Fein ASCD 18-W2 Setup guide

ASCD 18-W2; ASCD 18-W4
Repair instructions
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 1of 33
ASCD 18-W2 ASCD 18-W4

ASCD 18-W2; ASCD 18-W4
Contents
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 2of 33
1. Models described
2. Technical data
3. Notes and requirements
4. Tools required
5. Lubricants and auxiliary substances required
6. Disassembly
7. Assembly
8. Troubleshooting
9. Connection diagram

ASCD 18-W2; ASCD 18-W4
1. Models described
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 3of 33
These instructions describe how to repair the following models:
Model Order number
ASCD 18-W2 7 115 01 00 94 0
ASCD 18-W4 7 115 02 00 94 0

ASCD 18-W2; ASCD 18-W4
2. Technical data
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 4of 33
Technical data
The complete technical data can be found in the operating instructions for the model.
Test data
Up-to-date test data for all models can be found on the FEIN Extranet (Customer Service → Repair Guides).
Lubricants
The lubricants and container sizes available from FEIN can be found on the FEIN Extranet (Customer Service → Repair Guides).
Lists of spare parts
Lists of spare parts and exploded views are available online at www.fein.com

ASCD 18-W2; ASCD 18-W4
3. Notes and requirements
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 5of 33
Note
These instructions are only intended for persons with suitable technical training. It is assumed that the reader has mechanical and
electrical training.
Only use original FEIN spare parts!
Provisions
Please note that power tools may only be repaired, maintained and checked by a trained electrician, as improper repair can result in
serious risks to the user.
The provisions set out in DIN VDE 0701-0702 should be observed after repairs.
The relevant accident prevention regulations of the employers’ liability insurance associations are to be observed when
commissioning.
The German Equipment and Product Safety Act applies for correct use.
Outside Germany, the regulations applicable in the relevant country must be observed!

ASCD 18-W2; ASCD 18-W4
4. Tools required
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 6of 33
Standard tools Special tool
Torx T10 Assembly aid 6 41 22 121 01 0
Cross-tip screwdriver Sleeve and taper 6 41 22 125 01 0
Slotted screwdriver
Slotted screwdriver (small)
Circlip pliers (angled)
Soldering rod
Torque wrench

ASCD 18-W2; ASCD 18-W4
5. Lubricants and auxiliary substances required
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 7of 33
Lubricants
Grease 0 40 101 0100 4 4 g Tool holder
Grease 0 40 119 0500 7 1g Tool holder

ASCD 18-W2; ASCD 18-W4
6. Disassembly
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 8of 33
Disassembling motor housing
1. Press catch (1) and pull battery off tool.
2. Loosen four screws (2) and take off with cover (3).
3. Unscrew the four screws (4).
Tool:
- Torx T10
- Cross-tip screwdriver
2
1
4
3

ASCD 18-W2; ASCD 18-W4
6. Disassembly
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 9of 33
Disassembling motor housing
1. Unscrew the seven screws (1) and take off motor housing.
2. Remove switch (2), gearbox (3) and toggle switch (4) from motor housing. Tool:
- Torx T10
1
4
2
3

ASCD 18-W2; ASCD 18-W4
6. Disassembly
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 10 of 33
Disassembling motor housing
1. Remove the eight pressure pieces (1) from the motor housing halves.
1

ASCD 18-W2; ASCD 18-W4
6. Disassembly
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 11 of 33
Disassembling tool holder (applies to: ASCD 18-W4)
1. Remove circlip (1).
2. Remove disc (2), spring (3) and sleeve (3). Tool:
- Circlip pliers (angled)
- Slotted screwdriver
(small)
1
2
4
3

ASCD 18-W2; ASCD 18-W4
6. Disassembly
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 12 of 33
Disassembling the gearbox
1. Pull gearbox and gearbox housing (1) off armature.
2. Pull gearbox housing (1) off gearbox (2) and remove tool holder (3).
NOTE
Alternatively the gearbox can be removed without opening the motor housing.
by loosening the four screws on the gearbox housing. The gearbox can then be pulled out of the motor housing.
1
2
3
1

ASCD 18-W2; ASCD 18-W4
6. Disassembly
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 13 of 33
Disassembling gearbox housing
1. Remove disc (1) from housing with a slotted screwdriver. Tool:
- Slotted screwdriver
1

ASCD 18-W2; ASCD 18-W4
6. Disassembly
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 14 of 33
Disassembling brush holder set
1. Lift four tension springs (1) of brush holder on to notches provided (2).
2. Pull armature (3) off brush holder set. Tool:
- Assembly aid
1
2
3

ASCD 18-W2; ASCD 18-W4
6. Disassembly
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 15 of 33
Disassembling switch
1. Unsolder the two cables (1) from switch. Tool:
- Soldering rod
1

ASCD 18-W2; ASCD 18-W4
6. Disassembly
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 16 of 33
Disassembling motor
1. Pull stator (1) off armature.
Caution!
Risk of crushing due to strong pull of magnet!
During assembly/disassembly, only touch magnet on outer race.
1

ASCD 18-W2; ASCD 18-W4
7. Assembly
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 17 of 33
Assembling gearbox housing
1. Insert disc (1) into gearbox housing.
NOTE
Curve of disc must face down.
2. Insert ball (2) into tool holder.
3. Slide tool holder (3) into gearbox housing.
4. Coat inside (4) of tool holder with 1g of grease.
Tool:
- Grease
(0 40 119 0500 7)
1
3
2
4

ASCD 18-W2; ASCD 18-W4
7. Assembly
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 18 of 33
Assembling gearbox housing
1. Coat gearbox (1) with 4g of grease and insert into gearbox housing.
2. Slide armature (2) into stator (3).
The recess (4) must face right as shown.
Caution
Risk of crushing due to strong pull of magnet.
During assembly/disassembly, only touch magnet on outer race.
Tool:
- Grease
(0 40 101 0100 4)
1
2
3
4

ASCD 18-W2; ASCD 18-W4
7. Assembly
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 19 of 33
Assembling gearbox
1. Slide armature (1) into gearbox (2).
2. Solder red cable (3) of brush holder set on to position M1 on switch.
3. Solder black cable (4) of brush holder set on to position M2 on switch.
Tool:
- Soldering rod
1
2
3
M1
M2
4

ASCD 18-W2; ASCD 18-W4
7. Assembly
C-SC_CSSM
Version 1.0
2014-07-09
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 20 of 33
Assembling brush holder set
1. Lift the four tension springs (1) of brush holder on to notches provided (2) with hook. Tool:
- Assembly aid
1
2
