FERREX MS225-53E User manual

Dok./Rev.-Nr. 100903_220411
3
Contents
User Manual
LAWN MOWER
MS225-53E
YEARS
WARRANTY
5
Made in China
FERREX®is a registered trademark of ALDI Stores
DISTRIBUTED BY:
ALDI STORES
1 SARGENTS ROAD
MINCHINBURY NSW 2770
www.aldi.com.au
AUS
ALDI guarantees that our exclusive brand products are developed to our
stringent quality specifications. If you are not entirely satisfied with this
product, please return it to the nearest ALDI store within 60 days from the
date of purchase, for a full refund or replacement, or take advantage of our
after sales support by calling the supplier’s Customer Service Hotline.
Original instructions
Warning: Read the instructions before using the machine
MODEL:
MS225-53E
suppor[email protected]
1300 855 831
AFTER SALES SUPPORT
AUS
10093
09/2022
Overview
1
2
3
5
4
6 7
10
9
8
12
13
14
15
16
17
18
19
d
b
c
4
a
f
e
12 20
22 21
11
g
i
5a
1b
1
Overview..............................................................................03
Utilisation.............................................................................04
Contents of Box....................................................................06
Explanation of symbols.......................................................07
Introduction.........................................................................09
Layout................................................................................... 10
Scope of delivery ..................................................................11
Intended use.........................................................................11
Safety regulations ................................................................13
Technical data.......................................................................21
Before first use..................................................................... 22
Operation............................................................................. 24
Cleaning ............................................................................... 32
Transport.............................................................................. 32
Storage................................................................................. 33
Maintenance ........................................................................34
Troubleshooting..................................................................38
Disposal and recycling.........................................................39
Warranty Details ..................................................................33
Repair and refurbished goods or parts notice ..................34

4 5 6
Contents of Box
Lawn mower
Round head screw M8
Washer small
Washer big
Plastic star grip nut
Cable clip
Screw
Velcro
Mulch insert
1 x
4 x
2 x
2 x
4 x
1 x
4 x
1 x
4 x
Side discharge
Battery
Battery Charger
Warranty Certicate
1 x
1 x
1 x
1 x
Manual
1 x
Utilisation
4
d
a
c
5
a
c
d
6
4
c
5
d
b
3
7
4
9
f
18 3
2
5
35
8
3
18
13
11
e
kein Bild vorhanden
12
17
15
20
16
16
17
14
10
15
15
14
20
5a

AUS
GS650F <Chapter>
Text
19
20
22
18
18
3
19
2
25
12
21
12
min.
23
max.
11
AUS
MS225-53E
24

AUS
<Chapter> GS650F
Text
22
29
30
28
9
9
21
20
27
21
20
26
23
23
7
g
9
31
W
22
33
KLICK 21
22
32
KLICK
22
AUS
MS225-53E

Explanation of symbols
Observe all safety instructions before use.
Caution - Read the operating instructions to reduce
the risk of injury!
On a slope, do not mow uphill or downhill.
Before operating the lawn mower, remove lawn debris
which may be ejected by the blade.
There is a risk of debris being ejected when the engine
is running. Make sure you keep a safe distance.
Make sure other people also keep a safe distance.
Remove the ignition cable before all maintenance
work, and read the instructions for use.
Warning! Risk of injury! Do not let your hands or feet
come in contact with the blades when the motor is run-
ning.
Important. Exhaust gas is poisonous, do not operate in
an unventilated area.
Danger - Hot surface!
Wear ear-mu󰀨s and safety goggles!
Wear safety shoes!
Wear safety gloves!
AUS
MS225-53E Explanation of symbols
AFTER SALES SUPPORT 07
 1300 855 831  [e-mail]
MODEL: MS225-53E PRODUCT CODE: 10093 09/2022

AUS
<Chapter> GS650F
Text Attention! Operating materials are ammable and ex-
plosive.
Do not ll with fuel while the motor is hot or running.
Fuel tank capacity.
Length knives. Max. Cutting width.
98
Guaranteed sound power.
MIN
MAX
Check oil level.
Protect the battery from heat and re.
Protect the battery from temperatures above 45 °C.
Protect the battery from water and moisture.
Protection class II.
This charger is designed for indoor-use only.
Polarity.
5Warranty period.
Made in China
Comply with the Australian norms and directive.
Warranty class.
08 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: MS225-53E PRODUCT CODE: 10093 09/2022
AUS
Explanation of symbols MS225-53E

