Feig Electronic ID MAX.U500i Series User manual

IDENTIFICATION
M81211-2e-ID-B
INSTALLATION
ID MAX.U500i
(EU: 5118.001.00; FCC: 5118.001.10)

IDENTIFICATION
ID MAX.U500i
Note
Page 2 of 36
Note
Note
© Copyright by
FEIG ELECTRONIC GmbH
Lange Strasse 4
D-35781 Weilburg (Germany)
Tel.: [phone]
http://www.feig.de
identification-[email protected]
With the edition of this document, all previous editions become void. Indications made in this manual may be
changed without previous notice.
Copying of this document and giving it to others and the use or communication of the contents thereof are
forbidden without express authority. Offenders are liable to the payment of damages. All rights are reserved
in the event of the grant of a patent or the registration of a utility model or design.
Composition of the information in this document has been done to the best of our knowledge.
FEIG ELECTRONIC GmbH does not guarantee the correctness and completeness of the details given in this
manual and may not be held liable for damages ensuing from incorrect or incomplete information. Since,
despite all our efforts, errors may not be completely avoided, we are always grateful for your useful tips.
The instructions given in this manual are based on advantageous boundary conditions.
FEIG ELECTRONIC GmbH does not give any guarantee promise for perfect function in cross environments
and does not give any guarantee for the functionality of the complete system which incorporates the subject
of this document.
FEIG ELECTRONIC GmbH calls explicit attention that devices which are subject of this document are not
designed with components and testing methods for a level of reliability suitable for use in or in connection
with surgical implants or as critical components in any life support systems whose failure to perform can
reasonably be expected to cause significant injury to human health. To avoid damage, injury or death the
user or application designer must take reasonably prudent steps to protect against system failures.
FEIG ELECTRONIC GmbH assumes no responsibility for the use of any information contained in this
document and makes no representation that they are free of patent infringement. FEIG ELECTRONIC GmbH
does not convey any license under its patent rights nor the rights of others.

IDENTIFICATION
ID MAX.U500i
Contents
Page 3 of 36
Contents
Contents
1Safety Instructions 5
2Performance Features of ID MAX.U500i 6
2.1 Performance Features....................................................................................................... 6
2.2 myAXXESS Manager ......................................................................................................... 6
2.3 Available Reader Types .................................................................................................... 6
3Scope of Delivery 7
4Installation 8
5Terminals 12
5.1 Antenna Connection........................................................................................................ 13
5.2 Power Supply................................................................................................................... 14
5.2.1 Power Supply via Connector X2........................................................................... 14
5.2.2 Power Supply via PoE (Power over Ethernet) ...................................................... 15
5.3 Ethernet Interface on Connector X1............................................................................... 16
5.4 Digital Outputs on Connector X4.................................................................................... 17
5.5 Relay Outputs on Connector X4..................................................................................... 18
5.6 Digital Inputs on Connector X5 ...................................................................................... 19
5.7 USB Mini Interface on Connector X6.............................................................................. 21
5.7.1 USB Flash Drive Service Functions...................................................................... 21
5.7.2 Reading of Log and Service Data......................................................................... 21
5.7.3 Storing the Reader Configuration on a USB Flash Drive ...................................... 22
5.7.4 Copying the Configuration onto a Reader (Config-Cloning) .................................. 23
6Operating and Display Elements 24
6.1 Status LEDs ..................................................................................................................... 24
6.2 Push Button T1 ................................................................................................................ 24
6.2.1 Teach-In Mode ..................................................................................................... 24
6.2.2 Configuration Reset.............................................................................................. 25

IDENTIFICATION
ID MAX.U500i
Contents
Page 4 of 36
6.3 Buzzer .............................................................................................................................. 25
6.4 Reader Power Adjustment .............................................................................................. 25
7Positioning of the Antenna 26
8Mounting of the Transponder 28
9Technical Data 29
10 Radio Approvals 31
10.1 Europe (CE)...................................................................................................................... 31
10.2 USA (FCC) and Canada (IC) ............................................................................................ 32
10.2.1 USA (FCC) and Canada (IC) Warning Notices ................................................. 32
10.2.2 Installation with FCC/IC Approval ..................................................................... 32
10.2.3 Label Information.............................................................................................. 33
10.2.4 Antennas Approved in the USA (FCC) and Canada (IC)................................... 33
Annex A: Accessories ........................................................................................................... 34
List of Tables 35
List of Figures 36

