Fender BXR 200 User manual

BXR 200
BASS EXTENDED RANGE
COMBO & HEAD
SERVICE MANUAL
CONTENTS:
Notices
Specifications
Circuit description
Parts lists:
Preamp PCB assembly
Power amp PCB assembly
Chassis assembly
Cabinet assembly
Miscellaneous
Schematics/diagrams
Fender Musical Instruments Corp. 8860 E. Chaparral Road Suite 100 Scottsdale, AZ 85250

BXR 200
(This is the model name for warranty claims)
SERVICE MANUAL
MARCH 1996
IMPORTANT NOTICE:
The information contained herein is CONFIDENTIAL and PROPRIETARY to Fender Musical Instruments Corp. It is
disclosed solely for use by qualified technicians for purposes of equipment maintenance and service. It is not to be
disclosed to others without the expressed permission of Fender Musical Instruments Co. All specifications subject to
change without notice.
For warranty repair service, only Fender specified part numbers are to be used. It is recommended they also be used
for post-warranty maintenance and repair.
Parts marked with an asterisk (*) indicate the required use of that specific part. This is necessary for RELIABILITY
and SAFETY requirements. DO NOT USE A SUBSTITUTE!
A coded naming convention is used in the description of certain parts. The codes and what they mean are as follows:
CAPACITOR CODES HARDWARE CODES
CAP AE = Aluminum Electrolytic BLX = Black Oxide
CAP CA = Ceramic Axial CR = Chrome Plated
CAP CD = Ceramic Disk HWH = Hex Washer Head
CAP MPF = Metalized Polyester Film M = Machine Screw
CAP MY = Mylar NI = Nickel Plated
CAP PFF = Polyester Film/Foil OHP = Oval Head Phillips
PB = Particle Board
RESISTOR CODES PHP = Pan Head Phillips
PHPS = Pan Head Phillips Sems
RES CC = Carbon Comp SMA = Sheet Metal "A" Point
RES CF = Carbon Film SMB = Sheet Metal "B" Point
RES FP = Flame Proof SS = Stainless Steel
RES MF = Metal Film TF = Thread Forming
RES WW = Wire Wound ZI = Zinc Plated

BXR 200
SPECIFICATIONS
Product Release No.: PR 286 (This is not a model number)
POWER AMPLIFIER SECTION:
Power Output: 200 Watts RMS
Distortion at 200 watts: Less than .1% @ 1kHz, below compression
Less than 1% @ 1kHz, maximum compression
Rated Load Impedance: 4Ω
Sensitivity: 1.03V RMS
Input Impedance: 22kΩ
DELTACOMP Range: 20db
PREAMP SECTION:
Input Impedance: Input 1 – Greater than 420kΩ(typically
greater than 1M ohm in the passband)
Input 2 – 136kΩ
Sensitivity for 200 watts: Input 1 – 2.2mV
GAIN at maximum, all tone Input 2 – 4.4mV
controls at “0” detent, no
enhancement activated.
Shelving Tone Controls: LOW +/- 12dB at 60Hz
HIGH +/- 12dB at 10 kHz
Graphic Equalizer: +/- 12dB at 80,140,250,450,800,1.4k,2.5k, 4.5k and 8kHz.
Dimensions: BXR 200 Combo BXR 200 Head
Height:25-1/2" (64.8 cm) 6-29/32 inches (17.5cm)
Width: 21-1/2" (54.6 cm)
Depth: 13-1/2" (34.3 cm)
Weight:72 lbs. (32.7 kg) 27 lbs (12.3 kg)
Product specifications are subject to change without notice

BXR 200
CIRCUIT DESCRIPTION
PREAMP
J1 is a high sensitivity input which can be driven with as much as 2.5 volts RMS. J2 is a low sensitivity
input which is recommended for Bass Guitars with active pickups, and can handle as much as 5 volts
RMS.
U1A is a “cheater” Sallen Key filter with gain. R79 and C82 create a gradual boost in the high frequencies.
This sets up the initial response of the amplifier. C43 and C44 are used for local power supply decoupling
for the first two op-amp stages. This minimizes noise and hum in the front end of the preamp.
U1B is a variable gain stage. The Gain Control is used as the feedback resistor. This allows a gain
adjustment from less than 1 to about 10.
