Fellowes esi FlexCharge4CX User manual

Assembly instructions
FlexCharge™4CX
Model # FCH4CX-WHT
Model # FCH4CX-BLK
Personal desktop power

Page 2
FlexCharge4CX Safety instructions/warnings
Please review these instructions before beginning the installation. Check that all parts and tools needed
were provided with your order (see illustration on following page). Contact your supplier if any parts are
missing. Do not discard the packaging until content that the product operates to your satisfaction.
Safety instructions/warnings
Always read the safety instructions carefully.
• Do not install near heat sources such as radiators, heat registers, stoves or
other equipment (including amplifiers) that produce heat.
• Unplug the unit during lightning storms or when unused for extended
periods of time.
• To reduce the risk of fire or electric shock, do not expose this unit to rain or
moisture, including any drips or splashes.
• Objects filled with liquids such as vases, should never be placed on or near
the unit.
• Do not open the unit due to risk of electric shock hazard.
• The outlet used to power the unit should be easily accessible and located
near the equipment.
• The unit is for indoor use only.
• Please refer to the marking label on the unit for input and output ratings. Do
not overload the power supply.
• DO NOT USE this unit in life support applications where failure of the
unit can reasonably be expected to cause the failure of the life support
equipment or to significantly aect its safety or eectiveness.
• DO NOT USE this unit in the presence of a flammable anesthetic mixture
with air, oxygen or nitrous oxide.
• Failure to adhere to these instructions eectively voids the warranty.

Page 3
FlexCharge4CX Parts and tools
Parts provided
Additional tools required
• Phillips screwdriver
• Power drill with
1
/ 8 " drill bit (under-desk mounts only)
There are three ways to mount the FlexCharge4CX power module:
• Edge mount (page #4)
• Grommet mount (page #5)
• Under-desk mount (page #8)
Choose the best mounting method based on user preference and the mounting circumstances.
Edge mount Grommet mount Under-desk mount
power module (1)
power strip with
double sided tape (1)
M4 Allen key (1)
M3x12 panhead
screws (2)
M4x14 wood
screws (8)
bracket/clamp assembly (1)

Page 4
Edge Mount
With edge mounts, the product is clamped to the
edge of the worksurface.
Step #1: if necessary, raise clamp on bottom bracket
Skip this step if worksurface thickness is 0.9" or more.
• The clamp is attached to the lower two holes on bottom bracket. If worksurface thickness is less than
0.9", clamp attachment must be moved to the upper two holes.
• Use the M4 Allen key to unscrew the two
M5x8 socket cap screws that secure the
clamp.
• Raise the clamp to the upper two holes
and attach it using the socket cap screws.
Tighten securely using the Allen key.
Step #2: attach bracket/clamp assembly to power module
• Route the power cord through the opening in the
top bracket.
• Attach the top bracket to the rear of the power
module using the two M3x12 panhead screws.
Hand-tighten securely.
power module
clamp
bottom
bracket
top
bracket
M3x12
clamp
bottom
bracket
M5x8
socket cap
screw
FlexCharge4CX Edge mount

Page 5
Step #3: clamp FlexCharge4CX unit to worksurface and mount power strip
• Position the unit in the desired location and clamp it securely to the
worksurface by tightening the triangle knob.
• Mount the power strip underneath the worksurface in the desired location
using the double-sided tape and four M4x14 wood screws.
— Note: The double-sided tape is only temporary and is not intended for permanent installation.
• Plug the power strip into the AC outlet and flip the switch on.
You are now ready to use the eight AC power outlets (six on the power strip, two on the
power module) as well as the USB-A and USB-C charging ports located on the power
module.
worksurface
triangle knob
FlexCharge4CX Edge mount
Grommet mount
The grommet mount method is similar to the
edge mount method, except that the assembly is
clamped to the edge of a grommet hole, rather
than the edge of the worksurface. Minimum
diameter of the grommet hole is 2.3".

Page 6
Step #1: remove clamp from bottom bracket
• Unscrew the two M5x8 socket cap screws using the M4 Allen key.
— Remove the clamp from the bottom bracket.
Step #3: attach bracket assembly to power module
• Route the power cord through the opening in the top bracket.
• Attach the top bracket to the rear of the power module
using the two M3x12 panhead screws. Hand-tighten
securely.
power module
bottom
bracket
2"
top
bracket
M3x12
Step #2: attach M5x8 screws to bottom bracket
• Install the two M5x8 screws back onto the bottom bracket, leaving about 1/8" exposed between the
screw heads and the bracket.
— With worksurface thicknesses between
0.9" and 2", attach the screws to the lower
two holes.
— With worksurface thicknesses less than 0.9",
attach the screws to the upper two holes.
lower
uppe
r
0.9" to 2" 0.4" to 0.9"
1
/ 8 "
clamp
bottom
bracket
M5x8
s
ocket cap
screw
FlexCharge4CX Grommet mount

