Ferroli FG Troubleshooting guide

,
cod. 3540I950 — 06/2007 (Rev. 00)
FG
INSTRUCTIONS FOR USE, INSTALLATION AND MAINTENANCE
INSTRUCTIONS D'UTILISATION, D'INSTALLATION ET D'ENTRETIEN
KULLANMA, KURULUM VE BAKøM TALIMATLARø

FG
2GB
B
Declaration of conformity
Manufacturer: FERROLI S.p.A.
Address: Via Ritonda 78/a 37047 San Bonifacio VR Italy
declares that this unit complies with the following EU directives:
• Low Voltage Directive 73/23 (amended by 93/68)
• Electromagnetic Compatibility Directive 89/336 (amended by 93/68)
President and Legal Representative
Cav. del Lavoro
Dante Ferroli
BThis symbol indicates "Caution" and is placed next to all safety warnings. Strictly follow
these instructions in order to avoid danger and damage to persons, animals and things.
AThis symbols calls attention to a note or important notice.
cod. 3540I950 - 06/2007 (Rev. 00)
• Carefully read the warnings in this instruction book-
let since they provide important information on safe
installation, use and maintenance.
• This instruction booklet is an integral part of the
product and must be carefully kept by the user for fu-
ture reference.
• If the unit is sold or transferred to another owner or if
it is to be moved, always make sure that the booklet
accompanies the boiler so that it can be consulted
by the new owner and/or installer.
• Installation and maintenance must be carried out by
professionally qualified personnel, according to cur-
rent regulations and the manufacturer's instructions.
• Incorrect installation or poor maintenance can cause
damage or physical injury. The manufacturer de-
clines any responsibility for damage caused by er-
rors in installation and use or by failure to follow the
manufacturer's instructions.
• Before carrying out any cleaning or maintenance op-
eration, disconnect the unit from the electrical power
supply using the switch and/or the special cut-off de-
vices.
• In case the unit breaks down and/or functions poorly,
deactivate it, do not make any attempt to repair it or
directly intervene. Contact professionally qualified
personnel. Any repair/replacement of products must
only be carried out by qualified professional person-
nel using exclusively genuine parts. Failure to com-
ply with the above could affect the safety of the unit.
• Periodical maintenance carried out by qualified per-
sonnel is essential for guaranteeing good operation
of the unit.
• This unit must only be used for the purpose for which
it was designed. Any other use is considered im-
proper and therefore hazardous.
• After removing the packing, check the integrity of the
contents. Packing materials must not be left within
the reach of children as they are potentially hazard-
ous.
• In case of doubt do not use the unit, and contact the
supplier.
• The images shown in this manual are a simplified
representation of the product. In this representation
there may be slight, unimportant differences with the
supplied product.

FG
3
, cod. 3540I950 - 06/2007 (Rev. 00)
1 Operating instructions ............................................................................................................ 4
1.1 Introduction.............................................................................................................................................4
1.2 Control panel ..........................................................................................................................................4
1.3 Lighting and shutdown ...........................................................................................................................5
1.4 Adjustments............................................................................................................................................6
2 Installation................................................................................................................................ 8
2.1 General Instructions ...............................................................................................................................8
2.2 Place of installation ................................................................................................................................8
2.3 Plumbing connections ............................................................................................................................8
2.4 Safety coil connection (optional) ............................................................................................................9
2.5 Electrical connections...........................................................................................................................10
2.6 Connection to the flue ..........................................................................................................................11
3 Service and maintenance...................................................................................................... 12
3.1 Adjustments..........................................................................................................................................12
3.2 Startup..................................................................................................................................................12
3.3 Maintenance.........................................................................................................................................12
3.4 Troubleshooting....................................................................................................................................14
4 Technical data and characteristics ...................................................................................... 15
4.1 Dimensions, connections and main components .................................................................................15
4.2 Pressure loss........................................................................................................................................16
4.3 Technical data table .............................................................................................................................16
4.4 Wiring diagram .....................................................................................................................................17