At the input of U2A, the DEEP enhancement switch boosts and extends the low-frequency response.
Within the negative feedback loop, the BRIGHT enhancement switch adds high frequency “sparkle”. The
output of U2A drives the Notch Filter circuit. When engaged, this filter provides a narrow band notch of
about –20db at 650 Hz. The signal then feeds a unity gain amp (U2B) and couples to the first tone control
stage.
From the active tone controls the signal is routed to the second Gain stage (U8B). If the DeltaComp is off,
switch S5B places Q1 & Q2 into the feedback loop, where they are biased asymetrically to provide non-
symetrical soft clipping, which simulates a tube sound. The diode junctions Q1,Q2, CR1 and CR2 drop a
constant knee-voltage independent of current. As the signal increases above a certain level, the constant
voltage alters the feedback current to the op-amp in a non-linear fashion. This non-linear transfer
characteristic is what rounds off the resulting signal into a tube-type, soft-clipping waveshape. With the
DeltaComp engaged, the soft-clipping circuit is disabled.
CHORUS
The input signal to the Chorus circuit is capacitivly (C61) coupled to U10A, which drives the Bucket Brigade
Device (BBD) U13. Trimpot R105 sets the DC bias for U10A and U12A. When properly adjusted, the
output from U10A & U12A will display symmetrical clipping. (Refer to the adjustment procedure on the
service diagram). The BBD is clocked by U14 at 180kHz. The 180kHz carrier clock is Frequency
Modulated by the Low Frequency Oscillator U11, which deviates the carrier at maximum DEPTH from
60kHz to 300kHz. The RATE of deviation runs from about 0.3Hz to 8.7Hz. The FM deviation on top of the
BBD delay results in a pleasing choral effect.
C62 and R107 (@U10A) provide pre-emphasis above 7kHz. At the output of U12A, R121 and C74 provide
the de-emphasis. This helps to reduce noise. C64, C65 and C67 filter out clock noise. The Dry and
Chorus signals are summed at U12B and then fed to the power amplifier. Via the Chorus select switch or
the footswitch, the Chorus effect can be switched on or off. The collector of Q4 provides the control
voltage which enables U11, and determines the state of JFET Q5. A –15Vdc from Q4 enables U11 to
oscillate, and pinches off JFET Q5, which removes the ground from the node between R123 & R124.
DELTACOMP
The signal from the preamp feeds from P1B pin 4, through a ribbon cable, to P1A on the power amplifier
PCB. The signal couples (via C1) to the unity gain amplifier U1B. U1B contains a closed loop (gain of 1)
negative feedback path, along with positive feedback through the inverting Operational Transconductance
Amplifier (OTA) U2. U1B and U2 make up the gain reduction circuit for the DeltaComp clip protection
feature.

BXR 200
DELTACOMP(Cont)
The attack and release circuit for the DeltaComp is made up by the Diode, Resistor, and Capacitor network
which drives the Base of Q19. Comparator U1A senses the voltage from the Collectors of Q20 & Q21.
When the power amplifier approaches clipping on a positive swing, the collector of Q5 pulls up R56, which
turns on Q20, transferring –16Vdc to the collector, pulling down R60. This causes the output (pin 1) of U1A
to switch from +15Vdc to –15Vdc, lighting the DeltaComp/Clip Led. Note: when the DeltaComp is disabled,
the Led indicates clipping of the output stage. WIth the DeltaComp enabled, the Led indicates an active
DeltaComp circuit. The negative control voltage from R60 also feeds through P1A to P1B on the preamp
PCB. The voltage is routed to the DeltaComp switch (S5A), located on the front panel. With the switch
engaged, the control voltage is sent back through the ribbon cable (via P1 pin 6) to the attack/release
circuit.
The negative voltage drives through Diodes CR31-CR34, and charges Capacitors C16-C19 all at once in
parallel as a one pole filter through a single time constant of R60 X (C6+17+18+19) or 2.2k X 8.8 uF = 19.4
mSec. As they charge, Q19 turns on and provides current to pin 5 of the OTA (U2). The current controls the
output amplitude of U2. The inverted signal from U2 mixes with the input to U1B providing cancellation
which reduces amplitude of U2. The inverted signal from U2 mixes with the input ot U1B providing
cancellation which reduces the input to the power amplifier. This prevents the amplifier from clipping.