I. Introduction
Congratulations on choosing to buy a FERREX®product.
All products brought to you by FERREX®are manufactured to the highest
standards of performance and safety, and as part of our philosophy of customer
service and satisfaction, are backed by our comprehensive 5Years Warranty.
We hope you will enjoy using your purchase for many years to come.
Note:
According to the applicable product liability law the manufacturer of this product is
not liable for damages which arise on or in connection with this product in case of:
• improper handling,
• non-compliance with the instructions for use,
• repairs by third party, non-authorised skilled workers,
• installation and replacement of non-original spare parts,
• improper use.
Recommendations:
Read the entire text of the operating instructions prior to the assembly and operation
of the lawn mower.
These operating instructions are intended to make it easier for you to get familiar
with your lawn mower and utilise its intended possibilities of use.
The operating instructions contain important notes on how to work safely, proper-
ly and economically with your lawn mower and how to avoid dangers, save repair
costs, reduce downtime, and increase the reliability and working life of the lawn
mower.
In addition to the safety regulations contained herein, you must in any case comply
with the applicable regulations of your country with respect to the operation of the
lawn mower.
Put the operating instructions in a clear plastic folder to protect them from dirt and
humidity, and store them near the lawn mower. The instructions must be read and
carefully observed by each operator prior to starting the work. Only persons who
have been trained in the use of the lawn mower and have been informed on the
related dangers and risks are allowed to use the lawn mower. The required minimum
age of 16 years must be met.
In addition to the safety notes contained in the present operating instructions and
the special regulations of your country, the generally recognised technical rules for
the operation of this lawn mower must be observed.
AUS
MS225-53E Introduction
AFTER SALES SUPPORT 09
 1300 855 831  [e-mail]
MODEL: MS225-53E PRODUCT CODE: 10093 09/2022

AUS
<Chapter> GS650F
Text
II. Layout (Fig. 1-26)
1. Handle
1b. Pull cord holder
2. Drive lever
3. Upper push bar
4. Quick clamp lever
5. Lower push bar
5a. Locking lever
6. Fuel tank / fuel tank cap
7. Air lter cover
8. Idler
9. Spark plug
10. Exhaust pipe
11. Oil dipstick
12. Side discharge (side discharge ap and side discharge adapter)
13. Drive wheel
14. Wheel height adjustment
15. Pull cable starter
16. Discharge ap
17. Catch basket
18. Electric starter unit
19. Electric starter
20. Mulching insert
21. Battery
22. Battery charging unit
23. Filter
10 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: MS225-53E PRODUCT CODE: 10093 09/2022
AUS
Layout MS225-53E

AUS
GS650F <Chapter>
Text
AFTER SALES SUPPORT 11
 1300 855 831  [e-mail]
MODEL: MS225-53E PRODUCT CODE: 10093 09/2022
III. Scope of delivery
Fig. 1. (a - i)
a) 2 x Round-headed screws M8
b) 4 x Washer, small
c) 2 x Washer, large
d) 4 x Plastic star nut
e) 1 x Cable clip
f) 3x Screws
g) Spar plug wrench
h) 1x Operating manual
i) 1 x Key
• Mulching insert (20)
• Side discharge (12)
• Rechargeable battery (21)
• Battery charging unit (22)
• Filter (23)
• Open the packaging and take out the lawn mower carefully.
• Remove the packaging material as well as the packaging and transport bracing (if
available).
• Check that the delivery is complete.
• Check the lawn mower and accessory parts for transport damage.
• If possible, store the packaging until the warranty period has expired.
m Attention!
The lawn mower and packaging materials are not toys!
Children must not be allowed to play with plastic bags, lm and small parts!
There is a risk of swallowing and su󰀨ocation!
IV. Intended use
Before starting any work, all protective and safety devices must be in place.
• The machine has been designed to be operated by one person.
• The operator is responsible for third parties in the area of operations.
• All safety and hazard notices on the machine must be observed.
• All safety and hazard notices on the machine must be kept in a completely legible
condition.
AUS
MS225-53E Scope of delivery/Intended use