FG
4GB
cod. 3540I950 - 06/2007 (Rev. 00)
1. Operating instructions
1.1 Introduction
Dear Customer,
Thank you for choosing a FERROLI boiler featuring advanced design, cutting-edge technology, high reliability and qual-
ity construction. Please read this manual carefully since it provides important information on safe installation, use and
maintenance.
FG is a wood-burning steel boiler, with total gasification. It exploits the principle of reverse flame combustion, with grad-
ual burning of the wood, to the advantage long operation times before refuelling. In fact, thanks to a variable-speed fan
located at the back of the boiler, combustion occurs in a negative pressure. the lit wood, placed in a holder above a
special grill, develops a particular type of combustion which, thanks to the high temperature determined by a balanced
supply of primary combustion air from above and secondary air injected through the separation grill, turns the cellulose
into simpler compounds that burn in the underlying combustion chamber with a flame similar to that of natural gas, with
efficiencies exceeding 85%. In the wood loading stage the fan is activated when the door is opened, thus preventing
smoke from escaping.
The outer casing consists of painted steel panels, insulated internally with mineral wood to ensure optimum insulation
of the boiler body. A safety exchanger for eliminating the excess heat can be installed by request.
1.2 Control panel
fig. 1 - Control panel
Key
1Control panel
2Wood loading door
3Combustion chamber/ash compartment door
4Combustion air adjustment
5Heating temperature adjustment + - buttons
6Button M, Summer/Winter "Mode" changeover
7Parameter editing + - buttons
8Button R, configuration menu access
9Display
10 Lighting switch
During operation, the display shows the system delivery temperature.

FG
5GB cod. 3540I950 - 06/2007 (Rev. 00)
1.3 Lighting and shutdown
Fuel
The boiler must only operate with normal and untreated wood. The logs can be 50 cm long for models FG30 and FG40,
and 70 cm for model FG50. Pressed fuels and briquettes can also be used, provided they are entirely of wood.
BThe burning of waste, plastic or liquids can create dangerous burnt gases with risk of poisoning, death or ex-
plosion.
• Only use the specified fuels.
• In the presence of risk of explosion, fire, burnt gases or fumes, put the boiler out of service.
• The boiler must only be operated by adults who are familiar with the boiler instructions and its operation.
• The user is only authorised to start the boiler, set the heating temperature, put it out of service and clean it.
• Keep unsupervised children away from the boiler when it is operating.
• Do not burn liquids or use them to increase boiler performance.
• Only use non-flammable agents to clean the surface of the boiler.
• Do not place flammable objects on or near the boiler.
• Do not place flammable materials in the boiler installation compartment (e.g. wood, paper, petroleum, gas oil).
Wood is an extremely heterogeneous fuel for type, moisture content, shape and size. Boiler heating efficiency depends
on the type of wood used and its moisture content, as well as the method of loading and size of the fuel. Excellent quality
woods are oak, ash, beech, maple and fruit trees except cherry; chestnut and birch are good quality; lime, poplar and
willow are of adequate quality. Resiniferous woods are generally mediocre fuels. The higher the moisture-content, the
lower the heating power. The use of fuels that are not dry causes losses of efficiency. Use logs dried outdoors and in
the natural state (stored for 2 years with max. moisture content 20%).
Boiler lighting
• Open the bottom door and remove any ash present in the combustion chamber. Close the bottom door.
• Switch on the power to the unit. Turn the switch to ON.
• Open the top door. Place some paper and kindling on the burner plate.
• Light the fuel and add some slightly larger pieces of wood.
• Close the door and wait for a first bed of embers to form.
• Open the top door slowly to allow the fan to suck the smoke accumulated in the firewood holder.
• Spread the embers evenly on the burner plate, using a poker.
• Load wood when the bed of embers has formed on the main stone.
Loading wood
• Proceed with loading wood which must be 50 cm long for models FG30 and FG40, and approx. 70 cm for model
FG50.
• Since regular falling of the wood is essential for good combustion, make sure that the length of the pieces of wood
introduced, their shape and method of loading do not hinder it. The pieces must be arranged lengthwise and hori-
zontally. No pieces must be inclined or placed sideways.
• Consume the wood as much as possible before loading more.
• New loading can be carried out when the bed of embers in the holder is approx. 5 cm deep.
• Open the top loading door slowly.
• Arrange the new load of wood in the same way as previously described.
B- Pieces that are too long do not fall regularly, causing empty spaces in the wood holder, with the formation of
unburnt wood areas.
- Pieces that are too short cause uneven air passages, with a decrease in power and efficiency.
- Always open the top door slowly, in order to avoid puffs and the creation of smoke.
- Never open the bottom door during operation.
- During loading avoid keeping the top door open for long periods.
- In case of operation with reduced performance, low temperature distilled gases can form, with risk of poison-
ing if breathed.
- If dense smoke can be seen, do not breathe it.
- Make sure the installation room is well-ventilated.
- Clean the boiler and gas exhaust ducts as prescribed.