When the output of the power amplifier is reduced, the output of U1A toggles back to +15vdc. Due to the
blocking action of Diodes CR31-CR34, Capacitors C16-C19 are forced to discharge as a 4-pole filter with
different time constants through R55. R51 prevents Parasitic oscillation while Zener CR30 provides 2
slopes which results in smoother limiting.
When the power amplifier approaches clipping on a negative swing, R62 is pulled low, turning on Q22 which
pulls up the Base of Q21, transferring –16vdc to the collector.
POWER AMPLIFIER
JFET Q1 and associated components provide a 4-5 second turn-on delay for the audio input to the power
amplifier. When the power is switched on, Capacitor C5 charges through Resistor R7. The negative Gate
voltage pinches off the JFET, removing the ground from the input of the amplifier. When the power is
switched off, C5 immediately discharges through Diode CR1, grounding the input of the amplifier.
TROUBLESHOOTING TIP: Check for proper operation of this circuit when experiencing excessive turn-on
or turn-off “Pops”, or no output when signal applied to the input. Many times the JFET itself can be the
culprit. NOTE: Excessive turn-off “Pops” can also be caused by uneven discharge of the +/- power
supplies. Usually a mismatch in the Filter Capacitors will cause this problem. Its easy to look at both
supplies on an oscilloscope. Invert one scope input and check for even discharge to zero volts.
Q4 is the current source for the Differential Amplifier (Q2,Q3). For the Diff amp to work properly, one half of
the current from the current source must flow through each leg of the Diff amp. If the same amount of
current flows through each leg of the Diff amp, the voltage drop across resistors R14 &R15 must be the
same. If not, there will be a DC offset at the output of the amplifier. The overall gain of the amplifier is set
up around the Diff amp. R16 (27k) is the feedback resistor and R17 (1k) is the pull-down resistor. Rfb
+Rpd ÷Rpd = Av. Therfore 27k + 1k ÷1k = 28k ÷1k = 28Av.
Q9 & Q10 make up a voltage amplification stage. Again, to operate properly, the same amount of current
must flow trhough these transistors. Thus the voltage drop across R20 & R21 must be the same. Diodes
CR16-CR9 (BYV26D) make up the Fixed Bias circuit for the output transistors. The bodies of the Diodes
are mounted through the heatsink to properly track the temperature of the transistors. These Diodes were
selected because they exhibit a 2mV decrease in Knee Voltage for every 1 degree (Celsius) increase in
temperature. The Collectors of Q9 & Q10 are at 0 volts. Therefore the Bias Diodes provide 2 voltage drops
(1.2 volts) to the Base of Driver Transistors Q13 & Q14. One Diode drop (0.6 volts) Biases on the Driver
Transistors. The remaining 0.6 volts drops across the output transistors (Q15-Q18) in parallel, Biasing them
on.

BXR 200
Transistors Q11, Q12, and associated components comprise the Current Limiting or Short Proof protection
circuit. There are usually two conditions which demand excessive output current from the amplifier. A
shorted speaker cable, or a load impedance which is below the minimum rating of the amplifier. If these
conditions occur, the voltage drops across the Emitter Resistors (.33Ω5 Watt) will dramatically increase.
On the positive side of the amplifier, C11 charges through R29 & R34. On the negative side C12 charges
through R30 & R35. Htis will cause Q11 & Q12 to turn on. This limits the amount of signal which is
available to the Base of the Driver Transistors (Q13 & Q14). CR20-CR23 make up a latching circuit that
senses the signal through R22. This ensures that Q11 & Q12 turn on hard in conduction. When the fault
condition is removed from the output, the current limiting circuit will remain latched up until the input signal is
removed.
Q13 & Q14 are the Driver Transistors for the output section. Q15-Q18 are the output transistors. Notice on
the schematic that the Base resistors carry the “Fp” designation. Htis indicates a Flame Proof/Fuse Type
resistor. They won’t burn and they act like a fuse when exposed to an over-current condition. This prevents
catastrophic damage to the output section. If an output transistor shorts Base to Collector or Base to
Emitter, the resistor will simply open. IN many cases the amplifier will continue to operate, but at a reduced
power level. An increase in distortion may also become apparent. When replacing these resistors,
ALWAYS use the Fuse Type OEM part.