AUS
<Chapter> GS650F
Text
• Use the machine in a technically awless condition only, as well as for its intended
purpose, in a safe manner and being aware of dangers, in compliance with the
operating instructions!
• Disruptions which can a󰀨ect safety in particular must be eliminated straight away!
• The manufacturer’s safety, operation and maintenance instructions as well as the
technical data given in the calibrations and dimensions must be adhered to.
• Relevant accident prevention regulations and other generally recognized safety and
technical rules must also be adhered to.
• The machine may only be used, maintained or repaired by trained persons who are
familiar with the machine and have been informed about the dangers. Unauthorized
modications of the machine exclude a liability of the manufacturer for damages
resulting from the modications.
• The machine is intended for use only with original spare parts and original tools
from the producer.
• Any other use is considered to be not intended. The manufacturer excludes any
liability for resulting damages, the risk is exclusively borne by the user.
• The device must not be used for commercial, technical or industrial applications.
• If you are not sure whether working conditions are safe or unsafe, do not work with
the machine.
• The petrol lawn mower is intended for private domestic use. This product is not
intended for commercial, industrial or trade use.
Important! Due to the high risk of bodily injury to the user, the lawn mower may not
be used to trim bushes, hedges or shrubs, to cut scaling vegetation, planted roofs,
or balcony-grown grass, to clean (suck up) dirt and debris o󰀨 walkways, or to chop
up tree or hedge clippings. Moreover, the lawn mower may not be used as a power
cultivator to level out high areas such as molehills.
• For safety reasons, the lawn mower may not be used as a drive unit for other work
tools or tool kits of any kind.
•
mWARNING
For your own safety, please thoroughly read this manual and the general safety in-
structions before turning the device on. If you give the device to third parties, always
include these instructions.
12 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: MS225-53E PRODUCT CODE: 10093 09/2022
AUS
Intended use MS225-53E

AUS
GS650F <Chapter>
Text
V. Safety regulations
These operating instructions provide places concerning your safety which
are marked with this indication: m
Furthermore this manual contains other important sections which are
marked with the word "Attention!".
mDANGER
Failure to follow these instructions may cause serious danger to life of
danger or fatal injuries.
mWARNING
Failure to follow these instructions may cause danger to life or danger
of serious injuries.
mCAUTION
Failure to follow these instructions may cause light to medium risk of
injury.
mNOTE
Failure to follow these instructions may cause danger of damage of the
engine or other property values.
mCAUTION
When using the equipment, a few safety precautions must be observed
to avoid injuries and damage. Please read the complete operating in-
structions and safety regulations with due care. Keep this manual in a
safe place, so that the information is available at all times. If you give the
equipment to any other person, hand over these operating instructions
and safety regulations as well. We cannot accept any liability for damage
or accidents which arise due to a failure to follow these instructions and
the safety instructions.
AFTER SALES SUPPORT 13
 1300 855 831  [e-mail]
MODEL: MS225-53E PRODUCT CODE: 10093 09/2022
AUS
MS225-53E Safety regulations

AUS
<Chapter> GS650F
Text
The following must not use the machine:
Children and other people who do are not familiar with the operating
manual (local stipulations may specify a minimum age for users).
People under the inuence of alcohol, drugs and medication, as well as
those who are tired or ill.
1. Safety instructions for handoperated lawn mowers
Note
• Read the directions with due care. Know your controls. Read the owner’s
manual carefully. Learn how to stop the engine quickly in any emergency
Familiarize yourselfwiththesettingsandproperoperationofthemachine.
Never allow children or other persons who are not familiar with the op-
erating instructions to use the mower. Contact your local governmental
agency for information regarding minimum age requirements for oper-
ating the mower.
• Never mow in the direct vicinity of persons - especially children - or
animals. Always keep in mind that the operator is responsible for acci-
dents involving other persons and/or their property.
• If you give the equipment to any other person, give them these operat-
ing instructions as well.
• Always wear sturdy, non-slip footwear and long trousers when mowing.
Never mow while barefoot or wearing open sandals, or thongs.
• Check the grounds on which the machine will be used and remove all
objects such us stones, wires, toys, wood and so on. They could be
thrown by the blade.
• The lawnmower shall not be operated without either the entire grass
catcher or self-closing discharge opening guard in place
•
mWARNING
Petrol is highly ammable! Therefore:
• Only store petrol in containers designed to hold petroleum-based liq-
uids.
• Only refuel out in the open and do not smoke during the refueling pro-
cess.
• Always refuel the lawn mower before starting the engine. Always en-
sure that the fuel tank cap is closed when the engine is running and
when the mower is hot; also do not refuel.
14 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: MS225-53E PRODUCT CODE: 10093 09/2022
AUS
Safety regulations MS225-53E