FG
6GB
cod. 3540I950 - 06/2007 (Rev. 00)
Boiler shutdown
To shut down the boiler, allow all the fuel to be burned.
Shutdown for short periods
For short shutdown periods, turn the lighting switch to OFF after the fuel has finished and the boiler has cooled.
• Clean the loading door support surfaces and the loading compartment.
• Remove the ashes and clean the combustion chamber.
• Close the ash compartment door and the loading door.
Shutdown for long periods
To put the boiler out of service for long periods (e.g. at the end of the cold season), carefully clean the boiler to prevent
corrosion.
BTo avoid damage caused by freezing during long idle periods in winter, it is advisable to drain all water from
the boiler, or add a suitable antifreeze to the heating system, in compliance with that prescribed in sec. 2.3.
1.4 Adjustments
Summer/Winter changeover
Press the button to activate Summer/Winter changeover.
Heating temperature setting
Operate the buttons and (detail 5 fig. 1) to set the system delivery temperature.
The control system regulates the fan air delivery and therefore the speed of combustion for reaching and maintaining
the set temperature.
BAt too low boiler water temperatures tar forms inside the boiler, and at temperatures below 65 °C condensate
forms in the combustion chamber.
Frequent operation below 65 °C causes a big reduction in the boiler's useful life.
Make sure the boiler water temperature remains constantly between 80 - 90 °C.

FG
7GB cod. 3540I950 - 06/2007 (Rev. 00)
Secondary air adjustment
The smoke extractor fan located on the back of the boiler supplies the primary combustion air. The boiler is equipped
with a factory-set secondary air adjustment device, which must be checked with the aid of a combustion analyser in the
first lighting stage. The adjustment screw can subsequently be used to adapt the supply of secondary air according to
the quality and type of fuel.
fig. 2 - Secondary air adjustment
AOpen
BClosed
• Large, wet are hard to burn wood: close 1 notch.
• Dry and very flammable wood: open 1 notch or more.
• If the boiler tends to puff due to very wet fuel, close it gradually.
System pressure adjustment
Periodically check that the system is full of water. These checks must be carried out cold, checking the expansion tanks
(open types must have water at the initial level, whereas in closed types the pressure must be equal to or higher than
the initial prefilling pressure).