IDENTIFICATION
ID MAX.U500i
1Safety Instructions
Page 5 of 36
1 Safety Instructions
Safety Instructions
►The device may only be used for the intended purpose designed by the manufacturer.
►The manual should be conveniently kept available at all times for each user.
►Unauthorized changes and the use of spare parts and additional devices which have not been sold or
recommended by the manufacturer may cause fire, electric shocks or injuries. Such unauthorized
measures shall exclude any liability by the manufacturer.
►The liability-prescriptions of the manufacturer in the issue valid at the time of purchase are valid for the
device. The manufacturer shall not be held legally responsible for inaccuracies, errors, or omissions in
the manual or automatically set parameters for a device or for an incorrect application of a device.
►Repairs may only be executed by the manufacturer.
►Installation, operation and maintenance procedures should only be carried out by qualified personnel.
►Use of the device and its installation must be in accordance with national legal requirements and local
electrical codes.
►When working on devices the valid safety regulations must be observed.
►This device is not suitable to be used in places where children are present. Prevent children access to
the device.
►Equipment is intended for use only in restricted access area.
►Special advice for carriers of cardiac pacemakers:
Although this device doesn’t exceed the valid limits for electromagnetic fields you should keep a
minimum distance of 25 cm between the device or the antenna and your cardiac pacemaker.

IDENTIFICATION
ID MAX.U500i
2Performance Features
Page 6 of 36
2 Performance Features of ID MAX.U500i
Perf ormanc e Features
2.1 Performance Features
With its compact size, its weather-resistant housing, a read range of 8 to 10 m and the circular-polarized
antenna supporting any transponder orientation, the UHF Vehicle Access Control Reader ID MAX.U500i is
ideally suited to provide efficient and secure vehicle access control. Up to 9000 users and vehicles can be
stored in the internal storage of the ID MAX.U500i.
The vehicle access control reader can be easily installed on a VESA mount next to a barrier, gate or bollard
due to its mechanical construction. To install the compact reader one cable is required for each interface and
power supply; for PoE only the network cable is required.
2.2 myAXXESS Manager
With the help of the software myAXXESS Manager user data and access rights can be easily handled via
PC. After programming the access rights into the vehicle access control reader via a temporary USB or
network connection the reader is working offline as a standalone system.
The Windows software is suitable for network based vehicle and door access control systems and is based
on a SQL database. The myAXXESS Manager is available in the FEIG download area.
In small applications without any time restrictions for the access rights new transponders can be added to
the reader by the Teach-In Mode without above mentioned software (See chapter 6.2.1 Teach-In Mode on
page 24.).
2.3 Available Reader Types
The following readers are available:
Order Number
Reader Type
Description
5118.001.00 ID MAX.U500i-EU Device version for Europe
5118.001.10 ID MAX.U500i-FCC Device version for North America

IDENTIFICATION
ID MAX.U500i
3Scope of Delivery
Page 7 of 36
3 Scope of Delivery
Scope of Delivery
The scope of delivery includes following components:
•1 x ID MAX.U500i
•1 x MFD 25/01/065 M25 multiple sealing insert for 1 cable; cable ∅4–6.5 mm
•1 x ESKV 20 M20 cable gland for cable ∅6–13 mm; for USB
•1 x RDE 20 M20 reduction sealing insert for cable ∅4–8 mm
•1 x MFD 20/02/040 M20 multiple sealing insert for 2 cables; cable ∅2–4 mm
•1 x MFD 20/04/040 M20 multiple sealing insert for 4 cables; cable ∅2–4 mm
•1 x MFD 16/02/040 M16 multiple sealing insert for 2 cables; cable ∅2–4 mm
•2 x ID CTF-U UHF Windshield Transponder

IDENTIFICATION
ID MAX.U500i
4Installation
Page 8 of 36
4 Installation
Installation
The ID MAX.U500i is designed to be mounted outdoors on a VESA bracket. The reader should be mounted
with the connections facing downwards to ensure tightness as shown below. Four holes for M5 screws are
provided on the backside of the housing for mounting on the VESA bracket. The screws used should have a
screw-in depth of maximum 8 mm. The housing can be opened by means of a hinge Therefore loosen the
screws marked blue in Fig. 1and swing away the front part of the reader. During installation, the dimensions
of the reader when opened should be taken into account (see Fig. 3). For secondary protection the reader
should be secured by means of an eye bolt (see Fig. 4), that should be fixed with screw locking varnish, and
e.g. a wire rope. The suitable accessory ID ANT.UEB-A can be purchased from FEIG ELECTRONIC.
Fig. 1: Dimensional drawing – back view