Page 7
Step #4: clamp power module assembly to worksurface and
mount power strip
• Insert the bottom bracket through the grommet hole.
• Attach the clamp to the bottom bracket.
— Fit the keyhole openings in the clamp over the M5x8 screw heads.
Tighten the screws securely over the narrow portion of the keyholes using the M4 Allen key.
• Clamp the assembly securely to the worksurface by tightening the triangle knob.
• Mount the power strip underneath the worksurface in the desired location
using the double-sided tape and four M4x14 wood screws.
— Note: The double-sided tape is only temporary and is not intended for permanent installation.
• Plug the power strip into the AC outlet and flip the switch on.
FlexCharge4CX Grommet mount
hook keyholes onto
screws and tighten worksurface grommet
hole
You are now ready to use the eight AC power outlets (six on the power strip, two on the power
module) as well as the USB-A and USB-C charging ports located on the power module.

Page 8
Under-desk mount
With this method, the top bracket is turned
upside-down so that it can be mounted to the
underside of the worksurface with M4x14 wood
screws. As with the other methods, the power
module is mounted to the bracket using two
M3x12 panhead screws.
Step #1: remove top bracket
• Unscrew the M5x8 socket cap screws using the M4 Allen key.
• Remove the top bracket from the bracket/clamp assembly.
#6-32x
¼
top
brac
ket
top
bracket
Step #2: mark and drill pilot holes
• Use the top bracket as a template to mark where to drill
four pilot holes.
— Position the bracket at the desired location, typically at
the front of the worksurface on the left or right side.
— Mark hole locations.
• Drill ½" deep pilot holes using a
1
/ 8 " drill bit.
Caution: Be careful not to not drill through the top of the
worksurface.
FlexCharge4CX Under-desk mount

Page 9
Step #3: attach top bracket to underside of worksurface
• Attach the bracket using the four M4x14 wood screws. Hand-tighten securely.
Step #4: attach power module to bracket
• Route the power cord through the opening in the top bracket.
• Attach the power module to the bracket using the two M3x12 panhead screws.
Hand-tighten securely.
• Mount the power strip underneath the worksurface in the desired location
using the double-sided tape and four M4x14 wood screws.
— Note: The double-sided tape is only temporary and is not intended for permanent installation.
• Plug the power strip into the AC outlet and flip the switch on.
M4x14
M3x12
FlexCharge4CX Under-desk mount
You are now ready to use the eight AC power outlets (six on the power strip, two on the power
module) as well as the USB-A and USB-C charging ports located on the power module.

Page 10
Additional features
• FlexCharge4CX oers built-in surge protection with an indicator light. The light displays when surge
protection is active on your FlexCharge4CX.
— If the light is not illuminated, please contact ESI Customer Service Department.
• AC outlet orientation accommodate large plugs
• FlexCharge4CX complies with UL 962A Standard for Furniture Power Distribution Units and meets
respective spill test criteria.
FlexCharge4CX Additional features
27W output max. USB-A and USB-C (PD3.0) charging modules can charge multiple devices at the same
time. The power strip has six AC outlets.

LIMITED WARRANTY
ESI warrants this product to be free from defects in manufacturing for a period of five year from the date of original purchase.
This warranty extends only to the original purchaser, and does not apply if the product has been damaged or fails to function
properly as a result of misuse, abuse, modification, alteration, or improper cleaning or maintenance. This warranty does
not apply to damage in shipment caused by carriers, damage caused during installation, normal wear and tear, or excessive
use (meaning consistent use in excess of an eight hour shift). ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE ARE LIMITED IN DURATION TO ONE YEAR FROM THE DATE OF ORIGINAL RETAIL PURCHASE.
ESI’s sole obligation under this warranty or any implied warranty, and the purchaser’s sole remedy, is limited to the repair
or replacement, at ESI’s option, of the product or any defective part. Costs (such as installation, labor fees or express
shipping) incurred due to replacement of products are not covered under warranty. IN NO EVENT SHALL FELLOWES, ITS
AFFILIATES, SUBSIDIARIES, RELATED ENTITIES OR THEIR RESPECTIVE OFFICERS, DIRECTORS, OR EMPLOYEES, BE LIABLE
FOR INCIDENTAL, CONSEQUENTIAL, PUNITIVE, EXEMPLARY, OR SPECIAL DAMAGES.
To make a warranty claim, contact ESI at 800-833-3746 or [e-mail]. You must provide proof of
purchase, such as the original purchase order number.
The duration, terms and conditions of this warranty are valid worldwide, except where dierent limitations, restrictions or
conditions may be required by local law.
FCH4-DSK Rev G 11/2018© 2018 Fellowes, Inc.