AUS
GS650F <Chapter>
Text
• If petrol has overowed, do not under any circumstances attempt to
start the engine. Instead, remove the machine from the a󰀨ected area.
Avoid starting the engine until the petrol fumes have completely evap-
orated.
• For safety reasons, the petrol tank and other tank closures must be
replaced if they are damaged.
• Replace defective mu󰀪ers.
• Before using the mower, visually inspect it to ensure that the blade,
mounting bolts and the entire cutting apparatus are in good working
order (i.e. not worn out or damaged). To prevent any imbalance, re-
place worn out or damaged blades and mounting bolts as a set only (if
applicable).
• Please note that where a mower has more than one blade, the rotation
of one of the blades can cause the others to rotate as well.
Handling
• Do not let the combustion engine run in enclosed areas, as dangerous
carbon monoxide gas can build up.
• Only mow in broad daylight or in well-lit conditions. Avoid using the
machine on wet grass as far as possible.
• Do not use the lawn mower in a thunderstorm - risk of lightning strike!
• Always maintain good footing on inclines.
• Only operate the machine at a walking pace.
• For machines with wheels: Always mow across hills i.e. never straight
up or straight down.
• Be particularly careful when you change direction on a slope.
• Do not mow on overly steep inclines.
• Always be extra careful when turning the mower around and when pull-
ing it towards you.
• Switch o󰀨 the lawn mower and ensure that the blade has stopped ro-
tating whenever the mower has to be tilted for transporting over areas
other than lawns and whenever it has to be moved from or to the area
you want to mow.
• Never use the lawn mower if the blade or safety grilles are damaged,
or without the attached guards, e.g. deectors and/or grass catching
devices.
• Do not adjust or overclock the engine speed settings.
• Release the engine brake before you start the engine.
AFTER SALES SUPPORT 15
 1300 855 831  [e-mail]
MODEL: MS225-53E PRODUCT CODE: 10093 09/2022
AUS
MS225-53E Safety regulations

AUS
<Chapter> GS650F
Text
• Start the engine with care, in accordance with the manufacturerʼs in-
structions. Make sure that your feet are far enough away from the mow-
er blade!
• Do not tilt the lawn mower when you start the engine unless the mower
must raised o󰀨 of the ground a little in order to start it. In the latter case,
tilt the mower as little as absolutely necessary and only raise the side
opposite to that of the user.
• Never start the engine while standing in front of the chute.
• Never move your hands or feet toward or under any rotating parts.
Keep clear of the chute opening at all times.
• Never lift or carry a lawn mower with the engine running.
• Switch o󰀨 the engine and pull the spark plug boot. Make sure that all
rotating parts are stopped:
– before you dislodge any blockages or clogs in the chute.
– before carrying out any checks, cleaning, maintenance or other work
on the lawn mower
– if the lawn mower strikes a foreign body, examine it for signs of dam-
age and carry out any necessary repairs before restarting and contin-
uing to work with the mower. If the lawn mower begins to experience
exceptionally strong vibrations, immediately switch it o󰀨 and check it.
• Switch o󰀨 the engine:
– when you leave the lawn mower.
– before you refuel.
• Operation of the machine at higher than normal speed can lead to an
increased risk of accidents.
• Take care when carrying out installation work on the machine, and
avoid trapping ngers between the moving cutting tool and the xed
parts of the machine.
• Please be particularly careful when mowing on ground that may sub-
side, on nearby landlls, trenches and embankments.
• Observe improper maintenance, the use of non-compliant spare parts,
or removal or modication of the safety devices may result in damage
to the device and serious injury to the person working with it.
• Use only manufacturer recommended cutting tools and accessories.
The use of other tools and other accessories may cause injury to the
user. Always keep the lawnmower in good working condition.
• Check the device regularly and make sure before each use that all start
locks and push buttons function properly.
16 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: MS225-53E PRODUCT CODE: 10093 09/2022
AUS
Safety regulations MS225-53E