FG
8GB
cod. 3540I950 - 06/2007 (Rev. 00)
2. Installation
2.1 General Instructions
BOILER INSTALLATION MUST ONLY BE PERFORMED BY QUALIFIED PERSONNEL, IN ACCORDANCE WITH
ALL THE INSTRUCTIONS GIVEN IN THIS TECHNICAL MANUAL, THE PROVISIONS OF CURRENT LAW, THE PRE-
SCRIPTIONS OF NATIONAL AND LOCAL STANDARDS AND THE RULES OF PROPER WORKMANSHIP.
2.2 Place of installation
The boiler must be installed in a special room with ventilation openings towards the outside in conformity with current
regulations. If there are several burners or extractors that can work together in the same room, the ventilation openings
must be sized for simultaneous operation of all the units. The place of installation must be free of flammable objects or
materials, corrosive gases, volatile substances or dusts that can be sucked by the fan. The room must be dry and not
exposed to rain, snow or frost.
AEnsure enough space around the unit for removing the casing and for normal servicing operations. In partic-
ular, make sure there is enough space in the front part of the boiler for loading the fuel.
2.3 Plumbing connections
The heating capacity of the unit must be previously established by calculating the building's heat requirement according
to current regulations. The system must be provided with all the components for correct and regular operation. It is ad-
visable to install on-off valves between the boiler and heating system allowing the boiler to be isolated from the system
if necessary.
BThe safety valve outlet must be connected to a funnel or collection pipe to prevent water spurting onto the floor
in case of overpressure in the heating circuit. Otherwise, if the drain valve is activated and floods the room,
the boiler manufacturer cannot be held liable.
Do not use the water system pipes to earth electrical appliances.
Before installation, carefully wash all the pipes of the system to remove residuals or impurities that could affect correct
operation of the unit.
Carry out the relevant connections according to the diagram in cap. 4 "Technical data and characteristics" and the sym-
bols given on the unit.
Characteristics of the water system
In the presence of water harder than 25° Fr (1°F = 10ppm CaCO3), use suitably treated water in order to avoid possible
scaling in the boiler. Treatment must not reduce the hardness to values below 15°F (Decree 236/88 for uses of water
intended for human consumption). Treatment of the water used is indispensable in case of very large systems or with
frequent introduction of replenishing water in the system.
Antifreeze system, antifreeze fluids, additives and inhibitors
If necessary, antifreeze fluids, additives and inhibitors can be used only if the manufacturer of these products guaran-
tees that they are suitable for this use and do not cause damage to the boiler exchanger or other components and/or
materials of the unit and system. Do not use antifreeze fluids, additives or inhibitors that are not specific for use in heat-
ing systems and not compatible with the boiler materials and system.

FG
9GB cod. 3540I950 - 06/2007 (Rev. 00)
2.4 Safety coil connection (optional)
An external (cooling circuit) safety heat exchanger (optional) can be supplied together with the boiler.
In countries where Standard EN 303-5 is applied, the boiler must have a system enabling a safety outlet for the excess
heat without additional energy. In this way the maximum boiler water temperature will not exceed 100 °C (overheating
protection).
The minimum cooling water supply pressure must be 2.0 bar. A flowrate of at least 10 l/min. must be available.
• Remove the flange “A” located at the back of the boiler.
• Install the coil “N”, fixing it with the 4 bolts.
• Fit the safety valve "P" on the outlet of the coil "N", respecting the direction of the arrow. Insert the valve probe "Q"
in the special sheath "G". Connect the water inlet directly to the safety coil. Connect the valve outlet.
fig. 3 - Safety heat exchanger connection

FG
10 GB
cod. 3540I950 - 06/2007 (Rev. 00)
2.5 Electrical connections
Fitting the control panel
1. Remove the control panel cover "P" by undoing the two side screws "V".
2. Arrange the cables of the fan "B", the sensor "A" and the door microswitch "C" as shown in fig. 4
3. Connect the fan cable to the terminal block, respecting the colours indicated in fig. 5 and fix the condenser"R" with
the special adhesive clamp.
4. Connect the cable of the microswitch "C" to the terminals as shown in fig. 5.
5. Insert the probe "A" in the special pocket.
fig. 4 - Fitting the control panel
fig. 5 - Connection to the terminal block
CCondenser
16 Fan
34 Heating temperature sensor
296 Door microswitch
14131211109876543
34 296 16
Nero/Bianco
Blu
Giallo/Verde
R