PARTS LIST
NOTE: SHADED ITEMS ARE FOR REFERENCE ONLY
PREAMP PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
5 048451000 BUTTON PUSH OFF WHITE @S1-S5
1 033379000 CABLE RIBBON 3 CKT 10” @P3B
1 049334000 CABLE RIBBON 3 CKT 20” @P4B
1 048914000 CABLE RIBBON 8 CKT 7” @P1B
1 048845000 CABLE RIBBON 12 CKT 3-3/4” @P7B
1 033605000 CAP AE RDL .15uF 50V 20% C75
1 038689001 CAP AE AX .47uF 100V C8
2 028458000 CAP AE RDL 1uF 50V 20% C68,72
4 026517001 CAP AE AX 2.2uF 50V C4,16,42,45
12 038692001 CAP AE AX 10uF 35V C9,18,21,24,27,30,33,36,39,41,48,51
2 028456000 CAP AE RDL 22uF 25V 20% C63,81
1 028471000 CAP AE RDL 47uF 50V 20% C59
1 028479000 CAP AE RDL 220uF 25V 20% C70
1 038873001 CAP CA 22PF 100V LL C5
1 004026000 CAP CD 22PF 1000V 10% C69
3 038698001 CAP CA 47PF 100V 10% C3,58,80
1 007029000 CAP CD 220PF 1000V 10% C67
1 039264001 CAP CA 1500PF 100V LL C15
4 038703001 CAP CA .1uF 50V LL C43,44,83,84
1 027278000 CAP MPF .1uF 63V 10% C60
2 027280000 CAP MPF .15uF 63V C13,14
1 027281000 CAP MPF .22uF 63V C82
2 030933000 CAP PFF .0012uF 50V 5% C46,47
2 033579000 CAP PFF RDL .0015uF 100V 10% C65,71
2 030936000 CAP PFF .0022uF 50V 5% C37,38
2 030939000 CAP PFF .0039uF 50V 5% C34,35
2 033582000 CAP PFF RDL .0039uF 100V 10% C61,66
1 033583000 CAP PFF RDL .0047uF 100V 10% C62

BXR 200
PARTS LIST
PREAMP PRINTED CIRCUIT BOARD ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
2 030943000 CAP PFF .0068uF 50V 5% C31,32
2 030929000 CAP PFF 820PF 50V 5% C49,50
2 033588000 CAP PFF RDL .01uF 100V 10% C1,2
2 030946000 CAP PFF .012uF 50V 5% C28,29
1 036234000 CAP PFF RDL .015uF 100V 10% C7
2 030950000 CAP PFF RDL .022uF 50V 10% C25
,
26
3 033590000 CAP PFF RDL .022uF 100V 10% C10,11,12
2 033591000 CAP PFF RDL .033uF 100V 10% C17,40
2 030954000 CAP PFF .047uF 50V 5% C22,23
4 033592000 CAP PFF RDL .047uF 100V 10% C6,64,73,74
2 030959000 CAP PFF RDL .082uF 50V 5% C19,20
2 031087000 CONTROL SNAPIN 25K 2B W/DETENT R19,22 (LOW/HIGH TONE CONTROLS)
9 040673000 CONTROL SLIDE 20MM 50K CTRDET R57-63,77,78 (EQUALIZER)
2 027945000 CONTROL SNAP IN 100K B TAPER R95,100 (RATE, DEPTH)
1 031090000 CONTROL 100K 10A/100K 5C R8 (GAIN)
1 019994000 CONTROL T-POT 100K 20% PC MTG R105
6 006260001 DIODE 1N4448 SIGNAL LL CR1-6
1 027421000 HDR .1 CTR 12 CKT SQ PIN P7A
2 027410000 HDR .1CTR 3CKT AW PIN P2A, P4A
12 016795000 IC DUAL OP AMP TL072 U1-12
1 029671000 IC MN3007 BUCKET BRIGADE U13
1 029672000 IC MN3101 CLOCK GEN/DRIVER U14
2 030771000 JACK ¼ PCB 2/CD SCC J4,5 (SEND, RETURN)
1 030987000 JACK ¼ PCB 3/CD DOC J6 (LINE OUT)