AUS
GS650F <Chapter>
Text
• Please note that the safety systems or features of the lawnmower must
not be tampered with or deactivated.
• Note that the user should not modify or manipulate any sealed engine
speed control settings.
• The user must be adequately trained in use, adjustment and operation
(including prohibited operations).
• It is necessary to take su󰀩cient breaks to reduce the noise and vibra-
tion load.
• Never cut grass while walking backwards.
• Stop the engine before pushing mower across gravel drives, walks or
roads.
• Never pick up or carry a mower when it is operating
Residual risks and accident prevention standards
Neglect of ergonomic principles
Negligent handling of personal protective equipment (PPE)
Negligent handling or omission of the personal protective equipment may
cause serious injuries.
– Wear prescribed personal protection equipment.
Human behaviour, misbehaviour
– For any work be fully concentrated.
mResidual risks - Cannot be entirely excluded.
Danger from noise
hearing damage
Prolonged unprotected work with the device may
cause hearing damage.
– Always wear ear-mu󰀨s.
In case of emergency
In case of a possibly occurring accident take the necessary rst aid steps
as appropriate and obtain qualied medical aid as quickly as possible.
During longer work, because of vibrations, there is a risk of circulation
problems in the user‘s hands (white-nger-syndrome). White-nger-syn-
drome is a vascular disease where the small blood vessels in ngers
and toes contract seizure-like. The a󰀨ected areas are no longer supplied
with blood and therefore look very pale. Frequent use of vibrating ma-
AFTER SALES SUPPORT 17
 1300 855 831  [e-mail]
MODEL: MS225-53E PRODUCT CODE: 10093 09/2022
AUS
MS225-53E Safety regulations

AUS
<Chapter> GS650F
Text
chines can cause nerve damage in people whose circulation is compro-
mised (e.g. smokers, people with diabetes).
If you notice unusual impairment, immediately stop the work and consult
a doctor. Observe the following notices in order to reduce risks:
• Keep your body, and particularly your hands, warm in cold weather.
• Take regular breaks during which you should move your hands to
promote circulation.
• Ensure the lowest possible vibration of the machine by regularly main-
taining it and keeping components tight.
2. Safety instructions for battery and charger
These operating instructions provide places concerning your safety
which are marked with this indication: m
Furthermore this manual contains other important sections which are
marked with the word „Attention!“.
mDANGER
Failure to follow these instructions may cause serious danger to life of
danger or fatal injuries.
mWARNING
Failure to follow these instructions may cause danger to life or danger of
serious injuries.
mCAUTION
Failure to follow these instructions may cause light to medium risk of
injury.
mNOTE
Failure to follow these instructions may cause danger of damage of the
engine or other property values.
18 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: MS225-53E PRODUCT CODE: 10093 09/2022
AUS
Safety regulations MS225-53E

AUS
GS650F <Chapter>
Text
mCAUTION
When using the equipment, a few safety precautions must be observed
to avoid injuries and damage. Please read the complete operating in-
structions and safety regulations with due care. Keep this manual in a
safe place, so that the information is available at all times. If you give the
equipment to any other person, hand over these operating instructions
and safety regulations as well. We cannot accept any liability for damage
or accidents which arise due to a failure to follow these instructions and
the safety instructions.
Improper use of the battery and charger can result in an electrical
shock or re.
When Operating
• Keep battery charger dry. Avoid exposing battery pack to rain or wet
conditions.
• To reduce the risk of electrical shock, do not allow water to ow into
AC plug.
• Do not short circuit; never place any object into the battery contacts.
When Charging Battery Pack
• Charge original battery pack only with original battery charger.
• Do not use battery charger to charge non-rechargeable batteries.
• Keep battery charger dry. Avoid exposing battery pack to rain or wet con-
ditions.
• To reduce risk of damage to electric plug and cord, pull by plug rather than
cord when disconnecting charger.
• Do not operate charger with damaged plug or cord. The supply cord can-
not be replaced. If the cord is damaged, the charger should be replaced
immediately.
• Do not operate charger if it has received a sharp blow, been dropped, or
otherwise damaged in any way. If charger is damaged it must be replaced.
Charger is not serviceable.
• Do not disassemble charger; or attempt to service.
• To reduce risk of electric shock, unplug charger from outlet before clean-
ing.
• Do not short circuit; never place any object into the battery contacts.
• The charger is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
AFTER SALES SUPPORT 19
 1300 855 831  [e-mail]
MODEL: MS225-53E PRODUCT CODE: 10093 09/2022
AUS
MS225-53E Safety regulations