FG
11GB cod. 3540I950 - 06/2007 (Rev. 00)
Connection to the electrical grid
BThe unit's electrical safety is only guaranteed when correctly connected to an efficient earthing system exe-
cuted according to current safety standards. Have the efficiency and suitability of the earthing system checked
by professionally qualified personnel. The manufacturer is not responsible for any damage caused by failure
to earth the system. Also make sure that the electrical system is adequate for the maximum power absorbed
by the unit, as specified on the boiler dataplate.
The boiler is prewired and provided with a Y-cable and plug for connection to the electricity line. The connections to the
grid must be made with a permanent connection and equipped with a bipolar switch whose contacts have a minimum
opening of at least 3 mm, interposing fuses of max. 3A between the boiler and the line. It is important to respect the
polarities (LINE: brown wire / NEUTRAL: blue wire / EARTH: yellow-green wire) in making connections to the electrical
line. During installation or when changing the power cable, the earth wire must be left 2 cm longer than the others.
BThe user must never change the unit's power cable. If the cable gets damaged, switch off the unit and have it
changed solely by professionally qualified personnel. If changing the electric power cable, use solely “HAR
H05 VV-F” 3x0.75 mm2 cable with a maximum outside diameter of 8 mm.
2.6 Connection to the flue
The unit must be connected to a flue designed and built in compliance with current regulations. The pipe between the
boiler and flue must be made from material suitable for the purpose, i.e. heat and corrosion resistant. Ensure the seal
at the joints and insulate the entire pipe between boiler and flue, to prevent the formation of condensate.

FG
12 GB
cod. 3540I950 - 06/2007 (Rev. 00)
3. Service and maintenance
All adjustment, conversion, startup and periodical checking operations described below must only be carried out by Quali-
fied Personnel (meeting the professional technical requirements prescribed by current regulations).
FERROLI declines any liability for damage and/or injury caused by unqualified and unauthorised people tampering with the
unit.
3.1 Adjustments
Secondary air adjustment
During the startup stage it is advisable to check the setting of the secondary air adjustment device.
Light the boiler and carry out first loading with the same type of fuel to be used by the end-user.
Wait for the boiler to stabilise.
Using a combustion analyser check the CO in the fumes. If the CO content is > 0.5% gradually open the regulator until
obtaining a CO value of < 0.5%.
N.B.: opening the secondary air regulator of the boiler too much can result in uneven combustion (tendency to
"puff"). In this case close the regulator by 1/2 - 1 notch.
3.2 Startup
BChecks to be made at first lighting, and after all maintenance operations that involved disconnecting from the
systems or operations on safety devices or parts of the boiler.
Before lighting the boiler
• Open any on-off valves between the boiler and the systems.
• Check correct prefilling of the expansion tank
• Fill the water system and make sure that all air contained in the boiler and the system has been vented.
• Make sure there are no water leaks in the system, connections or boiler.
• Check correct connection of the electrical system and efficiency of the earthing system
• Make sure there are no flammable liquids or materials in the immediate vicinity of the boiler
Checks during operation
• Turn the unit on as described in sec. 1.3.
• Check the seal of the water systems.
• Check the efficiency of the flue and air-fume ducts while the boiler is working.
• Check that the water is circulating properly between the boiler and the systems.
• Check the seal of the wood loading and combustion chamber doors.
• Check combustion and correct setting of the secondary air control device.
3.3 Maintenance
Warnings
B- Before carrying out any maintenance make sure to disconnect the power to the boiler and wait until it is at
room temperature.
- Never drain (even partially) the water from the system, unless absolutely necessary.
- Do not clean the boiler and/or its parts with easily flammable substances (e.g. petrol, alcohol, etc.).
- Do not leave containers with flammable substances in the room where the boiler is installed.
- Do not clean the heating system with boiler operating.
- Use tube brushes and vacuum aspirators for cleaning; if rags are used, make sure they are not left inside
the boiler.