3 037036000 JACK PHONE PCB MONO CA PREMIUM J1,2,3 (INPUTS, FOOTSWITCH)
1 04012000 JACK XLR MALE (A/D XLM-3PV) J7 (LINE OUT)
60 020888001 JUMPER WIRE 22GA W1-60
1 028097000 LED 5X5MM YELLOW SLB-55YY3 LD2
2 028039000 LED RED 5X5MM SLB-55VR3 LD1,3
1 048947001 PCB ASSY PREAMP BXR 200 STUFFED
1 048946000 PCB FAB PRE AMP BXR 200 RAW PCB
1 025818001 RES CF 1/4W 5% 4.7 OHM LL R68
3 024974001 RES CF 1/4W 5% 47OHM LL R109,115,116
3 024965001 RES CF 1/4W 5% 1K LL R79,127,129
1 024969001 RES CF 1/4W 5% 1.5K LL R101
1 024970001 RES CF 1/4W 5% 1.8K LL R121
11 024973001 RES CF 1/4W 5% 3.3K LL R6,25,40,44,48,52,56,66,71,75,96
5 026504001 RES CF 1/4W 5% 3.6K LL R12,18,23,32,36
1 024977001 RES CF 1/4W 5% 4.7K LL R107
3 028034001 RES CF 1/4W 5% 5.1K LL R111,114,117
1 024978001 RES CF 1/4W 5% 5.6K LL R73
1 028948001 RES CF 1/4W 5% 6.2K LL R17
3 024979001 RES CF 1/4W 5% 6.8K LL R30,34,69
5 024980001 RES CF 1/4W 5% 8.2K LL R38,42,46,50,54
18 024981001 RES CF 1/4W 5% 10K LL R4,7,9,10,13,14,21,24,26-28,64,65,87,89,91-93
2 029539001 RES CF 1/4W 5% 13K LL R15,16
5 024986001 RES CF 1/4W 5% 18K LL R97,108,118,119,120
1 029006001 RES CF 1/4W 5% 20K LL R106
1 024987001 RES CF 1/4W 5% 22K LL R67
2 024989001 RES CF 1/4W 5% 33K LL R20,98
4 024993001 RES CF 1/4W 5% 47K LL R29,33,72,94
4 028990001 RES CF 1/4W 5% 51K LL R37,76,123,124
4 024994001 RES CF 1/4W 5% 56K LL R41,45,49,53
3 024995001 RES CF 1/4W 5% 100K LL R31,35,74,86,88,102,112,113,125,126,128
1 028549001 RES CF 1/4W 5% 110K LL R39
6 024998001 RES CF 1/4W 5% 120K LL R43,47,51,55,70,83
2 025059001 RES CF 1/4W 5% 220K LL R82,122
1 025060001 RES CF 1/4W 5% 270K LL R3

BXR 200
PARTS LIST
PREAMP PRINTED CIRCUIT BOARD ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
2 025061001 RES CF 1/4W 5% 330K LL R104,110
1 025065001 RES CF 1/4W 5% 470K LL R99
1 029617001 RES CF 1/4W 5% 750K LL R5
1 025069001 RES CF 1/4W 5% 1M LL R90
1 025075001 RES CF 1/4W 5% 2.2M LL R103
1 025084001 RES CF 1/4W 5% 10M LL R80
1 026549001 RES CF 1/2W 5% 1.5K LL R85
1 028861001 RES CF 1/2W 5% 3.3K LL R84
2 031188000 SCRW M4-40X1/4 PHPS ZI W/WSHR @EQ STANDOFFS
3 9904701440 SPACER LED .7X.125 BLUE @LD1,2,3
2 016746000 STANDOFF RND AL 4-40X1/2X1/4 @EQ PCB
5 028091000 SWITCH PUSH SLFLK SHORT STROKE S1-5
1 014689000 XSTR N-CH JFET J111 TO-92 Q5
4 016793000 XSTR NPN 2N4401 TO-92 Q1,2,4,6
1 016742000 XSTR PNP 2N4403 TO-92 Q3
POWER AMPLIFIER PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 029779* BREAKER THERMAL NC OPEN 248 TS1
8 02845900 CAP AE RDL 2.2uF 50V 20% C1,3,6,16-20