IDENTIFICATION
ID MAX.U500i
4Installation
Page 9 of 36
Fig. 2: Dimensional drawing – side view

IDENTIFICATION
ID MAX.U500i
4Installation
Page 10 of 36
Fig. 3: Dimensional drawing – top view: opened housing

IDENTIFICATION
ID MAX.U500i
4Installation
Page 11 of 36
NOTE:
FEIG ELECTRONIC GmbH strongly recommends to secure the reader against falling by means of an
eye bolt to prevent damage.
Fig. 4: Secondary protection via eye bolt

IDENTIFICATION
ID MAX.U500i
5Terminals
Page 12 of 36
5 Terminals
Terminals
The cable connections are located on the lower side of the reader. Fig. 5shows the arrangement of the
connectors and Table 1gives an overview on the available connectors and interfaces. Table 2lists the
available operating and display elements.
Fig. 5: Connection Overview
Connector Description
X1 10/100 Base-T Ethernet with RJ45
X2 Power Supply 12–24 V DC ±1 0 %
X4 Relay Outputs & Digital Outputs
X5 Digital Inputs
X6 USB Mini Interface
Table 1: Connection Terminals
Operating /
Display
Element
Description
T1 Push Button for configuration reset or Teach-In
Mode
LED Status LEDs for service & maintenance
1 Buzzer
Table 2: Operating and Display Elements

IDENTIFICATION
ID MAX.U500i
5Terminals
Page 13 of 36
5.1 Antenna Connection
The TNC socket for connecting the external antenna is located on the lower side of the reader.
The maximum tightening torque for the TNC sockets is 0.69 Nm (6.11 lbf in).
Fig. 6: External antenna connection
CAUTION:
•Exceeding the tightening torque will destroy the antenna connection.

IDENTIFICATION
ID MAX.U500i
5Terminals
Page 14 of 36
5.2 Power Supply
5.2.1 Power Supply via Connector X2
The supply voltage of 12–24 V DC has to be connected to terminal X2.
Pin Number at
Connector X2
Abbreviation
Description
1 GND Ground – suppy voltage
2 12–24 V Supply voltage 12–24 V DC ±10 %
Table 3: Pin assignment for power supply
CAUTION:
•The reader has to be supplied by a limited power supply according EN 62368-1 Chapter Q.1, or
with a NEC Class 2/LPS certified power supply.
•Each reader has to be supplied by a separate external power supply.
•Reversing the polarity of the supply voltage on X2 may destroy the device.
•External wiring for the power supply must fulfil the following norms/validation procedures:
Conductor Cross Section
Validation Procedure
from 0,5 mm² or bigger IEC 60332-1-2 and IEC 60332-1-3
smaller than 0,5 mm² IEC 60332-2-1 and IEC 60332-2-2
Table 4: Validation procedures for external wiring of the power supply
Fig. 7: Connector X2 pin assignment for power supply

IDENTIFICATION
ID MAX.U500i
5Terminals
Page 15 of 36
5.2.2 Power Supply via PoE (Power over Ethernet)
Optional the reader can be powered via the Ethernet interface on X1 with the use of a PoE „Power over
Ethernet“ power supply according to IEEE802.3at*, Class4 (30/25,5Watt). The DC supply can be achieved
via the free pins 4, 5 and 7, 8 (Midspan-Power). Also a “Phantom Powering” (Inline-Power) via the signal
pins 1, 2, 3 and 6 is possible. Depending on the conductor cross-section the following cable distances can
be used:
Conductor Cross Section
(CAT5…7)
Max. Cable Length for PoE
0,4 mm² ~ 30 m
0,6 mm² ~ 70 m
Table 5: Max. cable length depending on the conductor cross section
* For detailed technical information regarding the 802.3at standard, please refer to the most recent edition of the
corresponding IEEE specification.
NOTE:
•It must be ensured that the reader is supplied with 42.5 V (48 V DC – cable losses) at least.
•An operation of an ID MAX.U500i via an external power supply and PoE at the same time is not
recommended and can cause interferences during operation.
•If the reader is supplied via PoE, no DC voltage can be provided at the connection for the external
antenna.
Fig. 8: LAN and PoE Connection