AUS
<Chapter> GS650F
Text
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the
charger.
Extension Cord
An extension cord should not be used unless absolutely necessary. Use
of improper extension cord could result in a risk of re and electric shock.
If an extension cord must be used, make sure that;
a) Pins on plug of extension cord are the same number, size, and shape
as those of plug on charger,
b) Extension cord is properly wired and in good electrical condition, and
c) Wire size is a minimum of 16 AWG (American Wire Gauge) to allow
for AC ampere rating of charger.
When Storing Battery Pack
• Keep battery charger dry. Avoid exposing battery pack to rain or wet
conditions.
Before Performing Adjustments Or Repairs
• Remove battery pack from engine battery tray.
WARNING
Battery chemicals are toxic and corrosive.
Fire or explosion can cause severe burns or death.
• Never burn or incinerate discarded or used battery packs as they may
explode. Toxic fumes and materials are created when battery packs
are burned.
• Do not use a battery that has been crushed, dropped or damaged.
Warning! This electric tool generates an electromagnetic eld during
operation. This eld can impair active or passive medical implants un-
der certain conditions. In order to prevent the risk of serious or deadly
injuries, we recommend that persons with medical implants consult with
their physician and the manufacturer of the medical implant prior to op-
erating the electric tool.
20 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: MS225-53E PRODUCT CODE: 10093 09/2022
AUS
Safety regulations MS225-53E

AUS
GS650F <Chapter>
Text
VI. Technical data
Lawn mower:
Type engine Four stroke engine
Cubic capacity 224 cm3
Rotation speed 2800/min
Fuel Regular grade petrol/lead-free max. 5% bioethanol
Capacity tank/petrol 1200 mL
Motor oil SAE 30/10W30
Capacity tank/oil 400 mL
Cutting height adjustment 25 - 75 mm / 8-level
Collection bag capacity 65 l
Cutting width 53 cm
Cutting blade model 602037
Weight (empty tanks) 37 kg
Power 4.4 kW
Subject to technical changes!
Information concerning noise emission measured according to relevant standards:
Sound pressure level at the operator position LpA = 84.6 dB(A)
Uncertainty KPA = 3 dB(A)
Sound power level LWA = 96.2 dB(A)
Guaranteed sound power level = 98 dB(A)
Uncertainty KWA = 1.86 dB(A)
WARNING Wear ear-mu󰀨s.
The impact of noise can cause damage to hearing.
Vibration Ahv = 7.218 m/s2
Uncertainty K= 1.5 m/s2
Reduce noise generation and vibration to a minimum!
• Use only equipment that is in perfect condition.
• Maintain and clean the equipment regularly.
• Adopt your way of working to the equipment.
• Do not overload the equipment.
• Have the equipment checked if necessary.
• Switch o󰀨 the equipment when not in use.
• Wear gloves.
AFTER SALES SUPPORT 21
 1300 855 831  [e-mail]
MODEL: MS225-53E PRODUCT CODE: 10093 09/2022
AUS
MS225-53E Technical data

When using the petrol lawn mower for extended periods, vibration-induced circulatory
problems may occur (white nger disease).
We cannot give exact details about the duration of use in this case because it is dif-
ferent for each individual.
The following factors can inuence the condition:
• Circulatory problems in the user’s hands
• Low outside temperatures
• Extended periods of use
We therefore recommend you wear warm work gloves and take regular breaks.
Battery (A200) and charger (JLH122200370S):
Lithium-ion battery system 20V d.c. 2.0 Ah / Li-Ion
Number of battery cells 5
Charger input 100-240VAC, 50-60Hz, 15W
Charger output 22V DC, 370mA, 9.87W max.
Charger protection class IPX0, Class II
Subject to technical changes!
VII. Before rst use
m ATTENTION!
Always make sure the device is fully assembled before commissioning!
Some parts of the mower come disassembled. For quick and easy assembly, read
and follow the instructions below.
Note!
You will need the following additional tools (not supplied) for assembly, and also for
maintenance work:
• One oil collecting tray, at (for oil change)
• A 1 litre measuring beaker (oil / petrol-proof)
• A petrol canister (5 litres are su󰀩cient for approx. 6 operating hours)
• A funnel (to suit the petrol ller neck of the tank)
• Household wipes (to wipe up oil/petrol residue; dispose of these at a lling station)
• A petrol suction pump (plastic version, available in DIY stores)
• An oil can with hand pump (available in DIY stores)
22 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: MS225-53E PRODUCT CODE: 10093 09/2022
AUS
Technical data/Before rst use MS225-53E