1 028460000 CAP AE RDL 4.7uF 50V 20% C5
5 028471000 CAP AE RDL 47uF 50V 20% C13,14,31,32,34
3 025787000 CAP AE RDL MINI 100uF 16V NP C7,11,12
2 028494000 CAP AE RDL 1000uF 35V 20% C25,26
2 028031000 CAP AE RDL 3300uF 63V C22,23
1 025970000 CAP CD 5PF 1000V 10% C8
2 025982000 CAP CD 68PF 1000V 10% C9,10
1 033580000 CAP PFF RDL .0022uF 100V 10% C4
5 027278000 CAP MPR .1uF 63V 10% C21,27-30
1 024854000 CAP MPF RDL .1uF 400V 10% C15
7 064089001 DIODE 1N4003 LL CR38-41,44-46
25 006260001 DIODE 1N4448 SIGNAL LL CR1-3,5-9,11-14,20,21,24,25,31-37,42,43
2 020534000 DIODE 1N5402 RECTIFER 200V C&F CR28,29
4 028776000 DIODE BIAS BYV26D LEAD FORMED CR16-19
4 025821001 DIODE HV FDH-400 SWITCING LL CR10,15,26,27
1 027329001 DIODE ZEN 1N5228V 3.9V 5% LL CR30
2 027327001 DIODE ZEN 1N5234V 6.2V 5% LL CR22,23
1 031019001 DIODE ZEN 1N5245V.5W 15V 5% LL CR4
21 025802000 FSTN TAB MALE .250X.032 PCB MT CP1,2A,2B,3-16
2 025996000 FUSE CLIP PCB .250 & 5MM FUSE XF1
4 020775000 FUSE CLIP PCB 5MM XF2,3
1 090738000 FUSE QA 1-1/4X1/4 250V 6A F1 (100/120V ONLY)
1 020796 FUSE QA 20MMX5MM 250V 3.15A F1 (EXPORT 220/230/240V ONLY)
2 013112000 FUSE TD 20MMX5MM 250V 1A F2,3
1 027416000 HDR .1 CTR 8 CKT SQ PIN P1A
1 048939000 HEATSINK BAR BXR/KCR 200 MAIN HEATSINK
2 025796000 HEATSINK TO-220 @U3,4
1 027404000 IC CA3080AE OTA U2
1 016795000 IC DUAL OP AMP TL072 U1
1 013562000 IC REGULATOR +15V MC7815CT U3
1 013564000 IC REGULATOR –15V MC 7915CT U4
1 027387000 INDUCTOR AIR CORE RDL 2.5UH L1
4 038815000 INSULATOR SILICONE TO-3P @Q15-18
2 026043000 JUMPER WIRE 18GA .8X.175 JP1,2
27 020888001 JUMPER WIRE 22GA W1-27
1 048843001 PCB ASSY PWR AMP BXR 200 STUFFED
1 048842000 PCB FAB PWR AMP BXR 200 RAW PCB

BXR 200
PARTS LIST
POWER AMPLIFIER PRINTED CIRCUIT BOARD ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
4* 031693001 RES MF FUSE 1/4W 5% 4.7 OHM LL R39-37,40-41
2* 033205001 RES MF FUSE 1/4W 5% 15 OHM LL R27,28
2 024940001 RES CF 1/4W 5% 18 OHM R69-70
1* 027749001 RES MF FUSE 1/4W 5% 22 OHM LL R33
2 024947001 RES CF 1/4W 5% 47 OHM LL R10,11
1 024952001 RES CF 1/4W 5% 100 OHM LL R4
2 024956001 RES CF 1/4W 5% 220 OHM LL R20-21
2 024961001 RES CF 1/4W 5% 470 OHM LL R29-30
1 024963001 RES CF 1/4W 5% 680 OHM LL R67
8 024965001 RES CF 1/4W 5% 1K LL R5,8,17,22,24,25,49,64
7 024971001 RES CF 1/4W 5% 2.2K LL R14,15,18,19,34,35,60
1 024977001 RES CF 1/4W 5% 4.7K LL R51
5 025942001 RES CF 1/4W 5% 7.5K LL R12,52-55
6 024981001 RES CF 1/4W 5% 10K LL R3,47,50,57,58,61
2 024985001 RES CF 1/4W 5% 15K LL R13,65
1 024987001 RES CF 1/4W 5% 22K LL R1