FG
13GB cod. 3540I950 - 06/2007 (Rev. 00)
Routine maintenance
Soot and ash on the inside walls of the boiler and on the refractory bricks reduces the transfer of heat. However, during
the operation of a boiler with wood gasification less ash is produced than during heating with conventional boilers.
Remove the ash from the combustion chamber every 1-2 days, and in any case before it is full, so as to leave sufficient
space for combustion.
BIf the ash is still hot, use protective gloves.
Put the ash in a non-flammable container provided with a lid.
Carry out thorough cleaning at least once a week:
• Open the loading door and brush the combustion residuals in the ash compartment through the opening between
the burner plates.
• Clean the inside walls of the combustion chamber with a brush
• Remove the loose soot and ash from the combustion chamber.
• Check perfect door closure seal. Also make sure there is no tar or condensate dripping from the smokebox.
BDo not clean the burner plates with a wire brush, as they may become damaged.
Extraordinary maintenance
Clean the fume ducts once a month:
• Remove the top cover of the casing
• Open the inspection door at the back of the boiler (see fig. 6).
• Remove the turbulators and clean the fume ducts with a tube brush.
fig. 6 - Fume duct cleaning

FG
14 GB
cod. 3540I950 - 06/2007 (Rev. 00)
Periodical check
To ensure correct operation of the unit over time, have qualified personnel carry out a yearly check, providing for the
following:
• Check and if necessary clean the boiler and fume ducts as indicated in the previous paragraph.
• Remove the fume extractor and clean the fan.
• Check the conditions of the burner plates.
• Check the seal of the ash compartment and loading door; replace the gasket if necessary.
• The control and safety devices must work properly.
• The fume exhaust circuit must be perfectly efficient.
• The exhaust pipes and terminals must be free of obstructions and leaks
• The burner and exchanger must be clean and free of deposits. For possible cleaning do not use chemical products
or wire brushes.
• The water pressure in the system when cold must be approx. 1 bar; otherwise bring it to that value.
• The circulating pump must not be blocked.
• The expansion tank must be filled.
3.4 Troubleshooting
Diagnostics
In case of operation anomalies or problems, the display flashes and a fault identification code appears.
Table. 1 - Fault list
Fault
code Fault Possible cause Cure
E05 Heating temperature sensor
fault
Sensor damaged or short
circuited Check the wiring or replace the sensor
E06 Heating temperature sensor
fault
Sensor damaged or wiring dis-
connected Check the wiring or replace the sensor

FG
15GB cod. 3540I950 - 06/2007 (Rev. 00)
4. Technical data and characteristics
4.1 Dimensions, connections and main components
fig. 7 - Dimensions, connections and main components
Key
10 System delivery
11 System return
16 Fan
275 System water drain
Model A B C D E F G H I L (Ø)
Fg 30 550 970 750 550 457.7 600 195 160 652.5 130
Fg 40 550 1150 750 550 637.5 780 195 160 812 150
Fg 50 600 1150 930 730 627.5 780 220 185 812 150
A
360
240
B
C
D
E
F244
L
GH
275
10
11
16
86

FG
16 GB
cod. 3540I950 - 06/2007 (Rev. 00)
4.2 Pressure loss
4.3 Technical data table
Unit Value Value Value
Model FG 30 FG 40 FG 50
Max. heating capacity kW 34.9 46.2 57.5 (Q)
Min. heating capacity kW 16.9 22.3 27.8 (Q)
Max. heat output in heating kW 30 40 50 (P)
Min. heat output in heating kW 15 20 25 (P)
Efficiency Pmax % 86 86.5 87
Efficiency Pmin % 89 89.5 90
Working pressure in heating bar 3 3 3 (PMS)
Empty weight kg 185 220 286
Combustion chamber volume dm3100 140 200
0
2
4
6
8
10
12
14
16
18
20
0 500 1000 1500 2000 2500 3000 3500 4000 4500 5000
portata lt/h
mbar