IDENTIFICATION
ID MAX.U500i
5Terminals
Page 16 of 36
5.3 Ethernet Interface on Connector X1
The reader has an integrated 10/100 base-T network port for an RJ-45. Connection is made on X1 and has
an automatic “Crossover Detection” according to the 100BASE-T Standard.
With structured cabling STP CAT5 cables should be used. This ensures a reliable operation at 10 Mbps or
100 Mbps. The prerequisite for using TCP/IP protocol is that each device has a unique IP address on the
network. All readers have a factory set IP address. The transmission parameters can be configured as
required.
Network
Address
IP Address 192.168.10.10
Subnet Mask 255.255.0.0
Port 10001
DHCP OFF
Table 6: Standard factory configuration of the Ethernet connection
NOTE
The reader is equipped with a DHCP ready Ethernet interface.
Fig. 9: Ethernet connector

IDENTIFICATION
ID MAX.U500i
5Terminals
Page 17 of 36
5.4 Digital Outputs on Connector X4
There are 2 digital outputs available on terminal X4. The transistor connection, collector and emitter, of the
optocoupler output is galvanically isolated from the reader electronic and routed to the outside at terminal X4
without internal additional circuitry. The output must therefore be supplied with an external voltage. Each
output is linked fixed with an antenna. Reading of a valid transponder on the internal antenna will affect the
digital output OPTO1-OUT, a valid reading on the external antenna will affect the digital output OPTO2-OUT.
Pin Number at
Connector X4
Pin Assignment
1 OPTO2-OUT-C
2 OPTO2-OUT-E
3 OPTO1-OUT-C
4 OPTO1-OUT-E
Table 7: Pin Assignment X4 (Digital Outputs)
Fig. 10: Connector X4 pin assignment for digital outputs
Fig. 11: internal and external wiring of the digital outputs

IDENTIFICATION
ID MAX.U500i
5Terminals
Page 18 of 36
CAUTION:
•The outputs are designed for an input voltage of 12-24 V DC and an input current of max. 20 mA.
•Polarity reversal or overload of the outputs leads to their destruction!
•The output is only intended for switching resistive loads.
5.5 Relay Outputs on Connector X4
There are 2 relay outputs available at terminal X4 as normally open contacts. Each output is linked fixed with
an antenna. Reading of a valid transponder on the internal antenna will affect the relay REL1, a valid reading
on the external antenna will affect the relay REL2.
Pin Number at
Connector X4
Pin Assignment
5 REL2-COM
6 REL2-NO
7 REL1-COM
8 REL1-NO
Table 8: Pin Assignment Relay Outputs REL1/REL2
Fig. 12: Connector X4 pin assignment for relay outputs
Fig. 13: External wiring of the relay outputs

IDENTIFICATION
ID MAX.U500i
5Terminals
Page 19 of 36
CAUTION:
•The relay outputs are designed for max. 24 V DC / 2 A continuous load.
•The maximum switching current must not exceed 1 A.
•The relay outputs are intended for switching resistive loads only. In case an inductive load is
connected, the relay contacts must be protected by an external protective circuit.
5.6 Digital Inputs on Connector X5
There are 2 digital inputs available on X5. The optocouplers on X5 are galvanically isolated from the reader
electronics and must therefore be supplied with an external voltage.
Pin Number at
Connector X5
Pin Assignment
1 OPTO2-IN –
2 OPTO2-IN +
3 OPTO1-IN –
4 OPTO1-IN +
Table 9: Pin Assignment X5 (digital inputs)
Fig. 14: Connector X5 pin assignment for digital inputs
Fig. 15: External wiring of the digital inputs

IDENTIFICATION
ID MAX.U500i
5Terminals
Page 20 of 36
The external resistor Rext is optional. When wiring the reader, make sure that the input voltage is at least
10.5 V.
CAUTION:
•The inputs are designed for an input voltage of 12-24 V DC and an input current of max. 20 mA.
•Polarity reversal or overload of the inputs leads to their destruction!