4 024988001 RES CF 1/4W 5% 27K LL R9,16,31,32
1 024989001 RES CF 1/4W 5% 33K LL R2
5 024997001 RES CF 1/4W 5% 100K LL R56,59,62,63,66
1 024998001 RES CF 1/4W 5% 120K KK R48
2 025069001 RES CF 1/4W 5% 1M LL R6,7
1 028029001 RES FILM 1W 5% 1.5K LL R73
1 027627001 RES FILM 1W 5% 10 OHM LL R44
2 036621001 RES CF 1W 5% 6.8K LL R23,26
2 027628000 RES FILM 2W 5% 47 OHM R45,46
4 032958000 RES WW BT 5W 10% .33 OHM R38,39,42,43
1 041256000 RES WW BT 5W 10% 470 OHM R68 (IN BXR 200 ONLY)
2 041595000 SCRW 6-32X3/16 PHP STL ZI SEMS @TS1
8 027638000 SCRW TF 4-40X3/8 HWHS ZI .1” HD @Q13-18, U3,4
5 032908000 SCRW TF 6-32X3/8 PHP ZI PCB TO HEATSINK MOUNT
1 026411000 THERMISTER 2.5OHM 8A C30-19 TH1
1 014689000 XSTR NPN 2N4401 TO-92 Q11,20,21
3 016739000 XSTR NPN 2SC2362K/2SC2389 Q2-4,8
2 028763000 XSTR NPN 2SC3281 TOP-3L Q15,17
1 028760000 XSTR NPN 2SC3298A TOP-220 Q13
1 014867000 XSTR NPN MPSW10 TO-226AE Q10
2 016742000 XSTR PNP 2N4403 TO-92 Q12,22
3 025752000 XSTR PNP 2SA1016K TO-92 Q5,6,7
2 028762000 XSTR PNP 2SA1302 TOP-3L Q16,18
1 028759000 XSTR PNP 2SA1306A TOP-220 Q14
1 014408000 XSTR PNP DRLNGTN MPSA63 TO-92 Q19
1 014866000 XSTR PNP MPSW92 TO-226AE Q9
CHASSIS ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 048953000 CHS ASSY BXR 200 120V COMBP COMPLETE CHASSIS
1 049531 CHS ASSY BXR 200 120V HEAD
1 007565000 BUSHING SR .625X.125X37/64 BLK @ PWR CABLE 100/120V ONLY
1 010401 BUSHING SR .625X.125X37/64 WHT @ PWR CABLE 230/2440V ONLY
1 026541000 CABLE ASSY PWR W/.250 TAB 120V POWER CABLE 120V ONLY
1 048463 CABLE ASSY PWR .250 TAB 100V POWER CABLE 100V ONLY
1 033331 CABLE ASSY PWR 220/240V POWER CABLE AUSTRALIA 240V
1 040993 CABLE ASSY PWR 5A UK .250 TAB PCABLE UNITED KINGDOM 240V
1 047524000 CAP ASSY .1UF 400V W/RECP/TAB @BRIDGE RECTIFIER EMI SUPRESSION
1 024854000 CAP MPF RDL .1UF 400V 10%
1 048948000 CHS BXR 200 COMBO RAW CHASSIS
1 048948000 CHS BXR 200 HEAD RAW CHASSIS, PAINTED & SCREENED

BXR 200
PARTS LIST
CHASSIS ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 032925000 DIODE BRIDGE RECTIFIER
1 048974000 HEATSINK EXTRUDED BXR 200
2 021626 JACK PHONE 2/CD SOC L11 3/8” L SPEAKER OUTPUT JACKS, COMBO ONLY
9 041109000 KNOB EQ BXR SERIES
5 026403000 KNOB POINTER BLACK 180 DEG
3 069393000 NUT 6-32 HEX EXT LOCK GROUNG LUG MOUNT
1 022004000 NUT KEPS #8-32 ZINC BRIDGE RECTIFIER MOUNT
1 048949000 PANEL FRONT BXR 200 COMBO COMBO ONLY
1 048950000 PANEL REAR BXR 200 COMBO COMBO ONLY
6 017716000 SCREW 8-32X1/2 PHP BLX HEATSINK TO CHASSIS MOUNT
2 014172000 SCREW M 4-40X1/4 PHP BLX GEQ MOUNT