FG
17GB cod. 3540I950 - 06/2007 (Rev. 00)
4.4 Wiring diagram
fig. 8 - Wiring diagram
16 Fan
32 Heating circulating pump
72 Room thermostat (not supplied)
34 Heating temperature sensor
296 Door microswitch
N
N
N
L
N
230V
50Hz
32
16
34
34567891011121314 N L
296
CP24
MLC23.01
59 58 57 56 55 54 53 52
93 92 91
5 4 3 2 1
X12
X16
72
98

FG
18 FR
B
Déclaration de conformité
Le constructeur : FERROLI S.p.A.
Adresse: Via Ritonda 78/a 37047 San Bonifacio VR
déclare que cet appareil est conforme aux directives CEE ci-dessous:
• Directive basse tension 73/23 (modifiée 93/68)
• Directive Compatibilité Electromagnétique 89/336 (modifiée 93/68)
Président et fondé de pouvoirs
Cav. du travail
Dante Ferroli
BCe symbole signifie “Attention” et est mis en regard de toutes les annonces relatives à
la sécurité. Ces prescriptions sont à respecter scrupuleusement pour éviter tous risques
causés à des personnes, animaux et objets.
ACe symbole attire l'attention sur une note ou un avertissement important
cod. 3540I950 - 06/2007 (Rev. 00)
• Lire attentivement les avertissements contenus
dans le présent livret fournissant des indications im-
portantes pour la sécurité de l'installation, son utili-
sation et son entretien.
• Le manuel d'instructions fait partie intégrante du pro-
duit et en constitue un composant essentiel que l'uti-
lisateur aura soin de garder afin de pouvoir le
consulter par la suite.
• En cas de vente ou de cession de l'appareil à un au-
tre propriétaire ou d'un déménagement, s'assurer
que le manuel accompagne dans tous les cas la
chaudière de manière à pouvoir être consulté en tout
temps par le nouveau propriétaire et/ou installateur.
• L’installation et l'entretien doivent être effectués con-
formément aux normes en vigueur, selon les instruc-
tions du constructeur et par un personnel
professionnel qualifié.
• Une installation incorrecte ou un entretien impropre
peuvent entraîner des dommages à des personnes,
à des animaux ou à des choses. Le constructeur
n'assume aucune responsabilité pour les domma-
ges causés par des erreurs d'installation et d'utilisa-
tion et, dans tous les cas, en cas de non observation
des instructions qu'il a fournies.
• Avant d'effectuer toute opération de nettoyage ou
d'entretien, isoler l'appareil du réseau d'alimentation
électrique en actionnant l'interrupteur de l'installa-
tion et/ou au moyen des dispositifs d'isolement
prévus.
• Désactiver l'appareil en cas de panne et/ou de mau-
vais fonctionnement en s'abstenant de toute tentati-
ve de réparation ou d'intervention directe.
S'adresser uniquement à un personnel profession-
nel qualifié. Les éventuelles réparations ou rempla-
cements de composants devront être effectués
uniquement par du personnel professionnel qualifié
en n'utilisant que des pièces de rechange d'origine.
La non observation de ce qui précède compromet
les conditions de sécurité de l'appareil.
• Pour garantir le bon fonctionnement de l'appareil, il
est indispensable de faire effectuer l'entretien pério-
dique uniquement par du personnel professionnel
qualifié.
• Cet appareil ne peut servir que dans le cadre des uti-
lisations pour lesquelles il a été conçu. Tout autre
usage sera considéré comme impropre et dès lors
dangereux.
• Après avoir retiré l'emballage, s'assurer du bon état
du contenu. Les éléments du conditionnement ne
peuvent être laissés à la portée des enfants étant
donné qu'ils pourraient être la source potentielle de
dangers.
• En cas de doute, ne pas utiliser l'appareil et s'adres-
ser au fournisseur.
• Les images contenues dans ce manuel ne sont
qu'une représentation simplifiée du produit. Cette re-
présentation peut présenter de légères différences,
non significatives, par rapport au produit.

