TAB
SHELF SUPPORT
SHELF SUPPORT
SHELF SUPPORT, LONG CORD WHEN SUPPLIED
WITH SHELF LIGHT OPTION.
CORD RETAINER CLIP ON THIS SIDE
WHEN ORDERED WITH SHELF LIGHT OPTION
GLASS SHELF RETAINER CLIPS.
MUST INSTALL TO GLASS
GLASS SHELF RETAINER
CLIP LOCATED IN FAR
CORNER OF GLASS SHELF.
(FIELD INSTALLED TO GLASS
BOTTOM)
TOP VIEW
CLEAR PRODUCT STOP
CLEAR PRODUCT STOP
CLEAR PRODUCT STOP
(FIELD INSTALLED TO
GLASS FRONT LIP)
GLASS SHELF RETAINER CLIP
1. When installing for the first time, attach (2) glass shelf retainers to each glass shelf. Remove the backing
from the tape located on the flat side of the glass shelf retainer. Position the glass shelf retainer in the (2)
far corners of the glass as shown in the above figure. Repeat for each glass shelf.
NOTE: Clean the area of glass where the glass shelf holder is to be located with isopropyl alcohol and let
it air dry before installing the glass shelf holder.
2. When installing for the first time attach (1) clear glass product stop to each glass shelf as shown in the
figure above. Align the clear product stop edge with the edge of the glass and push the “U” portion of the
glass product stop onto the glass lip across the entire front of the glass. Repeat for each glass shelf.
3. Install the shelf brackets into the shelf standard as described in Step (1) of “Metal Shelves Installation” of
this manual.

Page 15 of 40
4. Place the front of the glass shelf onto the front shelf support.
5. Set the rear side of the glass shelf onto the rear shelf support so that the glass shelf retainers straddle the
rear shelf support.
6. Repeat steps 2 & 3 for each tier.
6.3 OPTIONAL SHELF LIGHTS - ELPRSS
1. Install shelves as described in the Metal Shelves Installation and Glass Shelves Installation sections in this
manual. Note: On models with glass shelves with lights, a shelf support will be placed on the back and
front of the shelf bracket.
2. Remove the cap from the appropriate female light sockets.
3. Plug in each shelf light by plugging the male plug on the appropriate shelf light cord plugs with the female
light sockets and push together.
Shelves and shelf light quantity
It is not required that all shelves and shelf lights supplied with each case are used. The quantity of shelves and
shelf lights can be tailored to your specific needs. If the supplied quantity of shelves and shelf lights are not
required, cap unused female socket located in interior of the case mullion with caps supplied.

Page 16 of 40
(7) PLASTIC END REMOVAL & INSTALLATION
(2) VELCRO STYLE
PADS ON CASE
PLASTIC END PANEL
(4) SCREWS WITH
SPACERS ON CASE
(4) KEY SLOTS IN
BACK OF PANEL
(2) VELCRO STYLE PADS
ON BACK OF PANEL
Right and Left plastic end panels are ordinarily shipped installed from the factory but can be easily removed
for cleaning. Removing end panels make it easier to grab on to case when moving or installing case and can
easily be reinstalled.
REMOVAL:
1. Lift the back side of the panel out to disengage (2) Velcro style pads
2. Slide the panel forward to disengage the (4) Key slots in panel from (4) screws in case.
INSTALLATION:
1. Hold panel tightly against the side of the case with the front lip of panel tight against front of case.
2. Slide panel forward about ½ until screws fall into key slots. Slide the panel towards the back of case
making sure all (4) key slots engage.
3. Push in on end panel in location of the (2) Velcro style pads to lock panel in place.

Page 17 of 40
(8) REAR DOORS (OPTIONS)
1. LIFT UP
2. SWING BOTTOM OUT
LOWER TRACK
UPPER TRACK
1. Start with the outer door and lift the door upward until the bottom edge of door clears the lower track
and then swing the bottom of the door outward and down out of upper track.
2. After the outer door is removed repeat the procedure for the inner door.
3. Reverse this procedure for door reinstallation. The doors are not interchangeable.

Page 18 of 40
(9) NIGHT CURTAIN
NIGHT CURTAIN
STRAP WITH SNAP
SNAP
NIGHT CURTAIN
HOLDER BRACKETS
FRONT TRIM
OPENING:
1. Grab night curtain strap and lift the rolled night curtain out of the night curtain holder brackets. Pull
the night curtain across the top of case and down the front.
2. Attach the snap located under the night curtain strap on to the snap located on the front trim.
CLOSING:
1. Grab the night curtain strap and detach the snap from the snap located in the front top trim.
2. While holding the night curtain strap allow the night curtain to roll up and place the rolled night curtain
carefully into the night curtain holder brackets.
Note: The 5’ and 6’ models have (2) night curtains.

Page 19 of 40
(10) SECURITY NIGHT CURTAIN (OPTION)
SECURITY NIGHT COVER
LOCK HANDLE
SECURITY NIGHT COVER
FRONT HANDLE
SECURITY NIGHT
COVER LOCK
HANDLE CATCH
FRONT TRIM
BOTTOM FLANGE
TOP FLANGE
TOP PANEL
REMOVAL:
1. Unlock the lock handle and turn handle to disengage from lock handle catch.
2. Grab the lock handle and the front handle and lift the cover straight up out of the case opening.
INSTALLATION:
1. Turn the lock handle so the latch is horizontal to the top of the case.
2. Holding the lock handle and the front handle place the bottom flange of the security night cover inside
of case opening. The bottom flange of the security night cover must be tight against the flat inner side
of the front trim.
3. Set the top flange of the security cover down against the top panel.
4. Turn the lock handle so it engages the lock handle catch and use key to lock it in place.
Note: The 6’ models have (2) security covers.
IMPORTANT: Cleaning the Acrylic plastic security night cover require special care to prevent hazing of
material. Lightly dust (not wipe) the surface with clean soft cloth. Then the surface can be wiped carefully with
a soft, wet cloth or chamois. The cloth or chamois must be kept free of grit by frequently rinsing in clean
water. Grease and oil can be removed with kerosene. Do not use window cleaners or kitchen scouring
compounds. DO NOT use solvents such as Acetone, Benzene, Carbon Tetrachloride, and Lacquer Thinners. A
spray wax such as Pledge or Maguire’s polish can be applied and wiped with a clean soft cloth. The wax tends
to fill in and hide small scratches.

Page 20 of 40
(11) OPERATING INSTRUCTIONS
11.1 USER CONTROLS OVERVIEW
POWER
SWITCH
TEMPERATURE
CONTROL
LIGHT
SWITCH
Power Switch
The unit has a power switch that turns off power to the entire unit, including the condensate evaporator and
the lights. This switch is located behind a lift up panel on the unit base.
Light Switch
The unit has a light switch that turns on and off the interior lights of unit. The switch is located inside the
display case on the left upright frame member near the top.
Temperature Control
Located in the front grille of the display case, the temperature control allows the user to adjust the
temperature of the display merchandiser to their needs.