4 015627000 SCREW M 6-32X3/4 PH BLX PWR AMP PCB TO CHASSIS MOUNT
4 017433000 SCREW M 6-32X3/8 PHP BLX PREAMP TO PCB TO CHASSIS MOUNT
5 027636000 SCREW TF 8-32X5/8 HWH BLX HEATSINK TO TRANSISTOR BAR
4 037997000 SCREW TF 10-32X5/8 HWHS BLX TRANSFORMER MOUNT
2 031868000 SCRW PLASTITE 4X1/4 PHP BLX @XLR JACK
1 050008000 SHIELD BXR 200 @PREAMP
1 040582000 SWITCH DPST .250 TAB GLOBAL POWER SWITCH
2 029894 WSHR LCK INTL 3/8X.500X.022 NI @ SPEAKER OUTPUT JACKS
5 026401000 WSH SHLDR FIBER 3/8X5/8 EFFECTS LOOP, LINE OUT, OUTPUTS
5 027520000 WSHR FLAT .380X.630 FIBER EFFECTS LOOP, LINE OUT, OUTPUTS
1 048960000 XFMR PWR 120V 200/300 WATT T1 (120V) T1 (120V)
1 041122 XFMR PWR EXPORT T1 (100V/120V/230V)
CABINET ASSEMBLY COMBO VERSION
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 048740000 CAB ASSY BXR 200 COMBO COMPLETE CABINET
REF 026317000 CLOTH GRILLE BLACK PVC
6 031867000 CORNER 2 HOLE W/NOTCH BLX PWDR
2 031840000 CORNER 3 HOLE BLX PWDRD
2 049564000 GASKET HANDL
4 027849000 GLIDE CAB 1.24X.335 BLX WAX STEEL ONLY, NO INSERT
2 048958000 HANDLE RECESSED KXR/BXR NO GASKET
4 019275000 INSERT GLIDE CUSHION 1.27 DIA RUBBER ONLY
1 011298000 NAMEPLATE FENDER SAMLL LOGO
12 021972000 NUT T 10-32X3/4 STR 3 PRNG BLX SPEAKER MOUNT
6 036199000 SCREW M 8-32X1-3/16 OHP BLX CP CHASSIS MOUNT
3 038796000 SCRW 8X1-1/2 PFH SM ZI
8 026577000 SCRW M 10-32X1 PHP BLX SPEAKER MOUNT
2 018113000 SCRW SMA 4X1/2 OHP BLX LOGO MOUNT
8 016627000 SCRW SMA 8X3/4 OHP BLX
14 026576000 SCRW SMA 8X5/8 THP BLACK
4 017942000 SCRW WOOD 8X1 FHP BLX
1 048941 SPEAKER 15” 4 OHM 150W BXR 200
REF 026570000 TOLEX BLACK LT WEIGHT
6 029527000 WSHR FNSH 8-5/8 FLNGD BLX WX CHASSIS MOUNT
CABINET ASSEMBLY HEAD VERSION
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 049059 CABINET ASSY BXR 200 HEAD COMPLETE CABINET
8 048976 FOOT RUBBER 1-1/2”
4 031838 CORNER 2 HOLE W/TAB BLK PWDRD
4 031867 CORNER 2 HOLE W/NOTCH BLK PWDR
2 031845 HANDLE CAP 2 HOLD BLK PWDRD HANDLE MOUNT

BXR 200
PARTS LIST
CABINET ASSEMBLY HEAD VERSION (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 025883 HANDLE SHORT NO LOGO RUBBER ONLY, NO INSERT
1 025884 HANDLE INSERT 7.78” SPRING STEEL
4 021972 NUT T 10-32X3/4 STR 3 PRNG BLX HANDLE MOUNT
4 017393 SCRW M 10-32X1-1/8 OHP BLX HANDLE MOUNT
8 026576 SCRW SMA 8X5/8 THP BLACK CORNER MOUNT
8 018988 SCRW SMA 8X1-1/8 PHP BLX FOOT MOUNTING
MISCELLANEOUS
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 048951 MANUAL OWNERS BXR 200
1 048944 SCHEM REDUCED BXR 200 PREAMP PREAMP
1 048840 SCHEM REDU W/SVC PA BXR/KXR200 POWER AMP