FG
19
, cod. 3540I950 - 06/2007 (Rev. 00)
1 Instructions d'utilisation ....................................................................................................... 20
1.1 Introduction...........................................................................................................................................20
1.2 Tableau des commandes .....................................................................................................................20
1.3 Allumage et extinction ..........................................................................................................................21
1.4 Réglages ..............................................................................................................................................22
2 Installation.............................................................................................................................. 24
2.1 Dispositions générales .........................................................................................................................24
2.2 Emplacement .......................................................................................................................................24
2.3 Raccordements hydrauliques...............................................................................................................24
2.4 Raccordement serpentin de sécurité (option) ......................................................................................25
2.5 Branchements électriques....................................................................................................................26
2.6 Raccordement au conduit de fumée ....................................................................................................27
3 Utilisation et entretien ........................................................................................................... 28
3.1 Réglages ..............................................................................................................................................28
3.2 Mise en service ....................................................................................................................................28
3.3 Entretien ...............................................................................................................................................28
3.4 Résolution des problèmes....................................................................................................................30
4 Caractéristiques et données techniques............................................................................. 31
4.1 Dimensions, raccords et composants principaux .................................................................................31
4.2 Perte de charge....................................................................................................................................32
4.3 Tableau des caractéristiques techniques .............................................................................................32
4.4 Schéma électrique................................................................................................................................33

FG
20 FR
cod. 3540I950 - 06/2007 (Rev. 00)
1. Instructions d'utilisation
1.1 Introduction
Cher Client,
Nous vous remercions d'avoir choisi FERROLI, une chaudière de conception avancée, de technologie d'avant-garde,
de fiabilité élevée et de haute qualité constructive. Lire attentivement les instructions contenues dans la présente notice,
car elles fournissent des indications importantes concernant la sécurité d'installation, l'utilisation et l'entretien de l'appa-
reil.
FG Il s'agit d'une chaudière en acier fonctionnant au bois, à gazéification totale. Elle utilise le principe de la combustion
à flamme inverse qui permet une consommation graduelle du bois, avec en conséquence une plus longue autonomie.
En effet, grâce à un ventilateur à vitesse variable, positionné dans la partie arrière de la chaudière, la combustion s'ef-
fectue en dépression ; le bois allumé, situé dans un magasin au-dessus d'une grille spéciale, développe une forme par-
ticulière de combustion qui, grâce à la tempéture élevée déterminée par l'apport équilibré de l'air comburant primaire
par le haut et secondaire injecté à travers la grille de séparation, transforme la cellulose en composés plus simples qui
brûlent dans la chambre de combustion sous-jacente, avec une flamme similaire à celle du méthane, et des rendements
supérieurs à 85%. En phase de chargement du bois, à l'ouverture de la porte, le ventilateur est activé pour éviter la
sortie de la fumée.
L'habillage extérieur est constitué par des panneaux en acier peints, isolés internement avec de la laine minérale pour
garantir une excellente isolation du corps de la chaudière. Sur demande, un échangeur de sécurité peut être installé
pour l'élimination de la chaleur en excès.
1.2 Tableau des commandes
fig. 1 - Tableau de contrôle
Légende
1Tableau des commandes
2Porte de chargement bois
3Porte logement cendre/chambre de combustion
4Réglage de l'air comburant
5Touches + - réglage température chauffage
6Touche M, "Mode" commutation Eté/Hiver
7Touches + - modification paramètres
8Touche R, accès menu configuration
9Afficheur
10 Interrupteur d'allumage
Durant le fonctionnement, l'afficheur visualise la température de refoulement installation.
